Table 1-3 Example of a Normal Base Station/Repeater Configuration
Numbering of base stations and repeaters in a normal configuration
First repeater
Second repeater
Third repeater
Table 1-4 Example of Repeater Jump Configuration
Numbering of repeaters in a repeater jump configuration
First repeater in chain
Second repeater in chain
Third repeater in chain
For more information about programming the repeater with the ServiceTool,
refer to the Help File in the ServiceTool. The ServiceTool is to be downloaded
from www.polycom.com.
No. of base station + 64
Base to synchronize on: Number of base station
No. of base station + 128
Base to synchronize on: Number of base station
No. of base station + 192
Base to synchronize on: Number of base station
No. of base station + 64
Base to synchronize on: Number of base station
No. of base station + 128
Base to synchronize on: Number of previous repeater
No. of base station + 192
Base to synchronize on: Number of previous repeater
Installing KIRK Repeater
1–17
