Humminbird 747c Operation Manual page 5

531526-1_A - 747c_&_777c2_Man_Eng.qxp
Table of Contents
Units - Distance (with Temp/Speed or GPS receiver) .............................................................. 60
Units - Speed (with Temp/Speed or GPS receiver) .................................................................. 61
User Mode................................................................................................................................ 61
Language (International only) .................................................................................................. 61
Triplog Reset (with Temp/Speed or GPS receiver) .................................................................. 62
Restore Defaults ...................................................................................................................... 62
Select Readouts (Advanced, Sonar view only) ........................................................................ 63
Depth Offset (Advanced) .......................................................................................................... 65
Aux. Temp. Offset (Advanced; with optional-purchase temp. probe or Temp/Speed only) ........ 65
Temp Offset (Advanced) .......................................................................................................... 66
Speed Calibration (Advanced, with Temp/Speed only) .......................................................... 66
Digits Format (Advanced) ........................................................................................................ 67
NMEA Output (Advanced)........................................................................................................ 68
Views Menu Tab
Accessories Menu Tab
Troubleshooting
700 Series™ Doesn't Power Up .............................................................................................. 71
700 Series™ Defaults to Simulator with a Transducer Attached ........................................ 71
Display Problems...................................................................................................................... 72
Finding the Cause of Noise .................................................................................................... 73
700 Series™ Fishing System Accessories
Specifications
Glossary
Contact Humminbird®
NOTE: Entries in this Table of Contents which list (International only) are only available on
products sold outside of the US by our authorized International Distributors. To obtain a list
of authorized International Distributors, please visit our website at www.humminbird.com
or contact our Customer Resource Center at 1-800-633-1468 to locate the distributor
nearest you.
NOTE: Entries in this Table of Contents which list (with Temp/Speed or GPS Receiver), or
(with PC Connect Cable Only) require the purchase of separate accessories. You can visit our
website at www.humminbird.com to order these accessories online or contact our
Customer Resource Center at 1-800-633-1468.
10/2/2006
iv
1:40 AM Page 5
69
70
71
74
77
79
91
