DHK Hobby Optimus User Instruction Manual

1/8 scale 4wd brushless electric buggy
Hide thumbs

Advertisement

Quick Links

Download this manual
用户使用说明书
User's Instruction Manual
1/8 Scale 4WD Brushless Electric Buggy

Advertisement

loading
Need help?

Need help?

Do you have a question about the Optimus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DHK Hobby Optimus

Summary of Contents for DHK Hobby Optimus

  • Page 1 用户使用说明书 User’s Instruction Manual 1/8 Scale 4WD Brushless Electric Buggy...
  • Page 2 Failure to do so might shorten the lifespan of your model. You are cordially advised that DHK Hobby makes all necessary parts and accessories to support you for any problem during and after your driving.

  • Page 3: Model Specifications

    Lipo balance charger (#P109) (for 2S/3S Lipo battery) 1,000mAh output with AC input. 2 Channel 2.4GHz radio system Optimus comes with a full function 2 channel 2.4GHz radio transmitter and receiver. Please refer to the 2.4GHz User’s Instructions Manual for detail.

  • Page 4: Lipo Batteries

    9kgs Servo Features : Metal gears, ball bearings Working voltage : 6.0V Speed (seconds/60˚C) : 0.16sec Torque : 9kg/cm (88.3Ncm) Net weight : 60g Size(LxWxH) : 55x21x43mm Note: When the motor temperature is over 120˚C(248˚F), please add a fan over the motor for better ventilation.
  • Page 5 > It is strongly recommended to use an ESC which is designed to handle the low voltage cutoff points or Lipo batteries (Always follow the instructions provided with the ESC for proper operation). Discharging Lipo batteries below 2.5V per cell (Norm is 3.7V per cell, at 4.2V once fully charged) can cause permanent damage and limit the number of times the battery can effectively be used again.
  • Page 6 BLDC motors may be described as stepper motors, with fixed permanent magnets and possibly more poles on the rotor than the stator, or reluctance motors. The latter may be without permanent magnets, just poles that are induced on the rotor then pulled into alignment by timed stator windings. However, the term stepper motor tends to be used for motors that are designed specifically to be operated in a mode where they are frequently stopped with the rotor in a defined angular position.

  • Page 7: Parts List

    Parts List Number Desc Number Desc 8381-100 Assembly of diff gear box 8381-602 Buffer bushing/adiustment ring 8381-101 Diff set 8381-603 Buffer spring (4 pcs) 8381-102 Diff outdrive/pins (dia 2*10mm) 8381-604 Buffer sus.arm-upper/lower/steering sus.arm 8381-103 Pins(dia 2*10mm) (16 pcs) 8381-605 B head screw-coarse thread(BB3*12mm) (16 pcs) 8381-104 Flathead screw-coarse thread(KB2.6*10mm) (16 8381-606 Screw bushing (16 pcs) pcs)
  • Page 8 Number Desc 8381-005 Central drive shaft-A 8381-006 Central drive shaft-B 8381-007 Receiver cover-upper/lower 8381-008 Antenna tube (3 pcs) 8381-009 Pin-B(dia 1.2mm) (16 pcs) 8381-010 Screw washer 8381-011 Flathead screw(KM3X10mm) (16 pcs) 8381-012 Flathead screw-coarse thread(KB3*10mm) (16 pcs) 8381-013 Flathead screw-coarse thread(KB3*12mm) (16 pcs) 8381-014 Flathead screw (KM3*5mm) (16 pcs) 8381-015 Flathead screw(KM3X18mm) (16 pcs)
  • Page 14 8381-103 Pins(dia 2*10mm) (16 pcs) 8381-104Flathead screw-coarse thread 8381-100 Assembly of diff 8381-102 Diff outdrive/pins (KB2.6*10mm) (16 pcs) gear box 8381-101 Diff set (dia 2*10mm) 8381-108 Gear-18T (2 pcs)/gear-12T (4 pcs) 8381-110 Ball 8381-105 Crown 8381-107 bearing(dia 8381-106 Diff case gear-41T (large)/ 8381-109 O Ring(dia Washer-A/washer-B...
  • Page 15 8381-203 Spur gear-43T 8381-204 Lock nut (M4*4mm) (plastic) (2 pcs) (16 pcs) 8381-205 Center diff outdrive/lock nut (M4*4mm) 8381-206 Center diff gear box/center diff gear box plate 8381-309 Shock shaft (4 pcs) 8381-305 Shock ball (8 pcs) 8381-300 Shock 8381-207 B head absorber complete screw-coarse thread 8381-306 M3 nylon...
  • Page 16 8381-50R Assembly of upper 8381-50L Assembly of upper 8381-405 Anti-roll bar(dia 2.2mm) (2 pcs) sus.arm-Right sus.arm-Left 8381-503 Upper sus.arm linkage (2 pcs) 8381-501 Upper 8381-502 Upper sus.arm ball 8381-602 Buffer 8381-601 Brass sus.arm/rod end 8381-600 Assembly of (4 pcs) (2 sets) bushing/adiustment ring washer (4 pcs) buffer set...
  • Page 17 8381-711 Hex 8381-708 Wheel axle 8381-710 Ball bearing(dia adapter/nut-M12 8381-709 Steering arm (2 pcs) (2 pcs) 5mm * dia 10*4mm) (2 pcs) 8381-719 Upper 8381-715 B head 8381-712 Pins screw (BM3*20mm) sus.arm shaft 8381-713 B head screw (dia 2*16mm) (16 pcs) 8381-714 C-hub (2 pcs) (16 pcs) (4 pcs)
  • Page 18 8381-803 B head 8381-805 B head screw(BM3*18mm) 8381-806 Rear wing screw(BM3*10mm) (16 pcs) rod-long/short (16 pcs) 8381-802 Rear hub-L/F 8383-003 Rear wing 8381-804 Wing mount/wing brace-L/R 8381-807 Pin-A(dia 1.5mm) (16 pcs) (black) 8381-9M2 Motor gear-15T/Lock 8381-9S0 Assembly of 9kgs servo (with 8381-9M1 Motor mount-Upper/ nut(M4*4) servo horns)
  • Page 19 8381-005 Central drive shaft-A 8381-007 Receiver cover-upper/lower 8381-006 Central 8381-010 Screw 8381-004 Upper deck 8381-008 Antenna 8 3 8 1 - 0 0 9 P i n - B ( d i a drive shaft-B washer (4 pcs) mount-F/R tube (3 pcs) 1.2mm) (16 pcs) 8381-013 Flathead screw- 8381-012 Flathead screw-...
  • Page 20 LCD Display D302H 4 channel 2.4GHz receiver Note: Images are for easy track of the parts, they don't alway srepresent the actual quantity of parts packs. DHK TECHNOLOGY CO.LTD. E2 Blk, Wan'feng Western Ind Zone, Heyi, Shenzhen, China 518104 Phone:+86 755 33895639 Fax:+86 755 33895635 email: inquiry@dhkhobby.com...
