Rolling code for remote controls and
keypads.
•
Fixed code for other accessories with over
16 millions possible combinations.
•
Silent alarm possible.
•
Anti jamming function, programmable.
•
Arm/disarm confirmation on outdoor &
indoor siren.
•
Doorbell function.
•
Keypad locking in case of multiple
erroneous codes.
•
Volume set up for integrated speaker
sound confirmations.
•
Tamper protection connectable for
maintenance.
•
5 different user codes (main/secondary
user, maid, temporary code)
•
Event log showing last 20 occurrences.
•
Dimensions: 265mm (L) x 180mm (W) x
65.mm (H)
•
Weight : g
•
Power by normal alkaline batteries:
4*Alkaline battery "D cell" 1.5V
•
Battery life: 2 years
•
Power adaptor connection for permanent
display (batteries in rescue)
Remote Control HA2000R
•
4 functions: Away Arm, Home Arm,
Disarm and Panic.
•
Weatherproof IP44
•
Weak battery signal
•
Power : Lithium battery "CR2032" 3.0V
180 mA/H
•
Battery life: 3 years
•
Bi-color LED: Red for transmission signal
and Green for weak battery
•
Rolling code among 16 777 216
Combinations
•
Dimensions: 65mm (L) x 38mm (W) x
15.00mm (H)
•
Weight : 35g
Open contact HA2000M
•
Weak battery detection
•
Supervised: random signal 30 min to 50
min
•
Terminal for connecting extra wired
detectors (NC loop)
•
Double tamper protection : back mount +
cover
•
LED light: Default & Test mode.
Do not HESITATE to call us via our assistance hotline (at the end of the notice). Our technicians will have the pleasure to
PIR Detector HA2000P
Remote keypad HA2000K
PROBLEM?
help you make a perfect installation.
•
Transmitted signals: Opening, Closing,
Weak battery, Tamper, Tamper closed,
Supervision and Test Mode.
•
Battery life: Over 3 years assuming 50
transmissions / day. Roughly 5 years
under normal use. 1 month after weak
battery signal. Lithium battery 1/2 AA 3.6V
1000mAH
•
Space Tolerance against magnet : 30mm
max
•
Dimensions : 103mm (L)*31mm
(W)*20.5mm (H)
•
Analysis by Conversion A/N (MSLT),
temperature compensation Protection
High Frequencies (magnetic and radio
interferences)
•
Detection range: 90° over 12 meters, 19
sectors with 9 on same line
•
Supervision: Random 30 min to 50 min
•
LED light and button: Default & Test
Mode.
•
Transmitted signals: Opening, Closing,
Weak battery, Tamper, Tamper closed,
Supervision and Test Mode.
•
White lens reflecting up à 6000 lux (solar
rays, vehicle beams...)
•
Double Tamper protection : rear mount +
cover
•
Battery life: Over 3 years assuming 50
transmissions / day. Roughly 5 years
under normal use. 1 month after weak
battery signal. Lithium battery AA 3.6V
2400mAH
•
Weak battery detection
•
Dimensions: 93mm (L)*64mm (W)*42mm
(H)
•
6 functions: Away arm, Home arm,
Disarm, Medical, Fire and Panic.
•
LED confirming: Transmission, fault, Test
mode, Control panel status and Weak
battery
•
Backlit keypad
•
Weatherproof IP 44
•
Tamper protection
•
Power: lithium battery CR2032, 3V
220mA/H
•
Battery life: Over 4 years assuming 8
transmissions per day.
•
Rolling code among 16 777 216
Combinations
•
Dimensions: 122mm (L) x 93mm (W) x
25mm (H)
