Installation and Operation Manual
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND
INSTALLATION INSPECTION REQUIREMENTS IN YOUR AREA.
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS
PELLET
FUEL-BURNING
INSTRUCTIONS COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR
EVEN DEATH.
This manual is available for free download on the manufacturer's web site. It is a
copyrighted document. Re-sale is strictly prohibited. The manufacturer may update this
manual from time to time and cannot be responsible for problems, injuries, or damages
arising out of the use of information contained in any manual obtained from unauthorized
sources.
READ AND KEEP THIS MANUAL FOR REFERENCE
Printed in Canada
Eco-65
PROFESSIONAL IS STRONGLY
ROOM
HEATER.
Safety tested according to ULC S627,
UL1482 and ASTM E1509 by
Intertek Testing Services.
INSTALLATION BY A
RECOMMENDED
Fabricant de poêles international inc.
250, rue de Copenhague, St-Augustin-de-
Desmaures (Québec) Canada G3A 2H3
Téléphone : (418) 878-3040
Télécopieur : (418) 878-3001
www.drolet.ca
FAILURE
TO
FOLLOW
THESE
45725A
23-06-2014

Advertisement

Table of Contents
loading

Related Manuals for Drolet Eco-65

Summary of Contents for Drolet Eco-65

  • Page 1 Installation and Operation Manual Eco-65 Safety tested according to ULC S627, UL1482 and ASTM E1509 by Intertek Testing Services. INSTALLATION BY A PROFESSIONAL IS STRONGLY RECOMMENDED Fabricant de poêles international inc. 250, rue de Copenhague, St-Augustin-de- Desmaures (Québec) Canada G3A 2H3 Téléphone : (418) 878-3040...
  • Page 2 Eco-65 Installation and Operation Manual THANK YOU FOR CHOOSING THIS DROLET PELLET STOVE As one of North America’s largest and most respected pellet stove, wood stove and fireplace manufacturers, Stove Builder International takes pride in the quality and performance of all its products.

  • Page 3: Table Of Contents

    Eco-65 Installation and Operation Manual Table of contents Introduction .............................. 5 1.1 About Pellet Heating ..........................5 1.1.1 Top 10 Reasons for Buying a Pellet Stove ................... 5 1.2 Eco-65 Specifications ..........................6 1.3 Overall Exterior Dimensions ........................7 PART A – INSTALLATION ..........................8 Installation Safety Information .......................
  • Page 4 Eco-65 Installation and Operation Manual Maintenance ............................35 7.1 Stove Maintenance ..........................35 7.1.1 Recommended Maintenance Schedule ..................35 7.1.2 Cleaning the Baffle, the Heat Exchanger and the Combustion Chamber ........36 7.1.3 Exhaust Channel and Exhaust Blower Maintenance ..............39 7.1.4...

  • Page 5: Introduction

    Eco-65 Installation and Operation Manual 1 Introduction 1.1 About Pellet Heating Pellet stoves offer a dramatic improvement in the convenience of heating with solid fuel. Wood pellets are handled in bags and are therefore easily and cleanly stored. A single loading of a pellet stove can provide long hours of warmth.

  • Page 6: Eco-65 Specifications

    Eco-65 Installation and Operation Manual 1.2 Eco-65 Specifications Fuel Type Wood pellets Test Standards (safety) ULC S627, ASTM E1509 and UL 1482 Heating capacity range* 800 to 2600 sq ft (74 to 242 m Input BTU range** From 10 500 BTU/h to 65 000 BTU/h...

  • Page 7: Overall Exterior Dimensions

    Eco-65 Installation and Operation Manual 1.3 Overall Exterior Dimensions FRESH AIR INLET EXHAUST...

  • Page 8: Part A - Installation

    Eco-65 Installation and Operation Manual PART A – INSTALLATION 2 Installation Safety Information 2.1 Installation Warnings, Cautions and Recommendations  PROFESSIONNAL INSTALLATION IS HIGHLY RECOMMENDED.  YOU MAY NEED TO OBTAIN A BUILDING PERMIT FOR THE INSTALLATION OF THIS STOVE AND ITS VENTING SYSTEM. CONSULT YOUR MUNICIPAL BUILDING DEPARTMENT OR FIRE DEPARTMENT BEFORE INSTALLATION TO DETERMINE THE NEED TO OBTAIN ONE.
  • Page 9 Eco-65 Installation and Operation Manual  DO NOT INSTALL A FLUE DAMPER IN THE EXHAUST VENTING SYSTEM OF THIS UNIT.  DO NOT CONNECT THIS STOVE TO ANY OTHER EXISTING VENTING SYSTEM SERVING ANOTHER APPLIANCE.  DO NOT CONNECT TO OR USE IN CONJUNCTION WITH ANY AIR DISTRIBUTION DUCTWORK.

  • Page 10: Regulations Covering Pellet Stove Installation

    Eco-65 Installation and Operation Manual 2.2 Regulations Covering Pellet Stove Installation When installed and operated as described in these instructions, this pellet stove is suitable for use as a freestanding heater in residential installations. In Canada, the CSA B365 Installation Code for Solid Fuel Burning Appliances and Equipment and the CSA C22.1 Canadian National Electrical Code are to be followed in the absence of...

  • Page 11: Before Operating Your Stove

    Eco-65 Installation and Operation Manual 2.3 Before Operating Your Stove Some minor installation and adjustment are required prior to use:  The handle and door must be adjusted; (see section 7.1.10: Door Adjustment)  The stove must be leveled using threaded legs;...

  • Page 12: Clearances To Combustible Material

    Eco-65 Installation and Operation Manual 3 Clearances to Combustible Material The clearances shown in this section have been determined by tests according to procedures set out in safety standards ULC S627 (Canada), ASTM E1509 (U.S.A). When the pellet stove is installed so that its surfaces are at, or beyond, the minimum clearances specified, combustible surfaces will not overheat under normal and even abnormal operating conditions.

  • Page 13: Floor Protection

    Eco-65 Installation and Operation Manual 3.3 Floor Protection For floor protection clearances refer to the following table. FLOOR PROTECTION LETTER CANADA 18″ (460 mm) 6″ (155 mm) N/A (USA only) 6″ (155 mm) N/A (Canada 8″ (205 mm) only) N/A (Canada 8″...

  • Page 14: Venting System

    Eco-65 Installation and Operation Manual 4 Venting system 4.1 General Even though the chimney draft is mechanical, a suitable venting system will ensure a natural draft which will prevent smoke spillage in your home if a power outage occurs. Moreover, a suitable venting system configuration will help getting the best efficiency out of your stove when installed in accordance with the required EVL (see Section 4.3: Equivalent Vent...
  • Page 15 Eco-65 Installation and Operation Manual  2 horizontal run of 1’ = (2 X 1’) X 1’ = 2’ of EVL  1 elbow 90° or "Tee" = 5’ of EVL  3 vertical length of 4’ = (3 X 4’) X 0.5’ = 6’ of EVL ...

  • Page 16: Termination Location

    Eco-65 Installation and Operation Manual WARNING: To reduce the risk of smoke spillage there should always be at least one foot of vertical rise for each foot of horizontal run. In all cases, at least 3 feet of vertical rise is needed.

  • Page 17: Permitted Termination Location

    Eco-65 Installation and Operation Manual 4.4.1 Permitted Termination Location Refer to NFPA 211 (USA) or CSA B365 (Canada) for rules for the distance of exit terminal from windows and openings. The exit terminal of a mechanical draft system, other than a direct vent appliance shall be located in accordance with the following.

  • Page 18: Installation Configurations

    Eco-65 Installation and Operation Manual United States:  Not Less than 36’’ (91 cm) above any forced air inlet located within 10 feet (305 cm);  Not Less than 48’’ (122 cm) below and horizontally from, or one foot (30 cm) above, any door, window or gravity air inlet into any building;...

  • Page 19: Through Wall Installation (Main Floor Or Basement)

    Eco-65 Installation and Operation Manual 4.5.2 Through Wall Installation (Main Floor or Basement) 1. Position stove following clearances given in Section 3: Clearances to Combustible Material and following vent manufacturer’s instructions. Then locate the position of the exhaust pipe in the wall.

  • Page 20: Through Roof Installation

    Eco-65 Installation and Operation Manual 4.5.3 Through Roof Installation Position stove following clearances given Section 3.2: Minimum Clearances to Combustibles and following vent manufacturer’s instructions. 2. Install a cleanout tee to the stove exhaust. If necessary, use a horizontal additional length between the exhaust and the tee.

  • Page 21: Through A Factory Built Chimney

    Eco-65 Installation and Operation Manual 4.5.4 Through a Factory Built Chimney To make an installation through a factory built chimney, run a 4" stainless steel liner inside the factory built chimney. 1. Position stove following clearances given Section 3.2: Minimum...

  • Page 22: Through An Existing Masonry Fireplace

    Eco-65 Installation and Operation Manual 4.5.5 Through an Existing Masonry Fireplace 1. Position stove, following clearances shown Section 3.2: Minimum 12”-18” Clearances Combustibles following vent manufacturer’s instructions. 2. Build and Install a blocking plate inside the chimney to seal the fireplace damper.

  • Page 23: Through An Existing Masonry Chimney

    Eco-65 Installation and Operation Manual 4.5.6 Through an Existing Masonry Chimney 1. Position stove following clearances shown Section 3.2: Minimum 12”-18” Clearances Combustibles following vent manufacturer’s instructions. 2. Mark the center of the hole where the vent pipe will go through the masonry chimney.

  • Page 24: Part B - Operation

    Eco-65 Installation and Operation Manual PART B - OPERATION 4.6 General Information 4.7 Operation Warnings, Cautions and Recommendations  KEEP THIS MANUAL FOR REFERENCE.  DURING THE FIRST FEW FIRES, YOUR STOVE WILL EMIT AN ODOR AND A SMALL AMOUNT OF FUMES AS THE HIGH TEMPERATURE PAINT CURES OR BECOMES SEASONED TO THE METAL.
  • Page 25 Eco-65 Installation and Operation Manual  THE VIEWING DOOR MUST BE CLOSED AND LATCHED AT ALL TIMES DURING OPERATION. THE ASH DRAWER ACCESS PANEL MUST ALSO BE CLOSED DURING OPERATION.  NEVER TRY TO REPAIR OR REPLACE ANY PART OF THE STOVE UNLESS INSTRUCTIONS ARE GIVEN BY THE MANUFACTURER.
  • Page 26 Eco-65 Installation and Operation Manual  THE STOVE WILL NOT OPERATE DURING A POWER OUTAGE. IF AN OUTAGE DOES OCCUR, CHECK THE STOVE FOR SMOKE SPILLAGE. OPENING A WINDOW WILL PREVENT NEGATIVE PRESSURE AND SMOKE SPILLAGE IN THE ROOM.  DO NOT UNPLUG THE STOVE IF YOU SUSPECT IT IS MALFUNCTIONING. TURN IT OFF, MONITOR IT AND CALL YOUR DEALER IF NECESSARY.

  • Page 27: Zone Heating And How To Make It Work For You

    Eco-65 Installation and Operation Manual 4.7.1 Zone Heating and How to Make It Work for You Your new pellet stove is a space heater, which means it is intended to heat the area it is installed in, as well as spaces that connect to that area, although to a lower temperature. This is called zone heating and it is an increasingly popular way to heat homes or spaces within homes.

  • Page 28: Where To Store Bags Of Pellets

    5 Stove Controls 5.1 Control Panel The blowers and automatic fuel supply are controlled from a control panel (A) on the right- hand side of the ECO-65. The control panel functions are as follows:...

  • Page 29: Mode Button

    Eco-65 Installation and Operation Manual Control panel screen Operation mode : THERMOSTAT: Thermostatic control MANUAL (optional) Button to select Button to clear between modes most error codes Button to change the Button to feed and start convection fan speeds when the auger is empty Pellet burn rate Button + and –...

  • Page 30: Fuel Feed Button

    Eco-65 Installation and Operation Manual 5.1.2 Fuel Feed Button When the “Fuel Feed” button is pushed the stove will feed pellets continuously into the burn pot during 1 minute and then the ignition cycle will begin. The “Feed and Start” message will appear.

  • Page 31: Adjustments

    Eco-65 Installation and Operation Manual 5.2 Adjustments 5.2.1 Selecting the Combustion Level (Heat Rate) The heat input of the stove varies between 10,500 BTU/h to 65,000 BTU/h. To change the combustion level select the + or – button when the stove is in function.

  • Page 32: Everyday Startup

    Eco-65 Installation and Operation Manual 6.2 Everyday Startup Before starting the stove, make sure there is enough pellets in the hopper and that the recommended maintenance schedule been followed (see Section 7.1.1: Recommended maintenance schedule). Press the icon for either MANUEL or THERMOSTAT.

  • Page 33: Pilot Mode Selection

    Eco-65 Installation and Operation Manual To use this mode, the button must be pushed to “Thermostat” upon starting the stove. The heat setting is then selected using the selector “+ or –”. When set in thermostatic mode, the stove will automatically run at the heat level selected until the set room temperature is reached.
  • Page 34 Eco-65 Installation and Operation Manual maintenance has been done properly. Press the and the buttons and hold simultaneously for 2 seconds to reset the stove. If an code occurs twice, call you dealer. He will be able to give you some recommendations so this code won’t appear again.

  • Page 35: Maintenance

    Eco-65 Installation and Operation Manual 7 Maintenance 7.1 Stove Maintenance 7.1.1 Recommended Maintenance Schedule Use this as a guide when used under average conditions. Weekly Twice a year Annually Components or after or after ± 250 pounds ± 1 tons ±...

  • Page 36: Cleaning The Baffle, The Heat Exchanger And The Combustion Chamber

    Eco-65 Installation and Operation Manual OR OTHERWISE LOCALLY DISPERSED, THEY SHOULD BE RETAINED IN THE CLOSED CONTAINER UNTIL ALL CINDERS HAVE BEEN THOROUGHLY COOLED. 7.1.2 Cleaning the Baffle, the Heat Exchanger and the Combustion Chamber Cleaning of the heat exchanger must be done on a regular basis (see Section 7.1.1: Recommended Maintenance Schedule).
  • Page 37 Eco-65 Installation and Operation Manual Using the provided sweeping rod, sweep up and down each exchanger. Make sure you go all the way down to the bottom. Reinstall the access panel to the combustion chamber and tighten the wing nuts.
  • Page 38 Eco-65 Installation and Operation Manual 1) Open the door and turn the lock (A) that can be found above the door opening. 2) Once the baffle (B) is unlocked, it will pivot downwards automatically. 3) Lift the baffle (B) from its pivots (C). Pull it down.

  • Page 39: Exhaust Channel And Exhaust Blower Maintenance

    Eco-65 Installation and Operation Manual 4) Take out the baffle from the combustion chamber. IT IS HIGHLY RECOMMENDED TO CLEAN THE EXHAUST CHANNEL (SEE SECTION 7.1.3: EXHAUST CHANNEL AND EXHAUST BLOWER MAINTENANCE) IMMEDIATLY AFTER CLEANING THE HEAT EXCHANGER 7.1.3 Exhaust Channel and Exhaust Blower Maintenance Exhaust channels and the exhaust blower are located on the left hand side of the stove.
  • Page 40 Eco-65 Installation and Operation Manual Using a Philips or Robertson screwdriver, remove both clean-out traps by unlocking them. Push the screw and give it a counter-clockwise quarter turn. Locate both openings. Using the provided scraper, remove the dirt in the bottom channel of the heat exchangers.

  • Page 41: Cleaning The Burn Pot

    Eco-65 Installation and Operation Manual 7.1.4 Cleaning the Burn Pot The burn pot must remain clean and the holes should not be obstructed by combustion residues (ashes or clinkers). 1. Clean the burn pot using the scraper provided with the stove or a smaller one.
  • Page 42 Eco-65 Installation and Operation Manual 2. The burn pot simply sits onto the air intake channel. You must lift to remove it from the stove. Two small pins guide the burn pot in place. Make sure that the burn pot is well in place before turning on the stove (as shown in the diagram).

  • Page 43: Ash Removal

    Eco-65 Installation and Operation Manual Verify that the clean out trap gasket is still in good condition, replace it if needed (3/16’’ black round gasket, AC06815). 7.1.5 Ash Removal 1. To empty the ash drawer (A) of its contents, open the ash pan access door by loosening the round knob on the bottom left hand side.

  • Page 44: Cleaning The Air Wash System

    Eco-65 Installation and Operation Manual WARNING: ASH PAN MUST BE IN PLACE AND THE ASH PAN ACCESS DOOR MUST BE KEPT CLOSED AT ALL TIMES WHEN THE STOVE IS IN USE. 7.1.6 Cleaning the Air Wash System Vacuum the ashes that may have accumulated into the airwash system inlet between the bottom glass retainer and the glass.

  • Page 45: Door Gasket Maintenance

    Eco-65 Installation and Operation Manual 7.1.9 Door Gasket Maintenance It is important to maintain the door gasket in good condition. After a while, the gasket will wear and compress; adjusting the door may then be required. If the door adjustment is not sufficient, replace the door gasket with a genuine part.

  • Page 46: Venting System Maintenance

    Eco-65 Installation and Operation Manual 7.2 Venting System Maintenance CAUTION: REGULARLY EXAMINE THE VENTING SYSTEM, THE JOINTS, AND THE SEALING TRIMS TO ENSURE THAT THE SMOKE AND THE COMBUSTION GASES ARE NOT DRAWN BY THE CONVECTION BLOWER. The most efficient method to sweep the venting system is by using a 4'' pellet brush depending on your installation.

  • Page 47: Troubleshooting

    Eco-65 Installation and Operation Manual 8 Troubleshooting When you have issues with your stove, your first reaction may be to call technical support. This section will help you save time and money by enabling you to solve simple problems by yourself.

  • Page 48: Testing A Component

    Eco-65 Installation and Operation Manual 8.2 Testing a Component If you suspect that an electrical component to be defective, you can test it by following the procedure given below. Note that you will be able to test only components when the stove is OFF and that all the components are no more in function.
  • Page 49 Eco-65 Installation and Operation Manual Push the control key to proceed. The frequency of the power source is displayed. Push any control key to proceed. The tension of the power source is displayed. Push any control key to proceed. Displays if polarity is good (POLP) If polarity is reversed (POLF).
  • Page 50 Eco-65 Installation and Operation Manual Displays the temperature read by the thermistor. Push any control key to proceed. Convection blower test. Push the control key to proceed. Combustion blower test. Push the control key to proceed. Exhaust blower test. Push the control key to proceed.

  • Page 51: Main Error Codes, Possible Causes And Solutions

    Eco-65 Installation and Operation Manual 8.3 Main Error Codes, Possible Causes and Solutions WARNING: RISK OF ELECTRICAL SHOCK. IF YOU NEED TO MANUALLY TEST, MANIPULATE OR REPLACE ANY COMPONENTS, THE STOVE NEEDS TO BE DISCONNECTED FROM THE WALL OUTLET. This section contains main error codes, possible causes and many suggestions to guide you in resolving them.
  • Page 52 Eco-65 Installation and Operation Manual ALARM CODES CHART MESSAGE CORRESPONDING WARNING Pressure switch warning. Warning caused by the automatic L-250 sensors: it is located over the pellet housing. Hopper is empty Lighting warning. Hopper lid stayed open more than 3 minutes.

  • Page 53: P Code

    Eco-65 Installation and Operation Manual 8.3.1 P Code STOVE SHUTS OFF AND APPEARS ON CONTROL BOARD Possible Remedies: (Unplug stove first Possible Causes: when possible) 1. Pressure tap (located on the exhaust Pull off the air hose from the exhaust blower blower) is blocked.

  • Page 54: H Code

    Eco-65 Installation and Operation Manual check fuse F4 and F5 on the control board. A defective fuse will be darkened or will have a broken filament. If the fuses are good, the combustion or exhaust blower is probably defective. Replace the faulty part.
  • Page 55 Eco-65 Installation and Operation Manual 4. The stove needs maintenance. Refer to Section 7: Maintenance. 5. The burn pot is not installed properly. Make sure the burn pot is installed correctly (see Section 7.1.4: Cleaning the Burn Pot). 6. The baffle is not installed properly or holes Make sure the baffle is well installed and the may be blocked.
  • Page 56 Eco-65 Installation and Operation Manual THIS PELLET STOVE IS EQUIPED WITH MULTIPLE DEVICES TO ENSURE YOUR SAFETY. IF A WARNING ERROR CODE STOPS YOUR STOVE ON SEVERAL OCCASIONS, IT IS MORE THAN LIKELY THAT THE STOVE DOES NOT EXHAUST PROPERLY.

  • Page 57: E Code

    Eco-65 Installation and Operation Manual 8.3.3 E Code STOVE SHUTS OFF AND DISPLAYS WARNING CODE Possible Remedies: (Unplug stove first Possible Causes: when possible) 1. The stove ran out of pellets. Refill the hopper. Erase the error code and press the auger button (see Section 5.1.2: Fuel Feed Button).
  • Page 58 Eco-65 Installation and Operation Manual that could have caused a jam. Clean the auger housing thoroughly to remove all pellet dust. 5. The flue temperature sensor failed. The “thermistor” is a heat sensor located on the exhaust motor housing. Its function is to...
  • Page 59 Eco-65 Installation and Operation Manual HOPPER AUGER Screws Auger and motor assembly gasket BURN POT AUGER Screws Auger and motor assembly GASKET...

  • Page 60: L Code

    Eco-65 Installation and Operation Manual 8.3.4 L Code STOVE FEEDS PELLETS, BUT WILL NOT IGNITE AND APPEARS ON THE CONTROL BOARD Possible Causes: Possible Remedies: 1. Inadequate fuel is used. Remove the burn pot, make sure that all openings are clear and check that no ash has filled the tube around the igniter.

  • Page 61: Code

    Eco-65 Installation and Operation Manual to keep the exhaust temperature high enough. To resolve the situation increase feed rate or replace the part (see Section 5.2.2: Adjusting Convection Speed). 8.3.5 d Code STOVE STOPS FEEDING PELLETS AND APPEARS ON THE CONTROL BOARD...

  • Page 62: N Code

    Eco-65 Installation and Operation Manual 8.3.6 N Code THE STOVE FUNCTIONS BUT DISPLAYS WARNING CODE Possible Cause: Possible Remedy: 1. A reversed polarity is detected on the Test and ensure the proper connections. electrical outlet or on the same electrical circuit.

  • Page 63: A Code

    Eco-65 Installation and Operation Manual 8.3.9 A Code STOVE FEEDS PELLETS, BUT WILL NOT IGNITE AND APPEARS ON THE CONTROL BOARD Possible Causes: Possible Remedies: 1. The auger jammed or auger motor failed. See Section 9.2: Testing a Component and test auger motors independently.

  • Page 64: Smoke Smell

    Eco-65 Installation and Operation Manual 2. The wiring harness shorted. Make sure the auger motor wiring is properly connected and not shorted. 8.3.10 Smoke Smell SMOKE SMELL COMING BACK INTO THE HOME Possible Causes: Possible Remedies: 1. Venting system leaks.

  • Page 65: Auger Motor Stops Momentarily

    Eco-65 Installation and Operation Manual 8.3.11 Auger Motor Stops Momentarily AUGER MOTOR STOP FEEDING PELLETS AND COMES BACK ON Possible Cause: Possible Remedy: 1. The auger motor is overheating and It’s possible that the auger is jammed. tripping the internal temperature shutoff Remove it from its housing (see drawing (thermal protector).

  • Page 66: No Display

    Eco-65 Installation and Operation Manual filled the tube around the igniter. Refer to Section 7: Maintenance. Also, make sure that recommended fuel is used (see Section 4.8.1: Proper Fuel) and settings are adjusted to the type of pellets that are being used 4.

  • Page 67: Wiring Diagram

    Eco-65 Installation and Operation Manual 9 Wiring Diagram...

  • Page 68: Access To Fuses

    Eco-65 Installation and Operation Manual 10 Access to Fuses WARNING: UNPLUG THE STOVE BEFORE CHANGING THE FUSES. All fuses are located inside the housing of the electronic board; the housing is on the back of your stove. Unplug your stove, remove the screw and turn the four spring clips to open...
  • Page 69 Eco-65 Installation and Operation Manual LETTER FUSE FUNCTION AMPERAGE MAIN BOARD FUSE 7.5A CONVECTION BLOWER COMBUSTION BLOWER EXHAUST BLOWER TOP AUGER #1 BOTTOM AUGER #2 IGNITOR...

  • Page 70: Components Location

    Eco-65 Installation and Operation Manual 11 Components Location LETTER COMPONENT HEAT EXCHANGER TUBES BURN POT IGNITOR CONVECTION BLOWER THERMISTOR L-250 THERMAL SWITCH HOPPER CONTROL PANEL HOPPER SAFETY SWITCH PRESSURE SWITCH F-160 THERMAL SWITCH POWER CORD RECEPTACLE THERMOSTAT TERMINAL BLOCK COMBUSTION BLOWER/FRESH AIR...

  • Page 71: Blower Replacement

    Eco-65 Installation and Operation Manual 12 Blower Replacement CONVECTION BLOWER Unscrew screw A (1), slightly pivot the fan upward then partially slide the fan out (2). Disconnect the fan from the harness and remove completely.
  • Page 72 Eco-65 Installation and Operation Manual COMBUSTION BLOWER Remove the 9 screws (A) and the bottom grille (B). Unlatch the clamps (C). Remove the back draft shutter (G) and the gasket (D). Pull the combustion blower (F) and unplug the wire connector from the harness. Remove the plug...
  • Page 73 Eco-65 Installation and Operation Manual EXHAUST BLOWER Remove the left panel. Unplug the connections (A) and (B). Unplug the silicone tube (C).
  • Page 74 Eco-65 Installation and Operation Manual Remove the clamp (D). With a Philips screwdriver, unlock and remove the access panel (E).
  • Page 75 Eco-65 Installation and Operation Manual Remove the nuts (F) located in the opening of the trapdoor. Remove the duct assembly (G).
  • Page 76 Eco-65 Installation and Operation Manual Remove the bolts (H) and nuts (I) to remove the exhaust blower (J)

  • Page 77: 250 And F-160 Thermal Switch Replacement

    Eco-65 Installation and Operation Manual 13 L-250 and F-160 Thermal Switch Replacement L-250 1. Remove both retaining screws (A) holding the thermal switch support bracket (B). 2. Lift up the support bracket. Rotate the bracket 90° clockwise then pull the bracket...
  • Page 78 Eco-65 Installation and Operation Manual Remove the faulty thermal switch. Replace new thermal switch (D) underneath the bracket (B) by means of 2 screws (C). F-160 Unscrew both screws (B) and take out the thermal switch F-160 (A).

  • Page 79: Exploded View And Replacement Parts

    Eco-65 Installation and Operation Manual 14 Exploded View and Replacement Parts SECTION A...
  • Page 80 Eco-65 Installation and Operation Manual SECTION B...
  • Page 81 Eco-65 Installation and Operation Manual SECTION C...
  • Page 82 Eco-65 Installation and Operation Manual SECTION D SECTION E...
  • Page 83 Eco-65 Installation and Operation Manual SECTION F SECTION G...
  • Page 84 Eco-65 Installation and Operation Manual SECTION H SECTION I...
  • Page 85 Eco-65 Installation and Operation Manual SECTION J...
  • Page 86 Eco-65 Installation and Operation Manual IMPORTANT: THIS IS DATED INFORMATION. When requesting service or replacement parts for your stove, please provide the model number and the serial number. We reserve the right to change parts due to technology upgrade or availability. Contact an authorized dealer to obtain any of these parts.
  • Page 87 Eco-65 Installation and Operation Manual Item Description 30799 STEEL ROUND KNOB, 3/8"-16 THREADED 30800 FULLY THREADED STEEL ROD END, 3/8"-16 SE67151 ASH DRAWER ACCESS DOOR AC06825 GASKET KIT SELF ROUND BLACK 3/4" 30055 HINGE PIN RETAINING RING 5/16" ID X 0.512" OD 30167 HINGE PIN 5/16 DIA.
  • Page 88 Eco-65 Installation and Operation Manual Item Description PL64459 MOTHER BOARD HOUSING COVER 49006 3/8'' X 24" SILICONE HOSE 30138 METAL SCREW #6 3/8'' QUADREX ''A'' TYPE BLACK 44029 PRESSURE SWITCH 60196 POWER CORD RECEPTACLE 60036 THERMOSTAT TERMINAL 60331 POWER CORD 6' 30050 LEVELING BOLT 3/8-16 X 1 1/2"...

  • Page 89: Appendix A: Horizontal And Vertical Vent Chart

    Eco-65 Installation and Operation Manual APPENDIX A: HORIZONTAL AND VERTICAL VENT CHART Possible Horizontal vent length (feet) For example, let’s imagine an installation consisting of a horizontal vent coming out at the back of the stove on a total distance of 8 feet. This horizontal run is followed by a tee and a 6-foot vertical rise.
  • Page 90 Eco-65 Installation and Operation Manual Instead, if the installation consisted of a horizontal vent coming out at the back of the stove on a total distance of 4 feet, followed by a tee and a 6-foot vertical rise, it would be acceptable.

  • Page 91: Appendix B: Flame Caracteristics

    Eco-65 Installation and Operation Manual APPENDIX B: FLAME CARACTERISTICS Efficient flame An efficient flame should be bright but not too vigorous. The flame should also have a yellow to bright look. There should also be some small embers or spark exiting the flame and burn pot.

  • Page 92: Appendix C: Installing A Thermostat (Ac05558)

    Eco-65 Installation and Operation Manual APPENDIX C: INSTALLING A THERMOSTAT (AC05558) Using a thermostat will help you maintain a constant temperature throughout the house. A low voltage thermostat (24 volts) is required. A fixed wall mount or hand held model can be used.
  • Page 93 Eco-65 Installation and Operation Manual Wired thermostat Before installing the thermostat, unplug the power cord from the power outlet. First, connect the two thermostat wires to the terminal block located at the rear on the right hand side of the stove when facing it. Loosen the two middle screws and insert the wires in the terminals.
  • Page 94 Eco-65 Installation and Operation Manual Wireless thermostat If you are using a wireless thermostat or a hand held thermostatic remote control, connect the two thermostat wires to the terminal block located at the rear on the right hand side of the stove while facing it.

  • Page 95: Appendix D: Mobile Home Installation

    Eco-65 Installation and Operation Manual APPENDIX D: MOBILE HOME INSTALLATION Anchor the stove WARNING: FOR MOBILE HOME INSTALLATION, IT IS MANDATORY TO CONNECT THE STOVE TO AN OUTSIDE COMBUSTION AIR SOURCE. (SEE APPENDIX E: COMBUSTION AIR SUPPLY). When installed in a mobile home, the stove must be anchored to the floor with two screws.
  • Page 96 Eco-65 Installation and Operation Manual Fresh air intake Pellet pipe length and/or slip section Ceiling support Attic insulation shield Roof flashing Storm collar Pellet pipe length Vertical rain cap...

  • Page 97: Appendix E: Combustion Air Supply

    Eco-65 Installation and Operation Manual APPENDIX E: COMBUSTION AIR SUPPLY WARNING: FOR MOBILE HOME INSTALLATION, IT IS MANDATORY TO CONNECT THE STOVE TO AN OUTSIDE COMBUSTION AIR SOURCE. INSULATED PIPE SHOULD NEVER EXCEED 10 FEET. It is recommended to install an outside air inlet in or near the room where the stove is installed.
  • Page 98 Eco-65 Installation and Operation Manual To complete the installation, make a hole of1/4" to 1/2" (6 mm à 13 mm) bigger than the insulate pipe diameter in the outside wall of the house at the chosen location. From outside, place the outside air inlet cap (E) in the hole (open side down) and fasten the register to the wall, with screw.
  • Page 99 Eco-65 Installation and Operation Manual Sources of Outside Combustion Air WARNING: IT IS FORBIDDEN TO DRAW COMBUSTION AIR FROM A BASEMENT, AN ATTIC, A GARAGE OR ANY CONFINED SPACE.  You can draw air from a ventilated crawl space underneath the floor.

  • Page 100: Appendix F: Optional Hot Air Distribution Kit (Ac01330)

    Eco-65 Installation and Operation Manual APPENDIX OPTIONAL DISTRIBUTION (AC01330) The hot air distribution kit AC01330 is available at your local dealer. Please note that the 3.25” x 10” duct is sold separately. Duct 3.25” x 10”...
  • Page 101 Eco-65 Installation and Operation Manual This hot air plenum kit contains the following parts: (A) -49068 (B) -PL62444 (C) -SE62443 (D) -PL62446 (5” x 17.5”) (E) -30153 (F) -30220 (G) PL67179 (DP00060) (3” x 16”)

  • Page 102: Drolet Limited Lifetime Warranty

    Bill of sale and dealer’s name; Nature of the defect and any relevant information. Before shipping your unit or defective component to our plant, you must obtain from your DROLET dealer an Authorization Number. Any merchandise shipped to our plant without authorization will be refused...
