Thomas Renegade TG-550H Owner's Manual And Operating Instructions

LIMITED WARRANTY

The Thomas Industries, Inc. Compressor is warrantied to you, the original purchaser,
for a period of one year from date of original retail purchase or 90 days, if used for
commercial or industrial use, to be free from defects in material or workmanship. If
during the specified warranty period you believe the purchased product of any part
thereof has such a defect, you must return the product or part during such period, with
proof of purchase and at your cost, to the nearest authorized service center (consult
the list of service centers enclosed with the product) for repair, or replacement of the
defective part. If you do not know the location of the nearest service center, contact
Thomas Industries at the address below for instructions. If the product or part is found
to have been defective in material or workmanship, it will be repaired or replaced (as
deemed necessary by the repair center), free of charge, and returned to the purchaser
at purchaser's cost. If repair work must be done at the Thomas Industries factory,
transportation costs of the product or part to and from the factory must be paid by the
purchaser.
This warranty shall not apply to any compressor which in Thomas' judgement has
been subject to misuse, negligence or accident, or which has been operated from a low
power supply. This warranty shall not apply to compressors that require oil for operation
which have been operated with oil levels below that specified by Thomas Industries.
THE MANUFACTURER LIMITS THE DURATION OF THE IMPLIED WARRANTY OF
MERCHANTABILITY TO THE LIMITED WARRANTY PERIOD SET FORTH ABOVE,
AND OTHERWISE DISCLAIMS ALL IMPLIED WARRANTIES WITH RESPECT TO
THE PRODUCT AND IT'S PARTS. Some states disallow certain limitations on implied
warranties. You should consult your state law if you have a question regarding this
limitation and disclaimer.
THE MANUFACTURER DISCLAIMS ANY AND ALL LIABILITY FOR INCIDENTAL,
CONSEQUENTIAL, SPECIAL OR INDIRECT DAMAGES ARISING OUT OF ANY
CLAIMED BREACH OF WARRANTY OR OTHERWISE. HOWEVER, SOME STATES
DO NOT ALLOW EXCLUSION OR LIMITATION OF SUCH DAMAGES, SO THIS
DISCLAIMER MAY NOT APPLY TO YOU.
The remedy provided in this Limited Warranty for a defective product is purchaser's
sole and exclusive remedy, subject to your state law. Further, this Warranty gives you
specific legal rights, and you may also have other rights which vary from state to state.
If you believe warranty service is needed, contact your nearest authorized service
center. If one does not exist in your area, please contact the manufacturer:
Thomas Industries, Inc.
C/O Customer Service
1419 Illinois Avenue
Sheboygan, Wisconsin 53082
Phone: (920) 457-4891
Fax: (920) 451-6307
www.thomasairpac.com
1419 ILLINOIS AVE., SHEBOYGAN, WI 53082 USA
OWNER'S MANUAL and OPERATING INSTRUCTIONS for
TG-550H
•
5.5 HP HONDA OHV GASOLINE ENGINE
• WOBL PISTON COMPRESSOR
• PERMA-LUBE™ COMPRESSOR DESIGN
Performance, portability, and reliability makes the RENEGADE TG-550
Series our finest, most convenient gas powered compressors. They are
ideal for use in applications requiring a heavy-duty compressed air source
in areas where an electrical connection is not available.
SPECIFICATIONS
Air Displacement....................................................................24CFM (680 LPM)
Air Delivery.............................12cfm @ 100 PSI..............340 LPM @ 690 kPa)
Safety Valve Setting.............................................................165 PSI (1140 kPa)
Engine Idle Speed..................................................................2200 ± 150 RPM
Engine Run Speed.................................................................3450 ± 150 RPM
Automatic Control............................................Continuous Run Unloader Valve
....................................................Unloads @ 135 PSI (930 kPa)
........................................................Loads @ 115 PSI (795 kPa)
Engine Oil-Recommended....................................See Engine Owner's Manual
Air Tank Capacity, .............................................................................. 7 Gallons
Unit Weight ................................................................................100 lbs. (46 kg)
Unit Dimensions LxWxH (in).............43 X 18 X 23 (cm).............110 X 46 X 59
Compressor Type...........................Oilless Compressor, Perma-Lube™ Design
Pump-Up Time ........................................................................ Approx. 1.0 Min.
Recovery Time ..............................................................Approx. 8 ± 3 Seconds
Regulator Connection Size..................................................................1/4 - NPT
CFM = Cubic Feet Per Minute kPa = kilopascals
RPM = Revolutions Per Minute
Part No. 642501 Rev O 10/05
• 7 GALLONS AIR STORAGE
• 12 CFM @ 100 PSI
PSI = Pounds Per Square Inch
LPM = Liters Per Minute
©2005 Thomas Industries Sheboygan Inc., Printed in U.S.A.
