EQUUS CUSTOMER DELIVERY CHECK LIST (continued)
BLUETOOTH – page 14
- Show phone compatibility website:
www.hyundaiusa.com/bluetooth
- Make a test call using Bluetooth with
the customer's phone.
- Demonstrate Voice Recognition (VR)
WINDSHIELD WIPER/WASHER – page 07
- Explain wiper function
(int speed, front & rear
wipers) and how it may
differ from customer's
previous vehicle
CLOCK – page 21
- Demonstrate how to set clock (including daylight
savings setting for Navigation equipped vehicles)
SMART CRUISE CONTROL – page 30
- Allows you to set the distance from the vehicle
ahead and maintain the selected distance even if
you do not press the accelerator or brake pedal.
the cruise control speed
A
the cruise control speed
B
1. Press button
to turn on.
A
2. Press
to set the speed.
B
Sales Consultant
Date
Sales Manager
Customer
@
Email
MAINTENANCE
Scheduled Maintenance
Engine Oil and Filter
Tire Rotation (staggered)
Air Cleaner Filter
Vacuum Hose
Climate Control Air Filter
(For Evaporator and Blower Unit)
Air Conditioning Refrigerant
Brake Hoses & Lines
Drive Shafts & Boots
Electronic Throttle Control
Front Disc Brake/Pads, Calipers & Rotors
Propeller Shaft
Steering Gear Box, Linkage & Boots/
Lower Arm Ball Joint, Upper Arm Ball Joint
Suspension Mounting Bolts
Brake Fluid
Fuel Filter
Fuel Lines, Fuel Hoses and Connections
Fuel Tank Air Filter
Rear Disc Brake/Pads, Parking Brake
Vapor Hose, Fuel Tank & Fuel Filler Cap
Valve Clearance
Drive Belt (Alt, A/C)
Spark Plugs (Iridium Coated)
Coolant
Automatic Transmission Fluid
*See Owner's Manual for details.
Looking for more detailed information?
Owner's Manual. If you require additional information or are unsure of a specific issue, you should
always refer to the vehicle's Owner's Manual or contact your authorized Hyundai Equus dealer. The
information contained in this Quick Reference Guide is correct at the time of printing; however,
specifications and equipment can change without notice. No warranty or guarantee is being
extended in this Quick Reference Guide, and Hyundai reserves the right to change product
specifications and equipment at any time without incurring obligations. Some vehicles are shown
with optional equipment.
Date
Date
Normal Usage
Severe Usage*
Replace
7,500 or 12 mos.
Replace
3,750 or 6 mos.
Perform
7,500
Perform
7,500
Inspect
7,500
Replace
More Frequently
Replace
30,000
Inspect
7,500
Inspect
Same As Normal
Replace
15,000
Replace
More Frequently
Inspect
15,000
Inspect
Same As Normal
Inspect
15,000
Inspect
Same As Normal
Inspect
15,000
Inspect
7,500
Inspect
15,000
Inspect
Same As Normal
Inspect
15,000
Inspect
Same As Normal
Inspect
15,000
Inspect
More Frequently
Inspect
15,000
Inspect
7,500 or 6 mos.
Inspect
15,000
Inspect
More Frequently
Inspect
15,000
Inspect
Same As Normal
Inspect
30,000
Inspect
Same As Normal
Inspect
30,000
Inspect
Same As Normal
Inspect
30,000
Inspect
Same As Normal
Inspect
30,000
Inspect
Same As Normal
Inspect
30,000
Inspect
More Frequently
Inspect
30,000
Inspect
Same As Normal
Inspect
60,000
Inspect
Same As Normal
1st Inspect 60,000 or 48 mos.
Inspect
Same As Normal
Add'l Inspect 15,000 or 12 mos.
Replace
100,000 or 10 yrs.
Replace
More Frequently
1st Replace 120,000 or 120 mos.
Replace
Same As Normal
Add'l Replace 30,000 or 24 mos.
Replace
60,000
Replace
60,000
This Quick Reference Guide does not replace your vehicle's
NP150-N2012
(Rev 10/12/11)
Printing 10/XX/11
AT YOUR SERVICE
Quick Reference Guide
www.hyundai.com
Service: 1-877-EQUUS27
(877-378-8727)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2011 EQUUS and is the answer not in the manual?

Questions and answers

Summary of Contents for Hyundai 2011 EQUUS

  • Page 1 Owner’s Manual. If you require additional information or are unsure of a specific issue, you should 2. Press to set the speed. always refer to the vehicle’s Owner’s Manual or contact your authorized Hyundai Equus dealer. The information contained in this Quick Reference Guide is correct at the time of printing; however, Quick Reference Guide specifications and equipment can change without notice.
  • Page 2: Table Of Contents

    To reduce the risk of serious injury to yourself and others, Hyundai. More detailed information read and understand the important SAFETY INFORMATION about these features are available in in your Owner’s Manual.
  • Page 3: Driver Position Memory System

    GETTING STARTED REMOTE KEYLESS ENTRY ENGINE START/STOP BUTTON Lock With the ignition OFF and foot OFF of brake pedal, press the engine start/stop Unlock button. Trunk unlock Panic Lock Unlock Press the door Pull handle to unlock. To start the engine in any mode (including OFF), press handle lock button.
  • Page 4: Driver Seat Lumbar Adjustment

    GETTING STARTED DRIVER SEAT LUMBAR ADJUSTMENT STEERING WHEEL ADJUSTMENT Toggle switch to adjust Press steering wheel. Increase lumbar support. Press Decrease lumbar support. NOTE Do not adjust steering wheel while driving. Press Move the support position up. Press Move the support position down. DRIVER SEAT MASSAGE ADJUSTMENT SEAT BELT HEIGHT ADJUSTMENT (front seats) Slow Massage...
  • Page 5 FEATURES & CONTROLS HEAD LIGHTS AND FOG LIGHTS WIPERS AND WASHER Auto light position Head light position MIST – Single wipe Parking light position OFF position AUTO – Auto control wipe LO – Low wiper speed Turn signals and HI – High wiper speed lane change signals Auto control wipe interval adjustment...
  • Page 6 FEATURES & CONTROLS Tachometer Odometer/Trip meter Shift position indicator Speedometer Fuel gauge Engine temperature gauge Turn signal indicators LCD screen INSTRUMENT PANEL ILLUMINATION WARNINGS AND INDICATORS When the vehicle’s parking lights or Anti-lock brake system Parking brake & brake Air bag warning light (ABS) warning light head lights are on, rotate the fluid warning light...
  • Page 7 FEATURES & CONTROLS Climate information screen selection button Passenger’s temperature control knob Air intake control button / Front windshield Rear window AQS (Air Quality System) button defrost button defrost button Driver’s temperature Dual temperature control knob control selection button AUTO (Automatic temperature OFF button Air conditioning button control) button...
  • Page 8 SEEK / PRESET system in your vehicle. NOTE MODE Use the Hyundai adapter cable Calling up main ® to operate your iPod through functions or switching the vehicle’s audio system.
  • Page 9 The contact list display may start with either first or last name depending on the phone make and model. Please visit www.hyundaiusa.com\Bluetooth for a list of compatible phones tested to work with Hyundai’s Bluetooth system. QUICK REFERENCE GUIDE QUICK REFERENCE GUIDE...
  • Page 10 FEATURES & CONTROLS REAR WINDOW CURTAIN MASSAGE SEAT - RIGHT REAR SEAT 1. Point the remote control to the front passenger seatback receiver. 2. Press the ON/OFF button. 3. Select desired function. NOTE Massage remote is located in upper rear armrest compartment. Ultimate Package Signature Package Receiver...
  • Page 11 FEATURES & CONTROLS TRUNK TRUNK LOCK BUTTON Opening The trunk lock button is used to prevent unauthorized access to the trunk. Rear soft-touch release To activate the trunk lock system: Press to open. 1. Open the glove box. Smart key needs to be 2.
  • Page 12: Clock Adjustment

    FEATURES & CONTROLS HEATED STEERING WHEEL CLOCK ADJUSTMENT Pressing the heated steering wheel button warms the steering wheel. The indicator on the button is Backward illuminated. Heated steering wheel button Forward Press and hold the button to set the clock backward or forward continuously.
  • Page 13: Cool Box

    FEATURES & CONTROLS FRONT CAMERA REAR SEAT CONTROLS – LOCKING The front camera is a supplemental system that can show blind spots in front of the vehicle through the AV monitor. The front camera will operate when you press the button and shift the shift lever into N (Neutral) or D (Drive) while driving less than 6 mph.
  • Page 14: Homelink Wireless Control

    FEATURES & CONTROLS DRIVING HOMELINK WIRELESS CONTROL ELECTRONIC STABILITY CONTROL (ESC) The ESC system is an electronic system designed to help the driver maintain vehicle control HomeLink under adverse conditions. To turn the ESC off, press the ESC OFF button. To turn ESC on, press it again.
  • Page 15 DRIVING ELECTRONIC PARKING BRAKE (EPB) AUTO HOLD Applying The Auto Hold feature assists in steep hill areas. Stop the vehicle, then It holds the brake applied until the accelerator press the EPB switch. pedal is pressed. 1. Press the AUTO HOLD WHITE switch.
  • Page 16: Eco System

    Illuminated when there is a TPMS MALFUNCTION INDICATOR: the cruise control malfunction with the TPMS system. Have the system checked by an speed authorized Hyundai Equus dealer as soon as possible. To turn cruise control On/Off 1. Press button to turn on. ECO SYSTEM 2.
  • Page 17 5 years or 60,000 miles, whichever comes first. and delivery time and location. The At Your Service Program is applicable to all 2011 model year Hyundai Equus United States specification vehicles purchased in the United States from Authorized Equus Dealerships.
  • Page 18 To qualify for replacement, the wear limit must be owners, with the exception of immediate family members. Immediate family BEFORE DELIVERY at or below the minimum service limits as specified by Hyundai Motor America members include the following: technical reference manuals. Tires are excluded from this program.
