Summary of Contents for Kathy Ireland DOWNTOWN LOFT

  • Page 1 DOWNTOWN LOFT U.S. Patents: D598,998; D599,001; D599,002 Additional U.S. Patent(s) Pending INSTRUCTION MANUAL WARRANTY CERTIFICATE...
  • Page 2 This product is protected by United States Federal and/or State Law, including Patent, Trademark and/or Copyright laws. Manual design and all elements of manual design are protected by U.S. Federal and/or State Law, including Patent, Trademark and/or Copyright laws.
  • Page 3 This is a limited warranty. Minka-Aire's only obligation under this limited warranty is to replace or repair, or refund the purchase price, in Minka-Aire's sole discretion without charge to the original owner, of the fan once Minka-Aire confirms that the fan has a defect covered by this limited warranty.
  • Page 4 This limited warranty is in lieu of all other express warranties. This limited warranty excludes all incidental and consequential damages, and Minka-Aire shall not under any circumstances be liable for incidental or consequential damages. Some States do not allow the exclusion of or limitation of incidental or consequential damages, so the foregoing limitation or exclusion may not apply to you.
  • Page 5: Table Of Contents

    CONTENTS SAFETY RULES..................BLADE INSTALLATION................. PACKAGE CONTENTS..............INSTALLING THE LIGHT PLATE............INSTALLING THE FAN..............INSTALLING THE LIGHT BULB & GLASS SHADE ....HANGING THE FAN................. OPERATING THE REMOTE CONTROL/WALL CONTROL..ELECTRICAL CONNECTIONS............CARE OF YOUR FAN................INSTALLING THE WALL TRANSMITTER........ TROUBLESHOOTING................
  • Page 6: Safety Rules

    SAFETY RULES 1. Before you begin installing the fan, shut power off at the circuit breaker of the fuse box. 2. Be cautious! Read all instructions and safety information before installing your new fan. Review accompanying assembly diagrams. 3. Make sure that all electrical connections comply with local codes, ordinances, or National Electrical Codes. Hire a qualified electrician or consult a do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring.
  • Page 7 ATTENTION: ATTENTION: The Energy Policy Act of 2005 requires this fan to be equipped with a 190 watt limiting device. If lamping exceeds 190 watts, the ceiling fan's light kit will shut off automatically. NOTE: NOTE: The important safeguards and instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur.
  • Page 8: Package Contents

    PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: 1. Fan blades (3) 16. Extra Wall Plate w/2 Mounting 2. Hanger bracket screws 3. Canopy 17. Balancing kit 4. Canopy cover 5. Standard downrod ass'y A.
  • Page 9: Installing The Fan

    HANGER BAR JOIST SUPPORT (OPTIONAL) Note:You may need a longer downrod to maintain proper blade clearance when installing on a steep, sloped ceiling. Longer downrods are available from your Minka-Aire dealer. HANGER OPENING must be FACING To hang your fan where there is an existing fixture but no ceiling joist, you may need to install...
  • Page 10: Hanging The Fan

    HANGING THE FAN WARNING: All of the parts, hardware and components such as the Step 4. Carefully feed fan wires up through the downrod. (Fig. 8) hanger bracket and hanger ball have been provided for your safety and Thread the rod into the coupling, next line up holes and replace lock the proper installation of your new ceiling fan.
  • Page 11 DOWNROD COUPLING COVER CANOPY *OMIT COUPLING OUTLET BOX COVER WHEN USING DOWNROD CROSS PIN THE MINIMUM-LENGTH SET SCREWS DOWNROD CANOPY COVER HITCH LOCK HANGER SUPPLY REGISTRATION BALL SET SCREW SET SCREWS WIRES SLOT DOWNROD HANGER BRACKET Fig. 10 Fig. 5 Fig.
  • Page 12: Electrical Connections

    ELECTRICAL CONNECTIONS WARNING: To avoid possible electrical shock be sure electricity is Step 2. Motor to Receiver Electrical Connections: Connect the WHITE turned off at the main fuse or breaker box before wiring. wire from the fan to the WHITE wire marked "TO MOTOR N" from the Receiver.
  • Page 13 Step 3. Receiver to House Supply Wires Electrical Connections: Connect the WHITE wire (Neutral) from the outlet box to the WHITE wire marked "AC in N" from the receiver. Connect the BLACK wire (Hot) from the outlet box to the BLACK wire marked "AC in L" from the receiver.
  • Page 14 INPUT AC120V OUTLET BOX WHITE (NEUTRAL) BLACK (HOT) WHITE GREEN OR BARE AC SUPPLY COPPER (GROUND) BLACK ("AC IN L") BLACK WHITE ("AC IN N") RECEIVER BLACK ("TO MOTOR L") WHITE ("TO MOTOR N") ORANGE GROUND (CONNECT TO GROUND- (FOR UPPER LIGHT) GROUND WIRE ON (GREEN) HANGER BRACKE...
  • Page 15: Installing The Wall Transmitter

    INSTALLING THE WALL TRANSMITTER WARNING! HOOK UP "IN SERIES" ONLY. DO NOT CONNECT NEUTRAL SUPPLY WIRE OF ELECTRIC CIRCUIT TO THE TRANSMITTER WALL SWITCH, DAMAGE TO THE TRANSMITTER WALL SWITCH AND POSSIBLE FIRE COULD OCCUR. Step 1. Remove the existing wall plate and switch from the wall outlet box. Step 2.
  • Page 16: Finishing The Installation

    FINISHING THE INSTALLATION OUTLET BOX Step 1. Slide the canopy up to the ceiling and over the two screws on hanger bracket. Rotate HANGER canopy clockwise, next, while holding the canopy with one hand, slide the canopy cover over the BRACKET screws and rotate clockwise until tight.
  • Page 17: Blade Installation

    BLADE INSTALLATION THE FOLLOWING OPERATION MUST BE ACCOMPLISHED BEFORE INSTALLING THE GLASS SHADE. SCREWS RUBBER Caution: Remove 5 rubber packing mounts and discard before WASHERS installation. BLADE Step 1. Attach the fan blade to the blade holder using the screws and rubber washers provided. Tighten screws securely. BLADE HOLDER Repeat process for remaining blades.(Fig.
  • Page 18: Installing The Light Plate

    INSTALLING THE LIGHT PLATE NOTE: Before starting installation, disconnect the power by turning off the circuit breaker or removing the fuse at fuse box. 1. Remove 1 of 3 screws from the mounting ring and loosen the other 2 screws. (Do not remove) 2.
  • Page 19: Installing The Light Bulb & Glass Shade

    INSTALLING THE LIGHT BULB & GLASS SHADE WARNING: Shut of the power supply before removing or replacing lamp. In handling of halogen bulb, care should be taken not to touch it with your bare hands. Oil residue will shorten the life of the halogen bulb.
  • Page 20: Operating The Remote Control/Wall Control

    OPERATING THE REMOTE CONTROL/WALL CONTROL Remote Control only: Install a A23 12 volt battery (included). To prevent damage to transmitter remove the battery if not used for long periods of time. Restore Power to Ceiling Fan. D. OFF-ON Slide Button (Wall Control Fans Only) instructions apply to ceiling fans that feature a DOWN This button turns the power Off and On to the Fan and light (...
  • Page 21 Speed settings for warm or cold weather depend on factors such as room size, ceiling height and number of fans. NOTE: To operate the reverse function on this fan, press the reverse button while the fan is running. Warm Weather (forward) A DOWNWARD airflow creates a cooling effect as shown in Figure 21.
  • Page 22: Care Of Your Fan

    CARE OF YOUR FAN Here are some suggestions to help maintain your fan. 4. There is no need to oil your fan. The motor has permanently lubricated 1. Because of the fan's natural movement some connections may become bearings. loose. Check the support connections, brackets and blade attachments twice a year.
  • Page 23: Troubleshooting

    TROUBLESHOOTING SYMPTOM SYMPTOM Fan will not start Fan Sounds Noisy SOLUTION SOLUTION Check to make sure the wall switch is turned on. Allow a 24-hour "break in" period. Most noises associated with a new fan will go away during this time. Check circuit fuses or breakers.
  • Page 24 SYMPTOM SYMPTOM Fan Wobble Lights shut off and will not come back on. SOLUTION SOLUTION NOTE: All blade sets are grouped by weight. Because wood and This unit is equipped with a wattage limiting device. Lamping in excess of 190 watts will disable your ceiling fan’s light kit. To reset plastic blades vary in density, the fan may wobble even though blades are matched.
  • Page 25 SYMPTOM Frequency Interference SOLUTION Turn the power off to your ceiling fan. Please use a small size tool to change the frequency settings on the control system. Return power to the unit. Note: After the AC power is on, do not press any other button on the transmitter before pressing the "Stop" button, doing so will cause the procedure to fail.
  • Page 26: Specifications

    SPECIFICATIONS These are typical readings. Your actual fan may vary. Fan Size Speed Volts Amps Watts RPM CFM N.W. G.W. C.F. They do not include amps and wattage used by the light(s). 0.38 2041 8.84 9.91 1.79' Medium 54" 0.56 3477 High 0.51...
