Summary of Contents for Soulution 755
- Page 1 Series 7 soulution nature of sound Phono-preamplifier 755 User manual...
- Page 3 Phono-Preamplifier User manual Dear client We are proud that you decided to go for a soulution product. You have acquired a phono-preamplifier with outstanding sonic performance which you will enjoy for many years. We understand your eagerness to get started but even though please study this manual step by step before you integrate the phono-preamplifier 755 in your High Fidelity system.
- Page 4 CE-Declaration of Conformity Spemot AG declares that this product is in conformance with the following direc- tives and standards: Low Voltage Directive 2006/95/EG (EN/IEC 60065:2002) Electromagnetic Compatibility 2004/108/EG (EN 55013:2001, EN 55020:2002, EN 61000-3-2:2006, EN61000-3-3:1995) FCC-Notice Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
-
Page 5: Table Of Contents
Connect the 755 with your turntables Cabling Connect all your components with the mains While manipulating with cables the 755 has to remain disconnected from the mains. Default values for all functions are programmed Settings No additional settings are required. -
Page 6: Highlights
Phono-stage (optional) The 755 phono-preamplifier provides a gain of +72 dB or +78dB (at 1 kHz) for the MC-inputs and +60 dB or +66dB (at 1 kHz) for the MM-input. The gain can be ad- justed individually per input. The phono amplifier works with an internal bandwidth of 1 MHz (-3 dB). -
Page 7: Phono-Preamplifier User Manual
(Cable losses are minimised). Power supply The phono-preamplifier 755 has two separate power supply units, one for the sup- ply of the audio section, another for the supply of the digital circuits. The stringent separation of the power supply units is amended with a multi stage filter network. -
Page 8: Safety Advice
Packing In order to omit condensation of water inside the 755, let it warm up within the packing. Please keep the original packing for future transports. Operation... -
Page 9: Scope Of Delivery
Rear panel Mains (A) Connect the phono-preamplifier 755 with the mains supply. In standby the 755 has a power consumption of <0.5W (red LEDs in display). Only switch-off the mains if your phono-preamplifier 755 is in standby. MC-inputs IN 1/IN 2 (B) Connect your turntables with MC-cartridges to input IN1 or IN2. - Page 10 The phono-preamplifier 755 can control the start-up sequence of soulution compo- nents connected through the LINK System (cable: CAT 5, RJ45). The phono-preamplifier 755 will trigger the switch on of connected components. It will remain protected until all connected components are switched on. The display shows LINK ERROR if a connected component does not switch on.
-
Page 11: Front Panel
Display in standby (OFF) Display for PROTECT ON Display for ON condition We suggest switching the 755 to standby (OFF) while not listening to music. (Power consumption <0.5 W). Unplug the 755 from the mains before you manipulate with cables, before cleaning, during thunder storms or before you leave for longer periods. - Page 12 Prog (J) The phono-preamplifier 755 can be adjusted to specific requirements of your sys- tem. The Prog-button (de)activates the Programming-Mode. Volume (L) Volume +/- Mute min. volume 80 = max. volume We suggest limiting the volume (Volume-Max function)
-
Page 13: Program-Mode
Phono-Preamplifier User manual Program-Mode Overview The available Program-Functions allow adjusting the phono-preamplifier 755 to your individual High-Fidelity setup. Push on the Prog button switches the phono-preamplifier 755 between operating-mode and Program-Mode. Timeout after 10 seconds. Rotating of the Select knob allows selecting the desired... - Page 14 Program-Functions Function Values Remarks IN 1, IN 2, Defines the active in put after IN 3 switch-on ON, OFF (De)activates the volume control function. 1..30..50 Defines the volume after switch-on. 1..20..40 Defines the DIM-volume. 50...80 Defines the MAX-volume.
- Page 15 Phono-Preamplifier User manual Function Values Remarks MC: 72…78dB Defines the gain for each input. MM: 60…66dB ON, OFF (De)activates the RIAA-IEC high pass filter. ON, OFF ((De)activates Mono-mode. = disconnected (De)activates Ground-Lift for the unbal- OFF = connected anced output. 1 = low Adjusts the brightness of the display.
-
Page 16: Remote Control
Remote control Button Pre-Modus CD-Modus IR-transmitter Operation until 5m distance and angel of ±45°. (2,3) Volume +/- DIM / Volume-Dim Play/Pause (5/6) Select +/- Next / Previous track Enter Function for Program-Mode... -
Page 17: Safety Functions
Transport damages are not subject to this guarantee, repairs will be charged. We recommend effecting transport insurance. If you do not have the original packaging no more please contact your soulution dealer. Basic repairs may be completed by your soulution dealer. Please clarify whether he is able to do the work before you send the product back to us. -
Page 18: Trouble Shooting
If you con not identify the error please disconnect the mains supply (before you dis- connect the phono-preamplifier 755 has to be in operating condition OFF) and con- tact your soulution dealer. -
Page 19: Specifications
Phono-Preamplifier User manual Specifications Data General Nominal voltage Model 220-240V 220 - 240 V, 50-60 Hz Model 100–120V 100 – 120 V, 50-60 Hz Nominal rating 250 W Power consumption (OFF) <0.5 W Power consumption (ON) 60 W MC - inputs: IN 1 In 2 Voltage gain +72...+78 dB... -
Page 20: Dimensions
Dimensions page... - Page 22 Spemot AG Industriestrasse 70 CH-4657 Dulliken www.soulution-audio.com info@soulution-audio.com soulution nature of sound part.no. 92194...
