Operation Guide 5117
Recovery Times
The table below shows the amount exposure that is required to take the battery from
one level to the next.
Exposure Level
Approximate Exposure Time
(Brightness)
Level 5
Level 4
Outdoor Sunlight
2 hours
(50,000 lux)
Sunlight Through a
7 hours
Window (10,000 lux)
Daylight Through a
10 hours
Window on a Cloudy
Day (5,000 lux)
Indoor Fluorescent
113 hours
Lighting (500 lux)
• The above exposure time values are all for reference only. Actual required exposure
times depend on lighting conditions.
Timekeeping
You can adjust the Home City time and date in the Timekeeping Mode manually. You
also can simultaneously display the current time in one other time zone, by specifying
a Dual Time City.
• For information about selecting a Dual Time City, see "To specify the Dual Time City".
• Pressing D in the Timekeeping Mode will cycle the lower display between the
screens shown below.
Home City date
Home City time
D
D
Read This Before You Set the Time and Date!
This watch is preset with a number of city codes, each of which represents the time
zone where that city is located. When setting the time, it is important that you first
select the correct city code for your Home City (the city where you normally use the
watch). If your location is not included in the preset city codes, select the preset city
code that is in the same time zone as your location.
• Note that all of the times for the World Time city codes and Dual Time City are
displayed in accordance with the time and date settings you configure for the
Timekeeping Mode.
To set the time and date manually
1. In the Timekeeping Mode, hold down A for about five
seconds until the left dial hand points to T1 and the city
code flashes on the upper display. This is the setting
screen.
2. Use D and B to select the city code you want.
• Make sure you select your Home City code before
changing any other setting.
• For full information on city codes, see the "City Code
Table".
3. Press C to move the flashing in the sequence shown below to select the other
settings.
12/24-Hour
DST
City Code
Format
Power Saving
Day
Month
4. When the timekeeping setting you want to change is flashing, use D or B to
change it as described below.
Screen:
To do this:
Change the city code
Cycle between Auto DST (
Daylight Saving Time (
Standard Time (
).
Toggle between 12-hour (
24-hour (
) timekeeping
Reset the seconds to
Change the hour and minutes
Change the year, month, or day
Toggle between Power Saving on
(
) and off (
)
5. Press A twice to exit the setting screen.
• For details about the Daylight Saving Time setting, see "To change the Daylight
Saving Time (summer time) setting". For information about Power Saving, see "To
turn Power Saving on and off".
• Auto DST (
AvtA
) can be selected only while LIS, LON, MAD, PAR, ROM, BER,
STO , ATH , MOW , TPE , SEL , TYO , HNL , ANC , YVR , LAX , YEA , DEN , MEX , CHI ,
MIA, YTO, NYC, YHZ, or YYT is selected as the Home City code. For more
information, see "Daylight Saving Time (DST)" below.
• The day of the week is displayed automatically in accordance with the date (year,
month, and day) settings.
Level 3
Level 2
Level 1
22 hours
6 hours
82 hours
22 hours
133 hours
36 hours
- - - - - - - -
- - - - - - - -
Dual Time
D
Seconds
Hour
Year
Minutes
Do this:
Use D (east) and B
(west).
Press D.
),
) and
Press D.
) and
Press D.
Use D (+) and B (–).
Press D.
12-hour and 24-hour timekeeping
• With the 12-hour format, the PM indicator appears to the left of the hour digits for
times in the range of noon to 11:59 p.m. and no indicator appears to the left of the
hour digits for times in the range of midnight to 11:59 a.m.
• With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without
any indicator.
• The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is
applied in all other modes.
Daylight Saving Time (DST)
Daylight Saving Time (summer time) advances the time setting by one hour from
Standard Time. Remember that not all countries or even local areas use Daylight
Saving Time.
The time calibration signals transmitted from Mainflingen (Germany), Anthorn
(England), or Fort Collins (the United States) include both Standard Time and DST
data. When the Auto DST setting is turned on, the watch switches between Standard
Time and DST (summer time) automatically in accordance with the signals.
• Though the time calibration signals transmitted by the Fukushima and Fukuoka/
Saga, Japan transmitters include summer time data, summer time currently is not
implemented in Japan (as of 2009).
• The default DST setting is Auto DST (
PAR, ROM, BER, STO, ATH, MOW, TYO, ANC, YVR, LAX, YEA, DEN, MEX, CHI,
MIA , YTO , NYC , YHZ , or YYT as your Home City code.
• If you experience problems receiving the time calibration signal in your area, it
probably is best to switch between Standard Time and Daylight Saving Time
(summer time) manually.
To change the Daylight Saving Time (summer time) setting
1. In the Timekeeping Mode, hold down A for about five
seconds until the left dial hand points to T1 and the city
code flashes on the upper display. This is the setting
screen.
2. Press C and the DST setting screen appears.
3. Use D to cycle through the DST settings in the
sequence shown below.
Auto DST (
DST indicator
4. When the setting you want is selected, press A twice to exit the setting screen.
• The DST indicator appears to indicate that Daylight Saving Time is turned on.
Dual Time
Dual Time lets you display the current time in another time zone called your "Dual
Time City", in addition your Home City's current time. This feature is very handy for
business professionals and others who need to keep track of the current time in two
different time zones.
• For information about how to display the current time in the Dual Time City in the
lower display, see "Timekeeping".
To specify the Dual Time City
1. In the Timekeeping Mode, hold down A for about five
seconds until the left dial hand points to T1 and the city
code flashes on the upper display.
2. Press A again. The left dial hand will move to T2 and
the current Dual Time City code will start to flash on the
upper display. This is the Dual Time City selection
screen.
3. Use D (eastward) and B (westward) to scroll through
the available city codes.
• See the "City Code Table" for information about city
Left dial hand
codes.
4. Press A to exit the setting screen.

Hand Home Position Correction

The hour and minute hands of the watch can be thrown off by exposure to strong
magnetism or impact.
• You can perform correction of the hour and minute hand home positions manually.
To adjust the home positions manually
1. In the Timekeeping Mode, hold down D for about three
seconds, until H-SET appears on the upper display.
• The dial hands are in their correct home positions
when the left dial hand moves to C (CHG) and the
stopwatch hand moves to 60. If they don't, use B to
adjust the left dial hand position and D to adjust the
stopwatch hand position.
2. After confirming that both dial hands are in their correct
home positions, press C.
• This will change to hour hand and minute hand home
Correct dial hand
position manual correction.
positions
• The hour and minute hands are in their correct home
positions if they are pointing to 12 o'clock. If they are
not, use D (+) and B (–) to adjust their positions as
required.
• Pressing C here will return to the setting at the
beginning of step 2.
3. After everything is the way you want, press A to return
to the Timekeeping Mode.
• After you complete the home position adjustment
procedure, place the watch in a location that allows
Correct hour and
good time calibration signal reception, and then a
minute hand
manual receive operation. See "To perform manual
positions
receive" for more information.
) whenever you select LIS , LON , MAD ,
)
DST off (
)
DST on (
)
5
