4.2.2.1 The SETUP:NETWORK Sub-Menus

Starting from the Main Menu and navigating to Setup option and pressing ▼, and then
navigating to Network option and pressing SET, a user will have access to the Network
sub-menus. In these sub-menus, the receiver‟s network settings can be made. The
network menu options include:
DHCP (on or off): allows the user to specify a dynamic or static IP (on or off
respectively).
LAN IP Address: in the case of a static IP, this allows the user to specify the LAN
IP address of the receiver.
LAN Subnet Mask: allows the user to specify the LAN Subnet mask.
WAN Address: specify the WAN IP address.
WAN Subnet Mask: specify the WAN subnet mask.
Gateway: allows the user to specify the default gateway to direct traffic to.
Test: when SET is pressed, this menu offers the user two test options. Pressing 1
allows you to ping the internet to ensure the network connection is functioning,
and pressing 2 tests the receiver‟s website to ensure it is functioning. Pressing 3
exits from the Test menu.
