CUBE4™ RGBW QUAD LED User
Manual
(Battery Powered DMX LED Fixture)
Please read over this manual before operating the light.

Advertisement

loading
Need help?

Need help?

Do you have a question about the CUBE4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Eternal Lighting CUBE4

  • Page 1 CUBE4™ RGBW QUAD LED User Manual (Battery Powered DMX LED Fixture) Please read over this manual before operating the light.
  • Page 2 Do not return this unit to your dealer without first contacting. Introduction: The CUBE4™ RGBW QUAD LED 1 is a DMX intelligent LED par light. This par light is lightweight and compact which makes it a great piece for mobile DJ‟s and clubs.
  • Page 3 Power Supply: Before plugging your unit in, be sure the source voltage in your area matches the required voltage for your CUBE4™ RGBW QUAD LED. The CUBE4™ RGBW QUAD LED is workable in 100-220V/50~60Hz. Because line voltage may vary from venue...
  • Page 4 DMX chain. Operating Instructions Operating Modes: You can use the CUBE4™ RGBW QUAD LED in 4 ways: ● Sound activation – The unit will activated by the sound signal. ● Static display – The unit will display the pattern in static way.
  • Page 5 DMX Values and Functions 4CH Mode Value Description 0-255 RED dimmer (0-255) 0-255 GREEN dimmer (0-255) 0-255 BLUE dimmer (0-255) 0-255 WHITE dimmer (0-255) 8CH Mode Value Description 0-255 RED dimmer (0-255) 0-255 GREEN dimmer (0-255) 0-255 BLUE dimmer (0-255) 0-255 WHITE dimmer (0-255) 0-255...
  • Page 6 LED Operation Menu: After initialization, the unit is ready for setting and working. Please see the following table for setting information. Display Function ADDR DMX Address(0-512) CHMD 4CH/8CH SLND NAST Master SLAL Slave SHND SOND Sound control COLO Color choose 1-15 Auto operation FADE Running Speed (SP1-SP8)
  • Page 7 (1) Alpha-numeric display (2) Touch switches (3) Microphone (4) DMX-In socket (5) DMX-Out socket (6) Power switch (7) Battery switch (8) GND (9) Power socket and fuse holder (10) Fixation screw (11) Mounting bracket There are two buttons on the rear panel of the lighting. One is for power, and the other is for battery.
  • Page 8 For wireless receiver Wireless Module of DMX512 MODE:PCB-WI-DMX Brief: DMX512 wireless receiver/transmitter transmits standard DMX512 protocol data (generated by console )by wireless way, which solves lighting control issues of wireless transmitting completely between console and lighting, lighting and lighting and so on, It get rid of connecting cable limited completely And also can ensure without any time delay when signal data is transmitting, signal data is real time and reliably.
  • Page 9 (1) Antenna (2)Power switch for wireless receiver (3) Wireless indicator (4)ID code selector Product feature: Product name:2.4G wireless DMX512 R/T molding board Small size,Easy to suit for interior of accessed lighting Single key to operate,tricolor LED displaying Transmitting standard DMX512 protocol data of console,also can transmitting lighting and lighting DMX512 protocol data.
  • Page 10 Compatible series product as follows: Wiresless transmitter Operating manual: ID code and LED color corresponding relationship:  1:RED  2:GREEN  3:RED+GREED  4:BLUE  5:RED+BLUE  6:GREEN+BLUE  7:RED+GREED+BLUE Press button on transmitter to select group to match corresponding color on the receiving fixture.
  • Page 11 1. Quiet or high pitched sounds will not activate the unit. If problems are not resolved, contact your dealer for service. Specifications Model: CUBE4™ RGBW QUAD LED Working Position: Any safe working position Power Supply: Switching power supply Voltage: AC 100-220V /50~60Hz...
  • Page 12 LED: 10pcs (4in1) Net Weight: 7lbs Dimensions: 8 inches x 8 inches x 6 inches Note: All information is subject to change without prior notice. 2011-07-06...
