Summary of Contents for Soulution 711
- Page 1 Series 7 Stereoamplifier 711 User manual...
- Page 3 We understand your eagerness to get started but even though please study this manual step by step before you integrate the stereoamplifier 711 in your High Fi- delity system. This manual contains also useful tips for the optimization of your overall HiFi-system.
- Page 4 CE-Declaration of Conformity Spemot AG declares that this product is in conformance with the following direc- tives and standards: Low Voltage Directive 2006/95/EG (EN/IEC 60065:2002) Electromagnetic 2004/108/EG (EN 55013:2001, EN 55020:2002, EN 61000-3- 2:2006, EN 61000-3-3:1995)
-
Page 5: Table Of Contents
Store the packing for future transportations. Unpacking Treat the high quality surface with care Position the stereoamplifier 711 on a stable base Positioning Cooling air must be able to escape unrestrictedly. Disconnect all components of your system from the mains ... -
Page 6: Technical Highlights
The output stage comprises 14 power transistors per channel, all mounted onto a massive copper rail which is temperature controlled for a constant quiescent cur- rent. The 711‘s impressive low level signal handling is reflected in its raw power de- livery. Current levels of 60A and more are readily attainable. -
Page 7: Safety Advice
foreign substances or liquidity have entered the 711 the 711 has seen rain the 711 seems to malfunction the 711 has fallen to the floor or the housing is damaged Page... -
Page 8: Scope Of Delivery
User manual Rear panel Mains (A) The stereoamplifier 711 does have no mains switch. As soon as connected with the mains it will be in operation mode OFF (<0.5W consumption) Input (B) Please use top grade audio cables. For longer connecting cables we suggest using the balanced inputs. - Page 9 Connect the LINK-In of the 711 with the LINK-Out of your soulution preamplifier. LINK-Out allows including further components in the LINK-network. Settings (E) The new setting gets activated after the 711 has been unplugged from the mains. Start-Mode OFF: The 711 remains in operation mode OFF...
-
Page 10: Front Panel
The power button defines the operating condition ON or OFF (red LEDs). In operat- ing condition OFF the loudspeaker terminals are muted. Mode (I) The mode button (de)activates the LINK function. The stereoamplifier 711 can al- ways be switched on/off via the front panel. Input (J) The input button defines the active input. -
Page 11: Protection Functions
711 has the following protection functions: Level limitation: For to high levels at the input of the stereoamplifier 711 the soft clip circuit is acti- vated. The activated soft clip circuit will distort the output signal significantly, the sonic performance is reduced. Please ensure that the input levels are within the limit of 1.8 Vrms. -
Page 12: Trouble Shooting
-CON Actions after the appearance of an error If you can not identify the error please disconnect the mains supply (before you dis- connect the stereoamplifier 711 has to be in operating condition OFF) and contact your soulution dealer. Page... -
Page 13: Warranty
The warranty is not transferable. The warranty is void if the stereoamplifier 711 has been subject to misuse, or negli- gence or has been modified, repaired or opened by a non authorised person without written authorisation of Spemot AG. -
Page 14: Specification
Specification Data Power rating Nominal rating 120V 1’800 Nominal rating 230V 2'300 2 x 150 Audio power rating @ 8 2 x 300 @ 4 2 x 600 @ 2 General data Standby / OFF <0.5 Idle ca. -
Page 15: Dimensions
Stereoamplifier 711 User manual Dimensions Page... - Page 18 Spemot AG Industriestrasse 70 CH-4657 Dulliken www.soulution-audio.com info@soulution-audio.com soulution nature of sound part.no. 92180...
