Scientific Atlanta ER1 User Manual

Model ER1

Remote Control

User's Guide
POWER
TV
SELECT
A B C
2
1 3
5
4 6
8
7 9
A
0
C
ER1 Remote Control Quick Reference
27
26
25
24
23
22
21
20
19
18
17
16
15
T8101

Inserting the Batteries

Procedure
Your remote control requires two AA
alkaline batteries.
CAUTION:
Make sure you correctly align
the positive (+) and negative (-)
terminals on the batteries to the
corresponding terminals in the
remote control.
Power
1 DHCT on or off
1
VCR on or off
25
2
TV on or off
26
3
27 LED
4
Sound
5
6
Mutes sound
22
7
Adjusts volume
20
8
Device Control
9
Switches control between
13
your VCR and Video On
10
Demand (VOD) program
11
Controls your VCR's
14
12
TV/VCR function.
13
Controls the BYPASS
15
option (See Optional
14
Bypass Feature)
1. Press forward then lift up on the lever
on the back cover of the remote control.
The battery cover releases, and you can
pull the cover up to remove it.

Controlling Volume

To Program for Volume Control
You can program the remote control to
control the volume and mute functions
through the EXPLORER 2000 DHCT, or
through your TV. The default is
through the TV.
1. Point the remote control away from
the EXPLORER 2000 DHCT, the TV,
and the VCR.
2. Press and hold the CBL key and the
SELECT key at the same time, until
the LED on the remote control
blinks twice.
3. Using the remote control keypad,
enter 993. The LED on the remote
blinks twice.
4. Press the TV key or the CBL key,
depending on which device you
want to control the volume. The
LED on the remote control blinks
twice to confirm a valid selection.
5. Point the remote toward the device
on which you chose to control the
volume, and adjust the volume to
confirm operation.
Record of Codes
Record your setup codes
in the following table.
TV
VCR
CBL
Channels
Displays channel
2
information
Selects channels, up or
6
down
Enter channel numbers
8
(also used to enter your
personal identification
number [PIN] for
parental control)
Views favorite channels
9
Returns to last channel
19
viewed
VCR/VOD
Fast forwards VCR/VOD
10
Records VCR program
11
Stops VCR/VOD
12
Rewinds VCR/VOD
18
Plays VCR/VOD
16
Pauses VCR/VOD
17
2. Remove and safely dispose of the old
batteries.
T6434

Identifying Codes

To Identify Programmed Codes
You can find out which code you used to
program your TV or VCR. You can
determine the code by counting the
number of times the LED blinks during the
following procedure.
1. Point the remote control away from the
EXPLORER 2000 DHCT , the TV, and
the VCR.
2. Do one of the following:
• To identify the TV code, press and
hold the TV key and the SELECT
key at the same time until the LED
on the remote control blinks twice,
or
• To identify the VCR code, press and
hold the VCR key and the SELECT
key at the same time until the LED
on the remote control blinks twice.
3. Using the remote control keypad, enter
990. The LED on the remote blinks
twice.
4. Press 1 on the keypad; then, count the
LED blinks. The number of blinks
indicates the first number in the code.
For example, 4 blinks indicates the first
number in the code is 4. If the LED
does not blink, the digit is 0 (zero).
5. Press 2 on the keypad; then, count the
LED blinks. The number of blinks
indicates the second number in the
code.
6. Press 3 on the keypad; then, count the
LED blinks. The number of blinks
indicates the third number in the code.
7. Write down the code in the table
provided for future reference.
Screens
Pages Up/Pages Down
3
Hides interactive screen
4
Makes on-screen
7
decisions
Displays interactive
24
program guide
Displays DHCT settings
23
Moves through interactive
5
screen choices
Chooses interactive
21
screen item
Notes:
• Program the remote control
before you use the DHCT. See
Programming the Remote
Control for programming
procedures.
• Make sure you use only alkaline
batteries in the remote control. See
Inserting the Batteries for more
information.
3. Insert and firmly seat two new AA
batteries (alkaline required) into the
battery compartment.
4. Slide the front of the battery cover back
onto the remote control and snap
the back of the cover into place.
T6435
