Thomas ULTRA AIR-PAC T-2820ST Series Owner's Manual And Operating Instructions

NOTICE
AN INTAKE AIR FILTER HAS BEEN SUPPLIED
(UNATTACHED) WITH THIS COMPRESSOR.BEFORE
OPERATION: REMOVE THE ORANGE PLASTIC PULL
PLUG FROM THE INTAKE PORT OF THE HEAD.
INSTALL THE SUPPLIED AIR FILTER IN THE (INTAKE)
PORT FROM WHICH THE PULL PLUG WAS REMOVED.
DO NOT OVERTIGHTEN FILTER WHEN INSTALLING
AVISO
UN FILTRO DE AIRE DE ENTRADA HA SIDO PRO-
VISTO (SUELTO) CON ESTE COMPRESOR. ANTES DE
PONER EN OPERACION. REMUEVA EL TAPON DE
PLASTICO ANARANJADO DE LA PUERTA DE ENTRADA
DE LA CABEZA.
INSTALE EL FILTRO DE AIRE PROVISTO EN LA
PUERTA (DE ENTRADA) DE DONDE SE SACO EL TAPON.
NO APRIETE DE MAS EL FILTRO AL INSTALARLO.
NOTICE
UN FILTRE D'ADMISSION D'AIR A ÉTÉ FOURNI
(NON ATTACHÉ) AVEC CE COMPRESSEUR. AVANT
L'OPÉRATION
ENLEVER LE BOUCHON PLASTIQUE ORANGE DE
L'ORIFICE D'ADMISSION DE LA TETE.
INSTALLER LE FILTRE A AIR FOURNI DANS
L'ORIFICE (ADMISSION). NE PAS TROP SERRER
LE FILTRE LORSQUE VOU L'INSTALLEZ.
1419 ILLINOIS AVE., SHEBOYGAN, WI 53081 USA (920) 457-4891 www.thomasairpac.com
OWNER'S MANUAL and OPERATING INSTRUCTIONS for
Model T-2820ST Series
Portable, Oilless Heavy Duty
Air Compressor
WOB•L PISTON COMPRESSOR
GENERAL DESCRIPTION
Performance in tandem with portability makes the T-2820ST our finest, most
convenient tank compressor which is perfect for the professional and serious do-it-
yourselfer. This compressor includes air storage tank, and an automatic pressure
switch control.
SPECIFICATIONS
Voltage.................................................................................. 115 V. 60 HZ
Starting Voltage (min.)...................................................................... 95 V
Fuse Requirements .............................................................. 15 A (min.)
Safety Valve Setting ............................................ 140 PSIG (965.3 KPa)
Air Displacement ......................................................9 CFM (240.5 LPM)
Air Delivery ................................................................ 6.6 CFM @ 50 PSI
.............................................................(186.9 LPM @ 345 KPa)
.................................................................... 5.0 CFM @ 100 PSI
.......................................................... (141.6 LPM @ 689.5 KPa)
Amps at Working Pressure .......................................................... 13.5 A
Automatic Control ............................... Starts @ 100 PSIG (689.5 KPa)
................................................. Stops @ 125 PSIG (861.9 KPa)
Tank Sizes..................................................... 2 Gal. EACH (Total 4 Gal.)
Weight ........................................................................................... 74 lbs.
Cord ..................................................................................... 6 ft. (1.83 M)
PSI = Pounds Per Square Inch
KPa = Kilopascals
Part No. 636936 Rev. AH 05/05
CFM = Cubic Feet Per Minute
LPM = Liters Per Minute
