- Page 1 Professional espresso coffee machine Models: SE Compact Models: SM Compact...
- Page 2 We thank you for your custom in the purchase of this product. Please therefore carefully read the instructions of use contained in this manual, which comply with essential safety regulations. read the following instruction solely by an installer or authorized technician.
- Page 3 EG-KONFORMITÄTSERKLÄRUNG – EC DECLARATION OF CONFORMITY DECLARACIÓ DE CONFORMIDAD CE La Ditta Saeco International Group S.p.a. Dichiara sotto la propria responsabilità chi i prodotti: Macchina per caffè per uso professionale Déclare que les produits suivants: Machines à café expresso pour usage professionnel Erklärt, dass die folgenden Produkte: Gewerbe Espresso Kaffeemaschinen...
- Page 5 INDICE INDICE 1- INSTRUCTIONS BOOKLET CONSERVATION AND USE 2- ENVISAGED MACHINE USE 3 - SAFETY ADVICE 4 - TECHNICAL FEATURES 5 - INSTALLATION 6 - START UP 7 - FUNCTION / USE AND PROGRAMMING 8 - PURIFIER REGENERATION 9 - MAINTENANCE AND USEFUL ADVICE 10 -TROUBLE SHOOTING 11 -MACHINE DISMANTLING...
-
Page 6: Envisaged Machine Use
1 - INSTRUCTIONS BOOKLET 2 - ENVISAGED MACHINE USE CONSERVATION... -
Page 7: Safety Advice
3 - SAFETY ADVICE... -
Page 8: Technical Features
4 - TECHNICAL FEATURES... -
Page 9: Installation
5.1 Water connection INSTALLATION Important: The machine must be supplied with water of over 8°F hardness. NB: before connecting the purifier to the machine, wash out thoroughly until the water becomes clear, then proceed to connect the purifier to the machine. 5.2 Electrical connection Important ! Before proceeding with electrical connection it is necessary to check to ensure that the... - Page 10 6 - START UP 10 11 12 13 14 mod. mod. ÷ 6.1 Long coffee gigleur...
-
Page 11: Pressure Switch Adjustment
6.2 Pressure switch adjustment Warning !! When the machine is new the filter-holder sump may not be aligned (perpendicular to the machine itself) as shown in the figure at the side, however this does not effect the efficient function of the same. After a short period of use the sump will gradually settle into a correct position. -
Page 12: Programming Introduction
Replacement of the thermostat to reduce the coffee dispensing group temperature. 7- FUNCTION / USE AND PROGRAMMING INTRODUCTION... -
Page 13: Coffee Measure Programming
7.1 Coffee measure programming IMPORTANT !! The settings made on unit 1 (operating on the first keyboard) will be automatically copied on to all the other units. Note: If none of the keys are pressed within 30 seconds, it will automatically escape from programming mode. -
Page 14: Coffee Delivery
IMPORTANT: Should the “PRE- INFUSION” function be active (see par. 7.5). Wait until the pre-infusion function is complete before stopping delivery in progress. NOTE: During the programming of a unit the function of the other units is deactivated as well as tea dispensing. 7.2 Coffee delivery... -
Page 15: Continuous Coffee Measures
7.3 Continuous coffee measures IMPORTANT ! Avoid keeping it pressed for more than 5 seconds or it will enter the programming mode. IMPORTANT ! The start of the relative “continuous” cycle occurs on the release (within 5 seconds) of key T5 and not on pressing of the same. -
Page 16: Alarm Condition
7.5 Alarm condition Boiler (filling) level time out... -
Page 17: Purifier Regeneration
8 - PURIFIER REGENERATION IMPORTANT : Regenerate the purifier at the intervals listed below: HARDNESS °F 8 LITRE PURIFIER 12 LITRE PURIFIER NB: These regeneration instructions are valid only providing the purifier is as that indicated in the figures. Should it fail to correspond proceed as indicated in the instructions attached to the purifier itself. -
Page 18: Maintenance And Useful Advice
9 - MAINTENANCE AND USEFUL ADVICE Weekly cleaning operations Below-cup seal replacement... -
Page 19: Troubleshooting
10 - TROUBLE SHOOTING PROBLEM CAUSE REMEDY 1. Mains switch off 2. Machine switch off 3. Incorrect electrical mains connection 1. Mains tap closed 2. Clogged pump filter 3. Motor driven pump not in operation 1. mains tap closed 2. motor driven pump out of order 3. - Page 20 LEGENDA COMPONENTI - COMPONENTS LIST - LEGENDE BAUTEILE LEGENDE DES COMPOSANTS- LEYENDA COMPONENTES Cavo alimentazione three-pole power cable Dreipoliges Câble d'alimentation Cable alimentación tripolare Stromversorgungskabel tripolaire tripolar Commutatore 4 posizioni 4-position commutator 4-stelliger Umschalter Commutateur à 4 Conmutador 4 posiciones positions Pressostato tripolare three-pole pressure switch Dreipoliger Druckwächter...
