2.2.7 Foreign Objects

Warning!
If a foreign object is inserted into the receiver, immediately power down the receiver and
contact X-Digital Systems technical support. Do not open the receiver, as doing so will
void the receiver‟s warranty.

Physical Installation of the Receiver

2.3
The following section will guide you through the physical installation of the PRO4
receiver. The receiver should be installed in a standard 19-inch rack.

2.3.1 Rack Mounting the Receiver

The PRO4 receiver has been specifically designed to fit into a 19-inch rack. There are
four screw holes provided on the front panel to directly mount the receiver in the rack.
All four screws must be in place after installing the receiver.
Caution!

2.3.2 Uneven Loading of Rack

When installing the PRO4 receiver into a rack, make sure to place heavier pieces of
equipment on the bottom and lighter pieces on the top.
Caution!

Connecting the Receiver to a Satellite Dish

2.4
This section contains information required for connection your PRO4 receiver to a
satellite hookup.
1226 R830002-1060
Rev A
Inserting any type of foreign object into the ventilation holes of the
receiver can result in shock or serious injury of the operator.
Do not paint mounting ears; it hinders the grounding path from
the receiver to the rack.
Uneven loading may cause the rack to be unstable and
hazardous.
