Summary of Contents for DHK Hobby Optimus XL
- Page 12 1-Antenna: pull up the antenna straight before use. 2-Power switch: slide the switch to turn on or off. 3-Power LED: shows the power strength. Green LED shows full power, Yellow LED flashes when the power is running short. 4-Charging port: charges Ni-Mh or Ni-Cd...
- Page 13 1. Antenna: Pull out the antenna completely Parts Diagrams 2. Connecting ports: receiver power port and channel signal connecting ports > ST/1: Channel 1, steering signal port > TH/2: Channel 2, throttle servo or ESC signal port > AUX/3: Auxiliary signal port >...
