2.2.2 Proper Ventilation

Air vents on the side and rear of the receiver are provided to ensure proper air flow
through the receiver unit. In order to ensure proper operation the PRO4 receiver should
be located such that its ventilation is not impeded. In a rack environment, at least two
inches on the sides and at least 5 inches in the rear should be provided. Proper ventilation
will help ensure the receiver performs both safely and efficiently.

2.2.3 Heat, Humidity, and Dust

In order to avoid unnecessary internal damage, avoid placing the receiver next to external
heat sources such as heaters, direct sunlight, heating ducts, etc. Also avoid locations of
high humidity, dust, and vibration.

2.2.4 Power Cord Cabling

Avoid running the power cord across places of high traffic where it can be crimped or
tripped over. Make sure the cords are securely fastened to both the wall outlet or power
strip, and the back of the receiver. Do not place objects on or leaning against power
cords.

2.2.5 Proper Grounding

When the receiver is installed, make sure that the antenna and coaxial cable are properly
grounded to avoid static build up and voltage spikes which may occur due to lightning or
other types of power surges. Proper earth grounding of the rack system should be
maintained at all times, with special attention paid to any connections which go through
power strips.
Make sure all power strips are properly grounded.
Warning!

2.2.6 Circuit Overloading

The PRO4 receiver can draw up to 0.5 Amps at 120VAC as indicated on the back of the
receiver. When adding the receiver to an already existing rack setup, take care to ensure
the maximum current rating of the circuit is not exceeded.
