Installation, Start-Up, and Operating Instructions
NOTE: Read the entire instruction
manual before starting the installation.
A93040
NOTE: This furnace can be installed as a
or non-direct vent (1-pipe)
This symbol → indicates a change since the last issue.
Index
SAFETY CONSIDERATIONS .....................................................2
DIMENSIONAL DRAWING........................................................3
Clearances to Combustibles......................................................4
CODES AND STANDARDS........................................................5
INTRODUCTION ..........................................................................6
APPLICATIONS............................................................................6
General ......................................................................................6
Upflow Applications.................................................................6
Downflow Applications ............................................................8
LOCATION..................................................................................14
General ....................................................................................14
Low-Heat Only Installation ....................................................15
Hazardous Locations...............................................................16
Furnace Location and Application .........................................16
AIR FOR COMBUSTION AND VENTILATION ....................17
INSTALLATION .........................................................................19
Leveling Legs (If Desired) .....................................................19
Installation In Horizontal Applications ..................................20
Air Ducts.................................................................................20
General Requirements .......................................................20
Ductwork Acoustical Treatment .......................................20
Supply-Air Connections ....................................................20
Return-Air Connections.....................................................22
Filter Arrangement..................................................................23
Bottom Closure Panel.............................................................23
Gas Piping...............................................................................24
Electrical Connections ............................................................25
115-v Wiring......................................................................25
24-v Wiring........................................................................27
Accessories ........................................................................27
Common Vent Systems.....................................................27
Combustion-air and Vent Pipe Systems ................................27
Condensate Drain .........................................................................40
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book 1 4
PC 101
Tab 6a 8a
Variable-Capacity Condensing Gas Furnace
For Sizes 040-120, Series 100
direct vent (2-pipe)
condensing gas furnace.
Page
Printed in U.S.A.
Catalog No. 58MVB-1SI
4-Way Multipoise
ISO 9001:2000
REGISTERED
As an ENERGY STAR®
Partner, Carrier Corpora-
tion has determined that
this product meets the EN-
ERGY STAR® guidelines
for energy efficiency.
UPFLOW
HORIZONTAL
LEFT
DOWNFLOW
AIRFLOW
Fig. 1-Multipoise Orientations
General ....................................................................................40
Application ..............................................................................41
Condensate Drain Protection ..................................................42
General ....................................................................................42
Select Setup Switch Positions ................................................43
Prime Condensate Trap With Water ......................................44
Purge Gas Lines......................................................................44
Sequence of Operation............................................................44
(Adaptive Mode) ..........................................................45
Cooling Mode ....................................................................46
Thermidistat Mode ............................................................47
Super-Dehumidify Mode...................................................47
Continuous Blower Mode .................................................47
Heat Pump .........................................................................48
Component Test.................................................................48
Adjustments.............................................................................48
Set Gas Input Rate ............................................................48
Set Temperature Rise ........................................................56
Set Thermostat Heat Anticipator ......................................56
Pg 1
58MVB
ama
CERTIFIED
AIRFLOW
HORIZONTAL
RIGHT
AIRFLOW
AIRFLOW
A93041
8-05
Replaces: 58MVP-16SI
®
