Appro SD-7800 Installation & Operation Manual

Sequentially rotating dome camera

Advertisement

Quick Links

INSTALLATION &
OPERATION MANUAL
Sequentially Rotating Dome Camera
SD-7800
Before trying to connect or operate this product, please read this manual completely

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SD-7800 and is the answer not in the manual?

Questions and answers

Summary of Contents for Appro SD-7800

  • Page 1 INSTALLATION & OPERATION MANUAL Sequentially Rotating Dome Camera SD-7800 Before trying to connect or operate this product, please read this manual completely...
  • Page 3: Table Of Contents

    CONTENTS Before Installing ………………………………….………….………… II Key Features ……………………………………………………. …… Environmental requirement ………………………………………… Dome setting Instruction …………………………………………… Camera ID Setting…………………………………………………………………. Camera Module Setting…………………………………………………………. . V Basic High Speed Dome Operation ………………………………… OSD Operation………………………………………………………………. …… Enter OSD …………………………………………………………………………. . 7 Menu function instructions……………………………………………………… Camera Exposure………………………………………………………………….
  • Page 4: I Before Installing

    Before Installing Installation should be carried out only by qualified personnel and in accordance with any wiring regulations in force at the time. Please read this instruction and warnings before installing. Do not attempt to service or repair the speed domes as opening or removing covers may expose dangerous voltages or other hazards.
  • Page 5 Setting Attention: Adequate protection against high speed dome falling and damage when installing. The dome should be hang setting, and please avoid up side down. Please install the dome at the low humidity condition and keep it sealing for avoiding any damage to dome.
  • Page 6: Camera Id Setting

    1、 Power supply communication cable: AC24V AC24V RS485 2、Video output: Alarm signal Alarm Relay Output “AUX1” Alarm Relay Output “AUX2 Alarm Input GND Alarm input signal: l -7 AL1、AL2、AL3、AL4…AL7:Alarm input. The switch setting ON=1 OFF=0 Protocol setting Baud rate setting Alarm Alarm mode DIP Switch...
  • Page 7: Camera Module Setting

    CAM ID ∶ ∶ ∶ ∶ ∶ ∶ : Note The address of the some protocol are from 0, and the others are from 1, please setting the address(±1) as your protocol. Alarm 7 alarm input. The dome will alarm when alarm input port connect the GND. The AUX will be closed when has alarm, and open when no alarm in.
  • Page 8: Basic High Speed Dome Operation

    Camera Switch 1 Switch 2 Switch 3 Switch 4 DIP-1 DIP-2 DIP-3 DIP-4 SONY HITACHI CNB-200L CNB-M1560 SAMSUNG(SDM300/SDM330) Note: Please make sure the camera parameters are correct or the camera cannot work or cannot work well. If this, please enter the camera menu and restore factory settings first, then setting the parameters as request.
  • Page 9: Osd Operation

    Function Control Camera mode 1 Call 100 preset Camera mode 2 Call 101 preset Camera mode 3 Call 102 preset 4 Privacy mask, only fit to SONY480, SONY980 and SONY1000 camera. Level area increase: FAR Privacy Mask Level area reduce: NEAR Vertical area increase: TELE Vertical area reduce: WIDE OSD Operation...
  • Page 10: White Balance

    2, Confirm Exposure. • Exp Mode press OPEN key, select effect, the menu change to Exp Mode 3, Cancel Exposure Exp Mode press CLOSE to cancel the Exposure mode change, the menu change to Mode Back the main camera menu •...
  • Page 11: Privacy Mask

    Privacy Mask Exposure ► White Balance ► Exposure ► operate the joystick to let the cursor Privacy ► come to Privacy press OPEN to enter the submenu, then set Other ► Camera Model ► the parameter. Zoom Speed Focus Speed There are 4 privacy masks, which have the same operation 1.
  • Page 12: Zoom Speed

    102 preset Zoom Speed At the submenu of Exposal, move the cursor to Zoom Speed, press OPEN, the cursor will change to , then the parameter can be changed. Press OPEN to confirm and back or CLOSE cancel and back. Focus Speed Move the cursor to Focus Speed, press OPEN, the cursor will change to , then the parameter can be changed.
  • Page 13: Leisure Time

    Nothing P Scan 1 Preset scan 1 P Scan 2 Preset scan 2 P Scan 3 Preset scan 3 P Scan 4 Preset scan 4 A Scan Auto scan (left and right limit scan Home Home place Operation: Press OPEN the cursor will change to , and the parameter can be change.
  • Page 14: Hitachi Camera Module

    Menu Submenu Third Menu Parameter Zoom Speed 005(001~007) Camera Focus Speed 001(001~007) Home place OFF(001-032,OFF) AS speed 060(000-080) PS1 Speed 120(100-120) PS1 time 005(005-120) PS2 Speed 120(100-120) PS2 time 005(005-120) PS3 Speed 120(100-120) PS3 time 005(005-120) PS4 Speed 120(100-120) PS4 time 005(005-120) Auto Flip On(On/Off)
  • Page 15: Cnb Camera Module

    Parameter Menu Submenu Third Menu On (On/Off) Lens Digital Zoom D Zoom MAG mag12(mag 0~mag12) Camera Zoom Speed High(High,Super h,Normal) Focus Speed 016(0~31) Home place OFF(001-032,OFF) AS speed 060(000-080) PS1 Speed 120(100-120) PS1 time 005(005-120) PS2 Speed 120(100-120) PS2 time 005(005-120) PS3 Speed 120(100-120)
  • Page 16 Menu Submenu Third Menu Parameter BACKLIGHT OFF(ON/OFF) SLOW FLD24(OFF , FLD2, FLD 4, FLD 8, FLD 12, FLD 16, SHUTTER FLD 24, FLD 32, FLD 64, FLD128) DAY/NIGHT AUTO(ON,OFF,AUTO) WB CONTROL AUTO(AUTO/PUSH) SHUTTER AUTO CAMERA ID 000(000~255) Camera ZOOM START X001(x001~X022) X220(X220,X209,X198,X187,X176,X165,X154,X143, ZOOM STOP...
  • Page 17: Lg Camera Module

    High speed dome with LG CAMERA MODULE MENU LG Camera module OSD Operation way Confirm decrease NEAR Confirm or increase the parameter parameter TELE WIDE Down NOT USE Can’t be use Have submenu and back FUNCTION OSD Format Description Remarks Non display Auto Mode Focus Mode...
  • Page 18 The Menu shortcut List of HIGH SPEED DOME WITH LG Main Submenu Last Menu Parameters(optical) Exp Mode Auto(Auto,manual;shutter up,iris,bright) Shutter speed 006(0~19) Iris 015(0~17) Exposure Gain 001(0~15) Bright 015(0~18) Back Light OFF(ON/OFF) Slow Shutter OFF(ON/OFF) WB Mode Auto( Auto,Manual;ATW,OPW,Outdoor,Indoor) White Balance R Gain 210(0~255) B Gain...
  • Page 19 Attention and operation advice for Samsung camera module. Enter the Camera menu: MAIN SETUP ►CAM TITLE WHITE BAL BACKLIGHT MOTION DET FOCUS EXPOSURE SPECIAL RESET EXIT CAM TITLE 1. CAM TITLE ABCDEFGHIJKLMNO PQRSTUVWXYZabcd e f g h i j k l m n o p q r s t u v w x y z 0 1 2 3 4 5 6 7 8 9 ( ) <...
  • Page 20 5. EXPOSURE EXPOSURE SETUP SET SHUTTER ►BRIGHTNESS 50 ►SHUTTER 1/60 IRIS AUTO SHUTTER MIDDL SSNR MIDDL Press SET to Return SENS-UP AUTO SHUTTER: Attention: When setting the BACKLIGHT as OFF, the A.FLK will show the best effect. If camera setting as ESC, the image will not steadily when fact to the high light. Can not use WDR when setting as MANUAL.
  • Page 21: Analysis On Common Malfunctions And Maintenance

    Analysis on Common Malfunctions and Maintenance If there is any problem at your operation, please work through the logical steps below to determine and rectify the problem. Symptom How to solve the problems ? 1 .Check the power supply and make sure if fuse is blow out or not 2.
  • Page 22 Connection: RMN0100173...
