Page 1: Digital Camera
Digital Camera User’s Guide Thank you for purchasing this CASIO product. • Before using it, be sure to read the precautions contained in this User’s Guide. • Keep the User’s Guide in a safe place for future reference. • For the most up-to-date information about this product, visit the official EXILIM...
Page 2: Accessories
Accessories As you unpack your camera, check to make sure that all accessories shown below are included. If anything is missing, contact your original retailer. Rechargeable lithium ion USB-AC adaptor battery (NP-130A) (AD-C54UG/AD-C53U) Power cord Micro USB cable Basic Reference Neck strap Lens cap The type of USB-AC adaptor included varies according to the country or...
Page 3: Attaching And Removing The Lens Cap
Attaching and Removing the Lens Cap The lens cap opens and closes Mark automatically in accordance with the lens position, so you can leave it in place, if you want. Make sure the lens cap is attached to the lens so the dot mark on the cap is upwards, with the Removal large blades of the cap on the left and...
Page 4: Read This First
CASIO COMPUTER CO., LTD. is forbidden under copyright laws. • CASIO COMPUTER CO., LTD. shall not be held liable for any damages or lost profits suffered by you or any third party due to the use or malfunction of this product.
Page 5: Table Of Contents
Quick Start Basics What you can do with your CASIO camera ......17 Tilting the Monitor Screen ........19 Using the Stand .
Page 6 Zooming with Super Resolution ......(Zoom (SR)) . . . 62 Expanding the Zoom Range to Shoot Clearer Snapshots . (Multi SR Zoom) . . . 63 Shooting with Bracketing .
Page 7 Saving a Second Normal Image When Shooting with HDR Art ..... . . (Double (HDR ART)) . 108 Configuring Handsfree Settings ..... . . (Handsfree) . 108 Configuring Motion Position Settings .
Page 8 Changing Available Image Menu Options ..(Image Menu Options) . . 136 Viewing Snapshots and Movies on a TV Screen ..... . 137 Other Playback Functions (PLAY MENU) 139 Assigning a Function to the Front Shutter Button .
Page 9 Printing Printing Snapshots..........166 Connecting Directly to a PictBridge Compatible Printer .
Page 10 Appendix Safety Precautions..........195 Precautions During Use.
Page 11: General Guide
General Guide The numbers in parentheses indicate the pages where each item is explained. Front Back cl ck bt Mode dial Front shutter button [MENU] button (pages 34, 42, 78) (pages 106, 139, 160) (pages 78, 104) Zoom controller Microphones (page 79) [p] (PLAY) button (pages 35, 58, 135) [0] (Movie) button...
Page 12: Control Dial
Bottom Battery/memory card slots (pages 22, 30) Battery cover Tripod hole Use this hole when attaching to a tripod. . Control Dial In addition to using the up, down, left, and right buttons, you can also use the control dial to perform operations. •...
Page 13: Monitor Screen Contents And How To Change Them
Monitor Screen Contents and How to Change Them The monitor screen uses various indicators, icons, and values to keep you informed of the camera’s status. • The sample screens in this section are intended to show you the locations of all the indicators and figures that can appear on the monitor screen in various modes.
Page 14: Movie Recording
. Snapshot Recording (Burst Shooting) Continuous Shutter (CS) speed (page 65) Recording mode (page 34) Remaining snapshot memory capacity (page 222) Allowable CS time/number of CS images (page 65) Remaining movie memory capacity (page 223) Continuous Shutter mode (page 65) Prerecord CS shots (page 66) Maximum CS shots (page 65) .
Page 15 . Snapshot Viewing Snapshot image quality (page 111) Recording mode (page 34) ND Filter (page 108) Histogram (page 122) Front shutter button function (page 106) Wireless LAN connection status (pages 162, 163) Date/time (page 191) Metering mode (page 57) White balance (page 146) Battery level indicator (page 27) Flash (page 55) File type...
Page 16: Movie Playback
. Movie Playback No audio data available Movie recording time (page 126) Recording mode/Movie quality/speed (pages 78, 81, 81) . Configuring Monitor Screen Settings Each press of [8] (DISP) will cycle through display settings that display or hide on-screen information. You can configure separate settings for the REC mode and PLAY mode.
Page 17: Quick Start Basics
Quick Start Basics What you can do with your CASIO camera Your CASIO camera is packed with a powerful selection of features and functions to make recording of digital images easier, including the following main functions. Intelligent Bracketing You can use this function to shoot a series of images, slightly changing the camera setup with each shot.
Page 18 ART SHOT A variety of artistic effects help to make even common, ordinary subjects become more novel and exciting. “ART SHOT” provides the following effects: HDR Art, Toy Camera, Soft Focus, Light Tone, Pop, Sepia, Monochrome, Miniature, Fisheye, Sparkling Shot, Crystal ball.
Page 19: Tilting The Monitor Screen
Tilting the Monitor Screen The monitor screen can be tilted upwards up to 180 degrees or downwards up to 55 degrees. . Tilting the Monitor Screen As shown in the illustration, you can tilt the monitor screen by opening it from the bottom or from the top.
Page 20 . Returning the Monitor Screen to Its Normal Position Hold the bottom of the monitor screen and rotate it, or press the top of the monitor screen to return it to its normal position. Slide the monitor screen up as far as it will go. .
Page 21: Using The Stand
Low-angle shots High-angle shots The tilt angle of the monitor screen can You can tilt the monitor screen in a way be adjusted for each composition of that allows you to shoot from high angles. images from various low angles. Using the Stand Your camera has a built-in stand.
Page 22: First, Charge The Battery Prior To Use
Note that the battery of a newly purchased camera is not charged. Perform the steps below to load the battery into the camera and charge it. • Your camera requires a special CASIO rechargeable lithium ion battery (NP-130A) for power. Never try to use any other type of battery.
Page 23: Charge The Battery
To replace the battery Stopper Open the battery cover and remove the current battery. Load a new battery. Charge the Battery You can use either of the two following methods to charge the camera’s battery. • USB-AC adaptor • USB connection to a computer (Using the included micro USB cable.) .
Page 24 IMPORTANT! • A battery that has not been used for a long time, or ambient temperature extremes can cause charging to take longer than normal. If charging takes longer than about five hours, a timer will terminate it automatically, even if the battery is not fully charged.
Page 25 . To charge using a USB connection to a computer USB connection lets you charge the battery while it is loaded in the camera. While the camera is turned off, connect in the sequence shown below ( Computer (power turned on) USB port [USB] port Micro USB cable...
Page 26 Back Lamp Operation Lamp Status Description Lit Red, Charging (Lit/Flashing Amber) Abnormal ambient temperature, Flashing Red charging taking abnormally long, or battery problem (page 208) Back lamp Off, (Lit Green) Charging complete • The information in parentheses in the above table shows the lamp status while the camera is turned on during charging.
Page 27: Configuring Basic Settings The First Time You Turn On The Camera
Checking Remaining Battery Power As battery power is consumed, a battery indicator on the monitor screen indicates remaining power as shown below. Remaining Power High Battery Indicator Indicator Color White * White indicates battery power is low. Charge the battery as soon as possible. Recording is not possible when is indicated.
Page 28 Press [ON/OFF] (Power) to turn on the [ON/OFF] (Power) camera. Use [8], [2], [4], and [6] to select the language you want and then press [SET]. Use [8] and [2] to select a date style and then press [SET]. Example: July 10, 2015 YY/MM/DD 15/7/10 DD/MM/YY...
Page 29: Preparing A Memory Card
Ultra High Speed Type SD memory card is recommended. Note, however that CASIO makes no guarantees about the operation of any Ultra High Speed Type SD memory card used with this camera.
Page 30: To Load A Memory Card
• Never insert anything besides a supported memory card (page 29) into the memory card slot. • Should water or any foreign object ever get into the card slot, immediately turn off the camera, remove the battery, and contact your retailer or nearest CASIO authorized service center. Quick Start Basics...
Page 31: To Format (Initialize) A New Memory Card
To replace the memory card Press the memory card and then release it. This will cause it to pop out of the memory card slot slightly. Pull the card out the rest of the way and then insert another one. •...
Page 32: Turning The Camera On And Off
Turning the Camera On and Off . To turn power on Pressing [ON/OFF] (Power) enters the [ON/OFF] (Power) REC mode so you can record images. Pressing [p] (PLAY) while in the REC Shutter button mode enters the PLAY mode, which you can use to view snapshots and movies (pages 38, 126).
Page 33: Holding The Camera Correctly
Holding the Camera Correctly Your images will not come out Horizontal Vertical clearly if you move the camera when you press the shutter button. When pressing the shutter button, be sure to hold the camera as shown in the illustration, and keep it still by pressing your arms firmly against your sides as you shoot.
Page 34: To Shoot A Snapshot
To shoot a snapshot Selecting an Auto Recording Mode You can select one of two auto recording modes (Program Auto or Premium Auto Pro) according to your digital imaging needs. REC Screen Setting Description Icon Display Program This is the standard Auto recording mode. Auto With Premium Auto Pro recording, the camera automatically determines whether you are shooting a...
Page 35: To Shoot A Snapshot
To shoot a snapshot Point the camera at the subject. If you are shooting with Premium Auto Pro, text will appear at the bottom of the monitor screen describing the type of shot the camera has detected. • You can zoom the image, if you want. Appears when the camera detects it is stationary on a tripod.
Page 36: Shooting With Auto
Continuing to keep the camera Full-press still, press the shutter button the Press all the rest of the way down. way. This records the snapshot. • With the initial factory default configuration of the camera when you purchase it, pressing the front shutter button will shoot a snapshot Snap (Image is recorded.) (page 106).
Page 37 . Shooting with Premium Auto Pro • Some menu items are not available while Premium Auto Pro is in use (page 104). Only the menu items whose settings can be configured will be displayed on the menus while Premium Auto Pro is in use. •...
Page 38: Viewing Snapshots
Viewing Snapshots Use the following procedure to view snapshots on the camera’s monitor screen. • For information about how to play back movies, see page 126. • For information about images recorded using continuous shutter (CS), see page 128. Turn on the camera and press [p] (PLAY) to enter the PLAY mode.
Page 39: Deleting Snapshots And Movies
Deleting Snapshots and Movies If memory becomes full, you can delete snapshots and movies you no longer need in order to free up storage and record more images. IMPORTANT! • Remember that a file (image) delete operation cannot be undone. •...
Page 40: Snapshot Shooting Precautions
Use [ ] and [2] to select “Yes” and then press [SET]. • This deletes the files you selected. • To cancel the delete operation, select “No” in step 5 and then press [SET]. . To delete all files Press [p] (PLAY) to enter the PLAY mode and then press [2] ( Use [8] and [2] to select “Delete All Files”...
Page 41: Auto Focus Restrictions
. Auto Focus Restrictions • Any of the following can make proper focus impossible. – Solid color wall or other very low contrast subject – Strongly back lit subject – Very shiny subject – Blinds or other subject with a repeating horizontal pattern –...
Page 42: Snapshot Tutorial
Snapshot Tutorial Selecting the Recording Mode Your camera has a variety of different recording Mode dial modes. Before recording an image, rotate the mode dial to select the recording mode that suits the type of image you are trying to record. P Program Auto Standard Auto recording mode.
Page 43 M M (Manual Exposure) mode This mode gives you total control over aperture and shutter speed settings. Press [SET] to open the Control Panel. Use [8] and [2] to select (Aperture), and then press [SET]. Use [8] and [2] to change the aperture setting, and then press [4]. Use [8] and [2] to select (Shutter Speed), and then press [SET].
Page 44: Using The Control Panel
Using the Control Panel The Control Panel can be used to configure camera [8] [2] [4] [6] settings. In the REC mode, press [SET]. [SET] • You can also display the Control Panel by pressing [2]. Use [8] and [2] to select the setting you want to change, and then press [SET].
Page 45: Configuring Camera Settings With The Function Ring
Configuring Camera Settings with the Function Ring Control Panel and menu item functions can be assigned to the function ring. After that, camera settings can be easily configured by rotating the function ring. Functions that can be assigned to the function ring depend on the recording mode. [RING] Function ring .
Page 46: Using The Self-Timer
Using the Self-timer (Self-timer) With the Self-timer, pressing the shutter button starts a timer. The shutter is released and the image is shot after a fixed amount of time. In the REC mode, press [SET]. Use [8] and [2] to select the (Self-timer) Control Panel option, and then press [SET].
Page 47: Adjusting White Balance
NOTE • The Self-timer cannot be used together with the following features. High Speed CS with Prerecord CS, Prerecord (Movie), Slide Panorama, Wide Shot, Triple Shot • The Triple Self-timer cannot be used together with the following features. Movie, Time Lapse, High Speed CS, Multi SR Zoom, HS Night Shot, HS Best Selection, Blurred Background, All-In-Focus Macro, Intelligent Bracketing •...
Page 48 REC Screen Setting Description Icon Display Tungsten For shooting under light bulb lighting « For configuring the camera manually to suit a particular light source Select “Manual WB”. Blank white paper Under the lighting conditions you plan to use when shooting, point ·...
Page 49: Selecting A Focus Mode
Selecting a Focus Mode (Focus) • The “Focus” setting is always fixed at “AF” (Auto Focus) whenever “Face Detection” (page 116) is being used. If you want to change the “Focus” setting, first select “Off” for “Face Detection”. In the REC mode, press [SET]. Use [8] and [2] to select the (Focus) Control Panel option, and then press [SET].
Page 50: Super Macro
Super Macro Super Macro fixes optical zoom at a position that allows you to shoot from the closest distance to the subject. The result is closer and larger subject images. NOTE • Zoom is fixed while Super Macro is selected, so no zoom operation is performed when you rotate the zoom controller.
Page 51: Specifying Iso Sensitivity
Using Focus Lock Subject to be focused on “Focus lock” is a technique you can use when you want to compose an image in which the subject you want to focus on is not within the focus frame in the center of the screen.
Page 52 Use [8] and [2] to select the setting you want and then press [SET]. REC Screen Setting Description Icon Display Adjusts sensitivity automatically according to Auto None conditions. ISO80 Lower Slow shutter speed Less noise sensitivity ISO100 ISO200 ISO400 ISO800 ISO1600 ISO3200 Some coarseness...
Page 53: Recording Beautiful Portraits
Recording Beautiful Portraits (Make-up Level) The Make-up Function smoothes the skin texture of the subject and softens facial shadows caused by harsh sunlight for better looking portraits. You can select a make- up level within the range of “0 (Off)” to “+12 (Max.)”. Enter the REC mode, and then press [SET].
Page 54: Correcting Image Brightness
Correcting Image Brightness (EV Shift) You can manually adjust an image’s exposure value (EV value) before shooting it. • Exposure Compensation Range: –2.0 EV to +2.0 EV • Unit: 1/3EV In the REC mode, press [SET]. Use [8] and [2] to select the (EV Shift) Control Panel option, and then press [SET].
Page 55: Using Flash
Using Flash (Flash) When flash is required, the flash unit will pop up automatically when you half-press the shutter button. In the REC mode, press [2] ( Flash once. Use [8] and [2] to select the flash setting you want and then [2] ( press [SET].
Page 56 Press the shutter button to shoot all the way down. Back lamp Flashes amber while the flash is charging to indicate that image recording is disabled. • You will not be able to take another flash snapshot until the lamp stops flashing amber, which indicates that charging is complete.
Page 57: Specifying The Metering Mode
Red-eye Reduction Using the flash to shoot at night or in a dimly lit room can cause red spots inside the eyes of people who are in the image. This is caused when the light from the flash reflects off of the retina of the eye. When red-eye reduction is selected as the flash mode, the camera fires a pre-flash to cause the irises in the eyes of any people in the image to close, which reduces the chance of red eye.
Page 58: Shooting With Zoom
Shooting with Zoom Your camera is equipped with various types of zoom: optical zoom, HD Zoom, Single SR Zoom, Multi SR Zoom, and digital zoom. The maximum zoom factor depends on the image size setting and the digital zoom on/off settings. Zooming is performed by changing the lens focal distance, so Optical zoom there is no deterioration of image quality.
Page 59 NOTE • Use of a tripod is recommended to protect against image blur due to camera movement when shooting with telephoto. • Performing a zoom operation changes the lens aperture. • Zoom operations are supported during movie recording. Zoom operations are disabled during high speed movie recording.
Page 60: Monitor Screen Information When Zooming
Monitor Screen Information when Zooming A variety of information is shown on the monitor screen while a zoom operation is in progress. . Zoom Mode Icons Zoom mode Focal distance (Converted to 35 mm film Focusing Range format.) (Displayed for Auto Focus, Macro Focus, and Manual Focus.) Image quality limit...
Page 61: Interpreting The Zoom Bar
. Interpreting the Zoom Bar During a zoom operation, a zoom bar appears on the monitor screen to show the current zoom setting. Range where image deterioration is Deteriorated image range suppressed. Wide Angle Telephoto Zoom pointer Optical zoom limit point (Indicates current zoom.) Point from which image deteriorates •...
Page 62: Zooming With Super Resolution
Zooming with Super Resolution (Zoom (SR)) There are two types of Super Resolution Zoom: Single SR Zoom and Multi SR Zoom. Single SR Zoom uses super resolution to expand the zoom range in which image quality deterioration is minimized. Multi SR Zoom shoots a series of High Speed CS images, which are then combined into an image that enables shooting at higher zoom ratios without loss of image quality.
Page 63: Expanding The Zoom Range To Shoot Clearer Snapshots (Multi Sr Zoom)
Expanding the Zoom Range to Shoot Clearer Snapshots (Multi SR Zoom) This feature uses super resolution technology and multiple Continuous Shutter (CS) images to expand the zoom range for overall images of higher quality and clarity. In the BEST SHOT Mode, select “Multi SR Zoom” (page 89). Press the shutter button to shoot.
Page 64 Adjust the shooting setup as you like. [4] and [6] keys, or Adjusts the horizontal axis function ring bracket setting. [8] and [2] keys, or Adjusts the vertical axis control dial bracket setting. • With scenes 5 through 12, you can adjust the horizontal axis setting only.
Page 65: Shooting A Burst Of Images
Shooting a Burst of Images (CS) Shooting with High Speed CS With High Speed CS, recording continues as long as you CS speed keep the shutter button depressed. The table below shows the settings that can be specified for the CS speed and the number of images per High Speed CS operation.
Page 66: Shooting With Prerecord Cs
Use [8] and [2] to select the (Maximum CS Shots) Control Panel option and then press [SET]. Use [8] and [2] to select the maximum number of shots and then press [SET]. Press the shutter button the rest of the way and hold it down. Shooting of images will continue as long as you depress the shutter button or until the maximum number of images specified by “High Speed CS fps”...
Page 67 Use [8] and [2] to select the continuous shutter (CS) speed you want and then press [4]. • Use a higher “High Speed CS fps” setting when shooting a fast-moving subject. Use [8] and [2] to select the (Maximum CS Shots) Control Panel option and then press [SET].
Page 68 NOTE • You can use any one of the following recording modes to shoot with AF CS: A (Aperture AE) mode, S (Shutter Speed AE) mode, M (Manual Exposure) mode. • The greater the number of shots, the longer it takes to save them after shooting is complete.
Page 69: Using Continuous Shutter With Auto Focus
Using Continuous Shutter with Auto Focus (AF CS) AF CS shoots up to 30 CS images while keeping the subject in focus. This feature comes in handy when shooting children and other fast-moving subjects. The CS speed is automatically adjusted in accordance with shooting conditions within the range of three to six frames per second.
Page 70: Triggering A Self-Timer Operation With Motion
Triggering a Self-timer Operation with Motion (Handsfree) With the Handsfree Mode, the camera automatically triggers a self-timer countdown whenever it detects movement in the vicinity of an icon on the monitor screen. This means you can control operation of the self-timer from a distance by waving your hand, so you can include yourself in the image being shot.
Page 71: Configuring Handsfree Mode Settings
• (preview icon) will appear on the monitor screen when a snapshot is shot. When the camera detects movement in the vicinity of the preview icon, it will display the image that was shot for three seconds. • “O Tracking” cannot be selected for the AF area setting while shooting with the Handsfree Mode.
Page 72: Repositioning The Motion Detection Area
Repositioning the Motion Detection Area (Motion Position) Use the procedure below to reposition the motion detection area (Start self-timer icon) as required when it (or the preview icon ) hinders your view of the display image. In the REC mode, press [MENU]. Start self-timer icon Press [4], use [8] and [2] to select the “...
Page 73: Shooting With Artistic Effects
Shooting with Artistic Effects (ART SHOT) A variety of artistic effects help to make even common, ordinary subjects become more novel and exciting. Scene Description Applies HDR (High Dynamic Range, page 92) photography to transform snapshots and movies into works of art that HDR Art provide a greater degree of expression than conventional imaging.
Page 74 Press [SET], use [8] and [2] to select the fifth Control Panel option from the top, and then press [SET]. The intensity of the selected effect can be adjusted as described below. Scene Adjustment HDR Art Effect level Toy Camera Soft Focus Effect level Light Tone...
Page 75: Saving A Second Normal Image When Shooting With Hdr Art
NOTE • Depending on the “ART SHOT” scenes, some of the items on the menu that appears may not be usable. • With this “ART SHOT” scene, the flash setting automatically becomes ? (Flash Off). • Movie recording is disabled while “Sparkling Shot” is selected. •...
Page 76: Creating And Using Your Own Setups
Creating and Using Your Own Setups (CUSTOM SHOT) You can register up to 12 setups, based on snapshots shot with the camera, as CUSTOM SHOT scenes. Selecting a registered CUSTOM SHOT scene configures the camera with its settings. . To register a CUSTOM SHOT scene Align the mode dial with [C] (CUSTOM SHOT).
Page 77 • Use the following steps when you want to delete a CUSTOM SHOT scene. In step 4 of the above procedure, select the scene you want to delete. • You can scroll through screens by rotating the zoom controller. Press [2] ( ), select “Cancel”, and then press [SET].
Page 78: Recording Movies
Recording Movies To record a movie The following procedure explains how to record a standard (STD) movie. This camera supports Premium Auto Pro movie recording (page 79). See the pages indicated below for more information about movies. High-definition movie (FHD movie): page 81 Mode dial High speed movie (HS movie): page 81 Align the mode dial with [P] (Program...
Page 79: Audio
Recording Movies with Premium Auto Pro When Premium Auto Pro is enabled (page 34), the camera automatically make judgments about the subject, shooting conditions, and other parameters. The result is higher quality images than those produced by Program Auto recording. The shooting environment detected by the camera is displayed at the bottom of the REC mode screen.
Page 80 IMPORTANT! • Spending a long time using movie recording will cause the camera to become slightly warm to the touch. This is normal and does not indicate malfunction. The camera may automatically adjust its monitor screen brightness in order to reduce heat generation.
Page 81: Recording A High-Definition Movie
Recording a High-definition Movie This camera supports recording of high-definition (FHD) movies. The aspect ratio of an FHD movie is 16:9, the image size is 1920 1080 pixels, and the frame rate is 30 fps. Image quality and image size settings cannot be changed. Align the mode dial with [P] (Program Auto) or [Ÿ] (Premium Auto Pro).
Page 82 Use [8] and [2] to select “Movie Quality” and then press [6]. Use [8] and [2] to select the frame rate (recording speed) you want and then press [SET]. A fast frame rate (such as 1000 fps) will result in a smaller image size. Movie REC Screen Image Size...
Page 83: Using Prerecord Movie
NOTE • The higher the frame rate (speed), the more lighting is required when shooting. When shooting a high speed movie, shoot in a well-lit environment. • When recording certain types of movies, the image that appears on the monitor screen may be smaller than normal.
Page 84 . To set up the camera to shoot with Prerecord Movie Align the mode dial with [b] (BEST SHOT). Press [MENU]. Press [4], use [8] and [2] to select the “ r REC MENU” tab, and then press [SET]. Use [8] and [2] to select “Movie Quality” and then press [6]. Use [8] and [2] to select the movie mode you want to use for shooting and then press [SET].
Page 85: Recording A Time Lapse Movie
NOTE • While the camera is set up for shooting with Prerecord Movie, pressing the shutter button will not shoot a snapshot unless movie recording is in progress. With high- definition (FHD) and standard (STD) movie, you can shoot still images while realtime movie recording is in progress.
Page 86 Press [SET]. • Time Lapse settings are shown at the bottom of the screen. Interval Scene Total Time Press the shutter button to start recording. Recording time • Shooting is repeated at the interval specified in step 6. • Recording stops when the recording time specified in step 6 elapses or when the shutter button is pressed again.
Page 87: Shooting A Snapshot While Shooting A Movie
• To adjust brightness when shooting with the Time Lapse “Night Scene”, use “ ” (Shutter Speed) on the Control Panel (page 44) to adjust the shutter speed. . Using the Scene Information Screen To find out more about a scene, select it with the boundary on the scene menu and then rotate the zoom controller in either direction.
Page 88 NOTE • Note that the flash cannot be used when shooting a Snapshot In Movie. • Note that shooting a snapshot while shooting a movie is supported during FHD movie and STD movie recording only. It is not supported during other types of movie recording.
Page 89: Using Best Shot
Using BEST SHOT BEST SHOT provides you with a collection of sample “scenes” that show a variety of different types of shooting conditions. When you need to change the setup of the camera, simply find the scene that matches what you are trying to achieve, and the camera sets up for it automatically.
Page 90 . Using the Scene Information Screen To find out more about a scene, select it with the boundary on the scene menu and then rotate the zoom controller in either direction. • To return to the scene menu, rotate the zoom controller again.
Page 91: Shooting With High Speed Anti Shake
Shooting with High Speed Anti Shake (HS Anti Shake) In addition to optical Anti Shake, a single press of the shutter button while HS Anti Shake is enabled causes the camera to record multiple images and automatically combine them. Use this feature to minimize image blur due to camera movement under conditions where optical anti shake is not possible for some reason.
Page 92: Digitally Correcting For Overexposure And Underexposure
NOTE • When shooting with this function, the “ISO” (page 51) becomes “Auto” (fixed). • If camera movement occurs when shooting with this function, the anti-shake process will result in an image range that is narrower than normal. • When shooting with this function, the “RAW+JPEG”, 3:2, and 16:9 image size settings cannot be selected.
Page 93: Shooting With A Blurred Background
Shooting with a Blurred Background (Blurred Background) This function analyzes a burst of consecutive images and then blurs the background behind the main subject. This creates an effect that really makes the subject stand out, just like photographs taken with a single-lens reflex camera. The blur effect can be set to one of three levels.
Page 94: Shooting With Full Focus Macro
Shooting with Full Focus Macro (All-In-Focus Macro) All-In-Focus Macro shoots and analyzes a burst of multiple images and combines them in a way that produces an image in which everything is in focus: from nearby objects to distant objects. “Program Auto” image All-In-Focus Macro In the BEST SHOT Mode, select “All-In-Focus Macro”...
Page 95: Shooting With Triple Shot
Shooting with Triple Shot Triple Shot shoots a burst of three images and stores them in memory. This feature is great for making sure you don’t miss those special moments when kids are around. In the BEST SHOT Mode, select “Triple Shot” (page 89). Point the camera at the subject and then half-press the shutter button.
Page 96: Shooting With Priority On Subject Faces
Shooting with Priority on Subject Faces (HS Best Selection) With HS Best Selection, the camera automatically shoots a series of images, and selects the best one based on facial image blur, and facial expression (whether the subject is smiling or blinking). In the BEST SHOT Mode, select “HS Best Selection”...
Page 97: Shooting A Panorama Image
Shooting a Panorama Image (Slide Panorama) With Slide Panorama, you move the camera to compose and record multiple images, which are then combined to a panorama. This feature lets you shoot a panorama of up to 360 degrees, which is dramatically greater than the physical capabilities of the lens.
Page 98 Press the shutter button the rest of the way down and a slide cursor will appear on the monitor screen. Slowly move the camera in the direction indicated by the arrow on the screen until the slide cursor reaches the other end of its movement range (i.e.
Page 99: Shooting With A Super Wide Angle Of View
Shooting with a Super Wide Angle of View (Wide Shot) With this feature, a number of images are shot and then combined to produce an image with a super-wide angle of view that exceeds the widest angle of view possible with the lens.
Page 100 Point the camera at the subject you want in the center of the image and then half-press the shutter button to focus. • The outer blue boundary on the screen indicates the Desired image recordable range of the image. Blue boundary Center part at the start of the shooting operation Press the shutter button the rest of the way...
Page 101 NOTE • The “17 mm” and “21 mm” angle of view values are approximate and are provided for reference only. Actual angle of view values are not guaranteed. • Zoom operations are not supported during Wide Shot shooting. The zoom setting is fixed at full wide angle.
Page 102: Using A Tv Screen To Shoot Snapshots
Using a TV Screen to Shoot Snapshots (HDMI TV Output) Use the procedure below to configure the camera for shooting snapshots with an aspect ratio of 16:9, as you compose them on a TV screen. Turn off the camera and use a commercially available HDMI cable to connect the camera to a TV.
Page 103 NOTE • For details about connecting to the camera and precautions when connecting, see page 137. • If you want to change the digital video signal format, first unplug the HDMI cable from the camera (page 138). • The settings in the table below are fixed while shooting with this function. Image Size 16:9 AF Area...
Page 104: Advanced Settings (Rec Menu)
Advanced Settings (REC MENU) The following are menu operations you can use to configure various camera settings. • You also can use the Control Panel (page 44) to configure some of the settings that appear on the menu screen. Refer to the page references provided in this section for information about configuring settings using the Control Panel.
Page 105: Using A Smartphone As A Camera Remote Controller (Remote Capture)
. Menu Operations in This Manual Menu operations are represented in this manual as shown below. The following operation is the same as the one described under “Example Menu Screen Operation” on page 104. Press [4] and then use [8] and [2] to select the “...
Page 106: Assigning A Recording Function To
Assigning a Recording Function to the Front Shutter Button (Front Shutter) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Front Shutter This setting can be used to assign the recording function to be performed when the front shutter button is pressed while the camera is in the REC mode.
Page 107: Assigning Functions To The Control Dial
Assigning Functions to the Control Dial (Key Customize) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Key Customize You can assign any one of the functions below to the Control Dial. After you do, you can change the setting of the function by rotating the Control Dial, or by pressing the left/right keys or up/down keys.
Page 108: Reducing Light Intensity
NOTE • Assigning functions to the up/down keys disables their normal [8] (DISP) function (which changes the monitor screen contents) and [2] ( ) function (which changes the flash setting). • The same function cannot be assigned to multiple controllers (keys, control dial). •...
Page 109: To Select The Snapshot Image Size
To select the snapshot image size (Image Size) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Image Size Suggested Image Size REC Screen Print Size and Description (Pixels) Icon Display Application A RAW image is stored along with a RAW+JPEG RAW+JPEG...
Page 110 • Available image sizes are limited for some functions as noted below. This option can be selected only when shooting snapshots in the modes below. Selecting a mode other than one included below while “RAW+JPEG” is selected will cause shooting to be RAW+JPEG performed with the “12M”...
Page 111: Specifying Snapshot Image Quality
Specifying Snapshot Image Quality (Image Quality) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Image Quality REC Screen Icon Setting Description Display Fine Gives image quality priority. Normal Normal • The “Fine” setting helps to bring out details when shooting a finely detailed image of nature that includes dense tree branches or leaves, or an image of a complex pattern.
Page 112: Specifying Iso Sensitivity
Settings REC Screen Approximate Data Rate (Quality Description Icon Display (Frame Rate) (pixels)) Use this setting for standard 3.9 Megabits/second movie recording. Recording with (30 frames/second) this setting is performed using an aspect ratio of 4:3. 40.0 Megabits/second HS1000 (1000 frames/second) 40.0 Megabits/second HS480 (480 frames/second)
Page 113: Specifying The Iso Sensitivity Upper Limit
Specifying the ISO Sensitivity Upper Limit (ISO High Limit) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * ISO High Limit REC Screen Settings Description Icon Display Shoots using the ISO sensitivity setting specified by the Auto None “ISO”...
Page 114: Reducing The Effects Of Camera And Subject Movement
Reducing the Effects of Camera and Subject Movement (Anti Shake) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Anti Shake You can turn on the camera’s Anti Shake feature to reduce image blur due to subject movement or camera movement when shooting a moving subject using telephoto, when shooting a fast-moving subject, or when shooting under dim lighting conditions.
Page 115: Turning Digital Zooming On Or Off
Zooming with Super Resolution (Zoom (SR)) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Zoom (SR) See page 62 for details. Turning Digital Zoom On or Off (Digital Zoom) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Digital Zoom Select “On”...
Page 116 Shooting with Face Detection (Face Detection) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Face Detection When shooting people, the face detection feature detects the faces of up to ten individuals and adjusts focus and brightness accordingly. Use [8] and [2] to select “On”...
Page 117: Specifying The Auto Focus Area
Specifying the Auto Focus Area (AF Area) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * AF Area You can use the following procedure to change the Auto Focus metering area for shooting snapshots. • When recording movies, the AF metering area is always “U Spot”. Settings Description The camera automatically determines the focus point on the...
Page 118: Shooting With Face Detection
Recording Beautiful Portraits (Make-up Level) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Make-up Level For details, see the Control Panel procedure on page 53. Shooting with Continuous Auto Focus (Continuous AF) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Continuous AF When shooting a snapshot while “On”...
Page 119: Reducing Wind Noise During Movie Recording
Reducing Wind Noise during Movie Recording (Wind Noise Cut) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Wind Noise Cut Select “On” to reduce wind noise during movie recording. Note, however, that this will also cause the sound quality to change.
Page 120: Specifying The Metering Mode
Specifying Flash Intensity (Flash Intensity) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Flash Intensity You can specify flash intensity to one of five levels from +2 (brightest flash) to –2 (least bright flash). •...
Page 121: Using The Auto Focus Assist Light
Using the Auto Focus Assist Light (AF Assist Light) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * AF Assist Light Half-pressing the shutter button while this setting is selected Front lamp causes the front lamp to light, which provides illumination for focusing in areas where lighting is dim.
Page 122: Using Icon Help
• When “Type 4” is selected for the “Review” setting, performing any one of the operations below will clear the currently displayed review image. – Entering the PLAY mode – Turning off the camera Using Icon Help (Icon Help) Procedure Enter the REC Mode * [MENU] * “...
Page 123 When this setting is “On”, a line on the monitor screen shows the current left/ right and front/back tilt of the camera. The line changes to blue when the camera is level (no left/right and front/ back tilt). Electronic Line Level NOTE •...
Page 124: How To Use The Histogram
. How to Use the Histogram A histogram is a graph that represents the lightness of an image in terms of the number of pixels. The vertical axis indicates the number of pixels, while the horizontal axis indicates lightness. If the histogram appears too lopsided for some reason, you can use EV shift to move it left or right in order to achieve better balance.
Page 125: Configuring Power On Default Settings
Configuring Power On Default Settings (Memory) Procedure Enter the REC Mode * [MENU] * “ r REC MENU” Tab * Memory This setting lets you specify which camera settings should be remembered by the camera when it is turned off, and restored the next time the camera is turned on. To have the camera remember a setting, you should enable the setting’s memory.
Page 126: Viewing Snapshots And Movies
Viewing Snapshots and Movies Viewing Snapshots See page 38 for the procedure for viewing snapshots. Viewing a Movie Press [p] (PLAY) and then use [4] and [6] to display the movie you want to view. Press [SET] to start playback. Movie icon: »/»...
Page 127: Viewing A Panorama Image
Rotate the zoom controller in the direction of z ([). • You can use [8], [2], [4], and [6] to scroll the zoomed image on the monitor screen. You can zoom a movie Zoom image up to 4.5 times normal size. •...
Page 128: Viewing Continuous Shutter Images
Viewing Continuous Shutter Images Each time you shoot with continuous shutter (CS) or Intelligent Bracketing, the camera creates a group that includes all of the images for that particular session. You can use the following procedure to play back the images in a particular group. .
Page 129 Playback Controls During playback, changes the playback direction and playback speed. While playback is paused, scrolls forward or back. [4] [6] • Forward and back scrolling can also be performed using the function ring. • Playback speed cannot be adjusted while the displayed image is zoomed.
Page 130: Playback Controls
Playback Controls Slide the zoom slider towards w (]). Displaying a List View • To return to the previous view, slide the zoom slider towards z ([). [8][2][4][6] • If a group has three images, you can select an image Selecting an Image using [4] and [6] only.
Page 131: Deleting Continuous Shutter Images
Deleting Continuous Shutter Images You can use the following procedures to delete images while playback is in progress or paused. . Deleting a Specific Group File While CS image playback is in progress or paused, press [2]. This will display the “Edit Group” menu. •...
Page 132: Dividing Up A Group
. Deleting All Files in a Group While CS image playback is in progress or paused, press [2]. This will display the “Edit Group” menu. • In the case of an image shot with Intelligent Bracketing, press [2] while the full-screen view of the image is shown.
Page 133: Copying A Group Image
. Dividing Up All Groups IMPORTANT! • Once a group is divided, it cannot be regrouped. In the PLAY mode, press [MENU]. Press [4], use [8] and [2] to select the “p PLAY MENU” tab, and then press [SET]. Use [8] and [2] to select “Divide Group” and then press [6]. Use [8] and [2] to select “All Files”...
Page 134: Scrolling Images At High Speed Or By Recording Date
Scrolling Images at High Speed or by Recording Date You can rotate the function ring to scroll images at high speed or by recording date. In the PLAY mode, press [RING]. [RING] Use [8], [2], [4] and [6] to select a scroll speed and then press [SET].
Page 135: Zooming An On-Screen Image
Zooming an On-screen Image In the PLAY mode, use [4] and [6] to scroll through the images until the one you want is displayed. Rotate the zoom controller towards z ([) to Zoom factor zoom. Image area You can use [8], [2], [4], and [6] to scroll the zoomed image on the monitor screen.
Page 136: Displaying The Image Menu
Displaying the Image Menu In the PLAY mode, rotate the zoom controller Boundary towards w (]). • Sliding the zoom slider towards w (]) will cycle through the number of images that are displayed in the image menu in the following sequence: 4, 25, 100. •...
Page 137: Viewing Snapshots And Movies On A Tv Screen
Viewing Snapshots and Movies on a TV Screen Use a commercially available HDMI cable to connect the camera to the • Use a commercially available HDMI cable that is marked with the logo shown to the right. • Make sure that the camera is turned off before plugging in or unplugging the cable.
Page 138 NOTE • Use a HDMI cable that with a plug that is compatible with the camera’s HDMI micro connector on one end, and a plug that is compatible with your TV’s HDMI connector on the other end. • Proper image and/or audio output and other operations may not be possible with some devices.
Page 139: Other Playback Functions (Play Menu)
Other Playback Functions (PLAY MENU) This section explains menu items that you can use to configure settings and perform other playback operations. For information about menu operations, see page 104. Assigning a Function to the Front Shutter Button (Front Shutter) Procedure [p] (PLAY) * [MENU] * “p PLAY MENU”...
Page 140: Playing A Slideshow On The Camera
Playing a Slideshow on the Camera (Slideshow) Procedure [p] (PLAY) * [MENU] * “p PLAY MENU” Tab * Slideshow Start Starts the slideshow Images Specifies the type of images to be included in the slideshow All images: Snapshots, movies, continuous shutter images All except Z : All non-continuous shutter (CS) images T Only: Snapshots only »...
Page 141: Transferring Music From Your Computer To Camera Memory
• To stop the slideshow, press [SET] or [MENU]. Pressing [MENU] stops the slideshow and returns to the menu screen. • Adjust audio volume by pressing [2] and then press [8] or [2] during playback. • All button operations are disabled while the slideshow is transitioning from one image to another.
Page 142: Creating A Snapshot Of Movie Frames
Double-click the “SSBGM” folder you created and copy the background music file to it. • See the user documentation that comes with your computer for information about moving, copying, and deleting files. • If there are background music files both in built-in memory and on the memory card loaded in the camera, the files on the memory card take priority.
Page 143: Editing A Movie On The Camera
Editing a Movie on the Camera (Movie Editing) Procedure [p] (PLAY) * Movie Screen of Movie to be Edited * [MENU] * “p PLAY MENU” Tab * Movie Editing The Movie Editing feature lets you use one of the following procedures to edit out a specific part of a movie.
Page 144 Use [8] and [2] to select “Yes” and then press [SET]. The selected cut operation will take considerable time to complete. Don’t try to perform any camera operation until the “Busy... Please wait...” message disappears from the monitor screen. Note that a cut operation can take a long time if the movie being edited is long.
Page 145: To Merge Two Movies
To merge two movies (Movie Merge) Procedure [p] (PLAY) * Display one of the movies you want to merge. * [MENU] * “p PLAY MENU” Tab * Movie Merge This procedure combines two movies. The play times of the each movies must be less than 10 minutes, and the two movies must be of the same quality and frame rate.
Page 146: Optimizing Image Brightness
Optimizing Image Brightness (Lighting) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * “p PLAY MENU” Tab * Lighting You can use this setting to adjust the balance between bright areas and dark areas in existing images in the range of 0 (no optimization) to +2 (bright). NOTE •...
Page 147: Adjusting The Brightness Of An Existing Snapshot
Adjusting the Brightness of an Existing Snapshot (Brightness) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * “p PLAY MENU” Tab * Brightness You can select one of five brightness levels, from +2 (brightest) to –2 (least bright). NOTE • The original snapshot is retained in memory and not deleted. •...
Page 148 IMPORTANT! • Note that even if a file is protected, it will be deleted if you perform the format operation (page 194). . To protect a specific image in a group While CS image playback is in progress or paused, press [2]. This will display the “Edit Group”...
Page 149: Editing The Date And Time Of An Image
. To protect all the images in a group While CS image playback is in progress or paused, press [2]. This will display the “Edit Group” menu. • In the case of an image shot with Intelligent Bracketing, press [2] while the full-screen view of the image is shown.
Page 150: Rotating An Image
Rotating an Image (Rotation) Procedure [p] (PLAY) * Snapshot or Movie Screen * [MENU] * “p PLAY MENU” Tab * Rotation Use [8] and [2] to select “Rotation” and then press [SET]. Each press of [SET] will rotate the displayed image 90 degrees left. When the displayed image is at the orientation you want, press [MENU].
Page 151: Cropping A Snapshot
Cropping a Snapshot (Trimming) Procedure [p] (PLAY) * Snapshot Screen * [MENU] * “p PLAY MENU” Tab * Trimming You can crop a snapshot to trim parts you do not need, and Zoom factor save the result in a separate file. The original snapshot is Represents also retained.
Page 152: Dividing Up A Continuous Shutter Group
Dividing Up a Continuous Shutter Group (Divide Group) Procedure [p] (PLAY) * [MENU] * “p PLAY MENU” Tab * Divide Group See page 132 for details. Combining CS Images into a Single Still Image (CS Multi Print) Procedure [p] (PLAY) * Display CS group. * [MENU] * “p PLAY MENU”...
Page 153: Editing A Cs Image
Editing a CS Image (Edit Group) Procedure [p] (PLAY) * [MENU] * “p PLAY MENU” Tab * Edit Group See the following pages for details. DPOF Printing: page 168 Protect: page 147 Copy: page 133 Delete: page 131 Changing Available Image Menu Options (Image Menu Options) Procedure [p] (PLAY) * [MENU] * “p PLAY MENU”...
Page 154: Establishing A Wireless Lan Connection
Establishing a Wireless LAN Connection Wireless LAN Functions Establishing a wireless LAN connection between the camera and a smartphone enables the functions described below. With this function: You can do this: page: Remote Capture Remotely control and shoot with the camera using a smartphone.
Page 155 IMPORTANT! • Never use wireless LAN functions inside an aircraft or anywhere else where such operation is restricted. • Some smartphone models may not be able to play back movie files that are sent to the smartphone. • Depending on your smartphone model, its operating system version, and/or its remaining storage capacity can cause failure of a movie or snapshot save operation.
Page 156: Establishing A Connection Between A Smartphone And Your Camera
Establishing a Connection between a Smartphone and Your Camera Installing the EXILIM Remote Smartphone app on your smartphone makes it possible to remotely control the camera from your smartphone and to send images recorded with the camera to your smartphone. Search the EXILIM Remote app on Google Play or App Store and install it on your smartphone.
Page 157: Configuring Wireless Lan Settings
Configuring Wireless LAN Settings Use the procedure below to establish a wireless LAN connection between the camera and a smartphone for the first time. This operation is required for the first connection only. Select Program Auto as the recording mode. Press [MENU].
Page 158: Using A Smartphone As A Camera Remote Controller (Remote Capture)
Using a Smartphone as a Camera Remote Controller (Remote Capture) This function lets you remotely shoot a snapshot or movie with the camera using a smartphone. You also can perform remote zoom, self-timer, and other operations as well. You can use any one of the recording modes below to shoot with Remote Capture.
Page 159 IMPORTANT! • The Movie Quality is always STD (640 480) when shooting with Remote Capture. • “O Tracking” cannot be selected for the AF area setting while shooting with the Handsfree Mode. If “O Tracking” is selected in another mode, selecting the Handsfree Mode will cause the AF area setting to change to “U Spot”.
Page 160: Sending The Currently Displayed Image To A Smartphone
Location Information You can add location information to snapshots shot with Remote Capture when they are sent to a smartphone using . On an Android terminal, select “Options” on the Remote Capture screen. On an iPhone, perform the following operation: “Settings” * “Privacy”...
Page 161: To Send The Displayed Image To A Smartphone
To send the displayed image to a smartphone On the smartphone, start up EXILIM Remote. In the upper right corner of the screen that appears, tap “Setting”. If you plan to upload the image to a social networking service after sending it to the smartphone, select “ON”...
Page 162: Sending A Snapshot Or Movie File From
NOTE • “Û” is displayed on the camera screen while there is a wireless LAN connection between the camera and a smartphone. • You can specify the size of the image sent to the smartphone using “Resize before send” (page 164). •...
Page 163 On your smartphone, start up the EXILIM Remote app. This will establish a connection between your camera and the smartphone, and send the files to the smartphone. • If the message “Connect your phone to the access point below.” remains on the camera’s monitor screen, change the smartphone’s Wi-Fi settings so your camera is selected for connection (page 157).
Page 164: Resizing Snapshots Before
Resizing Snapshots before Sending Them to a Smartphone (Resize before send) This feature can be use to resize snapshots before they are sent to a smartphone using “Quick Send”, “Remote Capture”, or “Send to phone”. Turn on the camera, and then press [MENU]. Press [4], use [8] and [2] to select the “...
Page 165: Viewing Snapshots And Movies In
Viewing Snapshots and Movies in Camera Memory on a Smartphone (View on phone) You can use this function to enable up to eight smartphones and/or computers to access snapshots and movies in camera memory for viewing and download. A smartphone does not need to have the EXILIM Remote app installed in order to access camera images using this function.
Page 166: Printing
Printing Printing Snapshots Professional Print Service* You can take a memory card that contains the images you want to print to a professional print service and have them printed. Printing on a Home Printer* Printing Images on a Printer with Memory Card Slot You can use a printer equipped with a memory card slot to print images directly from a memory card.
Page 167: Connecting The Camera To A Printer
. Connecting the Camera to a Printer Use the micro USB cable that comes bundled with the camera to connect the camera to your printer’s USB port. • For details about connecting to the camera and precautions when connecting, see page 25.
Page 168 Use [8] and [2] to specify the print option you want. 1 Image : Prints one image. Select and then press [SET]. Next, use [4] and [6] to select the image you want to print. DPOF Printing: Prints multiple images. Select and then press [SET]. With this option, images will be printed in accordance with DPOF settings (page 168).
Page 169 . Configuring DPOF Settings Individually for Each Image Procedure [p] (PLAY) * Snapshot Screen * [MENU] * “p PLAY MENU” Tab * DPOF Printing * Select images Use [4] and [6] to scroll through the files until the image you want to print is displayed.
Page 170 . To specify the number of copies for a specific image in a group While CS image playback is in progress or paused, press [2]. This will display the “Edit Group” menu. • In the case of an image shot with Intelligent Bracketing, press [2] while the full-screen view of the image is shown.
Page 171: Date Stamping
DPOF settings are not cleared automatically after printing is complete. The next DPOF print operation you execute will be performed using the last DPOF settings you configured for the images. To clear DPOF settings, specify “00” for the number of copies of all images. Tell your print service about your DPOF settings! If you take a memory card to a professional print service, be sure to tell them that it includes DPOF settings for the images to be printed and the number of copies.
Page 172 . Standards Supported by the Camera • PictBridge This is a standard of the Camera and Imaging Products Association (CIPA). You can connect the camera directly to a printer that supports PictBridge, and perform image selection and printing using the camera monitor screen and controls.
Page 173: Using The Camera With A Computer
Using the Camera with a Computer Things you can do using a computer... You can perform the operations described below while the camera is connected to a computer. Save images to • Save images and view them manually (USB a computer and connection) (pages 174, 178).
Page 174: Using The Camera With A Windows Computer
Using the Camera with a Windows Computer When you want Operating System Required Software to do this: Version page: Save images to Windows 8, a computer and Windows 7, Installation not required. view them there Windows Vista, manually Windows XP (SP3) Windows 8, Windows Media Player 12 Windows 7...
Page 175 . To connect the camera to your computer and save files Turn on the camera and press [MENU]. On the “¥ SETTING” tab, select “USB” and then press [6]. Use [8] and [2] to select “Mass Storage”, and then press [SET]. Turn off the camera and then USB port use the micro USB cable that...
Page 176 Windows 8 users: On the “Documents” menus, click “Home” and then “Paste”. Windows 7 users: On the “Documents” “Organize” menu, select “Paste”. Windows Vista users: On the “Documents” “Edit” menu, select “Paste”. Windows XP users: On the “My Documents” “Edit” menu, select “Paste”.
Page 177: Playing Movies
Playing Movies To play back a movie, first copy it to your computer and then double-click the movie file. Some operating systems may not be able to play back movies. If this happens, you need to install separately available software. •...
Page 178: Using The Camera With A Macintosh
Using the Camera with a Macintosh When you want to Operating Required Software do this: System Version page: Save images to your Macintosh and view OS X Installation not required. them there manually Save images to your Macintosh iPhoto, which comes bundled OS X –...
Page 179 . To connect the camera to your computer and save files Turn on the camera and press [MENU]. On the “¥ SETTING” tab, select “USB” and then press [6]. Use [8] and [2] to select “Mass Storage”, and then press [SET]. Turn off the camera and then USB port use the micro USB cable that...
Page 180: Playing A Movie
. To view copied images Double-click the camera’s drive icon. Double-click the “DCIM” folder to open it. Double-click the folder that contains the images you want to view. Double-click the image file you want to view. • For information about file names, see “Memory Folder Structure” on page 182. •...
Page 181: Files And Folders
. Movie Playback Precautions Proper movie playback may not be possible on some Macintosh models. If you experience problems, try the following. – Try recording movies with a quality setting of “STD”. – Upgrade to the latest version of QuickTime. –...
Page 182: Memory Card Data
File System (DCF). . About DCF The following operations are supported for DCF-compliant images. Note, however, that CASIO makes no performance guarantees concerning these operations. • Transferring this camera’s DCF-compliant images to another manufacturer’s camera and view them. • Printing this camera’s DCF-compliant images on another manufacturer’s printer.
Page 183: Supported Image Files
. Supported Image Files • Image files shot with this camera • DCF-compliant image files This camera may not be able to display an image, even if it is DCF-compliant. When displaying an image recorded on another camera, it may take a long time for the image to appear on this camera’s monitor screen.
Page 184: Other Settings (Setting)
Other Settings (SETTING) This section explains menu items that you can use to configure settings and perform other operations in both the REC mode and PLAY mode. For information about menu operations, see page 104. Enabling Power Saving (ECO Mode) Procedure [MENU] * “¥...
Page 185: Resizing Snapshots Before
Resizing Snapshots before Sending Them to a Smartphone (Resize before send) Procedure [MENU] * “¥ SETTING” Tab * Resize before send See page 164 for details. Configuring Camera Sound Settings (Sounds) Procedure [MENU] * “¥ SETTING” Tab * Sounds Startup Specifies the startup sound Half Shutter Sound 1 - 5: Built-in sounds (1 through 5)
Page 186: Creating An Image Storage Folder
Creating an Image Storage Folder (Create Folder) Procedure [MENU] * “¥ SETTING” Tab * Create Folder Creates a folder with a unique number (page 181). Files will be Create Folder stored in the new folder starting from when you record your next image.
Page 187: Auto Image Orientation Detection And Rotation
Auto Image Orientation Detection and Rotation (Auto Rotate) Procedure [MENU] * “¥ SETTING” Tab * Auto Rotate Rotates the displayed image in accordance with the camera orientation when the image was recorded. Images not rotated automatically. This setting can be used to configure the camera to display playback images in the same orientation as the camera when the image was shot.
Page 188: Configuring Sleep State Settings
Configuring Sleep State Settings (Sleep) Procedure [MENU] * “¥ SETTING” Tab * Sleep This feature turns off the monitor screen and lights the back lamp (green) whenever no camera operation is performed for a preset period of time. Press any button to turn the monitor screen back on.
Page 189: Specifying The Operation When The Monitor Screen Is Tilted (Screen Tilt)
Specifying the Operation when the Monitor Screen is Tilted (Screen Tilt) Procedure [MENU] * “¥ SETTING” Tab * Screen Tilt Power On Turns on the camera whenever the monitor screen is tilted. Turns on the camera whenever the monitor screen is tilted, and On/Off turns it off when the monitor screen is returned to its normal position.
Page 190: Configuring World Time Settings
Configuring World Time Settings (World Time) Procedure [MENU] * “¥ SETTING” Tab * World Time You can use the World Time screen to view the current time in a zone that is different from your Home City when you go on a trip, etc. World Time displays the current time in 162 cities in 32 time zones around the globe.
Page 191: Setting The Camera's Clock
Setting the Camera’s Clock (Adjust) Procedure [MENU] * “¥ SETTING” Tab * Adjust When the date and time settings are what you want, select “Apply” and then press [SET] to apply them. [8] [2] Change the setting at the cursor location [4] [6] Move the cursor between settings •...
Page 192: Specifying The Display Language
Specifying the Display Language (Language) Procedure [MENU] * “¥ SETTING” Tab * Language . Specify the display language you want. Select the bottom tab “¥”. Select “Language”. Select the language you want. • Camera models sold in certain geographic areas may not support display language selection.
Page 193: Changing The Camera Password For
Changing the Camera Password for Wireless LAN Connection (WLAN password) Procedure [MENU] * “¥ SETTING” Tab * WLAN password Use procedure to change the password you used when establishing a wireless LAN connection between the camera and a smartphone. Use [4] and [6] to move the cursor to the password digit you want to change.
Page 194: Formatting Built-In Memory Or A Memory Card
Formatting Built-in Memory or a Memory Card (Format) Procedure [MENU] * “¥ SETTING” Tab * Format If a memory card is loaded in the camera, this operation will format the memory card. It will format built-in memory if no memory card is loaded. •...
Page 195: Appendix
• The battery is intended for use with a CASIO Digital Camera only. Use with any other device creates the risk of the battery damage, or deterioration of battery performance and service life.
Page 196 DANGER • Failure to observe any of the following precautions creates the risk of battery overheating, fire, and explosion. – Never use or leave the battery near open flame. – Do not expose the battery to heat or fire. – Make sure the battery is oriented correctly when charging it. –...
Page 197 Also, remove the battery from the camera, taking care to protect yourself against burn injury. 3. Contact your retailer or nearest CASIO authorized service center. . Keep Away From Fire • Never expose the camera to fire, which can cause it to explode and creates the risk of fire and personal injury.
Page 198 2. If you are using the USB-AC adapter to power the camera, unplug the power plug from the wall outlet. Also, remove the battery from the camera, taking care to protect yourself against burn injury. 3. Contact your retailer or nearest CASIO authorized service center. Appendix...
Page 199: Memory Cards
Also, remove the battery from the camera, taking care to protect yourself against burn injury. 3. Contact your retailer or nearest CASIO authorized service center. . Memory Cards • Memory cards are small and present a risk of accidentally being swallowed by infants and young children.
Page 200 WARNING • Do not use the camera’s wireless function while in the vicinity of high precision digital devices or digital devices that use weak signals. Doing so can interfere with proper operation of such digital devices and create the risk of accident. •...
Page 201 CAUTION . Rechargeable Battery • If battery charging does not end normally within the specified charging time, stop charging anyway and contact your local CASIO authorized service center. Continued charging creates the risk of battery overheating, fire, and explosion. • Be sure to read the user documentation that comes with the camera and special charger unit before using or charging the battery.
Page 202: Monitor Screen
CAUTION . Monitor Screen • Do not apply strong pressure to the LCD panel surface or subject it to strong impact. Doing so can cause the display panel glass to crack and lead to personal injury. • Should the monitor screen ever become cracked, never touch any of the liquid inside the monitor screen.
Page 203 CAUTION . Camera Jacket • When wearing the strap around your neck, the camera can unexpectedly bump into objects, fall, or become caught in a door, creating the risk of malfunction or personal injury. Hold the camera in your hand or take other precautions to avoid such problems. Never swing the jacket around by the strap.
Page 204: Precautions During Use
Precautions During Use . Data Error Precautions Your digital camera is manufactured using precision digital components. Any of the following creates the risk of corruption of data in camera memory. – Removing the battery or memory card while the camera is performing some operation –...
Page 205: Caring For Your Camera
Note that the radio waves that are used to send and receive data can be intercepted by third parties. Unauthorized access CASIO COMPUTER CO., LTD. shall be held in no way liable for any unauthorized access and/or use of the access point equipped on this product if the product is ever lost or stolen.
Page 206 Intended Areas of Use 1)The wireless LAN functions of this camera are provided for use in the countries and geographic areas below. Hong Kong, Singapore, Thailand, The United Arab Emirates (UAE), Paraguay, Venezuela, Panama, Germany, Austria, France, The Netherlands, Spain, Italy, Sweden, Denmark, Slovakia, Poland, and Norway 2)Approval for use under radio regulations in the countries and geographic areas below is granted only when the camera is purchased within that particular country or geographic...
Page 207 Note that CASIO COMPUTER CO., LTD. shall not be held liable for use of this product in any way that infringes on the copyrights of others or that violates copyright laws.
Page 208: Power Supply
If problems persist after you perform the above steps or if the battery fails to charge after 5 hours, it could mean that the battery is faulty. Contact your nearest CASIO authorized service center. Appendix...
Page 209: Battery Precautions
Battery Precautions . Precautions during Use • Operation provided by a battery under cold conditions is always less than operation under normal temperatures. This is due to the characteristics of the battery, not the camera. • Charge the battery in an area where the temperature is within the range of 15°C to 35°C (59°F to 95°F).
Page 210: Using A Memory Card
Using a Memory Card See page 29 for information about supported memory cards and how to load a memory card. . Using a Memory Card • SD memory cards, SDHC memory cards, and SDXC memory cards have a write protect switch. Use the Write enabled switch when you need to guard against accidentally deleting data.
Page 211: Reset Initial Default Settings
Reset Initial Default Settings The tables in this section show the initial default settings that are configured for menu items (displayed when you press [MENU]) after you reset the camera (page 194). Menu items depend on whether the camera is in the REC mode or PLAY mode. •...
Page 212 FUNCTION RING: On / CS: Off / Flash: On / Focus: Off / ISO: Off / White Balance: Off / EV Shift: Off / Memory AF Area: On / Metering: Off / Self-timer: Off / Flash Intensity: Off / Zoom (SR): On / Digital Zoom: On / MF Position: Off / Zoom Position: Off...
Page 213 . ¥ SETTING ECO Mode Auto Power Off 5 min Screen Auto Screen Tilt Power On Resize before PLAY Power On send Delete Key Enabled Startup: Sound 1 / World Time – Half Shutter: Adjust – Sound 1 / Shutter: Sound 1 / Date Style –...
Page 214: When Things Don't Go Right
2)The battery may be dead. Charge the battery (page 23). If the battery goes dead soon after being charged, it means the battery has reached the end of its life and needs to be replaced. Purchase a separately available CASIO NP-130A rechargeable lithium ion battery. The camera 1)Auto Power Off may have activated (page 188).
Page 215 (page 55) or select a different BEST SHOT scene (page 89). The red ? (Flash The flash unit may be malfunctioning. Contact a CASIO Off) icon is authorized service center or your original retailer. Note that...
Page 216 Problem Possible Cause and Recommended Action A recorded image 1)Camera power may have been turned off before the save was not saved. operation was complete, which will result in the image not being saved. If the battery indicator shows , charge the battery as soon as possible (page 27).
Page 217 Problem Possible Cause and Recommended Action Playback The color of the Sunlight or light from another source may be shining directly playback image is into the lens when you are shooting. Position the camera so different from what sunlight does not shine directly into the lens. appears on the monitor screen when shooting.
Page 218 If the same message appears after you turn power back on, contact your retailer or a CASIO authorized service center. There are various The monitor screen shows indicators and other information indicators and about shooting conditions and the image you are recording.
Page 219: Display Messages
24 hours, it could mean that the camera’s setting camera’s battery. memory is defective. Contact your retailer or a CASIO authorized service center. Buttons are not With large capacity memory cards there is a delay after the...
Page 220 The Anti Shake unit of the camera may be malfunctioning. LENS ERROR 2 If the same message appears after you turn power back on, contact your retailer or a CASIO authorized service center. Load paper! The printer ran out of paper while printing.
Page 221 This card is not The memory card loaded in the camera is not formatted. formatted. Format the memory card (page 194). This file cannot be The file you are trying to access is corrupted or is a type played. that cannot be displayed by this camera. This message will appear part way through an operation This function cannot when you attempt to use a function that is not allowed in...
Page 222: Number Of Snapshots/Movie Recording Time
Number of Snapshots/Movie Recording Time Snapshot Built-in Memory SD Memory Card Image Size Quality File Size Recording Recording (Pixels) Capacity Capacity RAW+JPEG* Fine 25.77 MB (4000 3000) Normal 22.03 MB Fine 7.87 MB 1453 (4000 3000) Normal 4.13 MB 2221 Fine 6.87 MB 1672...
Page 223 Movies Maximum Built-in Continuous Image Size/ Recording File Size of Approximate Data Maximum Memory Recording Pixels Time with 1-minute Rate (Frame Rate) File Size Recording Time per (Audio) SD Memory Movie Capacity Movie Card 14.2 Megabits/ 2 hours (1920 1080) second 26 seconds 106.5 MB...
Page 224: Specifications
Recordable time when the entire movie is recorded at 30 fps. Recording time is shorter if the 30 fps frame rate is switched to 120 fps or 240 fps during recording. • Snapshot and movie recording capacity values are approximate and intended for reference only.
Page 225 Focusing Contrast Detection Auto Focus; with AF assist light • Focus Modes: Auto Focus, Macro Focus, Super Macro Focus, Manual Focus • AF Area: Intelligent, Spot, Multi, Tracking Approximate Focus Auto Focus: 1 cm to 9 (0.4" to 9 ) (Wide Angle) Range Macro Focus: 1 cm to 50 cm (0.4"...
Page 226 Flash Range 0.8 m to 10.9 m (2.6' to 35.8') (Wide Angle) (ISO Sensitivity: Auto) 0.8 m to 7.8 m (2.6' to 25.6') (Telephoto) • Range is affected by optical zoom. Flash Intensity –2, –1, 0, +1, +2 Adjustment Flash Charging Time Approximately 5 seconds Wireless data transfer Standard: IEEE 802.11b/g/n Operation frequency range: 1 to 11ch...
Page 227 • Battery: NP-130A (Rated Capacity: 1800 mAh) • Recording Medium: 16GB SDHC memory card (SanDisk Corporation) In accordance with CIPA (Camera and Imaging Products Association) standards In accordance with CASIO standards Other settings Time Lapse scene: Standard, Recording interval: 1/2 second, Total time: Off,...
Page 228 . Rechargeable lithium ion battery (NP-130A) Rated Voltage 3.7 V Rated Capacitance 1800 mAh Operating Temperature 0 to 40°C (32 to 104°F) Requirements Dimensions 37.8 (W) 44.8 (H) 11.2 (D) mm (1.49" (W) 1.76" (H) 0.44" (D)) (excluding projections) Weight Approximately 38 g (1.3 oz) .
Page 229 CASIO COMPUTER CO., LTD. 6-2, Hon-machi 1-chome Shibuya-ku, Tokyo 151-8543, Japan MA1403-B 2013...

This manual is also suitable for:

Ex-100

Casio EX-10 User Manual

General Guide

Monitor Screen Contents and How to Change Them

Quick Start Basics

Snapshot Tutorial

Recording Movies

Using BEST SHOT

Advanced Settings (REC MENU)

Viewing Snapshots and Movies

Other Playback Functions (PLAY MENU)

Establishing a Wireless LAN Connection

Printing

Using the Camera with a Computer

Other Settings (SETTING)

Appendix

Quick Links

Digital Camera

Related Manuals for Casio EX-10

Summary of Contents for Casio EX-10
