Inland SwapTop 10630 User Manual

vacuum to remove any debris from the bottom air vents on the unit.
• Always secure blades to the fl at side of the motor shaft. You can use a thin coat-
ing of Inland MotorShaft Lubricant™ (Inland no. 50022) or petroleum jelly to help
keep the arbor from seizing on the shaft.
• Check the power cord periodically for cuts or damage.
• Check all coolant lines and tubes to see that they are not clogged.
Product Specifi cations
Convertible Motor Unit
Variable Speed Motor Un
Permanent Magnet DC motor, rectifi ed for AC outlets
Max Torque: 48 oz-in
Max RPM: 2800
Shaft OD: .312" (5/16") Stainless Steel
Available in 115V or 230/240V models
Two Year Full Confi dence Warranty

Parts and Accessories

40960 6½" x .020" Trim Saw Blade - Standard: A great all-around use diamond
blade for cutting hard materials.
40961 6½" x .012" Trim Saw Blade - ThinCut™: A little thinner diamond blade that
cuts a little faster and consumes a little less material, but also a bit less durable.
40968 6½" x .008" Trim Saw Blade - Extra ThinCut™: Our thinnest diamond blade
for use on precious materials when waste in cutting needs to be minimized.
90964 WoodCut™ 6½" Trim Saw Blade: Toothed blade for cutting wood and some
plastics. 10 TPI (teeth per inch).
69801661 Rip Fence Kit: Use to saw uniform width strips and pieces.
10885 8" Flat Lap Conversion Kit: Convert any SwapTop Table Saw into a fl at lap
machine for shaping and polishing. Includes 4 graduated grit diamond laps, master
lap, polishing pad, and compound.
10685 6" Flat Lap Conversion Kit: Convert any SwapTop Table Saw into a fl at lap
machine for shaping and polishing. Includes 4 graduated grit diamond laps, master
lap, polishing pad, and compound.
10655 Grinder / Shaper Conversion Kit: Converts any SwapTop Table Saw into a
diamond grinder / shaper.
So that we can offer you the highest level of service possible, please take a
moment to register your product by going to www.inlandcraft.com or mailing in the
registration card.
Questions about your grinder can be answered by visiting the Inland Craft web site
at www.inlandcraft.com, watching our online videos at www.inlandcraft.com/videos, by
emailing Customer Service at helpdesk@inlandcraft.com or by calling Inland Customer
Service at 1-800-521-8428 Monday through Friday, 9:00 am to 5:00 PM EST.
Inland Craft Products, Co.
32052 Edward Drive
Madison Heights MI 48071
www.facebook.com/inlandcraft
www.inlandcraft.com
Rev No. 8 / 01-2013
Table Saw
Height: 6½"
Blade Diameter: 6½"
Work Surface: 12" x 9 3/4"
Maximum Cutting Thickness: 1"

Service

@inlandcraft
Stock No. 69861060
SwapTop™ Table Saws
Thank you for buying this Inland product. These instructions cover assembly
and use of the SwapTop™ Table Saw models 10630 and 10670 plus SwapTop™
Table Saw Conversion Kits 10635 and 10675. Please read all the instructions to
understand the correct components, set-up, and use of your machine.

Always wear safety glasses or goggles. You can use the FaceShield™ or Mag-
naShield™ for additional protection.

Plug into a grounded electrical system. Do Not override the grounding system.

If your motor unit has a speed control feature, make sure that you set it at the
maximum speed for proper operation.

Always unplug your machine when switching between set-ups, installing blades,
and making adjustments.

Place on a sturdy, level, water tolerant surface at a comfortable working height.

Never operate with guard covers and safety features removed or disabled.
Use the chart and picture to verify you have the parts needed for your model
Name Qty
A Machine Base 1
B Motor Unit 1
C Removable Work Surface 1
D Blade Guard 1
E Protractor 1
F Blade Arbor & Nut 1
G Plastic Drain Tube 1
H 5/64" Allen Wrench 2
not shown:
6½" Saw Blade 1
WaterDrip Kit 1
Users Guide

Safety

Parts List
10630 10635 10670
yes no yes
yes no yes
yes yes yes
yes yes yes
yes yes yes
yes yes yes
yes yes yes
yes yes yes
WoodCut™ WoodCut™ Diamond
- - yes
10675
no
no
yes
yes
yes
yes
yes
yes
Diamond
yes
