Secure tank struts (13) to pole.
4.
Rotate non-secured ends of tank
struts (13) outward to mounting
holes in tank as shown.
WARNING!
TIGHTEN BOLT (9) IN
LOCK NUT (12) UNTIL
FLUSH (EVEN) WITH
LOCK NUT'S OUTER
EDGE.
5.
Secure non-secured ends of tank struts (13) to
tank as shown. Repeat for opposite side.
16
12
12
17
11
13
11
12
12
14
13
13
13
1
13
1
04/03
P/N 211984A
