Summary of Contents for Hunter 44200
- Page 1 O W N E R ’ S M A N U A L Ceiling Fan Installation Instructions, 120V Model Hunter Fan Company 2500 Frisco Avenue Memphis, TN 38114 USA www.hunterfan.com Industrial Series 44200-01 02/06/2008...
- Page 2 • This fan is not intended for use by children or infirm persons without supervision. (16Kg/35 lb. min.) 44200-01 02/06/2008 BEFORE BEGINNING, DISCONNECT THE POWER SUPPLY AT THE SWITCHBOARD. FAILURE TO DO SO CAN RESULT IN SERIOUS INJURY OR DEATH...
- Page 3 WARNING! All electrical work and installation must be in accordance with all applicable local electrical codes and standards. Failure to use the supplied controller will void the warranty. 2.1m/ 7 ft. min. Wallplate (Wall control may vary.) 44200-01 02/06/2008...
- Page 4 NOTE: Using the fan’s hang bracket as a guide, mark the postions for the mounting screws on the support. Then, drill a 10mm pilot hole for each mounting bolt. 44200-01 02/06/2008...
- Page 5 Black White Ground / Earth These terminals are pre-wired at the factory. SEE WIRING DIAGRAM ON DO NOT REMOVE. PAGE 7 44200-01 02/06/2008...
- Page 6 Complete. THE TIPS OF THE BLADES SHOULD BE AT LEAST 90CM/36 INCHES FROM ANY WALLS OR OTHER OBJECTS. 44200-01 02/06/2008...
- Page 7 Line Out to Main Supply Line Main Main Terminal Out Terminal In Grey Green Brown Wiring Diagram for Wall Switch 44200-01 02/06/2008...
- Page 8 8. Positions are Off, High, Medium, and Low. Fan Directional Control During cooler weather, place switch in the up position. During warmer weather, place switch in the down position. 44200-01 02/06/2008 O P E R AT I O N High Medium...
