Appendix A: Safety Instructions for the VoIP Gateway

IMPORTANT: Please note the following instructions for your own safety:
The manufacturer assumes no responsibility for any personal injury, damage to property or
subsequent damage that can be attributed to improper use of the device.
All instructions specified in this Installation and Operation Manual should be followed
carefully and the devices should only be used in accordance with these instructions.
A.1 Power Supply
Note: This section only applies to VoIP Gateways equipped with a C6 type connector, see
figure 130.
Figure 130. C6 male socket
The external power supply is designed for operation with a 100-240 V, 50-Hz AC main
network. Never try to connect the equipment to other main systems.
• Internal power supply, 230 V AC + 10% - 15%, 47 – 62 Hz, 25 W.
The equipment cannot be operated during a main system failure. The equipment settings
however, are retained.
The mains socket must be near to the equipment and easy to access. The only way of
interrupting the power supply to the equipment is by removing the main power lead from
the mains socket.
Note: Use a connection cable with an IEC320/EN60320 – C5 type connector.
Figure 131. C5 female socket
A.2 Installation and Connection
Only qualified personnel may install and mount (if required) the equipment.
Make sure the equipment has adequate ventilation, particularly in closed cabinets.
Lay the connection cables in such a way that no-one can trip over them. None of the
cables may be bent excessively, pulled or subjected to mechanical strain.
The equipment is intended for use in dry rooms only.
• Operating temperature: 0 °C to 40 °C, 10% to 90% relative humidity, non condensing
• Storage temperature: -10 °C to 70 °C
The equipment may not be installed and operated under the following conditions:
• In damp, dusty rooms or in rooms where an explosion may occur,
• At temperatures over 40 °C or under 0 °C
