Notebook Specification
This appendix provides the technical specification of the A985 notebook:
A.1 System Specification
FIC A985 Service Manual
PDF created with FinePrint pdfFactory trial version
CPU Type
Clock Speed
Internal L1 Cache
Internal L2 Cache
CPU Package
Chipset Type
Thermal controller
Package
Size
Mode
Frequency
Data Path
Refresh
Supply Voltage
Extension
Parity Support
MICRO PROCESSOR
Intel Pentium-4-M Northwood Processor
Pentium-4-M CPU at 1.6/1.7/1.8/2.0/2.1/2.2GHz
12KB code and 8KB data
512 KB
uFCPGA packaging
SYSTEM LOGIC CHIPSET
• SIS 650 - North Bridge
• SIS 961 - South Bridge
Integrated in South Bridge
MEMORY MODULE
200 Pins SO-DIMM (1.25")
128 / 256 / 512MB
DDR SDRAM
266 MHz (Northwood)
64 Bit
CBR Refresh
2.5V
Upgradable to max. 1024MB using 512 MB SODIMM x 2
No parity bit for all memory
http://www.fineprint.com
Appendix
A-1
