Continuous Flow
Gas Booster
SOLAR WATER HEATER
OWNER'S MANUAL
WARRANTY / INSTALLATION INFORMATION
WARNING: Plumber – Be Aware
Use copper pipe ONLY. Plastic pipe MUST NOT be used.
It is a requirement of a solar water heater installation that all pipe work be in copper
and not plastic, due to the effects of high water temperatures and pressures.
Solahart Industries Pty Ltd
This water heater must be installed and serviced by a qualified person.
Please leave this guide with the householder.
AND
ABN 45 064 945 848

Advertisement

Table of Contents
loading

Summary of Contents for Solahart Continuous Flow

  • Page 1 It is a requirement of a solar water heater installation that all pipe work be in copper and not plastic, due to the effects of high water temperatures and pressures. Solahart Industries Pty Ltd ABN 45 064 945 848 This water heater must be installed and serviced by a qualified person.
  • Page 2 Solahart Industries Pty Ltd, Rheem Australia Pty Ltd or Paloma Co., Ltd. Solahart Industries Pty Ltd is the supplier of the Solahart range of continuous flow gas water heaters, manufactured by Paloma Co., Ltd., a world leader in water heater technology and manufacture.
  • Page 3: Table Of Contents

    Save A Service Call ........................11 Installation – Water Heater ....................... 14 Connections – Plumbing ......................23 Connections – Electrical ......................24 Multiple Installations ......................... 25 Commissioning .......................... 28 Draining The Water Heater ....................... 36 Warranty ............................. 37 Solahart Offices ......................... 40...
  • Page 4: About Your Water Heater

    ® The Solahart continuous flow water heater model you have chosen is for outdoor installation only and is only suitable for use with a solar water heater with an over temperature protection system, unless a solar transfer or solar bypass valve is installed. This water heater has been installed as an in-series gas booster to a solar water heater.
  • Page 5 The preset outlet temperature setting of this water heater cannot be Note: maximum adjusted by the householder. The setting can only be adjusted by the recommended supply installer or a Solahart Dealer. temperature to bathrooms and ensuites Note: AS 3498 requires that a water heater provides the means to inhibit the growth of Legionella bacteria in potable water.
  • Page 6 Warning: For continued safety of this water heater it must be installed, operated and maintained in accordance with the Owner‟s Guide and Installation Instructions. The Solahart warranty may not cover faults if relief valves or other safety devices are tampered with or if the installation is not in accordance with these instructions.
  • Page 7 Solahart Dealer. Note: The five year service and routine replacement of any components, if required, are not included in the Solahart warranty. A charge will be made for this work. Only genuine replacement parts should be used on this water heater.
  • Page 8 ABOUT YOUR WATER HEATER CIRCULATED HOT WATER FLOW AND RETURN SYSTEM This model continuous flow water heater can be installed as part of a circulated hot water flow and return “Circulated Hot Water Flow and Return System” system in a building. Refer to on page 19 for further information and notes on this type of installation.
  • Page 9 ABOUT YOUR WATER HEATER DRAINING THE WATER HEATER “Turn Off The Water Heater” Turn off the water heater (refer to on page 8). Open a hot tap (preferably the shower outlet). Unscrew the two drain plugs, one each at the solar heated water inlet and hot water outlet, on the underside of the water heater.
  • Page 10: Water Supplies

    In a corrosive water supply, the water can attack copper parts and cause them to fail. Where the saturation index is less than –1.0, the water is very corrosive and the Solahart warranty does not apply to a copper heat exchanger in a continuous flow water heater.
  • Page 11: Save A Service Call

    SAVE A SERVICE CALL Check the items below before making a service call. You will be charged for attending to any condition or “Terms of the Solahart Warranty” fault, which is not related to manufacture or failure of a part (refer to page 37).
  • Page 12 Collector area is too small For most installations, the number of solar collectors recommended in Solahart literature has been proven to provide the required solar energy to meet the average family needs. However, in some circumstances, it may be necessary to install an additional solar collector.
  • Page 13 If the error code persists, take note of the number of flashes or the numerical code and turn off the hot tap. Phone your nearest Solahart Dealer to arrange for inspection. HIGHER THAN EXPECTED GAS BILLS...
  • Page 14: Installation - Water Heater

    INSTALLATION – WATER HEATER THIS WATER HEATER IS FOR OUTDOOR INSTALLATION ONLY. THIS WATER HEATER IS NOT SUITABLE FOR POOL HEATING. Check the water heater is suitable for the gas type available. (refer to the rating label on the water heater) INSTALLATION STANDARDS The water heater must be installed: by a qualified person, and...
  • Page 15 At least 500 mm between the flue terminal and a fence, wall or other obstruction, in the direction of the flue discharge. Continuous Flow Gas Water Heater Note: * If these horizontal distances cannot be achieved, AS/NZS 5601.1 states an equivalent horizontal distance measured diagonally from the nearest discharge point of the flue terminal to the opening may be deemed to comply.
  • Page 16 Damage to the water heater caused by freezing of the pipe work to or from the water heater is not covered under the Solahart warranty. Refer to AS/NZS 3500.4 for precautions to be taken for installations in frost prone areas. The water heater is not suitable for installation in areas where the ambient temperature falls below -20°C (including wind chill factor).
  • Page 17 The temperature limiting device used with a continuous flow gas water heater should have: a specified „minimum temperature differential‟ between the hot water inlet and the tempered water outlet of no greater than 10°C, and...
  • Page 18 INSTALLATION – WATER HEATER from solar storage tank to solar storage tank In-series Gas Booster for Open Circuit Direct Thermosiphon Solar Water Heater Installation Two Temperature Zones Using a Temperature Limiting Device LEGEND LEGEND from solar storage tank to solar storage tank In-series Gas Booster for Open Circuit Direct Streamline Solar Water Heater Installation Two Temperature Zones Using a Temperature Limiting Device...
  • Page 19 CIRCULATED HOT WATER FLOW AND RETURN SYSTEM A Solahart in-series gas booster can be installed as part of a circulated hot water flow and return system in a building. The preset outlet temperature setting of the water heater must be set to at least 60°C, or at least 70°C to meet the requirement of AS 3498, or at least 70°C if the water temperature decreases by more than...
  • Page 20 INSTALLATION – WATER HEATER DIMENSIONS AND TECHNICAL DATA – 20 LITRE MODELS Model natural 10143204 propane 10143205 Rated delivery litres / min 12.5 (@ 40°C rise) Recovery litres / min (@ 25°C rise) Mass Empty (unpackaged) Hourly Gas Gas Details Test Point Gas Pressure (kPa) Min Gas Pressure Max Gas Pressure...
  • Page 21 INSTALLATION – WATER HEATER DIMENSIONS AND TECHNICAL DATA – 27 LITRE MODELS Model natural 10143274 propane 10143275 Rated delivery 16.7 litres / min (@ 40°C rise) Recovery litres / min (@ 25°C rise) Mass Empty (unpackaged) Hourly Gas Gas Details Test Point Gas Pressure (kPa) Min Gas Pressure Max Gas Pressure...
  • Page 22 INSTALLATION – WATER HEATER TYPICAL INSTALLATION – OUTDOOR LOCATION – 20 LITRE MODEL TYPICAL INSTALLATION – OUTDOOR LOCATION – 27 LITRE MODEL...
  • Page 23: Connections - Plumbing

    CONNECTIONS – PLUMBING All plumbing work must be carried out by a qualified person and in compliance with the Standard AS/NZS 3500.4 and all local codes and regulatory authority requirements. All gas work must be carried out by a qualified person and in compliance with the Standard AS 5601 or AS/NZS 5601.1, as applicable under local regulations, and all local codes and regulatory authority requirements.
  • Page 24: Connections - Electrical

    Warning: Always isolate the water heater before pressure testing the gas supply system. Disconnect the water heater after the isolation valve to prevent the risk of serious damage to the gas control. The Solahart warranty does not cover damage of any nature resulting from failure to observe this precaution. Refer to rating label for gas types and pressures.
  • Page 25: Multiple Installations

    MULTIPLE INSTALLATIONS A multiple installation of Solahart 27 litre in-series gas boosters on a single manifold is possible, using a parallel plumbing arrangement, where large volumes of hot water are required. It is good practice, but not ® essential, to install the water heaters in an Equa-Flow plumbing arrangement.
  • Page 26 MULTIPLE INSTALLATIONS PRESSURE REDUCING VALVE COMMISSIONING PROCEDURE The pressure reducing valves must be set and commissioned for each water heater so the water heaters will turn on and off in sequence when the flow rate increases or decreases to a particular rate. This procedure can be conducted with either cold water or solar heated water, however the temperature of the solar heated water must not exceed 58°C.
  • Page 27 MULTIPLE INSTALLATIONS To set and commission the pressure reducing valves: Commissioning: Commission each of the water heaters prior to setting the pressure reducing valve on “Commissioning” the solar preheat branch to the water heater (refer to on page 28). Turn on services: Turn on the water, gas and electricity to the water heaters. Locking screw: Loosen the locking screw on each SYR valve with a flat bladed screw driver.
  • Page 28: Commissioning

    COMMISSIONING All water heaters are tested and adjusted before dispatch from the factory, however further adjustments may become necessary because of local conditions. Note: If this water heater is installed as part of a multiple installation, i.e. in a bank of water heaters, it will be necessary to isolate the other water heaters and commission the water heaters one at a time.
  • Page 29 Observe the gas pressure reading on INLET GAS PRESSURE TEST the manometer. 865, 866, 867, 868 SERIES - CONTINUOUS FLOW GAS WATER HEATER If the manometer reading is between the minimum and maximum inlet gas pressure ratings on the rating label, no adjustment is required.
  • Page 30 COMMISSIONING BURNER GAS PRESSURE It is necessary to check the burner gas pressure at both the minimum and maximum operational settings. To check and if necessary adjust the operational gas pressures, the electrical supply to the water heater must be switched on, the burners ignited and hot water must be flowing from a hot tap. Warning: The removal of the front panel will expose 240 volt wiring.
  • Page 31 COMMISSIONING cable cable terminal screws cable connectors Kitchen controller Bathroom1 contoller Switch on the electrical supply at the power outlet to the i n us e pri ori ty water heater. Turn on the controller by pressing the on / off button. The priority light (standard controller) or ACTIVE light (Deluxe controller) and the light in the on / off button will both glow.
  • Page 32 MANOMETER Connect the manometer.  Test Point Gas Pressure Adjustment Switch on the electrical supply at the power outlet to the Continuous Flow Water Heater 86,87 Series, 022,024,027 Models water heater. DIP 1 SET OF DIP SWITCHES Open the gas isolation valve fully at the gas inlet to the water heater, if not already open.
  • Page 33 Switch off the electrical supply at the power outlet to the water heater 20 litre model – Disconnect the controller cable from the remote terminal screws. Refit the front panel and screws to the water heater. LED DISPLAY - TEST POINT GAS PRESSURE CONTINUOUS FLOW WATER HEATER...
  • Page 34 If the temperature displayed on the LED display is the desired preset outlet temperature setting, then proceed to step 7, as no further adjustment is necessary. DIP SWITCHES PRESET OUTLET TEMPERATURE SETTINGS CONTINUOUS FLOW FLOW WATER HEATER 86,87 SERIES, 022,024,027 MODELS...
  • Page 35 27 litre model – The temperature display will go blank. Switch off the electrical supply at the power outlet to the water heater. Refit the front panel and screws to the water heater. DIP SWITCHES PRESET OUTLET TEMPERATURE SETTINGS CONTINUOUS FLOW FLOW WATER HEATER 86,87 SERIES, 022,024,027 MODELS...
  • Page 36: Draining The Water Heater

    The frost protection system will be rendered inoperable if electrical power is not available at the water heater. Damage caused by freezing due to the unavailability of power at the water heater is not covered by the “Terms of the Solahart Warranty” Solahart warranty (refer to on page 37).
  • Page 37 2.1 The decision of whether to repair or replace a faulty component is at Solahart’s sole discretion. 2.2 If you require a call out and we find that the fault is not covered by the Solahart warranty, you are responsible for our standard call out charge.
  • Page 38 3. WHAT IS COVERED BY THE SOLAHART WARRANTY FOR THE WATER HEATERS DETAILED IN THIS DOCUMENT 3.1 Solahart will repair or replace a faulty component of your water heater if it fails to operate in accordance with its specifications as follows:...
  • Page 39: Warranty

    If a Solahart unit Tank Serial No Date of manufacture Collector Serial No’s Comments Installer Certification – I certify this installation has been installed and tested in accordance with Solahart Industries Pty Ltd specifications Signature: Installer Customer Date White Copy: Head Office...
  • Page 40: Solahart Offices

    + 1 800 621 5622 For SERVICE Telephone - 1800 638 011 Facsimile International: + 1 334 260 4672 or your nearest Solahart Dealer For Sales Telephone - 1300 769 475 or your nearest Solahart Dealer Revision Date: 2013 November...
