OWNER'S MANUAL
CAUTION: Exercise of a strenuous nature, as is customarily done on this equipment,
should not be undertaken without first consulting a physician. No specific health
0
claims are made or implied as they relate to the equipment.
IMPORTANT: Read all instructions carefully before using this product. Retain this
owner's manual for future reference.
Advertisement
Table of Contents
Related Manuals for Progression Fitness TM6400
Summary of Contents for Progression Fitness TM6400
- Page 1 OWNER’S MANUAL CAUTION: Exercise of a strenuous nature, as is customarily done on this equipment, should not be undertaken without first consulting a physician. No specific health claims are made or implied as they relate to the equipment. IMPORTANT: Read all instructions carefully before using this product. Retain this owner’s manual for future reference.
-
Page 2: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS 1. Plug the power cord of the treadmill directly into a dedicated grounded circuit. This product must be grounded well. If there is a surge, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. 2. - Page 3 7. Keep small children away from the treadmill during operation. 8. Always hold the handrails when initially walking or running on the treadmill, until you are comfortable with the use of the treadmill. 9. If the user wants to stop the exercise or the should the treadmill suddenly increase in speed due to an electronics failure, please be sure to put your hands on the both uprights, and then step on the ride rail to avoid injury by the moving running belt.
- Page 4 15. Please leave a 6ft X 3ft safety area behind the equipment. ASSEMBLY INSTRUCTIONS Please check following parts after you open the box. HARDWARE BAG CONTAINING: Parts # Description Remarks Qty. MAIN FRAME LEFT UPRIGHT POST RIGHT UPRIGHT POST FIXED FRAME ASSEMBLY COMPUTER ASSEMBLY LEFT PLASTIC COVER(LEFT) LEFT PLASTIC COVER(RIGHT)
-
Page 5: Assembly Steps
END CAP HEX BOLT M8*52 HEX BOLT M8*20 HEX BOLT M8*16 SCREW ST2.9*13 SCREW M6*10 FLAT WASHER Ø ALLEN WRENCH ALLEN WRENCH WRENCH W/SCREW DRIVER S=13,14,15 ASSEMBLY STEPS STEP (1): 1) Take all the parts from the boxes, and put the main frame & base frame on to floor. - Page 6 STEP (4): 1. Put the left plastic cover (right)(76) and right plastic cover (left)(77) into the fixed frame assembly (9), then insert them into the left and right upright post(4,5). 2. Use the allen wrench to connect the screw(16) with the flat washer (38). 3.
-
Page 7: Folding Steps
1. Put the left plastic cover (left)(75) into left upright post(4). Then use the screw(27) to connect the left plastic cover (left,right)(75,76) with left upright post(4). 2. Put the right plastic cover (right)(78) into right upright post(5). Then use the screw(27) to connect the right plastic cover (left,right)(77,78) with right upright post(5). -
Page 8: Technical Parameter
TECHNICAL PARAMETER ASSEMBLED SIZE(mm) 1800x735x1425 POWER SUPPLY FOLDABLE SIZE(mm) 900x735x1530 MAX OUTPUT RUNNING BOARD 1290x430 INPUT CURRENT SIZE(mm) MACHINE N.W. 70.5KG SPEED RANGE 1.0-16km/h INCLINE DEGREE 0%-15% MAX WEIGHT 105KG 3 LED DISPLAY SPEED DISTANCE TIME INCLINE PULSE CALORIES... - Page 9 ELECTRICAL SOURCE REQUIREMENT I mproper connection of the equipment grounding connector can result in a risk of an electric shock. Check with a qualified electrician or service man if you are in doubt as to whether the product is properly grounded. Do not modify the plug provided with the product.
-
Page 10: Operation Guide
OPERATION GUIDE Use the following instructions to help you use the treadmill. We recommend that you first get familiar with your... -
Page 11: Window Display
treadmill in the manual mode before you attempt any programmed workouts. CAUTION: 1. We recommend that you stay at a slow speed in the beginning and hold on to the handrails until you become comfortable. 2. Attach the magnet end of the safety pulling rope to the computer and attach the clip of safety pulling rope to your clothing. -
Page 12: Quick Start
for over 0.5 seconds and the rate of speed change will be increased or decreased. 5). “INCLINE+” “INCLINE-”: Press the button to adjust incline, its range is 1% per touch, keep pressing for over 0.5 seconds and the rate of change will be increased or decreased. 6). -
Page 13: Power Saving
P1—P9 CHART TIME INTERVAL SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE 8. DATA DISPLAYING RANGE: Parameter Initialvalue Initialvalue Setting Range Displaying Range Time(Min:Sec) 0:00 22:00 8:00-99:00 0:00-99:59 Incline(%) 0-15 0-15 Speed(Kph) 1.0-16.0... -
Page 14: Maintenance Instructions
Turning off the machine with the on/off switch under any situation will not damage the machine. MAINTENANCE INSTRUCTIONS CLEANING General cleaning of the unit will greatly prolong the life of the treadmill. Keep the treadmill clean by dusting regularly. Be sure to clean the exposed part of the deck on either side of the walking belt and also the side rails. - Page 15 WALKING BELT CENTERING AND TENSION ADJUSTMENT The walking belt may occasionally need to be centered and tightened. 1. In order to protect your treadmill, prolong its usage period, we suggest you to shut off the power for 10 minutes after 2 hours of continuous use. 2.Do not make running belt overly loose, it may slip when running;...
-
Page 16: Exploded View
EXPLODED VIEW... - Page 17 DESCRIPTION REMARKS DESCRIPTION REMARKS MAIN FRAME BLUE CUSHION PAD BASE FRAME FLAT FOOT PAD INCLINE FRAME COMPUTER UPPER COVER LEFT UPRIGHT POST COMPUTER BOTTOM COVER RIGHT UPRIGHT POST EVA WASHER MOTOR BRACKET RHOMBIC END CAP COMPUTER ASSEMBLY WHEEL TUBE END CAP TUBE WHEEL FIXED FRAME ASSEMBLY...
-
Page 18: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM CAUSE CORRECTION 1. Treadmill will not start. 1. Not plugged in.. 1. Plug into three prong grounded outlet. 2. Safety cord not inserted 2. Insert safety cord. 3. Treadmill circuit breaker tripped. 3. Reset circuit breaker (see exploded view for location) 4.
