- Page 1 DFG TitanCoil Heavy Duty Binding Machine Instruction Manual Provided By http://www.MyBinding.com http://www.MyBindingBlog.com...
- Page 2 TitanCoil - Heavy Duty Punch and Electric Binding Machine Full Die Disengagement Full Die Disengagement Pins Pins Electrical Power Roller Binding Punch Handle For clean and complete punching For clean and complete punching Features extra DURABLE roller For punching up to...
- Page 3 Warning: Do not connect this product to electrical power or attempt to operate it before you read these operating instructions and have been fully trained to operate this product. 1. Indoor use only. Do not expose to rain. 2. Keep hands, long hair, neckties, necklaces and other loose articles away from roller.
-
Page 4: Installation
Dear Customer, Thank you for purchasing TitanCoil machine. The following are basic installation and operation instruction. For advanced punching and binding, please contact DFG. Installation Remove the black knob from machine. Install the punch handle. Install the black knob back to machine. Connect power cord and connect the foot pedal. - Page 5 How to Bind Books with Power Roller (up to 7/8”) 1. Manually turn the spiral coil into the first 4 or 5 holes 2. Press the foot pedal. Touch the coils against the moving roller to spin the coil through the book. (You can speed up binding by moving the book to the right side while the roller is spinning the coil through the book)
- Page 6 3. Cut and crimp the ends of the spiral coil. Right handed A. Hold pliers with red dot up, with the coil near you. B. Place pliers with jaws inside the coil, near the center. C. Close the pliers to cut the coil and keep them closed D.
-
Page 7: Specification
How to Make Books Manually (any thickness) Manually turn your coil into the book. This is a very easy process. (Tip: It will be much easier to twist the front end of coils) Cut and crimp the coils (see #3 of power roller binding) How to Determine Appropriate Coil Size There are three ways you can choose an appropriate coil size:...
