GETTING STARTED - USING YOUR 900 SERIES™
Your 900 Series™ Fishing System user interface is easy to use. A combination of keys,
different views, and situation-specific, customizable menus allows you to control what
you see on the color display. Refer to the following illustration, and see Key Functions,
Views, and The Menu System for more information.
1
1
Screen
2 MMC/SD Card Slot
3
ZOOM (+/-) Key
4 POWER/LIGHT Key
5
INFO Key
6 MARK/GOTO Key
7:53 PM Page 28
11
9
10 8
7
5
3
6
4
2
7
4-WAY Cursor Control Key
MENU Key 8
9
VIEW Key
EXIT Key 10
11
VIEW PRESET Keys

POWERING UP THE CONTROL HEAD

Turn on your 900 Series™ control head by pressing the POWER key. The Title screen is
displayed until the 900 Series™ begins operation. Your 900 series™ will begin Normal
or Simulator operation, depending on the presence or absence of a transducer.
900 Series™ 947c 3D Combo Title Screen
23
