Maretron J2K100 Specifications

J2K100
Maretron's J2K100 attaches directly into
J1939 networks of compatible engines,
transmissions, and gensets and converts
the J1939 data to the new marine digital
interface (NMEA 2000
transmission, and genset data is then
distributed throughout the vessel over a
single cable where it can be monitored by
any NMEA 2000 ® compatible display.
The J2K100 can also be used as part of a
complete fuel computer. Simply connect the
J2K100 together with Maretron universal
displays (DSM200/DSM250/N2KView
GPS antenna/receiver (GPS100) and you
have a system capable of displaying gallons
per hour and/or miles per gallon.
Products
PART NUMBER DESCRIPTION
J2K100-01 J1939 to NMEA 2000® Gateway
MCF-2M-D4 J2K100 adapter Micro female to Deutsche 4 Pin 2 Meter Cordset
M CF-2M-D12 J2K100 adapter Micro female to Deutsche 12 Pin 2 Meter Cordset
MCF-2M-D12CAT J2K100 adapter Micro female to Deutsche 12 Pin 2 T cable
32
J1939 to NMEA 2000
Gateway
). Critical engine,
®
The J2K100 converts the
following information:
• AC Generator Current
• AC Generator Frequency
• AC Generator Voltage
• Tachometer
® ) and
• Engine Hours
• Coolant Pressure
• Coolant Water Temperature
• Engine Oil Pressure
• Engine Oil Temperature
• Boost Pressure
• Fuel Rate Monitoring
• Charging Voltage
• Percent Engine Load
• Percent Engine Torque
• Rated Engine Speed
• VIN
• Software ID
• Transmission Gear
• Transmission Oil Pressure
• Transmission Oil Temperature
®
The J2K100 is compatible with
any engine, transmission, or
genset equipped with a J1939
interface, including products
from the following manufacturers:
• Caterpillar
• Cummins
• Detroit Diesel
• John Deere
• Kohler
• Northern Lights
• Onan
• Perkins
• Steyr
• Volvo Penta
• Yanmar
www.maretron.com 1-866-550-9100
