Polycom
KIRK Repeater
®
Installation and
Configuration Guide
14183300 Version 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KIRK and is the answer not in the manual?

Questions and answers

Related Manuals for Polycom KIRK

Summary of Contents for Polycom KIRK

  • Page 1 Polycom KIRK Repeater ® Installation and Configuration Guide 14183300 Version 1...
  • Page 2 Polycom, Inc. Information contained herein is subject to change without notice and does not represent commitment of any type on the part of Polycom, Inc. Polycom and Accord are registered trademarks of Polycom, Inc.

  • Page 3: Table Of Contents

    KIRK Repeater Description ........

  • Page 4: Installing Kirk Repeater

    1-4 KIRK Repeater provides RF Channels to KIRK Handsets The KIRK Repeater is a building block to be used to extend the coverage area in a KIRK solution. The repeater does not increase the number of traffic channels, however it provides a larger physical spreading of the traffic channels and thereby increases the coverage area established with the KIRK 1–1...

  • Page 5: Kirk Repeater Types And Part Numbers

    Base Stations.The repeaters are mainly used in areas with limited traffic. The KIRK Repeater is available with either 2 or 4 voice channels. It is wireless and does not need physical connection to the KIRK Wireless Server, making it very easy to install.

  • Page 6: Kirk Repeater - Appearance And Components

    Installing KIRK Repeater Table 1-1 KIRK Repeater - Wall - Part Number Variants of KIRK Repeaters Part Number KIRK Repeater with external antenna 1.8 GHz, 0244 0000 2 channels (Supported on KWS300, KWS500, KWS600, KWS600v3 single and multi cell, KWS1500, KWS3000 and KWS6000).

  • Page 7: Kirk Repeater Led Indicators

    KIRK Repeater, Installation and Configuration Guide Figure 1-1 Repeater KIRK Repeater LED Indicators The repeater has one LED indicator describing the repeater operations. The indicator is off when the repeater is not powered. The LED flashes when the repeater initializes, and it is on when the repeater is in sync. The LED flashes each time a connected handset is off or on hook or makes handover from or to a repeater.

  • Page 8: Environmental Requirements

    Installing KIRK Repeater Environmental requirements • Avoid installing repeaters on large concrete or marble columns because these columns affect radio coverage. If possible, place the base station a minimum of one meter/3.3 feet from these types of columns. • Do not install a repeater with the antenna housings near metal objects. Be careful not to damage existing wiring or panels.
  • Page 9 KIRK Repeater, Installation and Configuration Guide Figure 1-2 Connect Power to the Bottom of the Repeater and External Antenna Cable to the Rear of the Repeater Holes for wall mounted screws External antenna cable (only for repeaters supplied with external...

  • Page 10: Recording The Installation Information

    Powering the KIRK Repeater Power Options The power supply for the repeater is 9VDC, 300mA. Programming a KIRK Repeater with the KIRK Programming Kit This section provides information about: • “Content of the KIRK Programming Kit Repeater”...

  • Page 11: Set Up Of The Hardware For Repeater Programming

    (ServiceTool) and the power supply for the repeater. The ServiceTool is not part of the Programming Kit Repeater but can be downloaded from www.polycom.com. The power supply for the repeater is to be ordered separately (Part no. UK version: 84642421, Part no. EU version: 84642420, Part no.

  • Page 12: Programming The Kirk Repeater With The Servicetool

    The ServiceTool identifies the type of repeater, and with this software it is possible to program the KIRK Repeater to connect to the KIRK DECT Radio Infrastructure solutions. Before you start programming the repeater, ensure that the repeater is connected to the computer and the mains.
  • Page 13 KIRK Repeater, Installation and Configuration Guide Table 1-2 Repeater Numbering in a Multi Cell Solution Base Station Repeater 1 Repeater 2 Repeater 3 1–10...
  • Page 14 Installing KIRK Repeater Table 1-2 Repeater Numbering in a Multi Cell Solution Base Station Repeater 1 Repeater 2 Repeater 3 1–11...
  • Page 15 KIRK Repeater, Installation and Configuration Guide Table 1-2 Repeater Numbering in a Multi Cell Solution Base Station Repeater 1 Repeater 2 Repeater 3 1–12...
  • Page 16 Installing KIRK Repeater Table 1-2 Repeater Numbering in a Multi Cell Solution Base Station Repeater 1 Repeater 2 Repeater 3 1–13...
  • Page 17 KIRK Repeater, Installation and Configuration Guide Table 1-2 Repeater Numbering in a Multi Cell Solution Base Station Repeater 1 Repeater 2 Repeater 3 1–14...
  • Page 18 Installing KIRK Repeater Table 1-2 Repeater Numbering in a Multi Cell Solution Base Station Repeater 1 Repeater 2 Repeater 3 1–15...
  • Page 19 KIRK Repeater, Installation and Configuration Guide Table 1-2 Repeater Numbering in a Multi Cell Solution Base Station Repeater 1 Repeater 2 Repeater 3 Repeater and base station numbers must not be the same. Neither can the Note repeater have a number similar to another base station or another repeater...
  • Page 20 Installing KIRK Repeater Table 1-3 Example of a Normal Base Station/Repeater Configuration Numbering of base stations and repeaters in a normal configuration First repeater No. of base station + 64 Base to synchronize on: Number of base station Second repeater No.

  • Page 21: Use Of Kirk Repeater With External Antenna

    KIRK Repeater, Installation and Configuration Guide Use of KIRK Repeater With External Antenna If radio coverage between a base station and a repeater is not needed, it is possible to synchronize between the radio units using a repeater with external antenna.

  • Page 22: Regulatory Notices

    Regulatory Notices This section contains important safety regulations for the KIRK Repeaters. International Regulatory and Product Information This KIRK product has been marked with the CE mark. This mark indicates compliance with EEC Directives 89/336/EEC, 73/23/EEC 1999/5/EC. A full copy of the Declaration of...
  • Page 23 KIRK Repeater è conforme ai requisiti essenziali ed alle altre disposizioni pertinenti stabilite dalla direttiva 1999/5/CE. Íslenska Hér með lýsir Polycom (UK) Ltd yfir því að KIRK (Icelandic): Repeater er í samræmi við grunnkröfur og aðrar kröfur, sem gerðar eru í tilskipun 1999/5/EC Latviski Ar šo Polycom (UK) Ltd deklare, ka KIRK Repeater...
  • Page 24 Polycom (UK) Ltd declara que este KIRK Repeater [Portuguese]: está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE. Slovensko Polycom (UK) Ltd izjavlja, da je ta KIRK Repeater v [Slovenian]: skladu z bistvenimi zahtevami in ostalimi relevantnimi dolocili direktive 1999/5/ES. Slovensky Polycom (UK) Ltd týmto vyhlasuje, že KIRK...
  • Page 25 KIRK Repeater, Installation and Configuration Guide Waarschuwing Gebruik dit draadloos netwerkapparaat alleen in de buurt van onbeschermde ontstekers of in een omgeving met explosieven indien het apparaat speciaal is aangepast om aan de eisen voor een dergelijk gebruik te voldoen.
  • Page 26 The above warning is inserted for regulatory reasons. If any customer believes that they have an interference problem, either because their KIRK product seems to cause interference or suffers from interference, they should contact their distributor immediately.

  • Page 27: Important Safety Instructions And Product Information

    KIRK Repeater, Installation and Configuration Guide Important Safety Instructions and Product Information Before using your telephone equipment, you should always follow basic safety instruction to reduce the risk of fire, electrical shock and injury to persons, and damage to property.
  • Page 28 Regulatory Notices 12 Do not use the telephone to report a gas leak in the vicinity of the leak 13 Do not place the unit near microwave ovens, radio equipment, or non-ground connected televisions. These appliances may cause electrical interference to the base or handset 14 The unit must be installed on a hard, plane surface and connected to a functional 120 volt AC power net adapter and plug the adapter into the power outlet...
  • Page 29 KIRK Repeater, Installation and Configuration Guide Information to user: The users manual or instruction manual for an intentional or unintentional radiator shall caution the user that changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 30 Regulatory Notices PERSON, OR DAMAGE TO PROPERTY CAUSED BY THE PRODUCT, LOSS OF REVENUE OR PROFIT OR DAMAGES FOR ANY FAILURE TO PERFORM. IN NO EVENT SHALL WE BE LIABLE FOR ANY SPECIAL, INCIDENTAL, PUNITIVE OR CONSEQUENTIAL DAMAGES EVEN IF WE ARE ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
  • Page 31 KIRK Repeater, Installation and Configuration Guide 2–10...
