• MAX Associations Limit: It refers to the maximum
number of connections. It is used to set the maximum
number of concurrent WLAN users on the device.
• Mode: It refers to the WLAN accessing mode. The
device can work in two modes, as shown in the
following table. The default value is Access Point.
Mode Description
Wireless It is used to connect two or more access
Bridge points.
Access The access points meeting the IEEE
Point 802.11b/g standard or the wireless
terminals can connect the wireless
device.
• Bridge Restriction: It refers to the limitation to the peer
MAC addresses. When it is Disabled, the device can
access all the remote bridges; when it is Enabled, the
device can only access the remote bridges that the
addresses are in the address list.
• Bridges: It refers to the physical address of the remote
peer bridge. The device supports the point-to-multipoint
(PTM) bridge mode.
• Peer MAC Address: It refers to the physical address
list of the remote peer bridges.
• Link Status: Up shows the successful connection and
Down shows the failed connection.

Dynamic DNS Settings

Dynamic DNS Settings
The DDNS feature will update Internet IP which
bound with registered Domain name periodically.
1
Click to access the DDNS page.
2
Configure the parameters of DDNS.
• Provider: By default, the service provider is
dyndns.org.
• Host Name/Username/Password: Enter the
value for DDNS registration.
3
Click Ok.
• Validate: Click Apply to validate.
• Change: Click
• Delete: Click in the Modification column
in the Modification column.
.
