6.

REPLACEMENT PARTS

Contact an Authorized DROLET Dealer to obtain any of these parts. Never use substitute materials. Use of non-
approved parts can result in poor performance and safety hazards.
#
1 1/2 " CHROME PLATED COIL HANDLE
2 CAST IRON DOOR WITH GASKET, HANDLE AND LATCH
3 BLACK 1/2'' ROUND X 9' GASKET KIT WITH ADHESIVE
4 HANDLE AND LATCH KIT
5 DOOR LATCH KIT
6 SPRING TENSION PIN 5/32" DIA X 1 1/2" LONG
7 SELF-ADHESIVE 1/8" X 3/8" GASKET HB26
8 ARCHED REPLACEMENT GLASS
9 BOTTOM GLASS RETAINER
10 TOP GLASS RETAINER
11 SCREW #8 - 32 X 5/16'' TRUSS QUADREX ZINC
12 BAFFLE
13 COMBUSTION POT ASSEMBLY
14 BURN POT SUPPORT ASSEMBLY
15 ROUND GASKET AND SILICONE KIT 5/16" X 6.6'
16 FIRE POT LATCH
17 ZINC WASHER ID 13/32" X OD 13/16"
18 WING NUT 3/8"-16
19 ASH DRAWER ACCESS DOOR
20 PIN 5/16" x 1 1/2"
21 ASH DRAWER
22 HING PIN 5/16" x 2"
23 500W - 120V IGNITER
24 SPRING CLIP
25 LEVELING BOLT 3/8-16 X 1 1/2"
26 FRESH AIR INTAKE TUBE GASKET
27 THERMODISC 36T11 L250-25 AUTOMATIC
28 2 FOLD ALUMINUM LINER 3" X 14'' COMPRESSED TO 7"
29 3" TO 4" STAINLESS STEEL COLLAR
30 THERMODISC 36T12 F160
31 JUNCTION WIRE MAIN CONTROL BOARD TO LCD
32 DECORATIVE RIGHT SIDE ASSEMBLY
33 HOUSING FOR ELECTRONIC CONTROL BOARD MEMBRANE
34 CONTROL BOARD MEMBRANE SWITCH
35 BLOWER WITH CAPACITOR (500 PCM, 115v, 60Hz, 1100 TPM)
36 BLOWER ANTI-VIBRATION CUSHION
37 RIGHT BLOWER MOUNT
38 BLOWER (500 CFM, 115v, 60Hz, 1100 RPM)
39 CAPACITOR 10MF
40 CAPACITOR HOUSING
41 BUILT TO ORDER
42 WOOL SEAL FOR BLOWER
43 PRESSURE SWITCH
44 3/8'' X 42" SILICONE HOSE
45 AIR PUMP 120VAC/60Hz 0.15A
46 AIR INTAKE BOX ASSEMBLY
47 COMBUSTION BLOWER 120V-60Hz
ITEM
47
# PIÈCES Qty
AC07867 1
SE24219 1
AC06900 2
AC09155 1
AC09185 1
30101 1
40018 5.1333
PL62417 1
PL62415 1
PL62416 1
30124 12
PL62412 1
SE62254 1
SE62302 1
AC06300 1
30686 1
30205 1
30416 1
SE62325 1
30341 2
SE62290 1
30363 2
44133 1
30710 24
30050 4
21345 1
44059 1
21077 1
49400 2
44058 1
60327 1
SE62340 1
SE62330 1
44139 1
SE44108 1
30335 4
PL62359 2
44108 1
60323 1
PL62420 1
99999 1
21350 1
44029 1
49606 2
60047 1
SE62306 1
44104 1
