Liebert PSA itON

Liebert PSA itON UPS

User Manual

Version:

V2.8

Revision date:

November 14, 2005

Emerson Network Power provides customers with technical support. Users may contact the nearest

Emerson local sales office or service center.

While every precaution has been taken to ensure accuracy and completeness in this manual,

Emerson Network Power assumes no responsibility and disclaims all liability for damages resulting

from use of this information or for any errors or omissions.

Emerson Network Power pursues a policy of continuous product development and reserves the

right to change the equipment design without notice.

Page １

V2.8

Installation and User Manual

Emerson Network Power

Table of Contents

Need help?

Do you have a question about the itON 600 and is the answer not in the manual?

Questions and answers

Summary of Contents for Liebert itON 600

Page 1 Liebert PSA itON Installation and User Manual Liebert PSA itON UPS User Manual Version: V2.8 Revision date: November 14, 2005 Emerson Network Power provides customers with technical support. Users may contact the nearest Emerson local sales office or service center.
Page 2: Table Of Contents
Liebert PSA itON Installation and User Manual Table of Contents Contents Safety Instructions Product Introduction System Description Installation Software Troubleshooting Technical data Page 2 V2.8 Emerson Network Power...
Page 3: Safety Instructions
The UPS must be serviced by an authorized representative of Emerson Network Power. Failure to do so could result in personnel safety risk, equipment malfunction and invalidation of warranty. • The Liebert PSA itON has been designed for Commercial/Industrial use only, and is not recommended for use in life support applications. •...
Page 4 Liebert PSA itON Installation and User Manual Safety Instructions Operation • Do not disconnect the mains cable on the UPS system or the building wiring socket outlet (shockproof socket outlet) during operations since this would cancel the protective earthing of the UPS system and of all connected loads.
Page 5: Product Introduction
Liebert PSA itON Installation and User Manual Product Introduction 2 . Product Introduction This UPS is specially designed for Personal Computer with multi-functions. Its light weight, compact design perfect fits to the limited working environment. The line of UPS is equipped with boost and buck AVR to stabilize input voltage range.
Page 6: System Description
Power Switch AC Mode: Green LED on Battery Mode: Green LED flashing Back Panel Output receptacles AC Input Modem / Phone line Surge Protection Communication Port itON 600 itON 1000 itON 600 (India Version) Page ６ V2.8 Emerson Network Power...
Page 7: Installation
Liebert PSA itON Installation and User Manual Installation 4. Installation Installing the UPS is as easy as following the steps shown. Be aware that the power Switch must be kept in the “ON” position, otherwise, the UPS will be disabled and your equipment will not be protected during a power failure.
Page 8 COMPUTER itON 600 itON 1000 itON 600 (India Version) 4.5 Modem / Phone line Connection Plug incoming internet line into the “In” socket at the back of the UPS. Use one more Internet line cable and plug one end of the Internet line cable to the “Out” socket at the back of the UPS. Plug the other end of the modem input socket as shown below.
Page 9 All these Series are equipped with Green Power Function*. If no load connects to the UPS, it will automatically shut down in 45 seconds for energy saving while power failure. The UPS will restart while AC recovers * This feature is only applicable with itON 600 Page ９ V2.8...
Page 10: Software
Liebert PSA itON Installation and User Manual Software 5. Software Free UPS Monitoring Software The UPS monitoring software, provides user-friendly interface to monitor and control your UPS. This unique software provides safe auto shutdown for multi-computer systems during a power failure.
Page 11: Troubleshooting
Liebert PSA itON Installation and User Manual Trouble Shooting 6. Trouble Shooting If any abnormal situations occur that are not listed above, please call the authorized Emerson Network Power service engineers immediately. Page １１ V2.8 Emerson Network Power...
Page 12: Technical Data
Liebert PSA itON Installation and User Manual 6. Technical Data Liebert PSA itON PS600-TN PS1000-TN 600VA 1000VA CAPACITY V/AW 600VA/360W 1000VA/600W Voltage Range 140-300 VAC 160-300 V INPUT Frequency 45-65 Hz (Auto Sensing) 45-65 Hz (Auto Sensing) Voltage Range 230V...
