• DO NOT TRY TO LIGHT ANY APPLIANCE.
• DO NOT TOUCH ANY ELECTRIC SWITCH: DO NOT USE ANY PHONE IN YOUR VEHICLE.
• IMMEDIATELY CALL YOUR GAS SUPPLIER FROM A NEIGHBOR'S PHONE. FOLLOW THE GAS SUPPLIER'S
INSTRUCTIONS.
• IF YOU CANNOT REACH YOUR GAS SUPPLIER, CALL THE FIRE DEPARTMENT.
WARNING:
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN
CAUSE INJURY OR PROPERTY DAMAGE. REFER TO THIS MANUAL. FOR ASSISTANCE OR ADDITIONAL
INFORMATION, CONSULT A QUALIFIED INSTALLER, SERVICE AGENCY OR THE GAS SUPPLIER.
DO NOT STORE OR USE GASOLINE OR OTHER COMBUSTIBLE MATERIALS OR LIQUIDS NEAR OR
ADJACENT TO THIS HEATER OR ANY OTHER APPLIANCE. THIS APPLIANCE SHALL NOT BE INSTALLED IN
ANY LOCATION WHERE FLAMMABLE LIQUIDS OR VAPORS ARE LIKELY TO BE PRESENT.
AN ODORANT IS ADDED TO THE GAS USED BY THIS WATER HEATER.
INSTALLER: AFFIX THESE INSTRUCTIONS TO OR ADJACENT TO WATER HEATER.
OWNER: RETAIN THESE INSTRUCTIONS AND WARRANTY FOR FUTURE REFERENCE.
ALL TECHNICAL AND WARRANTY QUESTIONS SHOULD BE DIRECTED TO THE COMPANY
LISTED ON THE WARRANTY, OR RATING PLATE WHICH CAME WITH YOUR WATER HEATER.
Part Number 204671
3-24-09
INSTALLATION AND OPERATION MANUAL
DIRECT VENT
GAS WATER HEATER
DIRECT SPARK IGNITION (DSI)
SW10D • SW10DM • SW10DE • SW10DEM
SW12D • SW12DE • SW12DEM
SW16D • SW16DE • 16DEM
FOR INSTALLATION IN RECREATIONAL
VEHICLES AND MOBILE HOUSING
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
FREEZE WARNING
DRAIN HEATER IF SUBJECT TO FREEZING TEMPERATURES.
FOR YOUR SAFETY
MODELS
SUBURBAN MANUFACTURING COMPANY
676 Broadway Street
Dayton, Tennessee 37321
423-775-2131
www.rvcomfort.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Suburban SW10D
Summary of Contents for Suburban SW10D
- Page 1 INSTALLATION AND OPERATION MANUAL DIRECT VENT GAS WATER HEATER DIRECT SPARK IGNITION (DSI) MODELS SW10D • SW10DM • SW10DE • SW10DEM SW12D • SW12DE • SW12DEM SW16D • SW16DE • 16DEM FOR INSTALLATION IN RECREATIONAL VEHICLES AND MOBILE HOUSING FOR YOUR SAFETY WHAT TO DO IF YOU SMELL GAS •...
-
Page 2: Installation Requirements
CAUTION: Do not install this appliance to where the vent terminates below a slide-out. This appliance is not to be installed under any overhang. It I. The module board on models SW10D, SW10DE, SW12D, SW12DE, SW16D must be free and clear of any type overhang. - Page 3 Figure 1 Figure 1A DOOR FRAME FRAMED OPENING DC JUNCTION BOX (SEE FIGURE NO. 1) CAULKING MODELS SW10D, DE SW12D, DE FRAMED OPENING SW16D, DE CAULK AROUND OPENING PLACE SCREW OR SUITABLE FASTENER AS SHOWN. DOOR FRAME WHEN INSTALLED MUST NOT OVERLAP ONTO SCREW HEAD OR FASTENER.
-
Page 4: Electrical Connections
A. Applicable to following models: SW10D, SW10DE, SW10DM, SW10DEM SW12D, SW12DE, SW12DEM, SW16D, SW16DE, and SW16DEM. B. Refer to Figure 2 for location of D.C. junction box on models SW10D ,SW10DE SW12D, SW12DE, SW16D and SW16DE. Refer to Figure 4 and 5 for location of D.C. -
Page 5: Installation Of Motor Aid Heat Exchanger
DISCONNECT POWER SUPPLY BEFORE REMOVING COVER frayed and that all terminals and connections are tight and in compliance with CODE COLOR SUBURBAN MANUFACTURING COMPANY, DAYTON, TENNESSEE codes (See “Making Wire Connections”). 120 V.A.C SINGLE PHASE - 1440 WATT ELEMENT - 60 CYC LE BLACK... -
Page 6: Thermostat And Manual Reset
BLUE OR BLUE/ORANGE WELL DEFINED PATTERN BLEU OU BLEU/ORANGE Suburban recommends that a check valve not be installed directly at the inlet to TYPE BIEN DEFINI the water heater tank. This will increase weeping of the pressure relief valve. WARNING! Do not remove or plug the relief valve. -
Page 7: Draining And Storage Instructions
Follow instructions in item B of the safety information. If you don’t smell gas, go heater. to next step. 4. On Models SW10D, SW10DE SW12D, SW12DE, SW16D and SW16DE 5. Turn “ON” gas supply. disconnect all wires at module board. -
Page 8: Water Heater
TO TURN OFF WATER HEATER 3. Turn off gas supply. 1. Turn switch to “OFF” position. 4. If vehicle is to be stored or heater is going to be turned off while subject to freezing temperature, drain water heater. (See “Draining and Storage 2. -
Page 9: Replacement Parts List
Screw 8mm - 4.0 x ½ Hex Washer Head (2 Required) ..........121943 121943 1/4 Loxit Nut (Manifold to Burner) ................171463 171463 Electrode Wire (Not Shown) SW10D, SW10DE, SW12D, and SW12DE ....232456 232456 Electrode Wire (Not Shown) SW16D and SW16DE.............232459 232459 Screw 10 x 1/4 (No Substitute) (2 Required)..............121577... - Page 10 PARTS LIST FOR MODEL SW10DM (Figures 15 and 16) Item Part Number Item Part Number Description SW10DM Description SW10DM Cover, Module Board ................090340 Electrode ....................232258 Cover Junction Box ................090344 Burner Assembly with orifice ..............010843 Screw 10-32 x 3/8 (Green) ..............121702 1/4 Loxit Nut (Manifold to Valve) ...............171463 Switch, Lamp and Plate Assembly ............
- Page 11 PARTS LIST FOR MODEL SW10DEM, SW12DEM AND SW16DEM (Figures 17 and 18) Item Part Number Description SW10DEM Item Part Number SW12DEM Description SW10DEM SW16DEM SW12DEM Cover Module Board ................090340 SW16DEM Cover, Junction Box (12 V.D.C.) ............090344 Burner Assembly with orifice ................010843 Screw 10-32 x 3/8 (Green) ..............
- Page 12 It is the responsibility of the consumer/owner to establish the warranty period. Suburban does not use warranty registration cards for its standard warranty. You are required to furnish proof of purchase date through a Bill of Sale or other payment records.
