O O W W N N E E R R ' ' S S M M A A N N U U A A L L
Operation
Maintenance

Specifications

All information in this Owner's Manual is current at the time of publication.
However, Hyundai reserves the right to make changes at any time so that
our policy of continual product improvement may be carried out.
This manual applies to all Hyundai models and includes descriptions and
explanations of optional as well as standard equipment. As a result, you
may find material in this manual that does not apply to your specific vehi-
cle.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2011 Genesis and is the answer not in the manual?

Questions and answers

Related Manuals for Hyundai 2011 Genesis

Summary of Contents for Hyundai 2011 Genesis

  • Page 1: Specifications

    Specifications All information in this Owner's Manual is current at the time of publication. However, Hyundai reserves the right to make changes at any time so that our policy of continual product improvement may be carried out. This manual applies to all Hyundai models and includes descriptions and explanations of optional as well as standard equipment.
  • Page 2 CAUTION: MODIFICATIONS TO YOUR HYUNDAI Your Hyundai should not be modified in any way. Such modifications may adversely affect the per- formance, safety or durability of your Hyundai and may, in addition, violate conditions of the limited warranties covering the vehicle. Certain modifications may also be in violation of regulations estab- lished by the U.S.
  • Page 3 SAFETY AND VEHICLE DAMAGE WARNING This manual includes information titled as WARNING, CAUTION and NOTICE. These titles indicate the following: WARNING This indicates that a condition may result in harm, serious injury or death to you or other persons if the warning is not heeded. Follow the advice provided with the warning. CAUTION This indicates that a condition may result in damage to your vehicle or its equipment if the caution is not heeded.
  • Page 4 Your Owner's Manual will introduce you to the features and operation of your new Hyundai. It is suggested that you read it care- fully because the information it contains can contribute greatly to the satisfaction you receive from your new car.

  • Page 5: Guide To Hyundai Genuine Parts

    English. facturing requirements. Using imita- tion, counterfeit or used salvage parts Hyundai Genuine Parts are only sold A100A03L is not covered under the Hyundai New through authorized Hyundai Vehicle Limited Warranty or any other Dealerships.

  • Page 7: Table Of Contents

    Introduction Your vehicle at a glance Safety features of your vehicle Features of your vehicle Driving your vehicle table of contents What to do in an emergency Maintenance Specifications, Consumer information, Reporting safety defects Index...

  • Page 8: Introduction

    Introduction How to use this manual / 1-2 Fuel requirements / 1-3 Vehicle break-in process / 1-5 Vehicle data collection and event data recorders / 1-6 Indicator symbols on the instrument cluster / 1-7...

  • Page 9: How To Use This Manual

    Introduction HOW TO USE THIS MANUAL A010000AHM The general layout of the manual is pro- You will find various WARNINGS, CAU- We want to help you get the greatest vided in the Table of Contents. A good TIONS, and NOTICES in this manual. possible driving pleasure from your vehi- place to start is the index;...

  • Page 10: Fuel Requirements

    (Consult ethanol (also known as grain alcohol), number ((R+M)/2) of 87 (Research an authorized HYUNDAI dealer for and gasoline or gasohol containing Octane Number 91) or higher. details.) methanol (also known as wood alcohol) are being marketed along with or instead 4.6 engine...
  • Page 11 To help contribute to cleaner air, exclusively for use in Flexible Fuel hol) should not be used in your vehicle. HYUNDAI recommends you use gaso- Vehicles. “E85” is not compatible with This type of fuel can reduce vehicle per- lines treated with detergent additives, your vehicle.

  • Page 12: Vehicle Break-In Process

    Introduction VEHICLE BREAK-IN PROCESS A030000BUN CALIFORNIA PROPOSI- No special break-in period is needed. By TION 65 WARNING following a few simple precautions for the first 600 miles (1,000 km) you may add to Items contained in motor vehicles the performance, economy and life of or emitted from them are known to your vehicle.

  • Page 13: Vehicle Data Collection/Event Data Recorders

    Introduction VEHICLE DATA COLLECTION AND EVENT DATA RECORDERS A040000AFD These data can help provide a better To read data recorded by an EDR, spe- This vehicle is equipped with an event understanding of the circumstances cial equipment is required, and data recorder (EDR).

  • Page 14: Indicator Symbols On The Instrument Cluster

    Introduction INDICATOR SYMBOLS ON THE INSTRUMENT CLUSTER A050000ABH-EU Door ajar warning light Trunk ajar warning light Malfunction indicator light EPB malfunction indicator Seat belt warning light Air bag warning light (if equipped) AUTO HOLD indicator AUTO High beam indicator Cruise indicator (if equipped) HOLD (if equipped) Cruise SET indicator...

  • Page 15: Your Vehicle At A Glance

    Your vehicle at a glance Interior overview / 2-2 Instrument panel overview / 2-3 Engine compartment / 2-4...

  • Page 16: Your Vehicle At A Glance

    Your vehicle at a glance INTERIOR OVERVIEW 1. Door lock/unlock button ....4-16 2. Power window switches ....4-23 3. Outside rearview mirror control switch ..........4-46 4. Trunk lid release switch.....4-20 5. Fuel filler lid release button....4-28 6. Hood release lever......4-27 7. Foot parking brake* ......5-19 8.

  • Page 17: Instrument Panel Overview

    Your vehicle at a glance INSTRUMENT PANEL OVERVIEW 1. Instrument cluster......4-47 2. Horn ..........4-38 3. Driver’s front air bag......3-44 4. Wiper/Washer........4-80 5. Ignition switch or Engine start/stop button*.........5-4, 5-7 6. Climate control system.....4-87 7. Digital clock ........4-106 8. Hazard warning flasher switch..4-74, 6-2 9.

  • Page 18: Engine Compartment

    Your vehicle at a glance ENGINE COMPARTMENT ■ ■ 3.8 Engine 1. Engine coolant reservoir ....7-17 2. Radiator cap ........7-18 3. Brake fluid reservoir......7-19 4. Air cleaner.........7-22 5. Engine oil dipstick ......7-15 6. Engine oil filler cap ......7-15 7. Windshield washer fluid reservoir ..7-21 8.
  • Page 19 Your vehicle at a glance ■ ■ 4.6 Engine 1. Engine coolant reservoir ....7-17 2. Radiator cap ........7-18 3. Brake fluid reservoir......7-19 4. Air cleaner.........7-22 5. Engine oil dipstick ......7-15 6. Engine oil filler cap ......7-15 7. Windshield washer fluid reservoir ..7-21 8.

  • Page 20: Safety Features Of Your Vehicle

    Seats / 3-2 Seat belts / 3-14 Child restraint system / 3-25 Air bag - advanced supplemental restraint system / 3-33 Safety features of your vehicle...
  • Page 21 Safety features of your vehicle SEATS Driver’s seat (1) Forward and backward/Seat cushion height (2) Seatback angle (3) Lumbar support (4) Seat warmer or Climate control seat* (5) Headrest (6) Driver position memory system* Front passenger’s seat (7) Forward and backward (8) Seatback angle* (9) Seat warmer* (10) Headrest...
  • Page 22 Safety features of your vehicle C010200AEN WARNING WARNING Loose objects - Driver’s seat Front seat adjustment - power Loose objects in the driver’s foot • Never attempt to adjust the seat The front seat can be adjusted by using area could interfere with the opera- while the vehicle is moving.
  • Page 23 Safety features of your vehicle CAUTION • The power seat is driven by an electric motor. Stop operating once the adjustment is complet- ed. Excessive operation may damage the electrical equipment. • When in operation, the power seat consumes a large amount of electrical power.
  • Page 24 Safety features of your vehicle OBH031004N OBH031005N OBH038075L C010203ABH C010204ABH C010104ABH-EU Seat cushion height (for driver’s seat) Lumbar support (for driver’s seat) Headrest Pull the front portion of the control knob The lumbar support can be adjusted by The driver's and front passenger's seats up to raise or push down to lower the pressing the lumbar support switch on are equipped with a headrest for the...
  • Page 25 Safety features of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height as the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes.
  • Page 26 Removal For your safety, the front headrest can’t be removed. If there is any problem with the front headrest, take your vehicle to an authorized HYUNDAI dealer and have the system checked. WARNING Do not operate the vehicle with the...
  • Page 27 Safety features of your vehicle • When pressing the switch for more WARNING than 1.5 seconds with the seat warmer - Seat warmer operating, the seat warmer will turn burns OFF. Passengers should use extreme • The seat warmer defaults to the OFF caution when using seat warmers position whenever the ignition switch is due to the possibility of excess...
  • Page 28 The air vent may not work properly as the air intake can be blocked. • When the air vent does not oper- ate, restart the vehicle. If there is no change, have your vehicle inspected authorized HYUNDAI dealer.
  • Page 29 Safety features of your vehicle WARNING For proper operation of the occu- pant classification system: • Do not place any items cumula- tively weighing over 2.2 lbs (1 kg) in the passenger’s seatback pocket or on the passenger’s seat. • Do not hang onto the front pas- senger seatback.
  • Page 30 Safety features of your vehicle WARNING • For maximum effectiveness in case of an accident, the headrest should be adjusted so the middle of the headrest is at the same height as the center of gravity of an occupant's head. Generally, the center of gravity of most peo- ple's head is similar with the height of the top of their eyes.
  • Page 31 Safety features of your vehicle OBH038078L OBH038074L OBH031017N Reinstall Rear center seats headrest C010304ABH-EU To reinstall the headrest, put the head- You can fold the rear center seat’s head- Armrest rest poles(1) into the holes while press- rest by pressing the upper part of the The armrest is located in the center of ing the release button(2).
  • Page 32 Safety features of your vehicle CAUTION WARNING - Cargo • Make sure the engine is off, the Cargo should always be secured to shift lever is in P and the parking prevent it from being thrown about brake is applied whenever load- the vehicle in a collision and caus- ing or unloading cargo.

  • Page 33: Seat Belts

    Safety features of your vehicle SEAT BELTS C020100AUN (Continued) (Continued) Seat belt restraint system • Avoid wearing twisted seat belts. Care should be taken to avoid con- A twisted belt can't do its job as tamination of the webbing with pol- WARNING well.
  • Page 34 Safety features of your vehicle If the driver's seat belt is not fastened when the ignition switch is turned on, the seat belt warning light and chime will operate for approximately 6 seconds. But if it is fastened within the 6 seconds, the warning light will blink for the 6 seconds and the warning chime will turn off imme- diately.
  • Page 35 Safety features of your vehicle ✽ ✽ NOTICE Front seat If you are not able to smoothly pull enough of the safety belt from the retractor, firmly pull the belt out and release it. Then you will be able to pull the belt out smoothly.
  • Page 36 Safety features of your vehicle To raise the height adjuster, pull it up (1). C020106ABH Seat belts - Front passenger and rear To lower it, push it down (3) while press- seat 3-point system with combination ing the height adjuster button (2). locking retractor Release the button to lock the anchor into position.
  • Page 37 Safety features of your vehicle When the seat belt is fully extended from the retractor to allow the installation of a child restraint system, the seat belt oper- ation changes to allow the belt to retract, but not to extend (Automatic Locking Retractor Type).

  • Page 38: Pre-Tensioner Seat Belt

    Safety features of your vehicle When the vehicle stops suddenly, or if the occupant tries to lean forward too quickly, the seat belt retractor will lock into position. In certain frontal collisions, the pre-tensioner will activate and pull the seat belt into tighter contact against the occupant's body.
  • Page 39 6 seconds, or if it pre-tensioner seat belts were activat- illuminates while the vehicle is being driven, have an authorized HYUNDAI dealer inspect the pre- tensioner seat belt and SRS air bag system as soon as possible.
  • Page 40 HYUNDAI deal- vehicle. Properly worn seat belts • Do not attempt to inspect or greatly reduce these hazards.
  • Page 41 Safety features of your vehicle ✽ ✽ NOTICE C020306AUN-EU C020301AUN Infant or small child Larger children Small children are best protected from All 50 states have child restraint laws.You Children who are too large for child injury in an accident when properly should be aware of the specific require- restraint systems should always occupy restrained in the rear seat by a child...
  • Page 42 Safety features of your vehicle If the shoulder belt portion slightly touch- C020302AKM C020304AUN Restraint of pregnant women One person per belt es the child’s neck or face, try placing the child closer to the center of the vehicle. If Pregnant women should wear lap/shoul- Two people (including children) should the shoulder belt still touches their face...
  • Page 43 (seat seat hinges, doors or other abuse. ing seat belt operation should be directed belts and air bags) is greatly to an authorized HYUNDAI dealer. reduced by reclining your seat. C020401AEN Seat belts must be snug against...

  • Page 44: Child Restraint System

    Safety features of your vehicle CHILD RESTRAINT SYSTEM C030000AEN-EU WARNING WARNING Children riding in the car should sit in the rear seat and must always be properly • A child restraint system must be To reduce the chance of serious or restrained to minimize the risk of injury in placed in the rear seat.
  • Page 45 Safety features of your vehicle Rearward-facing child restraint system (Continued) (Continued) • Never leave children unattended • Never use an infant carrier or a in a vehicle – not even for a short child safety seat that "hooks" time. The car can heat up very over a seatback, it may not pro- quickly, resulting serious...
  • Page 46 Placing a passenger seat belt into lock under extreme or emergency condi- by your authorized HYUNDAI the automatic locking mode tions (emergency locking mode), you dealer. The automatic locking mode will help must manually change these seat belts •...
  • Page 47 Safety features of your vehicle OEN036101 OBH039102 OBH039103 3. Pull the shoulder portion of the seat 4. Slowly allow the shoulder portion of To install a child restraint system on the belt all the way out. When the shoulder the seat belt to retract and listen for an outboard or center rear seats, do the fol- lowing: portion of the seat belt is fully extend-...
  • Page 48 Safety features of your vehicle WARNING - Automatic locking mode The lap/shoulder belt automatically returns to the “emergency locking mode” whenever the belt is allowed to retract fully. Therefore, the pre- ceding seven steps must be fol- lowed each time a child restraint is installed.
  • Page 49 Safety features of your vehicle WARNING WARNING Tether strap When using the vehicle's "Tether • A child can be seriously injured Anchor" system to install a child or killed in a collision if the child restraint system in the rear seat, all restraint properly unused vehicle rear seat belt metal...
  • Page 50 Safety features of your vehicle WARNING - Child restraint anchorage • Child restraint anchorages are Lower Anchor designed to withstand only those Position Indicator loads imposed by correctly fitted child restraints. Under no circum- stances are they to be used for adult seat belts or harnesses or for attaching other items or equipment to the vehicle.
  • Page 51 Safety features of your vehicle LATCH anchors have been provided in CAUTION WARNING your vehicle. The LATCH anchors are located in the left and right outboard rear Do not allow the rear seat belt web- When using the vehicle's "LATCH" seating positions.

  • Page 52: Air Bag - Advanced Supplemental Restraint System

    Safety features of your vehicle AIR BAG - ADVANCED SUPPLEMENTAL RESTRAINT SYSTEM C040000ABH (1) Driver’s front air bag (2) Passenger’s front air bag (3) Side impact air bag (front) (4) Side impact air bag (rear, if equipped) (5) Curtain air bag (if equipped) WARNING Even in vehicles with air bags, you and your passengers must always...
  • Page 53 Safety features of your vehicle C040900AEN-EU It is much more likely that you will sim- ply see the deflated air bags hanging WARNING How does the air bag system out of their storage compartments after operate • To avoid severe personal injury the collision.
  • Page 54 Safety features of your vehicle C040902AEN WARNING Noise and smoke When the air bags inflate, they make a loud • Extreme Hazard! Do not use a noise and they leave smoke and powder in rearward facing child restraint on the air inside of the vehicle. This is normal a seat protected by an air bag in and is a result of the ignition of the air bag front of it!

  • Page 55: Srs Components And Functions

    5. Retractor pre-tensioner assemblies occurs, this indicates a malfunction 6. Air bag warning light of the SRS. Have an authorized HYUNDAI dealer inspect the air bag 7. SRS control module (SRSCM) system as soon as possible. 8. Front impact sensors •...
  • Page 56 Safety features of your vehicle Driver’s front air bag (1) Driver’s front air bag (2) Driver’s front air bag (3) B240B01L B240B02L B240B03L The front air bag modules are located Upon deployment, tear seams molded A fully inflated air bag, in combination both in the center of the steering wheel directly into the pad covers will separate with a properly worn seat belt, slows the...
  • Page 57 If this occurs, instrument cluster nor on the have your vehicle immediately instrument panel surface. inspected authorized It may become a dangerous pro- HYUNDAI dealer. jectile and cause injury if the pas- (Continued) senger's air bag inflates.

  • Page 58: Occupant Classification System

    Safety features of your vehicle Main components of occupant If the front passenger seat is occupied by a person that the system determines to classification system be of adult size, and he/she sits properly • A detection device located under the (sitting upright with the seatback in an front passenger seat cushion.
  • Page 59 Safety features of your vehicle Always be sure that you and all vehicle C040301ABH occupants are seated and restrained Condition and operation in the front passenger occupant classification system properly (sitting upright with the seat in an upright position, centered on the seat Indicator/Warning light Devices cushion, with the person's legs comfort-...
  • Page 60 Safety features of your vehicle (Continued) OVQ036013N 1KMN3663 1KMN3665 - Never sit with hips shifted - Never place feet on the dash- - Never put a heavy load in the front passenger seat or seatback towards the front of the seat. board.
  • Page 61 Safety features of your vehicle ✽ ✽ NOTICE If the "PASS AIR BAG OFF" indicator is Proper position still on, ask the passenger to move to the The "PASS AIR BAG OFF" indicator rear seat. illuminates for about 4 seconds after the ignition switch is turned to the ON posi- tion or after the engine is started.
  • Page 62 • Air bags can only be used once – • Even though your vehicle is passenger seat. Don't place any- have an authorized HYUNDAI equipped with the occupant clas- thing on or attach anything such dealer replace the air bag imme-...

  • Page 63: Driver's And Passenger's Front Air Bag

    HYUNDAI dealer inspect front panel pad above the glove box. the occupant classification system and the SRS air bag system as The SRS consists of air bags installed soon as possible.
  • Page 64 SRSCM (SRS is being driven, have an authorized Control Module) controls the air bag HYUNDAI dealer inspect inflation. Failure to properly wear seat advanced SRS air bag system as belts can increase the risk or severity of soon as possible.
  • Page 65 Air bags inflate with con- please contact Hyundai the vehicle. siderable force and in the blink of Customer Assistance Center at 1- • You and your passengers should an eye.
  • Page 66 • No objects should be placed over • Air bags can only be used once – or near the air bag modules on have an authorized HYUNDAI the steering wheel, instrument dealer replace the air bag imme- panel, and the front passenger's diately after deployment.
  • Page 67 Safety features of your vehicle Front (Continued) (Continued) • Even though your vehicle is • Sitting improperly or out of posi- equipped with the occupant clas- tion can result in serious or fatal sification system, do not install a injury in a crash. All occupants child restraint system in the front should sit upright with the seat- passenger seat position.
  • Page 68 HYUNDAI dealer because your • Do not use any accessory seat vehicle is equipped with side covers. impact air bags and an occupant •...
  • Page 69 This should only OBH031052N done authorized C040700AEN HYUNDAI dealer. Curtain air bag (if equipped) Failure to follow the above instruc- Curtain air bags are located along both tions can result in injury or death to sides of the roof rails above the front and the vehicle occupants in an acci- rear doors.
  • Page 70 Safety features of your vehicle C040800ABH Why didn’t my air bag go off in a collision? (Inflation and non-infla- tion conditions of the air bag) There are many types of accidents in which the air bag would not be expect- ed to provide additional protection.
  • Page 71 Have the vehicle result in serious personal injury checked and repaired by an or death. authorized HYUNDAI dealer. • If the installation location or • Your vehicle has been designed angle of the sensors is altered in to absorb impact and deploy the any way, the air bags may deploy air bag(s) in certain collisions.
  • Page 72 Safety features of your vehicle Although the driver’s and front passen- ger’s air bags are designed to inflate only in frontal collisions, they also may inflate in other types of collisions if the front impact sensors detect a sufficient impact. Side impact and curtain air bags are designed to inflate only in side impact collisions, but they may inflate in other collisions if the side impact sensors...
  • Page 73 Safety features of your vehicle OBH038058 OBH038059L OBH038060 • Frontal air bags are not designed to • Front air bags may not inflate in side • In an angled collision, the force of inflate in rear collisions, because occu- impact collisions, because occupants impact may direct the occupants in a pants are moved backward by the move to the direction of the collision,...
  • Page 74 Safety features of your vehicle OBH038061 OBH038062 OBH038063 • Just before impact, drivers often brake • Air bags may not inflate in rollover acci- • Air bags may not inflate if the vehicle heavily. Such heavy braking lowers the dents because air bag deployment collides with objects such as utility front portion of the vehicle causing it to would not provide protection to the...
  • Page 75 • No objects should be placed over HYUNDAI dealer. Improper handling of HYUNDAI dealer knows these or near the air bag modules on the the SRS system may result in serious...
  • Page 76 Safety features of your vehicle C041300ABH • Keep occupants away from the air Additional safety precautions WARNING bag covers. All occupants should sit upright, fully back in their seats with • All occupants should sit upright, fully • Sitting improperly or out of posi- their seat belts on and their feet on the back in their seats with their seat belts tion can cause occupants to be...
  • Page 77 Safety features of your vehicle (if equipped) OBH038047/OBH038048/OBH038049/OBH038065 C041200AUN-EU Air bag warning label Air bag warning labels, some required by the U.S. National Highway Traffic Safety Administration (NHTSA), are attached to alert the driver and passengers of potential risks of the air bag system.

  • Page 78: Features Of Your Vehicle

    Keys / 4-3 Smart key / 4-6 Remote keyless entry / 4-11 Theft-alarm system / 4-14 Door locks / 4-16 Trunk / 4-20 Windows / 4-23 Hood / 4-27 Features of your vehicle Fuel filler lid / 4-28 Sunroof / 4-30 Driver position memory system / 4-34 Steering wheel / 4-37 Mirrors / 4-39...
  • Page 79 Windshield defrosting and defogging / 4-99 Storage compartments / 4-102 Interior features / 4-103 Audio system / 4-111 Features of your vehicle...
  • Page 80 The ignition Should you lose your keys, this number key would enable children to oper- will enable an authorized HYUNDAI deal- ate power windows or other con- er to duplicate the keys easily. Remove trols, or even make the vehicle...
  • Page 81 Features of your vehicle Trunk locking D010300CBH-EU Immobilizer system To activate the trunk lock system so that the trunk can only be opened with the Your vehicle is equipped with an elec- master key, perform the following: tronic engine immobilizer system to 1.
  • Page 82 FCC rules. If you need additional keys or lose your Operation is subject to the following two In order to prevent theft of your keys, consult an authorized HYUNDAI conditions: vehicle, do not leave spare keys dealer. anywhere in your vehicle. Your 1.

  • Page 83: Smart Key

    Features of your vehicle SMART KEY D040100ABH Smart key functions With the smart key, you can lock and unlock the vehicle doors (and trunk), and the smart key enables starting of the engine as well. Detailed information fol- lows: OTG040001 OBH048002 D040000ABH D040101ABH...
  • Page 84 Features of your vehicle Even though you press the outside door When the smart key is recognized in the D040103ABH-EU Trunk unlocking handle buttons, the doors will not lock area of 28~40 in. (0.7~1 m) from the front and the chime will sound for 3 seconds if outside door handle, other people can When all doors are locked if you are with- any of following occur:...
  • Page 85 WARNING ately take the vehicle and key to your Changes or modifications not authorized HYUNDAI dealer to pro- expressly approved by the party tect it from potential theft. responsible for compliance could • The smart key will not work if any of void the user’s authority to operate...
  • Page 86 Features of your vehicle When leaving your keys with a parking lot attendant or valet, perform steps 1 to 4 above, remove the mechanical key from the smart key and leave the smart key with the attendant. In this manner the smart key can only be used to start the engine and operate door locks.
  • Page 87 • If you suspect that your smart key your smart key or replace the battery, might have sustained some damage, contact an authorized HYUNDAI dealer. or you feel your smart key is not working correctly, contact an author- ✽ ✽ NOTICE ized HYUNDAI dealer.

  • Page 88: Remote Keyless Entry

    Features of your vehicle REMOTE KEYLESS ENTRY ✽ ✽ NOTICE However, if any door (or trunk) remains Type A open, the hazard warning lights and the You can change the system to unlock all chime will not operate. If all doors (and doors by one pressing the unlock button trunk) are closed after the lock button is on the smart key.
  • Page 89 If you have a problem responsible for compliance, it will with the transmitter, contact an author- not be covered by your manufactur- ized HYUNDAI dealer. er’s vehicle warranty. CAUTION Keep the transmitter away from water or any liquid. If the keyless...
  • Page 90 “+” sym- Dispose the battery according to bol faces up. your local law(s) or regulation. 3. Install the battery in the reverse order of removal. For replacement transmitters, see an authorized HYUNDAI dealer for transmit- ter reprogramming. 4 13...

  • Page 91: Theft-Alarm System

    Features of your vehicle THEFT-ALARM SYSTEM D030100BBH If any door, trunk lid or engine hood Armed stage remains open, the hazard warning lights won’t operate and theft-alarm Park the car and stop the engine. Arm will not arm. To arm the system close the system as described below.
  • Page 92 (for Canada) opened while the trunk lid open and the • If you lose your keys, consult your alarm armed, the alarm will sound. authorized HYUNDAI dealer. D030200ABH-EU Theft-alarm stage D030400ABH-EE The alarm will be activated if any of the...

  • Page 93: Door Locks

    Features of your vehicle DOOR LOCKS • Doors can also be locked and unlocked with the transmitter (or smart key). • Once the doors are unlocked, they may be opened by pulling the door handle. • When closing the door, push the door Unlock by hand.
  • Page 94 Features of your vehicle • Front doors cannot be locked if the Driver’s door ignition key is in the ignition switch (or if the smart key is in the vehicle) and any door is open. WARNING - Door lock mal- Lock Unlock function...
  • Page 95 Features of your vehicle • When pushing down on the front por- D050300AAM-EE WARNING tion (1) of the switch, all vehicle doors Unlocked Impact sensing door unlock system will lock. vehicles (if equipped) • When pushing down on the rear por- Leaving your vehicle unlocked can In the event of air bag deployment result- tion (2) of the switch, all vehicle doors...
  • Page 96 Features of your vehicle ✽ ✽ NOTICE 3. Close the rear door. To open the rear door, pull the outside You can activate or deactivate some auto door handle. door lock/unlock features in the INFO menu of DIS (Driver Information Even though the doors may be unlocked, System, if equipped) as follows;...
  • Page 97 Features of your vehicle TRUNK CAUTION Type A Make certain that you close the trunk before driving your vehicle. Possible damage may occur to the trunk lift cylinders and attached hardware if the trunk is not closed Type B prior to driving. OBH048012L OBH048013 •...
  • Page 98 Features of your vehicle D070200ABH WARNING Closing the trunk • No one should be allowed to To close, lower the trunk lid, then press occupy the trunk of the vehicle at down on it until it locks. To be sure the any time.
  • Page 99 Features of your vehicle ✽ ✽ NOTICE Close the trunk, and keep the trunk lid control button in the OFF (not depressed) position before washing the vehicle in an automatic car wash. OBH048021 D070403ABH-EU Trunk lid control button The trunk lid control button located in the vehicle glove box is used to prevent unauthorized access to the trunk.
  • Page 100 Features of your vehicle WINDOWS D080000AEN (1) Driver’s door power window switch (2) Front passenger’s door power win- dow switch (3) Rear door (left) power window switch (4) Rear door (right) power window switch (5) Window opening and closing (6) Automatic power window up/down (if equipped) (7) Power window lock switch ✽...
  • Page 101 Features of your vehicle D080100BBH Power windows The ignition switch must be in the ON position for power windows to operate. Each door has a power window switch that controls the door's window. The driv- er has a power window lock switch which can block the operation of passenger windows.
  • Page 102 Features of your vehicle ✽ ✽ NOTICE If the power window is not operated cor- rectly, the automatic power window sys- The automatic reverse feature for the tem must be reset as follows: driver’s and front passenger’s windows 1. Turn the ignition switch to the ON posi- are only active when the “auto up”...
  • Page 103 Features of your vehicle CAUTION WARNING - Windows • To prevent possible damage to • NEVER leave the ignition key (or the power window system, do not smart key) in the vehicle. open or close two windows or • NEVER leave any child unattend- more at the same time.
  • Page 104 Features of your vehicle HOOD WARNING • Before closing the hood, ensure that all obstructions are removed from the hood opening. Closing the hood with an obstruction present in the hood opening may result in property damage or severe personal injury. •...

  • Page 105: Fuel Filler Lid

    Features of your vehicle FUEL FILLER LID D100200AUN Closing the fuel filler lid 1. To install the cap, turn it clockwise until it “clicks” one time. This indicates that the cap is securely tightened. 2. Close the fuel filler lid and push it in lightly making sure that it is securely closed.
  • Page 106 Features of your vehicle (Continued) (Continued) WARNING - Refueling dan- Use only approved portable plas- • Do not get back into a vehicle gers tic fuel containers designed to once you have begun refueling Automotive fuels are flammable carry and store gasoline. since you can generate static materials.
  • Page 107 HYUNDAI cap or the equivalent If the fuel filler lid does not open using specified for your vehicle. An the remote fuel filler lid release, you can...
  • Page 108 Features of your vehicle CAUTION Do not continue to move the sun- roof control lever after the sunroof is in the fully open, closed, or tilt position(s). Damage to the motor or system components could occur. ✽ ✽ NOTICE The sunroof cannot slide when it is in the tilt position nor can it be tilted while in an open or slide position.
  • Page 109 Features of your vehicle WARNING - Sunroof • Be careful that no heads, hands and body parts are obstructing a closing sunroof. • Do not extend the face, neck, arms or body outside the sunroof while driving. • Make sure your hands and head are safely out of the way before closing a sunroof.
  • Page 110 TILT DOWN → SLIDE OPEN → SLIDE CLOSE Then, release the control lever. When this is complete, the sunroof sys- tem is reset. ❈ For more detailed information, contact an authorized HYUNDAI dealer. 4 33...
  • Page 111 The buzzer sounds 10 times if there is a malfunction of the memory system. D120101ABH Have the driver position memory system Storing driver’s seat positions checked by an authorized HYUNDAI 1. Shift the shift lever into P while the dealer. ignition switch is ON. 2. Adjust...
  • Page 112 Features of your vehicle ✽ ✽ NOTICE D120102ABH D120300BBH Recalling positions from memory Easy access function You can activate or deactivate the easy (if equipped) 1. Shift the shift lever into P while the access function in the INFO menu of ignition switch is ON.
  • Page 113 Features of your vehicle Left/Right : When the remote control outside rearview mirror switch is selected to the left/right position, both out- side rearview mirrors will move downward. Neutral : When the remote control out- side rearview mirror switch is placed in the middle position, the outside rearview mirrors will not operate.
  • Page 114 The steering wheel should be positioned vehicle operation, have the power steer- so that it is comfortable for you to drive, ing checked by an authorized HYUNDAI ✽ ✽ NOTICE while permitting you to see the instru- dealer.
  • Page 115 Features of your vehicle OBH048037L OBH048038L OBH048039L D130301ABH D130302ABH D130500AUN Manual type Electric type Horn To change the steering wheel angle, pull Adjust the steering wheel angle (2) and To sound the horn, press the horn sym- up the lock-release lever (1), adjust the position (3) with the knob (1).

  • Page 116: Inside Rearview Mirror

    Features of your vehicle MIRRORS ✽ ✽ NOTICE D140100AUN Inside rearview mirror To sound the horn, press the area indi- cated by the horn symbol on your steer- Adjust the rearview mirror to center on ing wheel (see illustration). The horn the view through the rear window.
  • Page 117 Features of your vehicle Automatic-Dimming Night Vision Automatic-dimming function Z-Nav™ Compass Display Safety™ (NVS ® ) Mirror Your mirror will automatically dim upon The NVS™ Mirror in your vehicle is also The NVS Mirror in your vehicle is the equipped with a Z-Nav™ Compass that ®...
  • Page 118 Features of your vehicle To adjust the Zone setting: 1. Determine the desired Zone Number based upon your current location on the Zone Map. 2. Press and hold the button for more than 3 but less than 6 seconds, the current Zone Number will appear on the display.
  • Page 119 Features of your vehicle Programming HomeLink ® 1. Press and hold the button for more CAUTION ✽ ✽ NOTICE than 6 seconds. When the compass Before programming HomeLink ® memory is cleared a "C" will appear in • When programming a garage door a garage door opener or gate oper- the display.
  • Page 120 Features of your vehicle Standard programming 6. To program remaining If there is difficulty locating the training HomeLink ® buttons, follow steps 2 button, reference the device owner's To train most devices, follow these through 5. manual or please visit our Web site at instructions: www.homelink.com.
  • Page 121 Features of your vehicle Gate operator & Canadian program- Reprogramming a single HomeLink ® Erasing HomeLink ® buttons ming button Individual buttons cannot be erased. During programming, your handheld To program a new device to a previously However, to erase all three programmed transmitter may automatically stop trans- trained HomeLink ®...

  • Page 122: Outside Rearview Mirror

    Features of your vehicle FCC ID: NZLZTVHL3 D140200AUN-EU CAUTION Outside rearview mirror IC: 4112A-ZTVHL3 Do not scrape ice off the mirror Be sure to adjust mirror angles before face; this may damage the surface driving. This device complies with Part 15 of of the glass.
  • Page 123 Features of your vehicle CAUTION • The mirrors stop moving when they reach the maximum adjust- ing angles, but the motor contin- ues to operate while the switch is depressed. Do not depress the switch longer than necessary, the motor may be damaged. •...

  • Page 124: Features Of Your Vehicle

    Features of your vehicle INSTRUMENT CLUSTER ■ ■ Conventional Type 1. Tachometer 7. Odometer/Trip computer 2. Turn signal indicators 8. Fuel gauge 3. Speedometer * The actual cluster in the vehicle may differ from the illustration. 4. Engine temperature gauge For more details refer to the "Gauges"...
  • Page 125 Features of your vehicle ■ ■ Supervision Type I 1. Tachometer 7. LCD screen 2. Turn signal indicators Low washer fluid level warning light* 3. Speedometer SCC sensor malfunction indicator* 4. Engine temperature gauge AUTO AUTO HOLD malfunction indicator* HOLD 5.
  • Page 126 Features of your vehicle ■ ■ Supervision Type II 1. Tachometer LDWS LDWS malfuntion indicator* FAIL 2. Turn signal indicators SCC malfunction indicator* 3. Speedometer SCC sensor malfunction indicator* 4. Engine temperature gauge Charging system warning light 5. Warning and indicator lights Low washer fluid level warning light* 6.

  • Page 127: Instrument Panel Illumination

    Features of your vehicle Conventional Type Conventional Type OBH048231 OBH048049 Supervision Type Supervision Type OBH048046L D150100AUN Instrument panel illumination When the vehicle’s parking lights or headlights are on, rotate the illumination control knob to adjust the brightness of the instrument panel illumination. OBH048233 OBH048050 Gauges...
  • Page 128 Features of your vehicle When the door is open, or if the engine is Conventional Type Supervision Type WARNING not started within 1 minute, the tachome- ter pointer may move slightly in ON posi- Never remove the radiator cap tion with the engine OFF. This movement when the engine is hot.
  • Page 129 Features of your vehicle Conventional Type Supervision Type WARNING - Fuel gauge Running out of fuel can expose vehicle occupants to danger. You must stop and obtain addition- al fuel as soon as possible after the warning light comes on or when the gauge indicator comes close to the E level.
  • Page 130 Features of your vehicle Conventional Type Conventional Type Supervision Type I Conventional Type Supervision Type I TRIP A TRIP B Supervision Type TRIP A OBH048055N OBH048054N Supervision Type II Supervision Type II TRIP B Odometer OBH041332N OBH041331N Odometer (mi. or km) Tripmeter (mi.
  • Page 131 Features of your vehicle The meter's working range is from 0.0 to 999.9 miles (0.0 to 999.9 km). Conventional Type Supervision Type I Pressing the TRIP button for more than 1 second, when the tripmeter (TRIP A or TRIP B) is being displayed, clears the tripmeter to zero (0.0).
  • Page 132 Features of your vehicle Pressing the RESET button for more Conventional Type Supervision Type I than 1 second, when the average speed Conventional Type Supervision Type I is being displayed, clears the average speed to zero (---). OBH048059N OBH048060N Supervision Type II Supervision Type II OBH041059N OBH049060L...
  • Page 133 Features of your vehicle Pressing the RESET button for more than 1 second, when the driving time is Conventional Type Supervision Type I Conventional Type Supervision Type I being displayed, clears the driving time to zero (0:00). OBH048208N OBH049236N Supervision Type II Supervision Type II OBH041061N OBH041062N...
  • Page 134 1.6 gallons (6 driving, have the SRS inspected by an liters) of fuel are added to the vehicle. authorized HYUNDAI dealer. • The fuel consumption and distance to empty values may vary significantly based on driving conditions, driving habits, and condition of the vehicle.
  • Page 135 Have the (ABS) warning light vehicle checked by an authorized HYUNDAI dealer as soon as possible. As a reminder to the driver, the seat belt This light illuminates if the ignition switch warning light will blink for approximately...
  • Page 136 D150331ABH when the engine is running, the Tail light indicator engine should be checked by an authorized HYUNDAI dealer before the car is driven again. This indicator illuminates when the tail lights are on. 4 59...
  • Page 137 D150308ABH-EU Have the vehicle towed to any author- D150331ABH Parking brake & brake fluid Low tire pressure ized HYUNDAI dealer for a brake sys- warning light telltale tem inspection and necessary repairs. Your vehicle is equipped with a dual- Parking brake warning diagonal braking system.
  • Page 138 2. With the engine off, check the genera- vehicle checked by an authorized tor drive belt for looseness or break- HYUNDAI dealer as soon as possible. age. 3. If the belt is adjusted properly, a prob- lem exists somewhere in the electrical charging system.
  • Page 139 Have the vehicle authorized HYUNDAI dealer. This warning light illuminates when the checked by an authorized HYUNDAI trunk lid is not closed securely with the dealer. ignition in any position.
  • Page 140 D150319AUN System inspected as soon as pos- tion, and will go out in a few seconds Low washer fluid level sible by an authorized HYUNDAI after the engine is started. If it illuminates warning light (if equipped) dealer. while driving, or does not illuminate when...
  • Page 141 For more information about the ESC may have a malfunction. Take your use of cruise control, refer to “Cruise car to an authorized HYUNDAI dealer control system or Smart cruise control and have the system checked. system” in section 5.
  • Page 142 FAIL tem is not functioning normally. Take your vehicle to an authorized With smart key HYUNDAI dealer and have the system If the LDWS malfunction indicator comes If the driver’s door is opened while the checked. on, the LDWS is not working properly.
  • Page 143 AUTO HOLD is not working properly. Take Front Light System is not working prop- Take your vehicle to an authorized your vehicle to an authorized HYUNDAI erly. HYUNDAI dealer and have the system dealer and have the system checked.
  • Page 144 Features of your vehicle D150401ABH D150402ABH D150403ABH Key is not detected Low key battery Warning on the LCD screen (if equipped) Key is not in vehicle Type I Type II Type I Type II If the smart key is not in the vehicle or is When the smart key in the vehicle dis- Type I Type II...
  • Page 145 Features of your vehicle D150404ABH D150405ABH D150406ABH Press brake pedal to start engine Shift to "P" position Remove key Type I Type I Type II Type I Type II Type II If the engine start/stop button turns to the If you push the engine start/stop button When you turn off the engine with the ACC position twice by pushing the with the engine start/stop button ON and...
  • Page 146 N(Neutral), but for your safe- If the warning illuminates each time you ty start the engine with the shift lever in push the engine start/stop button, take P(Park). your vehicle to an authorized HYUNDAI dealer and have the system checked. 4 69...
  • Page 147 Features of your vehicle D150410ABH D150411ABH D150412ABH Press start button while turn steering Check steering wheel lock Check stop lamp fuse Type I Type I Type II Type I Type II Type II When the steering wheel does not When the steering wheel does not lock, When the stop lamp fuse is disconnect- unlock, the warning illuminates for 10 the warning illuminates for 10 seconds...
  • Page 148 Features of your vehicle PARKING ASSIST SYSTEM (IF EQUIPPED) sensing range objects detectable by the sensors are limited. When moving the vehicle, pay as much attention to what is in front of and behind you as you would in a vehicle without a parking assist system.
  • Page 149 Features of your vehicle ✽ ✽ NOTICE D170200ABH 2. Objects generating excessive noise Non-operational conditions of such as vehicle horns, loud motorcycle The parking assist system may not oper- engines, or truck air brakes can inter- parking assist system ate if the vehicle’s distance from the fere with the sensor.
  • Page 150 If this occurs, have your vehicle ment or accessories may also interfere behind the vehicle when driving. checked by an authorized HYUNDAI dealer as soon as possible. with the sensor performance. Be sure to inform any drivers in the 3.
  • Page 151 Features of your vehicle REAR VIEW CAMERA (IF EQUIPPED) HAZARD WARNING FLASHER The green line (1) is the position 118.11 in (300 cm) from the rear bumper. The yellow line (2) is the position 39.37 in (100 cm) from the rear bumper. The red line (3) is the position 19.68 in (50 cm) from the rear bumper.

  • Page 152: Headlight Escort Function

    Features of your vehicle LIGHTING D190100ABH D190200ABH Headlight escort function Battery saver function (if equipped) • The purpose of this feature is to pre- vent the battery from being dis- If you turn the ignition switch to the ACC charged. The system automatically or OFF position with the headlights ON, turns off the parking lights when the the headlights (and/or tail lights) remain...
  • Page 153 Features of your vehicle OBH049073 OBH049074 OBH049075 D190401ABH D190402ABH D190403AUN Parking light position ( Headlight position ( Auto light position (if equipped) When the light switch is in the headlight When the light switch is in the parking When the light switch is in the AUTO light light position (1st position), the tail, position (2nd position), the head, tail, position, the taillights and headlights will...
  • Page 154 Features of your vehicle CAUTION • Never place anything over the sensor (1) located on the instru- ment panel. This will ensure bet- ter auto-light system control. • Don’t clean the sensor using a window cleaner. The cleaner may leave a light film which could interfere with sensor operation.
  • Page 155 Features of your vehicle To signal a lane change, move the turn signal lever slightly and hold it in position (B). The lever will return to the OFF posi- tion when released. If an indicator stays on and does not flash or if it flashes abnormally, one of the turn signal bulbs may be burned out and will require replacement.
  • Page 156 Headlight leveling device System) (if equipped) Have the system checked by an author- (if equipped) ized HYUNDAI dealer as soon as possi- AFLS uses the steering angle and vehi- ble to determine the cause of the prob- Automatic type cle speed. To keep your field of vision lem.

  • Page 157: Wipers And Washers

    In Windshield wipers · MIST – Single wipe this case, have your vehicle checked by an authorized HYUNDAI dealer as · OFF – Off Operates as follows when the ignition soon as possible. switch is turned ON.
  • Page 158 Features of your vehicle CAUTION CAUTION When the ignition switch is ON and When washing the vehicle, set the the windshield wiper switch is wiper switch in the OFF position to placed in the AUTO mode, use cau- stop the auto wiper operation. tion in the following situations to The wiper may operate and be dam- avoid any injury to the hands or...
  • Page 159 Features of your vehicle CAUTION To prevent possible damage to the washer pump, do not operate the washer when the fluid reservoir is empty. WARNING Do not use the washer in freezing temperatures without first warming the windshield with the defrosters; OBH049082 the washer solution could freeze on D200200AUN...

  • Page 160: Interior Light

    Features of your vehicle INTERIOR LIGHT D210000AEN When doors are unlocked by the transmitter (or smart key), CAUTION the map lamp and the room lamp come on for approximate- Do not use the interior lights for ly 30 seconds as long as any extended periods when the engine door is not open.
  • Page 161 Features of your vehicle OBH048084N OBH048085 OBH048086 D210200ABH-EU D210300ABH D210400AEN Room lamp Trunk room lamp Door courtesy lamp (if equipped) • : Push the switch to turn the The trunk room lamp comes on when the room lamp on or off. This light trunk is opened.
  • Page 162 Features of your vehicle OBH048087 OEN046081 D210500ABH D210600AUN Glove box lamp Vanity mirror lamp The glove box lamp comes on when the Opening the lid of the vanity mirror will glove box is opened. automatically turn on the mirror light. CAUTION CAUTION To prevent unnecessary charging...
  • Page 163 Features of your vehicle DEFROSTER D220000AUN D220101AEN Outside rearview mirror defroster CAUTION (if equipped) To prevent damage to the conduc- If your vehicle is equipped with the out- tors bonded to the inside surface of side rearview mirror defrosters, they will the rear window, never use sharp operate at the same time you turn on the instruments or window cleaners...

  • Page 164: Automatic Climate Control System

    Features of your vehicle AUTOMATIC CLIMATE CONTROL SYSTEM 1. AUTO (automatic control) button 7. AQS (Air quality system) button 2. Front windshield defrost button 8. Dual temperature control selection button 3. Rear window defrost button 9. Driver’s temperature control button 4.
  • Page 165 Features of your vehicle 2. Push the TEMP button to set the desired temperature. If the temperature is set to the lowest setting (Lo), the air conditioning sys- tem will operate continuously. 3. To turn the automatic operation off, press any button except the tempera- ture control button.
  • Page 166 Features of your vehicle D240200ABH Manual heating and air condition- The heating and cooling system can be controlled manually by pushing buttons other than the AUTO button. In this case, the system works sequentially according to the order of buttons selected. ✽...
  • Page 167 Features of your vehicle ❈ ❈ Rear outlet vents (F) • The air flow of the Rear outlet vents is Face-Level (B, C, D, E, F, G) delivered by the front climate control system and delivered through the Air flow is directed toward the upper body inside air duct of the front doors.
  • Page 168 Features of your vehicle OBH048094N OBH048095L OBH048096 Defrost-Level (A, D, F) Instrument panel vents D240202ABH-EU Temperature control Most of the air flow is directed to the The outlet vents can be opened or closed windshield with a small amount of air separately using the horizontal thumb- The temperature will increase to the directed to the side window defrosters.
  • Page 169 Features of your vehicle Adjusting the driver and passenger side temperature equally 1. Press the DUAL button again to deac- tivate DUAL mode. The passenger side temperature will be set to the same temperature as the driver side temperature. 2. Press the left temperature control but- ton.
  • Page 170 Features of your vehicle Recirculated air position WARNING With the recirculated air position selected, air from • Continued use of the climate con- the passenger compart- trol system operation in the recir- ment will be drawn through culated air position may allow the heating system and humidity to increase inside the heated or cooled according...
  • Page 171 Features of your vehicle Exhaust gas cutoff mode : Air enters the vehicle from the outside. If exhaust gas enters the vehicle from the outside, the exhaust gas cutoff mode of the Air Quality System automatically switches from the outside air position to the recirculated air position to prevent exhaust gas from entering the vehicle.
  • Page 172 Features of your vehicle System operation Operation Tips • To keep dust or unpleasant fumes from D230501AUN entering the car through the ventilation Ventilation system, temporarily set the air intake 1. Set the mode to the position. control to the recirculated air position. 2.
  • Page 173 • If the vehicle has been parked in direct • When using the air conditioning sys- sunlight during hot weather, open the All HYUNDAI Air Conditioning Systems tem, monitor the engine temperature windows for a short time to let the hot...

  • Page 174: Climate Control Air Filter

    • When the air flow rate suddenly operation in this mode may cause the decreases, the system should be Blower air inside the vehicle to become stale. checked at an authorized HYUNDAI Heater core Climate control Evaporator After sufficient cooling has been dealer.

  • Page 175: Rear Vent

    To close the vent, be serviced by an authorized rotate it down to the maximum position. HYUNDAI dealer. Improper service To open the vent, rotate it up to the may cause serious injury to the desired position.
  • Page 176 Features of your vehicle WINDSHIELD DEFROSTING AND DEFOGGING D250000AEN • For maximum defrosting, set the tem- perature control to the extreme right/hot position and the fan speed WARNING Windshield control to the highest speed. heating • If warm air to the floor is desired while Do not use the position defrosting or defogging, set the mode...
  • Page 177 Features of your vehicle D250300AUN-EU Defogging logic To reduce the possibility of fogging up the inside of the windshield, the air intake is controlled automatically according to certain conditions such as position. To cancel or return the defog- ging logic, perform the following steps: OBH049104 OBH048105 D250202AEN-EU...
  • Page 178 Features of your vehicle ✽ ✽ NOTICE This indicator illuminates when the auto defogging • If the A/C off or recirculated air posi- system senses the moisture tion is manually selected while the of inside the windshield and auto defogging system is on, the auto operates.
  • Page 179 Features of your vehicle STORAGE COMPARTMENTS D270000AUN These compartments can be used to store small items required by the driver or passengers. CAUTION • To avoid possible theft, do not leave valuables in the storage compartments. • Always keep the storage com- partment covers closed while driving.

  • Page 180: Interior Features

    To use the cigarette lighter, push it all the way into its socket. When the element has heated, the lighter will pop out to the “ready” position. If it is necessary to replace the cigarette lighter, use only a genuine HYUNDAI replacement or its approved equivalent. 4 103...

  • Page 181: Cup Holder

    CAUTION • To reduce the risk of personal OBH048115 Only a genuine HYUNDAI lighter injury in the event of sudden stop should be used in the cigarette D280200ABH or collision, do not place uncov- lighter socket.
  • Page 182 Features of your vehicle To use the vanity mirror, pull down the Front visor and slide the mirror cover (3). Adjust the sunvisor forward or backward (4). CAUTION - Vanity mirror lamp Close the vanity mirror cover securely and return the sunvisor to its original position after use.

  • Page 183: Power Outlet

    Features of your vehicle CAUTION • Use the power outlet only when the engine is running and remove the accessory plug after use. Using the accessory plug for pro- longed periods of time with the engine off could cause the bat- tery to discharge.
  • Page 184 Features of your vehicle • If the battery has been discharged or D280601AUN Type A disconnected, the temperature mode Hour (1) display will reset to Fahrenheit. Pressing the H button with your finger, a This is a normal condition. You can pencil or similar object will advance the time displayed by one hour.
  • Page 185 To avoid any interference with pedal operation, HYUNDAI recommends that only the HYUNDAI floor mat designed for use in your vehicle be installed.

  • Page 186: Luggage Net (Holder)

    Features of your vehicle CAUTION To prevent damage to the goods or the vehicle, care should be taken when carrying fragile or bulky objects in the luggage compart- ment. WARNING Avoid eye injury. DO NOT over- stretch the luggage net, ALWAYS OBH048125 OBH048126 keep your face and body out of the...

  • Page 187: Bluetooth Hands-Free

    Features of your vehicle Type A OBH048139N Type B OBH041141N OBH048139L D281400AFD D282000ABH Aux, USB and iPod port DIS (Driver Information System) ® (if equipped) If your vehicle has an aux and/or USB(universal serial bus) port or iPod Information for DIS is provided in the DIS port, you can use an aux port to connect manual.

  • Page 188: Audio System

    Features of your vehicle AUDIO SYSTEM ✽ ✽ NOTICE If you install an aftermarket HID head- lamp, your vehicle's audio and electron- ic device may malfunction. OBH048136 Antenna D300102ABH Glass antenna (if equipped) When the radio power switch is turned on while the ignition key is in either the “ON”...
  • Page 189 Features of your vehicle D300204ABH RADIO mode FM radio reception VOLUME ( ) (1) It will function as the PRESET STATION select buttons. • Press the up button ( ) to increase volume. • Press the down button ( ) to CDP mode decrease volume.
  • Page 190 Features of your vehicle AM radio receptionreception FM radio station JBM002 JBM003 JBM004 AM broadcasts can be received at FM broadcasts are transmitted at high • Fading - As your car moves away from greater distances than FM broadcasts. frequencies and do not bend to follow the the radio station, the signal will weaken This is because AM radio waves are earth's surface.
  • Page 191 Features of your vehicle Satellite radio reception • If you are driving on a mountain road where the signal is blocked by moun- You may experience problems in receiv- tains. ing XM™ satellite radio signals in the fol- lowing situations. JBM005 •...
  • Page 192 Features of your vehicle Using a cellular phone or a two-way Care of discs • Keep CDs in their cases after use to radio protect them from scratches or dirt. • If the temperature inside the car is too When a cellular phone is used inside the •...
  • Page 193 Features of your vehicle RADIO, SET UP, VOLUME CONTROL (CD Player : PA710BH) 1. FM/AM Button 2. POWER Button & VOLUME Knob 3. SEEK Button 4. PRESET Buttons 5. DISPLAY (Screen ON/OFF) Button 6. TUNE Knob & SETUP Button 7. SCAN Button BH_PA710BH_RADIO...
  • Page 194 Features of your vehicle Using RADIO, SET UP, VOLUME 4. PRESET Buttons 7. SCAN Button Control Press [1]~[6] buttons less than 0.8 second Press to hear a brief sampling of all sta- to play the channel saved in each button. tions on the frequency band.
  • Page 195 Features of your vehicle (CD Player : PA710BH) 1. RANDOM Button 2. REPEAT Button 3. CD Button 4. TRACK Button 5. SCAN Button 6. CD Eject Button 7. TUNE Knob & SETUP Button 8. INFO Button 9. FOLDER Button 10. CD Indicator 11.
  • Page 196 Features of your vehicle Using CD Player 9. FOLDER Button • Press [TRACK ] button for 0.8 sec- ond or longer to initiate high speed • Press [FOLDER ] button child folder 1. RANDOM Button sound search of current song. of the current folder and display the first song in the folder.
  • Page 197 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
  • Page 198 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • Please avoid using USB memory logical drives, only the music files products which can be used as on the highest-priority drive are key chains or cellular phone recognized by car audio.
  • Page 199 Features of your vehicle (CD Player : PA710BH) 1. RANDOM Button 2. REPEAT Button 3. USB Button 4. TRACK Button 5. SCAN Button 6. TUNE Knob & SETUP Button 7. INFO Button 8. FOLDER Button BH_PA710BH_USB...
  • Page 200 Features of your vehicle Using USB device 4. TRACK Button 7. INFO Button Using a USB that is connected to the Displays the information of the file cur- • Press [TRACK ] button for less than ➟ rently played in order of FILE TITLE multiple terminal inside the console on 0.8 second to play from the beginning...
  • Page 201 Features of your vehicle ® ® iPod (CD Player : PA710BH) 1. RANDOM Button 2. REPEAT Button 3. iPod Button 4. TRACK Button 5. CATEGORY Button 6. TUNE Knob & SETUP Button 7. INFO Button ❈ iPod ® is a trademark of Apple Inc. ®...
  • Page 202 Features of your vehicle ® ® Using iPod 6. TUNE Knob & SETUP Button • Press the [TRACK ] button for less Using an iPod when the exclusive cable than 0.8 second and press again with- Turn this button clockwise or counter- is connected to the multiple terminal clockwise, it will display the category in 1 seconds to play the previous song.
  • Page 203 DEVICE the system can be switched to the • Some iPod models might not sup- • The Hyundai iPod Power Cable is AUX mode even without the iPod port the communication protocol needed in order to operate an device and may cause noise.
  • Page 204 Features of your vehicle XM Satellite Radio (CD Player : PA710BH) 1. XM Button 2. SEEK Button 3. SCAN Button 4. PRESET Buttons 5. TUNE Knob & SETUP Button 6. INFO Button 7. CAT/FOLDER Button BH_PA710BH_XM RADIO 4 127...
  • Page 205 Features of your vehicle Using XM Satellite Radio 4. PRESET Buttons 7. CAT/FOLDER Button Push [1]~[6] buttons less than 0.8 sec- • Press [CAT ] button to search previ- ond to play the channel saved in each 1. XM Button ous category.
  • Page 206 Features of your vehicle RADIO, SET UP, VOLUME CONTROL (CD Changer : PA760BH) 1. FM/AM Button 2. POWER Button & VOLUME Knob 3. SEEK Button 4. PRESET Buttons 5. DISPLAY(Screen ON/OFF) Button 6. TUNE Knob & SETUP Button 7. SCAN Button ❈...
  • Page 207 Features of your vehicle Using RADIO, SET UP, VOLUME 4. PRESET Buttons 7. SCAN Button Control Push [1]~[6] buttons less than 0.8 second Press to hear a brief sampling of all sta- to play the channel saved in each button. tions on the frequency band.
  • Page 208 Features of your vehicle (CD Changer : PA760BH) 1. RANDOM Button 2. REPEAT Button 3. CD Button 4. TRACK Button 5. SCAN Button 6. CD Eject Button 7. TUNE Knob & SETUP Button 8. INFO Button 9. FOLDER Button 10. LOAD Button 11.
  • Page 209 Features of your vehicle Using CD Player 8. INFO Button • Press [SEEK ] button for less than 0.8 second to play the next song. Displays the information of the current CD TRACK (or FILE) in the order of DISC 1.
  • Page 210 Features of your vehicle 11. CD Slot Insert CD with printed side upward and gently push in. When the ignition switch is on ACC or ON and power is off, power is automatically turned on if the CD is loaded. This CDP supports 12 cm CDs. But if VCD, Data CD, or DVD discs are loaded, "Media Error"...
  • Page 211 Features of your vehicle (Continued) (Continued) CAUTION IN USING • An encrypted MP3 PLAYER is not • If you disconnect the external USB USB DEVICE recognizable. device during playback in USB • To use an external USB device, mode, the external USB device can •...
  • Page 212 Features of your vehicle (Continued) (Continued) • If the USB device is divided by • Please avoid using USB memory logical drives, only the music files products which can be used as on the highest-priority drive are key chains or cellular phone recognized by car audio.
  • Page 213 Features of your vehicle (CD Changer : PA760BH) 1. RANDOM Button 2. REPEAT Button 3. USB Button 4. TRACK Button 5. SCAN Button 6. TUNE Knob & SETUP Button 7. INFO Button 8. FOLDER Button BH_PA760BH_USB...
  • Page 214 Features of your vehicle Using USB device 4. TRACK Button 7. INFO Button Using a USB that is connected to the Displays the information of the file cur- • Press the [TRACK ] button for less ➟ rently played in order of FILE TITLE multiple terminal inside the console on than 0.8 second to play from the begin-...
  • Page 215 Features of your vehicle iPod ® (CD Changer : PA760BH) 1. RANDOM Button 2. REPEAT Button 3. iPod Button 4. TRACK Button 5. Category Button 6. TUNE Knob & SETUP Button 7. INFO Button ❈ iPod ® ® is a trademark of Apple Inc. iPod BH_PA760BH_...
  • Page 216 Features of your vehicle Using iPod ® 7. INFO Button • Press the [TRACK ] button for less Using an iPod when the exclusive cable than 0.8 second and press again with- Displays the information of the file cur- ➟ is connected to the multiple terminal rently played in order of TITLE ARTIST...
  • Page 217 DEVICE the system can be switched to the • Some iPod models might not sup- • The Hyundai iPod Power Cable is AUX mode even without the iPod port the communication protocol needed in order to operate an device and may cause noise.
  • Page 218 Features of your vehicle XM Satellite Radio (CD Changer : PA760BH) 1. XM Button 2. SEEK Button 3. SCAN Button 4. PRESET Buttons 5. TUNE Knob & SETUP Button 6. INFO Button 7. CAT/FOLDER Button BH_PA760BH_XM RADIO 4 141...
  • Page 219 Features of your vehicle Using XM Satellite Radio 4. PRESET Buttons 7. CAT/FOLDER Button Push [1]~[6] buttons less than 0.8 sec- • Press [CAT ] button to search previ- ond to play the channel saved in each 1. XM Button ous category.
  • Page 220 Features of your vehicle HD RADIO RECEPTION (CD Changer : PA760BH) 1. SEEK UP/DOWN Button 2. SCAN Button 3. INFO Button 4. PRESET Buttons 5. TUNE Knob & SETUP Button BH_PA760BH_HD_RADIO 4 143...
  • Page 221 Features of your vehicle HD RADIO INFORMATION Currently, radio stations broadcasting an HD Radio signal delay HD Radio signal are operating in a To overcome the delay that digital sys- hybrid mode of both, analog and digital, tems inherently produce, HD Radio Licensing information in order to reach both receivers.
  • Page 222 Features of your vehicle Automatic switching between dig- Radio display while receiving a 1. SEEK UP/DOWN Button ital and analog broadcasting digital HD Radio Press this button to automatically select previous or next station. If the digital signal reception is lost, the ➟...
  • Page 223 Features of your vehicle 4. PRESET Buttons 1. You can off/on FM HD Radio reception. • Push [1] ~[6] buttons less than 0.8 sec- ond to play the channel saved in each 2. You can off/on AM HD Radio button. reception.
  • Page 224 Features of your vehicle ■ ® General Feature ■ ® BLUETOOTH PHONE OPERATION Bluetooth Language Setting ® • This audio system supports Bluetooth (IF EQUIPPED) The system language can be changed by hands-free and stereo-headset features. the following steps: - HANDS-FREE feature: Making or 1.
  • Page 225 Features of your vehicle ■ ■ ■ Voice Recognition Activation Menu tree Voice Operation Tip • The voice recognition engine contained The menu tree identifies available voice To get the best performance out of the ® in the Bluetooth System can be activat- recognition Bluetooth functions.
  • Page 226 • If the phone is paired to two or more name you stated. paired in the system. vehicles of the same model, i.e. both 7. Say "Yes" to confirm. vehicles are HYUNDAI GENESIS, ✽ ✽ NOTICE 8. The audio displays “searching ---- some phones handle •...
  • Page 227 Features of your vehicle • Connecting phone 6. By manual operation: 1. Press button. ® When the Bluetooth system is enabled, - Select “PRIORITY” in PHONE menu, 2. Say “Set Up”. the phone previously used is automati- then select desired phone from the 3.
  • Page 228 Features of your vehicle ✽ ✽ NOTICE ■ Phone Book (In-Vehicle) This process may take over 10 minutes depending on the phone model and • Adding Entry • The system can recognize single digits number of entries from zero to nine. Numbers that are Phone numbers and voice tags can be 7.
  • Page 229 Features of your vehicle ✽ ✽ Tip ■ ■ Making a Phone Call Talking on the Phone A shortcut to each of the following func- • Calling by Name When talking on the phone, “Active Calls” tions is available: message and the other party’s phone A phone call can be made by speaking 1.
  • Page 230 Features of your vehicle ■ Using the head unit as Bluetooth • Please refer to User's Guide of your music phone for more detailed information. • To stop music, try stop music by the The head unit supports A2DP (Audio phone or change audio mode to Advanced Distribution...
  • Page 231 Features of your vehicle ■ Key matrix Disconnected(BT Icon off) Connected (BT Icon On) Connected Paired H/P Paired H/P TRANSFER Incoming Call Outgoing Call Active Call CALL Empty Exist Normal mode BT SETUP menu Transfer Call Not Connect Accept Call SHORT (Handsfree <->Phone) LONG...
  • Page 232 Features of your vehicle (Continued) CAUTION IN USING • Do not place the phone near or ® BLUETOOTH CELLU- inside metallic objects, otherwise LAR PHONE ® communications with Bluetooth • Do not use a cellular phone or system or cellular service sta- ®...

  • Page 233: Driving Your Vehicle

    Before driving / 5-3 Key / 5-4 Engine start/stop button / 5-7 Automatic transmission / 5-11 Brake system / 5-18 Cruise control system / 5-33 Smart cruise control system / 5-37 Lane departure warning system (LDWS) / 5-50 Economical operation / 5-53 Special driving conditions / 5-55 Winter driving / 5-59 Driving your vehicle...

  • Page 234: Driving Your Vehicle

    HYUNDAI dealer. • Do not run the engine in an enclosed area.

  • Page 235: Before Driving

    Driving your vehicle BEFORE DRIVING E020100AUN E020300AUN CALIFORNIA PROPOSI- Before entering vehicle Before starting TION 65 WARNING • Be sure that all windows, outside mir- • Close and lock all doors. Engine exhaust and a wide variety ror(s), and outside lights are clean. •...
  • Page 236 Driving your vehicle KEY (FOR CANADA) WARNING WARNING Always check the surrounding When you intend to park or stop the areas near your vehicle for people, vehicle with the engine on, be care- especially children, before putting a ful not to depress the accelerator car into D (Drive) or R (Reverse).

  • Page 237: Ignition Switch Position

    Driving your vehicle E030202ABH E030204AUN ACC (Accessory) START The electrical accessories are operative. Turn the ignition switch to the START position to start the engine. The engine will crank until you release the key; then E030203AUN it returns to the ON position. The brake warning lamp can be checked in this The warning lights can be checked position.
  • Page 238 Driving your vehicle Starting the engine (Continued) CAUTION E040000AUN-EU • Never reach for the ignition switch, If the engine stalls while you are in or any other controls through the motion, do not attempt to move the WARNING steering wheel while the vehicle is shift lever to the P (Park) position.

  • Page 239: Engine Start/Stop Button

    Driving your vehicle ENGINE START/STOP BUTTON Engine start/stop button position WARNING E030701BBH-EU You are able to turn off the engine (START) or vehicle power (ON), only To turn off the engine, press the engine when the vehicle is not in motion. In start/stop button with...
  • Page 240 Driving your vehicle ✽ ✽ NOTICE E030202ABH-EU (Continued) ACC(Accessory) • If you press the engine start/stop but- • Before leaving the driver’s seat, Press the engine start/stop button when ton without depressing the brake always make sure the shift lever the button is in the OFF position without pedal, the engine does not start and is engaged in P (Park), set the...
  • Page 241 Driving your vehicle Starting the engine CAUTION WARNING E040000ABH If the engine stalls while you are in The engine will start by pressing motion, do not attempt to move the the engine start/stop button, only WARNING shift lever to the P (Park) position. If when the smart key is in the vehi- Always wear appropriate shoes traffic and road conditions permit,...
  • Page 242 Driving your vehicle CAUTION • Do press engine start/stop button for more than 5 seconds except when the stop lamp fuse is disconnected. • When you eject the smart key from the smart key holder, press the smart key inward and pull it out.

  • Page 243: Automatic Transmission

    Driving your vehicle AUTOMATIC TRANSMISSION E060100ABH Automatic transmission operation The automatic transmission has 6 for- ward speeds and one reverse speed. The individual speeds are selected automati- cally, depending on the position of the shift lever. ✽ ✽ NOTICE The first few shifts on a new vehicle, if the battery has been disconnected, may + (UP) be somewhat abrupt.
  • Page 244 Driving your vehicle Always depress the brake pedal when E060101ABH CAUTION shifting from N (Neutral) to a forward or Transmission ranges reverse gear. • To avoid damage to your trans- The indicator in the instrument cluster mission, do not accelerate the displays the shift lever position when the engine in R (Reverse) or any for- ignition switch is in the ON position.
  • Page 245 Driving your vehicle R (Reverse) N (Neutral) CAUTION Use this position to drive the vehicle The wheels and transmission are not The transmission may be damaged backward. engaged. The vehicle will roll freely even if you shift into P (Park) while the on the slightest incline unless the parking vehicle is in motion.
  • Page 246 Driving your vehicle ✽ ✽ NOTICE E060102BBH Shift lock system • In sports mode, the driver must exe- For your safety, the automatic transmis- cute upshifts in accordance with road sion has a shift lock system which pre- conditions, taking care to keep the vents shifting the transmission from P engine speed below the red zone.
  • Page 247 • Slow down before shifting to a lower access hole and press down on the gear. Otherwise, the lower gear may key (or screwdriver). not be engaged. 3. Move the shift lever. 4. Have your vehicle inspected by an authorized HYUNDAI dealer immedi- ately. 5 15...
  • Page 248 Driving your vehicle • Always use the parking brake. Do not WARNING WARNING depend on placing the transmission in P (Park) to keep the car from moving. • Always buckle-up! In a collision, If your vehicle becomes stuck in • Exercise extreme caution when driving an unbelted occupant is signifi- snow, mud, sand, etc., then you on a slippery surface.
  • Page 249 Driving your vehicle E060203AUN Moving up a steep grade from a stand- ing start To move up a steep grade from a stand- ing start, depress the brake pedal, shift the shift lever to D (Drive). Select the appropriate gear depending on load weight and steepness of the grade, and release the parking brake.

  • Page 250: Brake System

    Driving your vehicle BRAKE SYSTEM E070100ABH E070101AUN WARNING In the event of brake failure Power brakes Brakes If service brakes fail to operate while the Your vehicle has power-assisted brakes • Do not drive with your foot rest- vehicle is in motion, you can make an that adjust automatically through normal ing on the brake pedal.
  • Page 251 Driving your vehicle E070102AUN CAUTION Disc brakes wear indicator • To avoid costly brake repairs, do Your vehicle has disc brakes. not continue to drive with worn When your brake pads are worn and new brake pads. pads are required, you will hear a high- •...
  • Page 252 If the brake warning light remains on after checked by an authorized HYUNDAI the parking brake is released while engine dealer. is running, there may be a malfunction in the brake system.

  • Page 253: Electronic Parking Brake (Epb)

    D (Drive) while pressing the foot brake position. pedal. Make sure that the brake warning light goes off. If the parking brake does not release or does not release all the way, have the system checked by an authorized HYUNDAI dealer. 5 21...
  • Page 254 Driving your vehicle Type I WARNING • To prevent unintentional move- ment when stopped and leaving the vehicle, do not use the shift lever in place of the parking brake. Set the parking brake and make sure the shift lever is securely positioned in P (Park).
  • Page 255 EPB may have malfunctioned. sible by pressing and holding the EPB Take your vehicle to an authorized switch. Braking is possible only while you HYUNDAI dealer and have the system are holding the EPB switch. checked. The EPB malfunction indicator may illu-...
  • Page 256 If the vehicle does not return gency release cable by turning it clock- to normal condition, take your vehicle wise. to an authorized HYUNDAI dealer and 7. Pull up the handle until sounds a have the system checked. "took".
  • Page 257 Driving your vehicle 2. When you stop the vehicle completely Type I Type I by pressing the brake pedal, the AUTO HOLD maintains the brake pressure in order to hold the vehicle stationary. The indicator changes from white to green. 3.
  • Page 258 Driving your vehicle Type I Type I WARNING When driving off from AUTO HOLD by applying accelerator pedal, always check the surrounding area near your vehicle. Slowly press the accelerator pedal for a smooth launch. OBH059013 OBH058014 Type II Type II OBH059073 OBH059016 Leaving...
  • Page 259 AUTO HOLD indicator ing properly. Take your vehicle to an changes from green to white, and authorized HYUNDAI dealer and warning sounds and a message will have the system checked. appear to inform you that EPB has been automatically engaged.

  • Page 260: Anti-Lock Brake System (Abs)

    Take your vehicle to an authorized system (or Electronic Stability Control system) may be longer than HYUNDAI dealer and have the sys- for those without it in the following tem checked. road conditions. During these conditions the vehicle...
  • Page 261 ABS will go through self-diagnosis and the light will go off if everything is normal. If the light stays on, you may have a problem with your ABS. Contact an authorized HYUNDAI dealer as soon as possible. 5 29...

  • Page 262: Electronic Stability Control (Esc)

    Even with ESC installed, always fol- E070500AUN-EU lem with the ABS. Contact an low all the normal precautions for Electronic stability control (ESC) authorized HYUNDAI dealer as driving - including driving at safe The Electronic Stability control (ESC) soon as possible. speeds for the conditions.
  • Page 263 Driving your vehicle The Electronic Stability Control (ESC) E070501ABH-EU • When moving out of the mud ESC operation system is an electronic system designed or driving on a slippery road, to help the driver maintain vehicle control the engine rpm (revolution ESC ON condition under adverse conditions.
  • Page 264 ESC may have a malfunction. Take your Have the vehicle checked by an author- ESC indicator light is blinking, or car to an authorized HYUNDAI dealer ized HYUNDAI dealer as soon as possi- when the road surface is slippery. and have the system checked. ble.
  • Page 265 Driving your vehicle E070504ABH-EU E070600BFD ESC OFF usage WARNING Good braking practices When driving Never press the ESC OFF button while ESC is operating. • ESC should be turned on for daily driv- WARNING ing whenever possible. If the ESC is turned off while ESC is •...
  • Page 266 To avoid creeping for- parking brake may freeze, apply it only an authorized HYUNDAI dealer for ward, keep your foot firmly on the temporarily while you put the gear assistance.

  • Page 267: Cruise Control System

    Driving your vehicle CRUISE CONTROL SYSTEM ✽ ✽ NOTICE WARNING During normal cruise control operation, • If the cruise control is left on, when the SET switch is activated or (CRUISE indicator light in the reactivated after applying the brakes, instrument cluster illuminated) the cruise control will energize after the cruise control can be activat-...
  • Page 268 Driving your vehicle OBH058020 OBH058021 OBH058022 E090100ABH-EU 3. Push the SET- switch, and release it at E090200ABH-EU To set cruise control speed: To increase cruise control set the desired speed. The SET indicator light in the instrument cluster will illumi- speed: 1.
  • Page 269 Driving your vehicle E090400ABH To temporarily accelerate with the cruise control on: If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with cruise control operation or change the set speed. To return to the set speed, take your foot off the accelerator.
  • Page 270 Driving your vehicle • Press the parking brake pedal or pull the EPB switch (if equipped). Do not operate the parking brake while driving except in an emergency situation. Each of these actions will cancel cruise control operation (the SET indicator light in the instrument cluster will go off), but it will not turn the system off.
  • Page 271 Driving your vehicle SMART CRUISE CONTROL SYSTEM (IF EQUIPPED) E150000ABH Type I (Continued) The smart cruise control system allows • Do not use the smart cruise con- you to program the vehicle to maintain a trol when it may not be safe to constant speed and distance detecting keep the car at a constant speed, the vehicle ahead without depressing the...
  • Page 272 Driving your vehicle OBH058020 OBH058021 OBH058022 E150100ABH 3. Push the SET- switch, and release it at E150200ABH To set cruise control speed: To increase cruise control set the desired speed. The SET indicator light, set speed and vehicle to vehicle speed: 1.
  • Page 273 Driving your vehicle E150400ABH To temporarily accelerate with the cruise control on: If you want to speed up temporarily when the cruise control is on, depress the accelerator pedal. Increased speed will not interfere with cruise control operation or change the set speed. To return to the set speed, take your foot off the accelerator.
  • Page 274 Driving your vehicle ✽ ✽ NOTICE • Decreasing the vehicle speed to less than approximately 6 mph (10 km/h) as Always check the road conditions when the vehicle in front of you. pressing the RES+ switch to resume the • Accelerating the vehicle speed to more speed.
  • Page 275 Driving your vehicle The vehicle to vehicle distance will auto- matically activate when the smart cruise control system is on. Select the appropriate distance accord- ing to road conditions and vehicle speed. Each time the button is pressed, the vehi- cle to vehicle distance changes as fol- lows;...
  • Page 276 Driving your vehicle Type I Type I Type I Distance 3 Distance 2 Distance 1 Distance 3 Distance 2 Distance 1 OBH059025N OBH059026N OBH059052N Type II Type II Type II Distance 3 Distance 2 Distance 1 Distance 3 Distance 2 Distance 1 OBH051025N OBH051026N...
  • Page 277 Driving your vehicle • If the system is deactivated, you must Type I actively adjust the vehicle speed, as well as the distance to the vehicle ahead by depressing the accelerator or brake pedal. • Always check the road conditions. Do not rely on the warning chime.
  • Page 278 If this occurs, have your vehicle have limits to its ability to detect distance checked authorized to the vehicle ahead due to road and traf- HYUNDAI dealer as soon as pos- fic conditions. sible. • Use only a genuine HYUNDAI On curves sensor cover for your vehicle.
  • Page 279 Driving your vehicle OBH058030 OBH058053 OBH058045 • Your vehicle speed can be reduced E150902ABH E150903ABH On inclines Lane changing due to a vehicle in the adjacent lane. Apply the accelerator pedal and select • During uphill or downhill driving, the •...
  • Page 280 Driving your vehicle A vehicle ahead cannot be recognized WARNING correctly by the sensor if any of following occurs: • The vehicle cannot be stopped by - When the vehicle is pointing upwards using the smart cruise control due to overloading in the trunk system.
  • Page 281 Driving your vehicle (Continued) CAUTION • The smart cruise control system The smart cruise control system is not a substitute for safe driving may not operate temporarily due to practices but a convenience electrical interference. function only. It is the responsi- bility of the driver to always check the speed and the distance to the vehicle ahead.
  • Page 282 Driving your vehicle LANE DEPARTURE WARNING SYSTEM (LDWS) (IF EQUIPPED) WARNING • The LDWS does not make the vehicle change lanes. It is the dri- ver's responsibility to always check the road conditions. • Do not turn the steering wheel suddenly, when the LDWS warns you that your vehicle is leaving the lane.
  • Page 283 LCD display blinks yellow with an comes on, the LDWS is not working 0.8 second interval. properly. Take your vehicle to an author- ized HYUNDAI dealer and have the sys- tem checked. 2. Auditory warning If you leave the lane, the warning sound operates with an 0.8 second interval.
  • Page 284 Driving your vehicle The LDWS does not operate The LDWS may not warn you even • The distance from vehicle ahead is very short or the vehicle ahead drives when: if the vehicle leaves the lane, or hiding the lane line. may warn you even if the vehicle •...

  • Page 285: Economical Operation

    Driving your vehicle ECONOMICAL OPERATION E100000AEN • Don't "ride" the brake pedal. This can • Keep your car in good condition. For Your vehicle's fuel economy depends increase fuel consumption and also better fuel economy and reduced mainly on your style of driving, where you increase wear on these components.
  • Page 286 Therefore, have an authorized speeds. loss of vehicle steering which HYUNDAI dealer perform scheduled could cause serious injury or inspections and maintenance. death.

  • Page 287: Special Driving Conditions

    Driving your vehicle SPECIAL DRIVING CONDITIONS E110200ABH-EU WARNING - Rocking the vehicle Do not pump the brake pedal on a If it is necessary to rock the vehicle to free vehicle equipped with ABS. it from snow, sand, or mud, first turn the steering wheel right and left to clear the area around your front wheels.

  • Page 288: Smooth Cornering

    Driving your vehicle WARNING - Spinning tires Do not spin the wheels, especially at speeds more than 35 mph (56 km/h). Spinning the wheels at high speeds when the vehicle is station- ary could cause a tire to overheat which could result in tire damage that may injure bystanders.

  • Page 289: Driving In Flooded Areas

    Driving your vehicle • Adjust your mirrors to reduce the glare • If your tires are not in good condition, from other driver's headlights. making a quick stop on wet pavement can cause a skid and possibly lead to • Keep your headlights clean and prop- an accident.

  • Page 290: Highway Driving

    Driving your vehicle Fuel, engine coolant and engine oil WARNING High speed travel consumes more fuel than urban motoring. Do not forget to • Underinflated overinflated check both engine coolant and engine tires can cause poor handling, oil. loss of vehicle control, and sud- den tire failure leading to acci- dents, injuries, and even death.

  • Page 291: Winter Driving

    Driving your vehicle WINTER DRIVING E120100AUN E120101AUN Snow tires Snowy or icy conditions If you mount snow tires on your vehicle, To drive your vehicle in deep snow, it may make sure they are radial tires of the be necessary to use snow tires or to same size and load range as the original install tire chains on your tires.
  • Page 292 Driving your vehicle Chain installation CAUTION When installing chains, follow the manu- • Make sure the snow chains are facturer's instructions and mount them as the correct size and type for your tightly as you can. Drive slowly with tires. Incorrect snow chains can chains installed.
  • Page 293 • Stop driving and retighten the 7. The level of charge in your battery can chains any time you hear them be checked by an authorized HYUNDAI hitting the vehicle. dealer or a service station. 5 61...
  • Page 294 Window washer anti-freeze is Under some conditions, snow and ice available from an authorized HYUNDAI can build up under the fenders and inter- dealer and most auto parts outlets. Do fere with the steering. When driving in...

  • Page 295: Vehicle Load Limit

    Driving your vehicle VEHICLE LOAD LIMIT E150100AUN E150102ABH Seating capacity: Tire and loading information label Total : 5 persons The label located on the driver's door (Front seat : 2 persons, sill gives the original tire size, cold Rear seat : 3 persons) tire pressures recommended for your vehicle, the number of people that Seating capacity is the maximum...
  • Page 296 Driving your vehicle Towing capacity: R1-090003 5. Determine the combined weight of Steps For Determining Correct Load luggage and cargo being loaded We do not recommend using this Limit - on the vehicle. That weight may vehicle for trailer towing. 1.
  • Page 297 Driving your vehicle Example 1 Example 2 Example 3 C190F01JM C190F02JM C190F03JM Item Description Total Item Description Total Item Description Total Vehicle Capacity 1400 lbs Vehicle Capacity 1400 lbs Vehicle Capacity 1400 lbs Weight (635 kg) Weight (635 kg) Weight (635 kg) Subtract Occupant Subtract Occupant...
  • Page 298 Driving your vehicle To find out the actual loads on your (Continued) front and rear axles, you need to go • Do not load your vehicle any to a weigh station and weigh your heavier than the GVWR, either vehicle.Your dealer can help you with the maximum front or rear this.
  • Page 299 Driving your vehicle CAUTION WARNING WARNING - Loose cargo • Overloading your vehicle may • Overloading your vehicle can Items you carry inside your cause damage. Repairs would cause heat buildup in your vehicle can strike and injure not be covered by your warran- vehicle's tires and possible occupants in a sudden stop or ty.

  • Page 300: Vehicle Weight

    Driving your vehicle VEHICLE WEIGHT E160000ABH E160300AUN E160700AUN-EU Cargo weight GVWR (Gross vehicle weight rating) This section will guide you in the proper This figure includes all weight added to This is the maximum allowable weight of loading of your vehicle, to keep your the Base Curb Weight, including cargo the fully loaded vehicle (including all loaded vehicle weight within its design...
  • Page 301 Driving your vehicle TRAILER TOWING E140000ABH We do not recommend using this vehicle for trailer towing. 5 69...

  • Page 302: What To Do In An Emergency

    Road warning / 6-2 In case of an emergency while driving / 6-2 If the engine will not start / 6-3 Emergency starting / 6-4 If the engine overheats / 6-6 Tire pressure monitoring system (TPMS) / 6-7 If you have a flat tire / 6-12 Towing / 6-20 What to do in an emergency...

  • Page 303: Road Warning

    What to do in an emergency ROAD WARNING IN CASE OF AN EMERGENCY WHILE DRIVING It should be used whenever emergency repairs are being made or when the vehi- If the engine stalls at a crossroad cle is stopped near the edge of a road- or crossing way.
  • Page 304 3. If the engine still does not start, call an starter, the battery is discharged. authorized HYUNDAI dealer or seek F020300AEN other qualified assistance. 4. Check the starter connections to be If engine stalls while driving sure they are securely tightened.

  • Page 305: Emergency Starting

    What to do in an emergency EMERGENCY STARTING F040100AEN Jumper Cables WARNING Jump starting - Battery • Keep all flames or sparks away Jump starting can be dangerous if done from the battery. The battery pro- incorrectly. Therefore, to avoid harm to duces hydrogen gas which may yourself or damage to your vehicle or explode if exposed to flame or...
  • Page 306 If the cause of your battery discharging is of the jumper terminal (4). Do not con- not apparent, you should have your vehi- nect it to or near any part that moves cle checked by an authorized HYUNDAI when the engine is cranked. dealer.

  • Page 307: If The Engine Overheats

    If over- heating happens again, call an author- 2. Place the shift lever in P and set the ized HYUNDAI dealer for assistance. parking brake. If the air conditioning is WARNING on, turn it off.

  • Page 308: Tire Pressure Monitoring System (Tpms)

    What to do in an emergency TIRE PRESSURE MONITORING SYSTEM (TPMS) F060000ABH Conventional Type Supervision Type II Each tire, including the spare (if pro- vided), should be checked monthly when cold and inflated to the inflation pressure recommended by the vehi- cle manufacturer on the vehicle plac- ard or tire inflation pressure label.
  • Page 309 3 seconds, take your car to your When the tire pressure monitoring nearest authorized HYUNDAI deal- system warning indicators are illumi- er and have the system checked. Your vehicle has also been equipped...
  • Page 310 Have the system checked by an When you drive your vehicle authorized HYUNDAI dealer as soon from a warm area to a cold area as possible to determine the cause or from a cold area to a warm of the problem.
  • Page 311 HYUNDAI dealer as soon as possi- with TPMS too. In rare cases, police stations, government ble. this may temporarily delay the...
  • Page 312 • If you feel any vehicle instabil- • In order to correctly monitor after a few minutes, please visit an ity, immediately take your foot tire inflation, the 4 tire pres- authorized HYUNDAI dealer. off the accelerator, apply the sure monitoring sensors...
  • Page 313 What to do in an emergency IF YOU HAVE A FLAT TIRE This device complies with Part 15 F070101AUN Jacking instructions of the FCC rules. The jack is provided for emergency Operation is subject to the following tire changing only. two conditions: To prevent the jack from “rattling”...
  • Page 314 What to do in an emergency (Continued) CAUTION • Be sure to use the correct When you remove or store the front and rear jacking posi- spare tire, don't contact or tions on the vehicle; never bump the battery with the spare use the bumpers or any other tire.
  • Page 315 What to do in an emergency OBH068002L OBH068009 OBH068024L F070300ABH 4. Remove the wheel lug nut wrench, 6. Insert the screwdriver into the Changing tires jack, jack handle, and spare tire groove of the wheel cap and pry from the vehicle. gently to remove the wheel cap (If 1.
  • Page 316 What to do in an emergency OBH068010 OBH068011 OBH068012 7. Loosen the wheel lug nuts coun- 8. Place the jack at the front or rear 9. Insert the jack handle into the jack terclockwise one turn each, but do jacking position closest to the tire and turn it clockwise, raising the not remove any nut until the tire you are changing.
  • Page 317 What to do in an emergency 10. Loosen the wheel nuts and 11. To reinstall the wheel, hold it on WARNING remove them with your fingers. the studs, put the wheel nuts on Slide the wheel off the studs and the studs and tighten them finger Wheels may have sharp edges.
  • Page 318 If in doubt, consult an author- tightness. After changing wheels, ized HYUNDAI dealer. have an authorized HYUNDAI dealer tighten the wheel nuts to their proper torque as soon as possible. Wheel nut tightening torque: Steel wheel & aluminum alloy wheel: 65~79 lb·ft (9~11 kg·m)
  • Page 319 What to do in an emergency F070301BBH WARNING Important - use of compact spare tire WARNING - Wheel studs Your vehicle is equipped with a com- If the studs are damaged, they The compact spare tire is for pact spare tire. This compact spare may lose their ability to retain emergency use only.
  • Page 320 What to do in an emergency When using a compact spare tire, • Do not take this vehicle through an • The compact spare tire should not observe the following precautions: automatic car wash while the com- be used on any other wheels, nor pact spare tire is installed.
  • Page 321 Do not overly tighten the tie downs or recommend having it done by an author- the vehicle may be damaged. ized HYUNDAI dealer or a commercial tow-truck service. Proper lifting and tow- ing procedures are necessary to prevent damage to the vehicle. The use of wheel...
  • Page 322 What to do in an emergency When towing your vehicle in an emer- Front gency without wheel dollies : 1. Set the ignition switch in the ACC posi- tion. 2. Place the shift lever in N (Neutral). 3. Release the parking brake. CAUTION Failure to place the transmission OBH068016...
  • Page 323 • The drivers of both vehicles should communicate with each other frequent- OBH068020 F080300AFD Emergency towing If towing is necessary, we recommend you to have it done by an authorized HYUNDAI dealer or a commercial tow truck service.
  • Page 324 Attach a white or red cloth • Before emergency towing, check that (about 12 inches (30 cm) wide) in the HYUNDAI dealer or a commercial the hook is not broken or damaged. middle of the strap for easy visibility.
  • Page 325 What to do in an emergency F080301ABH CAUTION - Automatic Emergency towing precautions transmission • Place the ignition switch in ACC so the steering wheel isn’t locked. • If the car is being towed with all four wheels on the ground, it can •...

  • Page 326: Maintenance

    Engine compartment / 7-2 Maintenance services / 7-4 Owner maintenance / 7-5 Scheduled maintenance service / 7-7 Explanation of scheduled maintenance items / 7-12 Engine oil / 7-15 Engine coolant / 7-16 Brake fluid / 7-19 Power steering fluid / 7-20 Washer fluid / 7-21 Automatic transmission fluid / 7-21 Parking brake / 7-22...
  • Page 327 Maintenance ENGINE COMPARTMENT ■ ■ Gasoline Engine (3.8L) 1. Engine coolant reservoir 2. Radiator cap 3. Brake fluid reservoir 4. Air cleaner 5. Engine oil dipstick 6. Engine oil filler cap 7. Windshield washer fluid reservoir 8. Fuse box 9. Power steering fluid reservoir (with EHPS) 10.
  • Page 328 Maintenance ■ ■ Gasoline Engine (4.6L) 1. Engine coolant reservoir 2. Radiator cap 3. Brake fluid reservoir 4. Air cleaner 5. Engine oil dipstick 6. Engine oil filler cap 7. Windshield washer fluid reservoir 8. Fuse box 9. Power steering fluid reservoir (with EHPS) 10.

  • Page 329: Maintenance Services

    An authorized HYUNDAI dealer has fac- ✽ ✽ NOTICE shown on the following pages. You need tory-trained technicians and genuine this information to establish your compli-...

  • Page 330: Owner Maintenance

    G030101AUN inspections that should be performed by work When you stop for fuel: the owner or an authorized HYUNDAI • Performing maintenance work on • Check the engine oil level. dealer at the frequencies indicated to a vehicle can be dangerous. You •...
  • Page 331 Maintenance G030102ABH G030103AUN G030105AUN-EU While operating your vehicle: At least monthly: At least once a year: • Note any changes in the sound of the • Check coolant level in the engine • Clean body and door drain holes. exhaust or any smell of exhaust fumes coolant reservoir.

  • Page 332: Scheduled Maintenance Service

    Maintenance SCHEDULED MAINTENANCE SERVICE G040000AUN-EU If your vehicle is operated under the above conditions, you should inspect, Follow Normal Maintenance Schedule if replace or refill more frequently than the the vehicle is usually operated where following Normal Maintenance Schedule. none of the following conditions apply. If any of the following conditions apply, fol- After 120 months or 150,000 miles low Maintenance Under Severe Usage...

  • Page 333: Normal Maintenance Schedule

    Maintenance G040100ABH-EU NORMAL MAINTENANCE SCHEDULE The following maintenance services must be performed to ensure good emission control and performance. Keep receipts for all vehicle emission services to protect your warranty. Where both mileage and time are shown, the frequency of service is deter- mined by whichever occurs first.
  • Page 334 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) R : Replace I : Inspect and, after Inspection, clean, adjust, repair or replace if necessary. MILES X 1000 22.5 37.5 52.5 67.5 82.5 97.5 105 112.5 120 127.5 135 142.5 150 DESCRIPTION KILOMETERS X 1000 108 120 132 144 156 168 180 192 204 216 228 240 102 108...
  • Page 335 Maintenance NORMAL MAINTENANCE SCHEDULE (CONT.) R : Replace I : Inspect and, after Inspection, clean, adjust, repair or replace if necessary. 22.5 37.5 52.5 67.5 82.5 97.5 105 112.5 120 127.5 135 142.5 150 MILES X 1000 DESCRIPTION KILOMETERS X 1000 108 120 132 144 156 168 180 192 204 216 228 240 MONTHS...

  • Page 336: Maintenance Under Severe Usage Conditions

    Maintenance G040200ABH-EU MAINTENANCE UNDER SEVERE USAGE CONDITIONS The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. R : Replace I : Inspect and, after inspection, clean, adjust, repair or replace if necessary MAINTENANCE MAINTENANCE DRIVING...

  • Page 337: Explanation Of Scheduled Maintenance Items

    Have driven in severe conditions, more fre- issues such as hard starting. If an exces- an authorized HYUNDAI dealer replace quent oil and filter changes are required. sive amount of foreign matter accumu- any damaged or leaking parts immedi- lates in the fuel tank, the filter may ately.
  • Page 338 G050800AEN G051200AUN Vacuum hose Air cleaner filter Coolant Inspect the surface of hoses for evidence A Genuine HYUNDAI air cleaner filter is The coolant should be changed at the of heat and/or mechanical damage. Hard recommended when filter intervals specified in the maintenance and brittle rubber, cracking, tears, cuts, replaced.

  • Page 339: Parking Brake

    Maintenance G051700AUN G052200AUN G052400AUN Parking brake Steering gear box, linkage & Drive shafts and boots boots/lower arm ball joint Inspect the parking brake system includ- Check the drive shafts, boots and clamps ing the parking brake pedal and cables. for cracks, deterioration, or damage. With the vehicle stopped and engine off, Replace any damaged parts and, if nec- check for excessive free-play in the...

  • Page 340: Engine Oil

    Maintenance ENGINE OIL 3. Turn the engine off and wait for a few 3.8L 3.8L minutes (about 5 minutes) for the oil to return to the oil pan. 4. Pull the dipstick out, wipe it clean, and re-insert it fully. WARNING - Radiator hose Be very careful not to touch the...

  • Page 341: Engine Coolant

    The high-pressure cooling system has a reservoir filled with year-round antifreeze Have engine oil and filter changed by an coolant. The reservoir is filled at the fac- authorized HYUNDAI dealer according to tory. the Maintenance Schedule at the begin- Check the antifreeze protection and ning of this section.
  • Page 342 F, but do not overfill. If frequent when removing the radiator cap. additions are required, see an authorized Wrap a thick towel around it, and HYUNDAI dealer for a cooling system turn it counterclockwise slowly to inspection. the first stop. Step back while the pressure is released from the cooling system.
  • Page 343 Maintenance For mixture percentage, refer to the fol- G070200AEN 3.8L Changing the coolant lowing table. Have coolant changed by an authorized HYUNDAI dealer according to the Mixture Percentage (volume) Maintenance Schedule at the beginning Ambient of this section. Temperature Water...
  • Page 344 HYUNDAI dealer. guaranteed. It should be disposed of properly. Don't put in the wrong kind of fluid. A few drops of miner-...

  • Page 345: Power Steering Fluid

    • The use of the non-specified fluid vehicle should be inspected by an could reduce the effectiveness of authorized HYUNDAI dealer. the power steering system and cause damage to it. Use only the specified power steering fluid.

  • Page 346: Washer Fluid

    HYUNDAI dealer. reservoir. In severe conditions, the fluid should be • Radiator coolant can severely changed at an authorized HYUNDAI obscure visibility when sprayed dealer in accordance to the scheduled on the windshield and may cause maintenance at the beginning of this loss of vehicle control or damage chapter.

  • Page 347: Foot Parking Brake

    G160100ABH-EU 1. Loosen the air cleaner cover attaching HYUNDAI dealer. Filter replacement clips and open the cover. It must be replaced when necessary, and Stroke : 3 notches (or 3 clicks) should not be cleaned and reused.
  • Page 348 3. Lock the cover with the cover attaching ter, be careful that dust or dirt clips. does not enter the air intake, or damage may result. • Use a HYUNDAI genuine part. Use of non-genuine parts could dam- age the air flow sensor. 7 23...
  • Page 349 Maintenance OBH078015 OBH078016 OBH078017 G170200ABH 2. Remove the climate control air filter 3. Replace the climate control air filter. Filter replacement case pulling out both sides of the 4. Reassemble in the reverse order of cover. disassembly. 1. With the glove box open, remove the stoppers on both sides to allow the ✽...

  • Page 350: Wiper Blades

    Maintenance WIPER BLADES Contamination of either the windshield or G180200AUN the wiper blades with foreign matter can Blade replacement reduce the effectiveness of the wind- When the wipers no longer clean ade- shield wipers. Common sources of con- quately, the blades may be worn or tamination are insects, tree sap, and hot cracked, and require replacement.
  • Page 351 Maintenance OBH079041 OBH078042 OBH078043 G180201ABH-EU 3. Raise the wiper arm. 4. Press the button and pull the blade Front windshield wiper blade assembly upward. For your convenience, move the wind- CAUTION shield wiper blades to the service posi- Do not allow the wiper arm to fall tion as follows;...
  • Page 352 Maintenance OBH078044 5. Install the blade assembly in the reverse order of removal. 6. Return the wiper arm on the wind- shield. 7. Turn the ignition switch to the ON posi- tion. 8. Move the wiper switch to any position and then to the OFF position.
  • Page 353 Maintenance BATTERY (Continued) WARNING - Battery dangers If electrolyte gets on your skin, thoroughly wash the Always read the following contacted area. If you feel a instructions carefully when pain or a burning sensa- handling a battery. tion, get medical attention Keep lighted cigarettes and immediately.
  • Page 354 Maintenance (Continued) CAUTION WARNING - Recharging • When you don’t use the vehicle battery • The electrical ignition system for a long time in the low temper- works with high voltage. Never When recharging battery, ature area, separate the battery touch these components with the observe the following precautions: and keep it indoors.
  • Page 355 • The battery is in the trunk, so you should be careful when you load a container filled with liquid into the trunk. • For your safety, use a genuine HYUNDAI approved battery when you replace the battery.
  • Page 356 If a recommended for your vehicle. tire frequently needs refilling, have it checked by an author- G200200AEN-EU ized HYUNDAI dealer. Recommended cold tire inflation • Overinflation produces OBH088004N pressures...
  • Page 357 Maintenance G200300AUN CAUTION CAUTION - Tire pressure Checking tire inflation pressure • Warm tires normally exceed Always observe the following: Check your tires once a month or recommended cold tire pres- • Check tire pressure when the more. sures by 4 to 6 psi (28 to 41 tires are cold.
  • Page 358 • Remember to check the pres- sure your spare tire. HYUNDAI recommends that you check the spare every time you check the pressure of the other tires on your vehi- cle. 7 33...
  • Page 359 Maintenance G200500AUN Without a spare tire WARNING Wheel alignment and tire balance • Do not use the compact spare The wheels on your vehicle were tire for tire rotation. aligned and balanced carefully at the factory to give you the longest tire life •...
  • Page 360 • Replace tires that are worn, • Wheels that do not meet show uneven wear, or are HYUNDAI’s specifications damaged. Worn tires can may fit poorly and result in cause loss of braking effec-...
  • Page 361 Maintenance G200601AUN G200700ABH G200800AUN Compact spare tire replacement Wheel replacement Tire traction A compact spare tire has a shorter When replacing the metal wheels for Tire traction can be reduced if you tread life than a regular size tire. any reason, make sure the new drive on worn tires, tires that are Replace it when you can see the wheels are equivalent to the original...
  • Page 362 Maintenance G201002AEN 95 - Load Index, a numerical code 2. Tire size designation associated with the maximum A tire’s sidewall is marked with a tire load the tire can carry. size designation. You will need this H - Speed Rating Symbol. See the information when selecting replace- speed rating chart in this section ment tires for your car.
  • Page 363 Maintenance Tire speed ratings G201003AEN 3. Checking tire life (TIN : Tire WARNING - Tire age The chart below lists many of the dif- Identification Number) ferent speed ratings currently being Tires degrade over time, even Any tires that are over 6 years old, used for passenger car tires.
  • Page 364 Maintenance G201005AUN G2010007AEN-EU Traction - AA, A, B & C 5. Maximum permissible inflation 7. Uniform tire quality grading The traction grades, from highest to pressure Quality grades can be found where lowest, are AA, A, B and C. Those applicable on the tire sidewall This number is the greatest amount grades represent the tire’s ability to...
  • Page 365 Maintenance Temperature -A, B & C G201100ABH WARNING - Tire Tire terminology and definitions The temperature grades are A (the temperature highest), B and C representing the Air Pressure: The amount of air tire’s resistance to the generation of inside the tire pressing outward on The temperature grade for this heat and its ability to dissipate heat the tire.
  • Page 366 Maintenance Cold Tire Pressure: The amount of Intended Outboard Sidewall: The Occupant Distribution: Designated air pressure in a tire, measured in side of an asymmetrical tire, that seating positions. pounds per square inch (psi) or kilo- must always face outward when Outward Facing Sidewall: The side pascals (kPa) before a tire has built mounted on a vehicle.
  • Page 367 Vehicle Maximum Load on the Summer tires code assigned to a tire indicating the Tire: Load on an individual tire due to HYUNDAI specifies summer tires on maximum speed at which a tire can curb and accessory weight plus some models to provide superior operate.
  • Page 368 Maintenance Do not drive faster than 75 mph (120 Radial-ply tires WARNING - Snow or ice km/h) when your car is equipped with Radial-ply tires provide improved snow tires. • When driving on roads cov- tread life, road hazard resistance and ered with snow or ice, drive at smoother high speed ride.
  • Page 369 Avoid using Normal Blown the system involved and immediately CAUTION consult an authorized HYUNDAI dealer. Fusible link Three kinds of fuses are used: blade type Do not use a screwdriver or any for lower amperage rating, cartridge type,...
  • Page 370 Inner panel fuse replacement If it fits loosely, consult an authorized 1. Turn the ignition switch and all other HYUNDAI dealer. switches off. If you do not have a spare, use a fuse of 2. Open the fuse panel cover.
  • Page 371 Maintenance ✽ ✽ NOTICE 3.8L • If the memory fuse is pulled up from the fuse panel, the warning chime, audio, clock and interior lamps, etc., will not operate. Some items must be reset after replacement. Refer to “Battery” in this section. •...
  • Page 372 4. Push in a new fuse of the same rating, and make sure it fits tightly in the clips. If the main fuse is blown, consult an If it fits loosely, consult an authorized authorized HYUNDAI dealer. HYUNDAI dealer. 7 47...

  • Page 373: Fuse/Relay Panel Description

    Maintenance G210300ABH-EU Fuse/relay panel description Inside the fuse/relay panel covers, you can find the fuse/relay label describing fuse/relay name and capacity. Inner panel fuse panel Engine compartment fuse panel ✽ ✽ NOTICE Driver’s side 3.8L Not all fuse panel descriptions in this manual may be applicable to your vehi- cle.
  • Page 374 Maintenance Instrument panel (Driver’s side fuse panel) Description Fuse rating Protected component P/WDW (LH) Driver Power Window Module, Rear Door Module LH P/WDW (RH) Passenger Power Window Module, Rear Door Module RH CHASSIS UNIT Steering Angle Sensor, Key Lock Module, Tire Pressure Monitoring Module CRUISE SWITCH Multifunction Switch, Crash Pad Switch, A/C Control Module START...
  • Page 375 Maintenance Description Fuse rating Protected component F/LID OPEN Fuel Filler Door Switch AUDIO 3 AV Head Module, Audio, Active Headrest Sensor Module, Passenger Air Bag Indicator A/CON 3 RF Receiver, A/C Control Module P/CONN I/P Junction Box Fuse LH (BODY UNIT 2 10, A/CON 3 10A, AUDIO 2 15A) Instrument panel (Passenger’s side fuse panel) Description Fuse rating...
  • Page 376 Maintenance Engine compartment main fuse panel Description Fuse rating Protected component WIPER Electronic Control Wiper Module FAM POWER-1 FAM POWER-2 START Start Relay Engine Control Relay BLOWER MOTOR Blower Relay IGN SW-1 Ignition Switch (IG1, ACC) HTD GLASS (RR) Heated Glass (RR) Relay IGN SW-2 Ignition Switch (IG2, START) A/CON...
  • Page 377 Maintenance Description Fuse rating Protected component ENG SNSR-2 Canister Purge Control Solenoid Valve, Variable Intake Manifold Valve, Oil Control Valve, ECM, Cooling Fan Relay, Immobilizer Module, Canister Close Valve ENG SNSR-3 ECM (GSL 3.8L), Injector, Fuel Pump Relay H/LP (LO-RH) Head Lamp RH H/LP (LO-LH) Head Lamp LH, ECM...
  • Page 378 Maintenance Engine compartment sub fuse panel Description Fuse rating Protected component 200A Generator I/P LH PWR I/P Junction Box LH I/P RH PWR I/P Junction Box RH COOLING Cooling Fan Relay EHPS EHPS Module AMP-1 AV JBL Amp AMP-2 ESCL (ACC) ESCL (ACC) Relay ABS-1 ESC Control Module, Multipurpose Check Connector...

  • Page 379: Light Bulbs

    (6) Tail light to the condensation on your windows inside your vehicle during the rain and doesn’t indicate a problem with your vehicle. If the water leaks into the lamp bulb circuitry, have the vehicle checked by an authorized HYUNDAI dealer.
  • Page 380 (if equipped) sions. If the bulbs are lit, avoid by an authorized HYUNDAI Dealer. contact with liquids. If the light bulb is not operating, have the vehicle checked by an authorized •...
  • Page 381 If the light bulb is not operating, have the (1) Back-up light vehicle checked by an authorized (2) Rear turn signal light HYUNDAI dealer. (3) Stop and tail light (4) Rear side marker light OBH078034 Rear turn signal light 1.

  • Page 382: High Mounted Stop Light Replacement

    If the light is not operating, have the vehi- 1. Loosen the lens retaining screws with 7. Install the service cover by putting it cle checked by an authorized HYUNDAI a philips head screwdriver. into the service hole. dealer.
  • Page 383 3. Install a new bulb in the socket. If the light is not operating, have the vehi- 4. Align the lens tabs with the interior cle checked by an authorized HYUNDAI light housing notches and snap the dealer. lens into place.

  • Page 384: Appearance Care

    Maintenance APPEARANCE CARE Exterior care After washing, rinse the vehicle thor- oughly with lukewarm or cold water. Do G230101AUN not allow soap to dry on the finish. Exterior general caution It is very important to follow the label CAUTION directions when using any chemical cleaner or polish.
  • Page 385 Maintenance Waxing G230103AUN G230105AUN Finish damage repair Underbody maintenance A good coat of wax is a barrier between your paint and contaminate. Keeping a Deep scratches or stone chips in the Corrosive materials used for ice and good coat of wax on your vehicle will help painted surface must be repaired snow removal and dust control may col- protect it.
  • Page 386 Maintenance G230106AUN G230107AUN WARNING Aluminum wheel maintenance Corrosion protection The aluminum wheels are coated with a After washing the vehicle, test the Protecting your vehicle from corrosion clear protective finish. brakes while driving slowly to see if By using the most advanced design and they have been affected by water.
  • Page 387 Maintenance High-corrosion areas Moisture breeds corrosion To help prevent corrosion If you live in an area where your car is Moisture creates the conditions in which You can help prevent corrosion from get- regularly exposed to corrosive materials, corrosion is most likely to occur. For ting started by observing the following: corrosion protection is particularly impor- example, corrosion is accelerated by...
  • Page 388 Maintenance • When cleaning underneath the car, Keep paint and trim in good condition Interior care give particular attention to the compo- Scratches or chips in the finish should be G230201AUN nents under the fenders and other covered with "touch-up" paint as soon as Interior general precautions areas that are hidden from view.
  • Page 389 Maintenance G230202AUN G230203AUN Cleaning the upholstery and interior Cleaning the lap/shoulder belt web- trim bing Vinyl Clean the belt webbing with any mild soap solution recommended for cleaning Remove dust and loose dirt from vinyl upholstery or carpet. Follow the instruc- with a whisk broom or vacuum cleaner.

  • Page 390: Emission Control System

    System is designed to prevent fuel inspected and maintained by an author- vapors from escaping into the atmos- ized HYUNDAI dealer in accordance with phere. the maintenance schedule in this manu- (The ORVR system is designed to allow...
  • Page 391 Maintenance G270201AUN G270300AUN Canister WARNING 3. Exhaust emission control Exhaust Fuel vapors generated inside the fuel system Engine exhaust gases contain car- tank are absorbed and stored in the bon monoxide (CO). Though color- The Exhaust Emission Control System is onboard canister.
  • Page 392 HYUNDAI dealer. • When the engine stalls or fails to start, • Avoid driving with a very low fuel level. Your vehicle is equipped with a catalytic...

  • Page 393: California Perchlorate Notice

    Maintenance CALIFORNIA PERCHLORATE NOTICE G280000AEN Perchlorate Material-special handling may apply, See www.dtsc.ca.gov/haz- ardouswaste/perchlorate. Notice to California Vehicle Dismantlers: Perchlorate containing materials, such as air bag inflators, seatbelt pretensioners and keyless remote entry batteries, must be disposed of according to Title 22 California Code of Regulations Section 67384.10 (a).

  • Page 394: Specifications, Consumer Information, Reporting Safety Defects

    Dimensions / 8-2 Bulb wattage / 8-2 Tires and wheels / 8-3 Recommended lubricants and capacities / 8-4 Vehicle identification number (VIN) / 8-6 Vehicle certification label / 8-6 Tire specification and pressure label / 8-7 Engine number / 8-7 Consumer information / 8-8 Reporting safety defects / 8-9 Binding arbitration / 8-9...

  • Page 395: Bulb Wattage

    Specifications, Consumer information, Reporting safety defects DIMENSIONS BULB WATTAGE I010000ABH I030000ABH Item in (mm) Light Bulb Wattage Overall length 195.9 (4975) Headlights (Low) 55 or 35 (HID) Headlights (High) Overall width 74.4 (1890) Front turn signal lights Overall height 58.1 (1475) / 58.2 (1480)* Position lights Front tread 63.8 (1620) / 63.1 (1604)*...

  • Page 396: Tires And Wheels

    Specifications, Consumer information, Reporting safety defects TIRES AND WHEELS I020000AEN-EU Inflation pressure Tire Wheel lug nut torque kPa (psi) Wheel size Item size Maximum load lb•ft (kg•m, N•m) Normal load Front Rear Front Rear P215/60R17 6.5J×17 Full size tire P225/55R17 (33) (33) (33)

  • Page 397: Recommended Lubricants And Capacities

    6.87 US qt. (6.5 l) ATF 9638, NWS 9638 or other brands meeting the 8.66 US qt. (8.2 l) 3.8L above specification approved by Hyundai Motor Co., Automatic transmission fluid ATF M 1375.4 or other brands meeting the above 10.04 US qt. (9.5 l) 4.6L...
  • Page 398 Specifications, Consumer information, Reporting safety defects I040100ABH-EU Engine oil viscosity (thickness) has an When choosing an oil, consider the range Recommended SAE viscosity effect on fuel economy and cold weather of temperature your vehicle will be oper- operating (engine start and engine oil number ated in before the next oil change.

  • Page 399: Vehicle Identification Number (Vin)

    Specifications, Consumer information, Reporting safety defects VEHICLE IDENTIFICATION VEHICLE CERTIFICATION NUMBER (VIN) LABEL Frame number VIN label OBH088005N OBH088001 OBH089002 The VIN is also on a plate attached to the H010000ABH H020000ABH-EU top of the dashboard. The number on the The vehicle identification number (VIN) is The vehicle certification label attached plate can easily be seen through the...

  • Page 400: Tire Specification And Pressure Label

    Specifications, Consumer information, Reporting safety defects TIRE SPECIFICATION AND ENGINE NUMBER PRESSURE LABEL 3.8L OBH088003L 4.6L OBH088004N H030000AUN The tires supplied on your new vehicle are chosen to provide the best perform- ance for normal driving. The tire label located on the driver's side center pillar gives the tire pressures rec- ommended for your car.

  • Page 401: Consumer Information

    Safety Administration U.S. Department of Transportation. Your Eastern Region Central Region Hyundai dealer will help answer any 1100 Cranbury South River Road 1705 Sequoia Drive questions you may have as you read this Jamesburg, NJ 08831 Aurora, Illinois 60506 information.
  • Page 402 Written notice must be and if it finds that a safety defect exists in administered through delivered (via certified mail) to Hyundai a group of vehicles, it may order a recall American Arbitration Association (AAA). Motor America, Attn: Consumer Affairs, and remedy campaign.
  • Page 403 Index...
  • Page 404 Index Air bag - advanced supplemental restraint system ······ 3-33 Battery ········································································· 7-28 Air bag warning label ················································ 3-58 Before driving ································································ 5-3 Curtain air bag ··························································· 3-50 Binding arbitration ························································· 8-9 Driver's and passenger's front air bag ······················· 3-44 Brake fluid ···································································...
  • Page 405 Index Defroster ······································································ 4-86 Foot parking brake·························································7-22 Dimensions ···································································· 8-2 Fuel filler lid ································································ 4-28 Door locks ··································································· 4-16 Emergency fuel filer lid release ································ 4-30 Central door lock switch ··········································· 4-17 Fuel requirements ·························································· 1-3 Child-protector rear door lock ··································· 4-19 Fuses ············································································...
  • Page 406 Index Instrument cluster ························································ 4-47 Engine temperature gauge ········································· 4-51 Key ················································································· 5-4 Fuel gauge ································································· 4-52 Ignition switch position ··············································· 5-5 Instrument panel illumination ··································· 4-50 Starting the engine ······················································· 5-6 Speedometer ······························································ 4-50 Keys ··············································································· 4-3 Tachometer ································································ 4-50 Trip computer ····························································...
  • Page 407 Index Maintenance services ····················································· 7-4 Scheduled maintenance service ····································· 7-7 Mirrors ········································································· 4-39 Normal maintenance schedule ···································· 7-8 Electric chromic mirror (ECM) with compass and Maintenance under severe usage conditions ············· 7-12 HomeLink® system ················································ 4-39 Seat belts ······································································ 3-14 Inside rearview mirror ···············································...
  • Page 408 Index Storage compartments ··············································· 4-102 Tire sidewall labeling ················································ 7-37 Center console storage ············································ 4-102 Tire terminology and definitions ······························· 7-40 Glove box ································································ 4-102 Tire traction ······························································· 7-36 Sunglass holder ······················································· 4-103 Wheel alignment and tire balance ····························· 7-34 Sunroof ········································································...
  • Page 409 Index GAW (Gross axle weight) ········································· 5-68 GAWR (Gross axle weight rating) ···························· 5-68 GVW (Gross vehicle weight) ···································· 5-68 GVWR (Gross vehicle weight rating) ······················· 5-68 Washer fluid ································································· 7-21 Windows ······································································ 4-23 Auto up/down window ·············································· 4-24 Power window lock button ········································ 4-26 Windshield defrosting and defogging ·························...

Table of Contents

Save PDF
