J2K100
J1939 to NMEA 2000
Gateway
®
User's Manual
Revision 1.1
Warning: Improper installation of the Maretron J2K100 may prevent existing engine
accessories (i.e., engine gauge displays, key switches, throttle and shift controls, etc.) from
working properly. You must have an understanding of J1939 data networks before attempting
to install the J2K100. Maretron strongly recommends that you understand SAE documents
J1939-11 and J1939-15 (see Section 3.1 of Appendix B) before attempting to install the
J2K100 and that you consult the engine/genset manufacture for their recommendations before
connecting anything to the J1939 network.
Copyright © 2007 Maretron, LLP All Rights Reserved
Maretron, LLP
rd
9014 N. 23
Ave #10
Phoenix, AZ 85021-7850
http://www.maretron.com
Maretron Manual Part #: M001201

Revision History

Revision 1.1
Page i
