Page 1: Service Manual
Service Manual Model : iDP-3540/3541 Rev. Issued Japan CBM Corporation Information Systems Div. - Page 2 Service Manual Contents 1. Disassembly and Assembly..........................3 2. Parts List................................9 3. Circuit Diagram............................. 34 CITIZEN...
- Page 3 Service Manual 1. Disassembly and Assembly CITIZEN...
- Page 4 Service Manual 1. How to remove the Upper Cover 1) Remove the Printer Cover 2) Unfasten 4 screws as shown in the figure and lift the Upper Cover CITIZEN...
- Page 5 Service Manual 2. How to remove the Printer Mechanism and the Printer Unit 2-1. How to remove the Printer Mechanism 1) Remove the Printer Cover 2) Remove the Upper Cover 3) Disconnect each connectors 4) Unfasten 2 screws as shown in the figure 5) Lift the Printer Mechanism in the arrow position for removal 2-2.
- Page 6 Service Manual 3. How to remove the Control Board 1) Remove the Printer Cover 2) Disconnect each connectors 3) Unfasten 2 screws on the Shield Plate mounting screw to remove the Shield Plate Serial Interface Board 1) Unfasten 2 screws to remove the interface board...
- Page 7 Service Manual 4. How to remove the Power Supply Unit 1) Remove the Printer Unit and the Control Board 2) Remove the AC Cord from the Chassis 3) Unfasten the 2 screws called the Power Supply mounting screws 4) Unfasten the screw called the Head Sink mounting screw...
- Page 8 Service Manual 5. How to remove the PE Switch 1) Remove the Printer Unit and the Printer Mechanism 2) Remove the connector from the Control Board 3) Push the jointing parts in the direction of the arrow and remove the jointing parts from the Chassis.
- Page 9 Service Manual 2. Parts List CITIZEN...
- Page 10 Service Manual PARTS LIST EXPLODED VIEW iDP3540 / 3541-PF / RF / XF Symbol Parts No. Description Q'ty iDP3540 iDP3541 E 4002-370 Chassis <- <- E 4002-320 Stand, Transformer <- <- E 6601-220 Printer Support <- <- E 4035-640 Plate, Ground <-...
- Page 11 Service Manual PARTS LIST EXPLODED VIEW iDP3540 / 3541-PF / RF / XF Symbol Parts No. Description iDP3540 iDP3541 Q'ty E 6600- Printer DP-610DFC <1> E 6600- Printer DP-612DFC <1> E 6600- Printer DP-614DFC <1> E 6600- Printer DP-610MPC <1>...
- Page 12 Service Manual iDP-3540/3541 (1) CITIZEN...
- Page 13 Service Manual iDP-3540/3541 (2) CITIZEN...
- Page 14 Service Manual PARTS LIST POWER SUPPLY UNIT iDP3540 / 3541-PF / RF / XF Q'ty Symbol Parts No. Description 120V 220-240V PC Board E 4006-220 Fuse Holder UF-0033#01 <- <- F 1, 3 E 4005-475 Fuse 5MF1 <- E 4005-470...
- Page 15 Service Manual PARTS LIST POWER SUPPLY UNIT iDP3540 / 3541-PF / RF / XF Q'ty Symbol Parts No. Description 120V 220-240V E 3331-041 Resistor 1 / 4W <- <- E 3561-041 Resistor 1 / 4W <- <- E 3223-100...
- Page 16 Service Manual CITIZEN...
- Page 17 Service Manual CITIZEN...
- Page 18 Service Manual PARTS LIST MAIN CONTROL BOARD UNIT iDP3540-PF / RF / XF Symbol Parts No. Description Q'ty iDP3540 iDP3540 iDP3540 PC Board <- <- E 4002-360 Blind Plate <- E 4010-360 Heatsink <- <- PC Board <- E 48000285 D-Sub Connector Holder <-...
- Page 19 Service Manual PARTS LIST MAIN CONTROL BOARD UNIT iDP3540-PF / RF / XF Symbol Parts No. Description Q'ty iDP3540 iDP3540 iDP3540 E 501-150 X'tal SA7.37MT40 <- <- <- E 48000260 Connector B5P-SHF-1 <- <- <- E 4800-690 Connector 5267-02A <-...
- Page 20 Service Manual PARTS LIST MAIN CONTROL BOARD UNIT iDP3540-PF / RF / XF Symbol Parts No. Description Q'ty iDP3540 iDP3540 iDP3540 E 403-061 Zener Diode RD3.OEL1 <- <- <- D 5, 7 E 400-041 Diode 1S2076 <- LED1, 2...
- Page 21 Service Manual PARTS LIST MAIN CONTROL BOARD UNIT iDP3540-PF / RF / XF Symbol Parts No. Description Q'ty iDP3540 iDP3540 iDP3540 E 2110-805 C. Cap. DD306-979F104Z25 <- 19-25 E 2010-725 El. Cap. 100uF / 25 <- <- <- E 2047-630 El.
- Page 22 Service Manual PARTS LIST MAIN CONTROL BOARD UNIT iDP3540-PF / RF / XF Symbol Parts No. Description Q'ty iDP3540 iDP3540 iDP3540 E 3105-041 1 / 4W <- <- <- 16, 17 E 3331-041 1 / 4W <- <- <- E 3152-020 Me.
- Page 23 Service Manual CITIZEN...
- Page 24 Service Manual CITIZEN...
- Page 25 Service Manual CITIZEN...
- Page 26 Service Manual PARTS LIST MAIN CONTROL BOARD UNIT iDP3541-PF / RF / XF Symbol Parts No. Description Q'ty iDP3541 iDP3541 iDP3541 E 48000260 Connector B5P-SHF-1 <- <- <- E 4800-690 Connector 5267-02A <- <- <- 3, 6, 7 E 48000265...
- Page 27 Service Manual PARTS LIST MAIN CONTROL BOARD UNIT iDP3541-PF / RF / XF Symbol Parts No. Description Q'ty iDP3541 iDP3541 iDP3541 E 501-150 X'tal CSA 7.3MT40 <- <- <- D 1-4 E 400-200 Diode MPG06D-G3 <- <- <- E 400-041 Diode 1S2076 <-...
- Page 28 Service Manual PARTS LIST MAIN CONTROL BOARD UNIT iDP3541-PF / RF / XF Symbol Parts No. Description Q'ty iDP3541 iDP3541 iDP3541 E 2110-810 C. Cap. DD003-298B102K50 <- 11,12 15,34 10,14 E 2110-815 C. Cap. DD003-298F103Z50 <- <- <- E 2110-805 C.
- Page 29 Service Manual PARTS LIST MAIN CONTROL BOARD UNIT iDP3541-PF / RF / XF Symbol Parts No. Description Q'ty iDP3541 iDP3541 iDP3541 E 3473-041 1 / 4W 47 K <- <- 6,44 E 3473-041 1 / 4W 47 K <-...
- Page 30 Service Manual PARTS LIST MAIN CONTROL BOARD UNIT iDP3541-PF / RF / XF Symbol Parts No. Description Q'ty iDP3541 iDP3541 iDP3541 PC Board <1> <- <- E 4002-360 Blind Plate <- E 4010-360 Heatsink <- <- PC Board <1>...
- Page 31 Service Manual CITIZEN...
- Page 32 Service Manual CITIZEN...
- Page 33 Service Manual CITIZEN...
- Page 34 Service Manual 3. Circuit Diagram CITIZEN...
- Page 35 Service Manual CITIZEN...
- Page 36 Service Manual CITIZEN...
- Page 37 Service Manual CITIZEN...
- Page 38 Service Manual CITIZEN...
