OWNER'S MANUAL and OPERATING INSTRUCTIONS for
Model Model T-2820 SERIES Model T-2820 SERIES T-2820 SERIES T-2820 SERIES
Model Model T-2820 SERIES
Portable, Oilless Heavy Duty Air Compressor
WOB•L PISTON COMPRESSOR
GENERAL DESCRIPTION
Performance in tandem with portability makes
the T-2820 our finest, most convenient tank
mounted compressor which is perfect for the
professional and serious do-it-yourselfer. This
compressor includes air storage tanks,and an
automatic pressure switch control.
APPLICATION
Ideal as primary or secondary air source for
almost any operation. Particularly suitable for
shops, garages; and factories where repetitive
use demands high reliability.
FOR SERVICE AND PARTS
For service contact the dealer from whom you
purchased the compressor.
To place parts orders: Provide the model data
located on the nameplate of the compressor
and call our national parts center. 1-800-323-
0620
Part No. 636936 Rev. W 12/00
U.S.A.
SPECIFICATIONS
Voltage..................................................... 115 V. 60 HZ
Starting Voltage (min.)......................................... 95 V
Fuse Requirements .................................. 15 A (min.)
Safety Valve Setting ............... 140 PSIG (965.3 KPa)
Air Displacement ...................... 8.9 CFM (240.5 LPM)
Air Delivery .................................... 6.6 CFM @ 50 PSI
...........................................(186.9 LPM @ 345 KPa)
.....................................................5.5 CFM @ 80 PSI
.......................................... (155.7 LPM @ 552 KPa)
.................................................. 5.0 CFM @ 100 PSI
....................................... (141.6 LPM @ 689.5 KPa)
Amps at Working Pressure ............................. 13.5 A
Automatic Control ....................... Starts @ 100 PSIG
.............................................................. (689.5 KPa)
................................................... Stops @ 125 PSIG
.............................................................. (861.9 KPa)
Tank Sizes......................... 2 Gal. EACH (Total 4 Gal.)
........ (T-2820) 3.5 Gal. EACH (total 7 Gal.)
Weight.......................................T-2820WT ...... 77 Ibs.
....................................... T-2820ST ....... 74 lbs.
........................................... T-2820 .....119 lbs.
Cord ......................................................... 6 ft. (1.83 M)
PSI = Pounds Per Square Inch
KPa = Kilopascals
CFM = Cubic Feet Per Minute
LPM = Liters Per Minute
© 1995Thomas Industries, Inc., Printed in
