Summary of Contents for Humminbird ProFlasher
-
Page 2: Installation Preparation
Customer Support section. INSTALLATION OVERVIEW Your Humminbird fishfinder consists of two primary components to install: the control head and the transducer. The control head contains the sonar transmit and receive circuitry, as well as the user controls and display. -
Page 3: Installation Overview
INSTALLATION PREPARATION Determining How to Mount the Transducer Your Humminbird fishfinder includes a standard transducer. This transducer can be mounted on the transom of the boat or bonded to the inside of a fiberglass hull boat. The transom installation, which is the most widely used, places the transducer on the outside of the boat hull. -
Page 4: Alternate Mounting Methods
ALTERNATE MOUNTING METHODS ALTERNATE TRANSDUCERS AND MOUNTING METHODS Your Humminbird fishfinder comes with everything necessary for installation and operation on most boats. However, there are several situations which may require a different type of transducer. Inboard boats, wood or metal hulls, and sail boats create unique transducer mounting needs Alternate transducers and mounting methods are detailed below. -
Page 5: Beginning Installation
BEGINNING INSTALLATION Now that you have determined the transducer mounting method you can begin installation of your new Humminbird fishfinder. The installation guide included on the next few pages provides detailed step by step instructions for installation of the control head and transducer. For transom mount transducer installations you will need the mounting template included with your manual. -
Page 6: Transom Installation
Do not begin this transducer installation until you read the Installation Preparation in the Operation Guide. This chapter contains information critical to the correct installation of your transducer. Due to the wide variety of boat hulls, only general instructions are presented in the installation guide. - Page 7 If the propeller(s) is (are) forward of the transom, it may be impossible to find an area clear from turbulence, and a different mounting technique or transducer type should be considered. Step Two - Drill the Mounting Holes 1. Remove the mounting template from the front of the Operations Manual. 2.
- Page 9 Step Four - Mount the Transducer to the Transom 1. Apply silicone sealant to the mounting holes drilled into the transom. 2. Align the transducer assembly with the drilled holes in the transom (Figure 8). 3. Use either a flat head screwdriver, a 5/16" (8mm) hex driver, or a 5/16" (8mm) socket to mount the assembly.
- Page 10 mounting bracket. Drill this hole and install the screw after final testing and adjustments have been completed.
- Page 11 If the cable is too short, extension cables are available to extend the transducer cable up to a total of 50' (15 m). Call Humminbird Customer Support for more information. Follow these steps to route the cable through the transom: 1.
-
Page 12: Inside The Hull Installation
Inside the hull mounting generally produces good results in single thickness fiberglass-hulled boats. Humminbird cannot guarantee depth performance when transmitting and receiving through the hull of the boat since some signal loss occurs. The amount of loss depends on hull construction and thickness, and the installation. - Page 13 The transducer cannot transmit through air. The water purges any air from between the transducer and the hull and fills any voids in the coarse fiberglass surface.
- Page 14 3. Power up the Control Head. 4. Run the boat at various speeds and water depths while observing the screen on the Control Head. If the unit functions well at low speeds but begins to skip or miss the bottom at higher speeds, the transducer needs to be moved. If depth performance is required, test the fishfinder in water at the desired depth.
-
Page 15: Control Head Installation
CONTROL HEAD INSTALLATION Step One - Determine Where to Mount Begin the installation by determining where to mount the control head. Consider the following to determine best location: The cables for power, transducer and temp/speed accessories (if applicable) should be installed first and must reach the mounting location. Extension cables are available. - Page 16 fuse in the connection. If you must wire the control head directly to a battery, be sure to install an inline fuse holder...
- Page 17 (not included) for the protection of the unit (Figure 21). Humminbird is not responsible for over voltage or over current failures. In order to minimize the potential for interference with other marine electronics a separate power source (such as a second battery) may be necessary.
- Page 18 Optional: If the cables pass outside the mounting bracket, install the hole cover over the hole and fasten in place using the two #8 x 7/8” (22mm) wood screws (Figure 24).
- Page 19 5. Install the control head by sliding it onto the mounting bracket until it is fully seated. To remove the unit simply depress the latch on the rear of the unit and lift (Figure 29). Your Humminbird is now ready for operation. INSTALLATION CONTROL HEAD INSTALLATION...
-
Page 20: Test The Installation
Note: it is often necessary to make several incremental transducer adjustments before optimum high-speed performance is achieved. Important: For Transom Mount transducer installations, install the third mounting screw after the final transducer adjustments. Humminbird 3 Humminbird Lane Eufaula, Alabama 36027... - Page 21 Increase your boat speed to ensure that the transducer remains in contact with turbulence-free water at higher boat speeds. All Humminbird depthsounders are designed to work at speeds of 70 MPH or more, however use caution when operating any boat at high speed. High-speed testing does not apply to portable or trolling motor mounted transducers.
- Page 22 "light emitting", it is ideal for use at night or in low- light situations. The rubber lens hood prevents washout in even the brightest sunlight. As with all Humminbird products, all moving parts are ruggedized for tough shock and vibration endurance, and special components allow the Pro Flasher to operate at temperatures more extreme than you are likely to encounter.
- Page 23 Reject control slowly clockwise until it is filtered out. If no noise is detected, the control should be left in the "MIN" position. WHAT YOU SEE ON THE DISPLAY A "Zero" line is always present on the dial. This indicates that the unit is transmitting a signal. Any additional light displayed indicates a reflected sonar signal.
- Page 24 Broken but continuously displayed signals near the bottom return indicate vegetation or ground cover. It is often possible to see a "second return" from the bottom. This is usually seen in shallower water when the sensitivity is adjusted higher than normal. The sonar signal is transmitted downward from the boat and is reflected from the bottom back up.
- Page 25 A thermocline is the horizontal boundary where significant water temperature differences exist. When a thermocline exists, it will often tend to reflect sonar signals and is therefore visible on the display. The thermocline is identifiable because it usually exists over a broad area, and as a result will appear more continuous than returns from fish.
- Page 26 120'. MAINTAINENCE Your Humminbird Pro Flasher depthsounder is designed to provide you with years of trouble-free operation with virtually no maintenance. Follow the simple procedures below to ensure that your Pro Flasher continues to deliver top performance.
- Page 27 Repairs should be performed only by authorized Humminbird technicians. Many requests for repair received by Humminbird involve units that do not actually need repair. If you have trouble with your Pro Flasher, consult the following troubleshooting guide before contacting Humminbird.
- Page 28 and can produce electrical output in excess of 17 volts at higher engine speeds. Installation of an external voltage limiting device will prevent this from occurring.
