SERVICING PRECAUTIONS

BEFORE ATTEMPTING TO SERVICE OR ADJUST ANY PART OF THE VACUUM CLEANER, DIS-
CONNECT THE ELECTRICAL POWER SUPPLY CORD FROM THE WALL OUTLET.
1. Motor exchange
1) Separate the Body Cover and Body Base by unfastening
the screws.
2) Disconnect the lead wires.
3) Lift the old motor and replace it with a new one.

SPECIFICATIONS

• MODEL : REFER TO THE COVER PAGE
• POWER SOURCE : ON RATING PLATE
• POWER CONSUMPTION : ON RATING PLATE
• POWER CONTROL :
- MAIN : ROTARY ON BODY
(V-C3850RD/RT/RDV/RTV)
(V-C3854RTV)
(V-C3860RD/RT/RDV/RTV)
ON/OFF ON BODY
(V-C3850ND/NT/NDV/NTV)
(V-C3852ND/NT/NDV/NTV)
-SUB : VACUUM POWER ADJUSTMENT BY
SLIDE KNOB
• CAPACITY : 3.3 L
• CORD LENGTH : 7 m
• HOSE LENGTH : 1.5 m / 1.8 m
• NET WEIGHT : 4.1 kg
• PACKING WEIGHT : 7.0 kg
• NET DIMENSION : 400 280 220 (L W H)mm
• PACKING DIMENSION : 495 330 290 (L W H)mm
• This specifications are subject to change according to the buyer's request.

FEATURES

THIS VACUUM CLEANER IS THE MOST MODERN STYLE GOODS, SUITABLE FOR HOUSEHOLD USE
AND IT RUNS AFTER A NEW VARIATION IN ORDER TO MEET MODERN LIFE SENSE BY IMPROVING THE
DESIGN, THE STRUCTURE AND THE POWER.
1. Strong Suction Power
This vacuum cleaner has a strong suction power because
it utilizes a highly efficient and powerful motor.
2. Automatic Cord Winding Mechanism
It is very convenient becasue it winds the cord
automatically after operating the unit.
3. Vacuum Power Adjustment
It is very convenient because vacuum power varies with
cleaning work by rotating the control button.
(with steel pipe)
565 330 290 (L W H)mm
(with telescopic pipe)
2. In case of exchanging other parts, refer to the
exploded view.
• ATTACHMENTS
HOSE ......................................................................... 1EA
STEEL PIPE ASS'Y.................................................... 2EA
TELESCOPIC PIPE ASS'Y ........................................ 1EA
PLASTIC PIPE .......................................................... 2EA
NOZZLE ASS'Y ...........................................................1EA
CREVICE TOOL (ON BOARD) .................................. 1EA
DUST BRUSH (ON BOARD).......................................1EA
CLOTH BAG ASS'Y (OPTION) ...................................1EA
EXTRA PAPER BAG ASS'Y (PAPER, OPTION) ........1EA
UPHOLSTERY NOZZLE(OPTION).............................1EA
QUILT, NOZZLE ASM(OPTION).................................1EA
4. Convenient Push Button Switch
Using the switch located in the main body, this vacuum
cleaner can be operated easily.
5. Excellent Running
Running is execllent by adopting large wheel.(˘ 150)
6. Miscellaneous
1) The dust indicator shows you red color when to
exchange the filter bag or to clean the cloth bag.
2) The washable cloth bag can be used for a long time.
-4-
