Summary of Contents for Soulution 701
- Page 1 Series 7 Monoamplifier 701 User manual...
- Page 3 We understand your eagerness to get started but even though please study this manual step by step before you integrate the monoamplifier 701 in your High Fidel- ity system. This manual contains also useful tips for the optimization of your overall HiFi-system.
- Page 4 CE-Declaration of Conformity Spemot AG declares that this product is in conformance with the following direc- tives and standards: Low Voltage Directive 2006/95/EG (EN/IEC 60065:2002) Electromagnetic 2004/108/EG (EN 55013:2001, EN 55020:2002, EN 61000-3- 2:2006, EN 61000-3-3:1995)
-
Page 5: Table Of Contents
Treat the high quality surface with care Position the monoamplifier 701 on a stable base Positioning Do not put the 701 in a closed cabinet, at least two sides must be open for unrestricted airflow Disconnect all components of your system from the mains ... -
Page 6: Technical Highlights
The ideal amplifier is perfectly load stable and 100% level and phase accurate. The monoamplifier 701 is closest of all to this ideal. It is capable to output up to 1’200W of continuous power (into 4Ω) and more than 12,000W of transient power. -
Page 7: Safety Advice
foreign substances or liquidity have entered the 701 the 701 has seen rain the 701 seems to malfunction the 701 has fallen to the floor or the housing is damaged Page... -
Page 8: Scope Of Delivery
User manual Rear panel Mains (A) The monoamplifier 701 does have no mains switch. As soon as connected with the mains it will be in operation mode OFF (<0.5W) Input (B) Please use top grade audio cables. For longer connecting cables we suggest using the balanced inputs. - Page 9 Connect the LINK-In of the 701 with the LINK-Out of your soulution preamplifier. LINK-Out allows including further components in the LINK-network. Settings (G) The new setting gets activated after the 701 has been unplugged from the mains. Start-Mode OFF: The 701 remains in operation mode OFF...
-
Page 10: Front Panel
The power button defines the operating condition ON or OFF (red LEDs). In operat- ing condition OFF the loudspeaker terminals are muted. Mode (K) The mode button (de)activates the LINK function. The monoamplifier 701 can al- ways be switched on/off via the front panel. Input (L) The input button defines the active input. -
Page 11: Protection Functions
701 has the following protection functions: Level limitation: For to high levels at the input of the monoamplifier 701 the soft clip circuit is acti- vated. The activated soft clip circuit will distort the output signal significantly, the sonic performance is reduced. Please ensure that the input levels are within the limit of 1.8 Vrms. -
Page 12: Trouble Shooting
The communication to the audio channels is broken -CON Actions after the appearance of an error If you cannot identify the error please disconnect the mains supply (before you dis- connect the monoamplifier 701 has to be in operating condition OFF) and contact your soulution dealer. Page... -
Page 13: Warranty
The warranty is not transferable. The warranty is void if the monoamplifier 701 has been subject to misuse, or negli- gence or has been modified, repaired or opened by a non-authorised person without written authorisation of Spemot AG. -
Page 14: Specification
Specification Dual Mono Power rating 2 x 150 W 600 W Audio power rating @ 8 2 x 300 W 1’200 W @ 4 2 x 600 W 2’000 W @ 2 General data Standby / OFF <0.5 W... -
Page 15: Dimensions
Monoamplifier 701 User manual Dimensions Page... - Page 18 Spemot AG Industriestrasse 70 CH-4657 Dulliken www.soulution-audio.com info@soulution-audio.com part.no. 92178...
