Ozito CDL-072 Instruction Manual

Ozito CDL-072 Instruction Manual

Lithium-ion cordless drill/driver 7.2v

Advertisement

Lithium-ion Cordless
Drill/Driver
7.2V
Instruction Manual
3 Year Replacement Warranty
CDL-072
WARNING! Read all safety warnings and all instructions. Failure to follow
the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
0512
www.ozito.com.au
To view the full range visit:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDL-072 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ozito CDL-072

  • Page 1 7.2V Instruction Manual 3 Year Replacement Warranty CDL-072 WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
  • Page 2: Specifications

    SpecificationS - model no. cdl-072 input power: 7.2V charge time: 3 - 5 hrs no load speed: 0-400/min chuck: 10mm Keyless max torque: torque Settings: 15 + 1 max drilling capacity: Wood : 8mm Metal : Not recommended max driving capacity:...
  • Page 3: Table Of Contents

    taBle of contentS SPECIFICATIONS ……………………………………….. Page 1 KNOW YOUR PRODUCT ………………………………。 Page 1 INTRODUCTION………………………………………… Page 3 ELECTRICAL SAFETY…………….……………………… Page 3 GENERAL POWER TOOL SAFETY WARNINGS……… Page 4 BATTERY & CHARGER SAFETY WARNING…………… Page 6 ADDITIONAL SAFETY WARNINGS FOR DRILLS…….. Page 7 LITHIUM ION BATTERY AND CHARGER SAFETY FEATURES………………………………………...
  • Page 4: Introduction

    We hope you will enjoy using this tool for many years. Your Cordless Drill CDL-072 has been designed for light duty drilling or screwdriving into wood and plastic around the home and is intended for DIY use only.
  • Page 5: General Power Tool Safety Warnings

    General poWer tool Safety WarninGS WarninG! read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term “power tool” in all of the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
  • Page 6 General poWer tool Safety WarninGS f) dress properly. do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. g) if devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
  • Page 7: Battery & Charger Safety Warning

    Battery and cHarGer Safety WarninGS THIS MANUAL CONTAINS IMPORTANT SAFETY AND OPERATING INSTRUCTIONS FOR YOUR BATTERY CHARGER. Before using the charger read all instructions and cautionary markings on the charger, battery pack and the product using the battery pack. danger! If the battery pack case is cracked or damaged, do not insert it into charger.
  • Page 8: Additional Safety Warnings For Drills

    additional Safety WarninG for drillS Do not use the drill in wet or damp conditions. Always keep the work area free of tripping hazards. When using the drill always ensure you are wearing protective safety equipment including safety glasses/goggles, ear muffs, dust mask and other protective clothing including gloves and apron.
  • Page 9: Preparation And Set-Up

    litHium ion Battery and cHarGer Safety featureS over current protection If the battery (8) is overloaded and the maximum current draw is exceeded the battery will temporarily stop working to protect the internal components. The battery (8) will resume normal operation once the current draw has returned to its normal safe level.
  • Page 10 preparation and Set-up (cont.) Keyless chuck The keyless chuck (1) on your drill enables easy installation and removal of bits/accessories. To open and close the keyless chuck (1), hold the chuck collar (a) with one hand and rotate the chuck body (c) with your other hand (Fig.
  • Page 11: Drill/Driver Operation

    drill driVer operation It is important to understand the functions of the various controls. See below how and when to use the variable speed trigger, forward/reverse lever and torque control. Variable Speed trigger Turn the drill on by depressing the variable speed trigger (4) (Fig.
  • Page 12 The CDL-072 is not recommended for metal drilling. led lights The drill has 1 LED Light (6) built into the unit (Fig. 7).
  • Page 13: Maintenance

    If the housing of the drill requires cleaning, do not use solvents but cloth only. Blow out the ventilation slots with compressed air periodically . note: Ozito Industries will not be responsible for any damage or injuries caused by repair of the cordless drill/driver by an unauthorised person or by mishandling.
  • Page 14: Description Of Symbols

    deScription of SymBolS...
  • Page 15: Pack Contents

    1 x 7.2V Cordless Drill/ Driver 1 x AC Charging Adaptor 2 x 50mm Screwdriver Bits 1 x Instruction Manual ozito induStrieS pty ltd auStralia (Head office) 1 - 23 Letcon Drive, Bangholme, Victoria, Australia 3175 Telephone: 1800 069 486 Facsimile: +61 3 9238 5588 Website: www.ozito.com.au...
  • Page 16: Warranty

    If the tool shows signs of damage or defects caused by or resulting from abuse, accidents or alterations. • Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. ozito Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175...
