- Page 1 ® ® IPG100 Internet Protocol Gateway User’s Manual Revision 1.2 Copyright © 2012 Maretron, LLP All Rights Reserved Maretron, LLP 9014 N. 23 Ave #10 Phoenix, AZ 85021 http://www.maretron.com Maretron Manual Part #: M003004 Revision 1.2 Page i...
-
Page 2: Revision History
IPG100 User’s Manual Revision History Revision Description Original document Corrected current utilization figures Added documentation on Cloud Services Page ii Revision 1.2... -
Page 3: Table Of Contents
Maintenance ........................12 Troubleshooting ......................... 13 Technical Specifications ..................... 14 Technical Support ......................16 Installation Template ......................17 Maretron (2 Year) Limited Warranty ................... 18 Revision 1.2 Page iii... - Page 4 IPG100 User’s Manual Table of Figures Figure 1 – IPG100 Network Diagram ..................1 Figure 2 – LAN Client/Server Architecture Example with USB100 ..........3 Figure 3 – WAN Client/Server Architecture Example through the Internet ........ 4 Figure 4 –...
-
Page 5: General
1.1 Introduction Congratulations on your purchase of the Maretron Internet Protocol Gateway (IPG100). Maretron has designed and built your gateway to the highest standards for years of reliable, dependable, and accurate service. The Internet Protocol Gateway (IPG100) lets you connect Maretron black boxes (MBB100’s), ®... -
Page 6: Firmware Revision
However, no piece of marine electronic equipment can function properly unless installed, calibrated, and maintained in the correct manner. Please read carefully and follow these instructions for installation, calibration, and usage of the Maretron IPG100 in order to ensure optimal performance. -
Page 7: General Concepts
Examples of NMEA 2000 Client/Server Architectures ® N2KServer may run on a Windows PC (using Maretron’s USB100 gateway - see Figure 2 and ® Figure 3) or N2KServer may run directly on an IPG100 (see Figure 4). Figure 2 – LAN Client/Server Architecture Example with USB100 Figure 2 shows an example of a Local Area Network (LAN) connection including the PC to ®... -
Page 8: Figure 3 - Wan Client/Server Architecture Example Through The Internet
IPG100 User’s Manual Figure 3 – WAN Client/Server Architecture Example through the Internet Figure 3 extends the example shown in Figure 2 by adding an external internet access point across a Wide Area Network (WAN). Although it is possible to setup t he network as shown in ®... -
Page 9: Tcp/Ip Networks
® ® Figure 5 – Single Client Connection to IPG100 Figure 5 shows an example of a single client connection to an IPG100. A DSM800 (or a computer, or a MBB100) is connected directly to the IPG100. 1.7.2 TCP/IP Networks The networking protocol that is used for the communication between the server an d stations in ®... -
Page 10: Pat (Port Address Translation)
IPG100 User’s Manual In the early days of the Internet, each computer connected to the Internet had its own IP address. With the explosive growth of the Internet, the number of distinct IP addresses is starting to run out. It is no longer practical for an Internet Service Provider (ISP) to provide its customers with individual IP addresses for each component the customer wishes to connect to the Internet. -
Page 11: Software Firewall Configuration
® station granted access to the NMEA 2000 network data. 2 Installation 2.1 Unpacking the Box hen unpacking the box containing the Maretron IPG100, you should find the following items: Revision 1.2 Page 7... -
Page 12: Choosing A Mounting Location
• 1 – IPG100 User’s Manual • 1 – Warranty Registration Card If any of these items are missing or damaged, p lease contact Maretron. 2.2 Choosing a Mounting Location lease consider the following when choosing a mounting location. 1. The IPG100 is waterproof, so it can be mounted in a damp or dry location. Note that t USB Waterproof Cover and Waterproof Ethernet Cable accessories must be purchased ®... -
Page 13: Connecting The Ipg100
(see Figure 7). You connect the IPG100 to an ® ® ® NMEA 2000 network using a Maretron NMEA 2000 cable (or an NM EA 2000 compatible able) by connecting the female end of the cable to the IPG100 (note the key on the male connector and keyway on the female connector). -
Page 14: Indicators
PC software (version 3.0.4 and later). If you have an “old” key from a version of ® N2KView you previously purchased, please contact Maretron sales to upgrade it to a “new” key so that you can use it with the IPG100. 2.5 Indicators... -
Page 15: Installation Description
® which it was installed, for later reference. Tools such as Maretron N2KAnalyzer allow you to view these values later. The default installation description is blank text. -
Page 16: Configuring Ip Address
Regular maintenance is not required; however, an occasional inspection will ensure conti nued proper operation of the Maretron IPG100. Perform the following tasks periodically: • Clean the unit with a soft cloth. Do not use chemical cleaners as they may remove paint or markings or may corrode the IPG100 enclosure or seals. -
Page 17: Troubleshooting
NMEA 2000 cable, and that the NMEA 2000 connection is sec ure. Figure 8 – Troubleshooting Guide If these steps do not solve your problem, please contact Maretron Technical Support (refer to Section 7 for contact information). Revision 1.2 Page 13... -
Page 18: Technical Specifications
IPG100 User’s Manual 6 Technical Specific ations Specifications Parameter Value Comment ® NMEA 2000 Connector DeviceNet Micro-C Industry Standard Waterproof ® NMEA 2000 Isolation Opto-Isolated No Electrical Connection Across Br idge USB Standard USB 1.1 ® USB Connector USB Type A Industry Standard Waterproof, for Connection of N2KView Hardware License Key O USB Supported Signals... - Page 19 ® ® Environmental Parameter Value IEC 60945 Classification Exposed Degree of Protection IP67 Operating Temperature -25°C to 55°C Storage Temperature -40°C to 70°C Relative Humidity 93%RH @40° per IEC60945-8.2 Vibration 2-13.2Hz @ ±1mm, 13.2-100Hz @ 7m/s per IEC 60945-8.7 Rain and Spray 12.5mm Nozzle @ 100liters/min from 3m for 3 0min per IEC 60945-8.8...
-
Page 20: Technical Support
IPG100 User’s Manual 7 Technical Support If you require tech nical support for Maretron products, you can reach us in any of the following ways: Telephone: 1-866-550-9100 Fax: 1-602-861-1777 E-mail: support@maretron.com World Wide Web: http://www.maretron.com Mail: Maretron, LLP Attn: Technical Support 9014 N. -
Page 21: Installation Template
® ® 8 Installation Templa Please check the dimensions befor e using the following diagram as a template for drilling the mounting holes because the printing process may have distorted the dimensions. 3.9” (99.1mm) 4.5” (114.3mm) Figure 9 – Mounting Surface Template Revision 1.2 Page 17... -
Page 22: Maretron (2 Year) Limited Warranty
Maretron’s option, of any product not meeting the above limited warranty and which is returned to Maretron; or if Maretron is unable to deliver a replacement that is free from defects in materials or workmanship, Purchaser’s payment for such product will be refunded.
