Summary of Contents for Defender Security 82-12890
- Page 1 User’s Manual 8CH DVR 82-12890 ’ ’ 8-Channel Standalone DVR Installation Guide & User’s Manual Version 2.41 - 0 -...
-
Page 2: Table Of Contents
User’s Manual 8CH DVR Directory DVR Feature ......................3 Outlook ........................3 2.1. Front Panel .......................... 3 2.2. Rear Panel........................... 4 2.3. Remote Controller........................ 5 2.4. Removable HDD Box Introduction ..................5 DVR Installation ......................6 3.1. Install Hard Disk........................6 3.2. Connect Camera and Monitor....................7 3.3. - Page 3 User’s Manual 8CH DVR Language........................... 18 Exit............................. 18 NTSC/PAL Output Select....................18 Record ........................19 6.1. Start Recording ........................19 6.2. Stop Recording ........................19 6.3. Recording Length ......................20 Playback ........................21 Backup…………………………………………………………………………………….21 9. Network……………………………………………………………………………………22 9.1. Hardware Install......................... 22 9.2. Setup IP Address Of DVR....................22 9.3.
-
Page 4: Dvr Feature
User’s Manual 8CH DVR 1. DVR Feature 8 Channel BNC Camera Input 2 Channel BNC Monitor Output Support Network: Static, DHCP, PPPOE USB 2.0 Port For Backup And Playback With PC VGA Output (Optional) NTSC / PAL Video Loss Alarm Motion Detection With Area Setting PTZ Control With RS485 Port. -
Page 5: Rear Panel
User’s Manual 8CH DVR 1 Full Screen 2 Channel Up 3 Channel Down 4 Quad View 5 All Channel 6 Enter/Exit Menu Setup 7 Move Prompt Up 8 Modify Item 9 Move Prompt Down 10 Record, Stop manual record or Reduce value 11 Stop playing or dome running 12 Forward or Zoom+ 13 Play or Focus+... -
Page 6: Remote Controller
User’s Manual 8CH DVR 2.3 Remote Controller 1. FULL One Channel View or Move Dome Up 2. ALL All Channel View 3. UP CH. UP Channel View or Move Dome Down 4. QUAD Quad View or Move Dome Right 5. DOWN CH. Down Channel View or Move Dome Left 6. -
Page 7: Dvr Installation
User’s Manual 8CH DVR 3. DVR Installation 3.1 Install Hard Disk Slide the carrier body out of the cartridge frame (Fig1) DON’T take out HDD when DVR running! Fig1 Connect the HDD data cable and the power cable to the HDD (Fig2) Fig2 Push carrier body further into cartridge frame until fully inserted (Fig3) -
Page 8: Connect Camera And Monitor
User’s Manual 8CH DVR 3.2 Connect Camera and Monitor There are eight cameras input and two monitors output with BNC connector. 3.3 Connect Power Cord Please use the power adapter supplied with DVR. 4. DVR System Boot 4.1 Detect Installed Hard Disk After connecting the power, system will boot-up FW:2.41,UCODE:86 firmware, date, video and detect installed hard... -
Page 9: Dvr Setup
User’s Manual 8CH DVR 5. DVR Setup Press “ Menu” into setup menu, use “ Up” and “ Down” to select item, then press“ Select” to modify setting and “ Menu” to confirm and exit. Menu Directory Camera Record Frame Rate Record Quality Record Record Schedule... -
Page 10: Record
User’s Manual 8CH DVR 5.2 Record Press 「 Up」 or 「 Down」 to move the prompt. Press 「 Select」to enter each sub menu, and press 「 Select」 or 「REC」 to modify each parameter. 5.2.1 Record Framerate Record frame rate will affect the movement of object in recorded video. -
Page 11: Alarm
User’s Manual 8CH DVR Press 「 Up」 or 「 Down」 to move the prompt ,and press 「 SEL」 to select video record method. User can press the button 「ALL」to set up the same record method during the whole time. λ “ ” Manual Record(System Default) λ... -
Page 12: Sensor
User’s Manual 8CH DVR 5.3.1 SENSOR There are three different modes for sensor setting: NONE & N.C & N.O. NONE means NOT INSTALLED, N.C means NORMAL-CLOSE, N.O means NORMAL-OPEN. It depends on what type of external sensor you use. If sensor’s output is N.O, then select N.O mode in DVR. -
Page 13: Motion
User’s Manual 8CH DVR Install example diagram: PTZ Setup Connect PIR sensor PIR Sensor NO/NC output to DVR Power input terminal. (Max. 5V DC) Alarm Power 5.3.2 MOTION The first step, User need setup video record method by Motion Triggered. Please make Reference to 5.2.3. -
Page 14: Audio
User’s Manual 8CH DVR CHANNEL 1- 8 AREA SET: Press “ Select” to enter motion area setting state, and then press “ Select” to set the block is active or not. Press “ Select” once to pitch on the area, press “ Select”... -
Page 15: Password Change
User’s Manual 8CH DVR 5.5.1 Password Change Press 「 SEL」 to enter “password change” setup. Press 「 SEL」to input value, and then move the prompt to the option of “ENTER”, press 「 SEL」to input current password. And the same operation measure input password confirm... -
Page 16: Time Setup
User’s Manual 8CH DVR 5.5.3 Time Setup Press「 Up」and「 Down」to move prompt and press「 Select」or 「REC」to modify. User can select time zone. After confirming time zone, configure DVR system time. Move the prompt to the order of “APPLY”, and then press to confirm. When “SYNC. -
Page 17: Local Ip
User’s Manual 8CH DVR 5.5.5.1 Local IP In the menu of “Local IP” user can set up IP type. IP type includes static, DHCP and PPPOE. If IP type is static, user can adjust the order of “IP address, gateway and net mask”. If IP type is PPPOE, user can adjust the order of “PPPOE ID and PPPOE password”. -
Page 18: Screen Adjustment
User’s Manual 8CH DVR BAUD RATE: Press “EDIT” button to select the value 1200,2400,4800,9600,19200bps. SPEED: Having “1-10” to select. PRESET: If protocol is PELCO-D, preset includes “1-32”. If protocol is PELCO-P, preset includes “1-255”. When it displays 0, it suggests that the place’s preset is not using. Button function: 「Select」:Make sure the setting. -
Page 19: Search
User’s Manual 8CH DVR Press「Select」button accessing to “ Screen Adjustment”. Press 「CH1」button to move the screen up, press 「CH2」 button to move down, press 「CH3」 button to move left, press 「CH4」 button to move right. 5.6 SEARCH Press the button 「SEL」 to enter “ Time Search”, on the menu user can look over start time and end time of all recording. -
Page 20: Record
User’s Manual 8CH DVR 6. Record 6.1 Start Recording Press “ Record” to start recording. System will display some information on Screen. Note: When the DVR is recording, user can play back or handle menu bar simultaneously. ① Channel Name ②... -
Page 21: Recording Length
User’s Manual 8CH DVR 6.3 Recording Length The lengths of record time based on 250G HDD are estimated as follows, using eight cameras:(just for reference) Record Frame Data Rate Record Time Format Record Quality Rate (GB/Hour) (Hour) High 5.85 50F/Sec Normal 4.59 2.48... -
Page 22: Playback
User’s Manual 8CH DVR 7. Playback Press “ Play” then system will list the time of all videos from HDD. Press “ Select” and then press “ Up” and “ Down” to move prompt. Press “ Select” to edit time value and press “ Menu ”to confirm. -
Page 23: Network
User’s Manual 8CH DVR “Complete”, press 「MENU」to return to live view. Note: Before backup, user must stop recording firstly. Complete backup once, user must pull out USB disk. If user wants to backup over again, he must plug into USB disk again. 9. -
Page 24: Configure Ip Address Of Pc
User’s Manual 8CH DVR 9.3 Configure IP address of PC If IP address of DVR is “192.168.1.161”, ”IP Type” is “Static” and “Gateway” is”192.168.1.1”. User must manually configure IP address of PC to connect DVR. For example: Configure PC address as 192.168.1.171. Windows XP: Click “Start”→... -
Page 25: Connect Pc To Dvr-Net Viewer
User’s Manual 8CH DVR settings”. 9.4 Connect PC to DVR—Net Viewer 9.4.1 Install 1. Put the Driver Program CD in your CD-ROM. 1. Go for installing by setup. 2. Set up the install directory. 3. Execute: 1.Start >Program> VxViewer8Ch. 2.Start>Program> VxDDns. 9.4.2 Program Interface A: Run Vxviewer8Ch. - Page 26 User’s Manual 8CH DVR B: Run VxDDns. Make use of VxDDns, user can connect synchronously many DVRs to one PC. First set up DVR, enter menu bar “Network Settings”, adjust “Network” is “ON”, select order of “Name Server”. On the interface of “Name Server”, make sure “Network” is “ON”, “IP Address” is the PC which is connected to the DVR, “Port”...
-
Page 27: Button Function
User’s Manual 8CH DVR 2. Double click “ ” icon on desktop to run the program. 3. First make sure the button “ ” is red. Click “the right button of the mouse” →”Options…”. In the bar of “DDNS Configuration” input IP and port. IP is PC’s IP (192.192.10.173) connected to the DVR, port is TCP port (8881). -
Page 28: Local Recording
User’s Manual 8CH DVR 1. Connect/Disconnect 2. Pause 3. Rewind 4. Play 5. Fast forward 6. Stop playing or Dome running 7. Record, Stop manual record or Reduce Value 8. Split 9 9. Channel 1 10. Channel Up 11. Channel Down 12. -
Page 29: Play Local Recording
User’s Manual 8CH DVR 9.4.5 Play Local Recording Click “ ” to change to the Player mode. Then click “ ” to play the video in “”VVF” format. Still Capture In the player mode, click the right button of the mouse to select “Options…” to setup path for still capture. -
Page 30: Connect Pc To Dvr -Ie Browser
User’s Manual 8CH DVR 9.5. Connect PC to DVR — IE Browser At first please turn all the Active X option ON at IE Internet safety setup. Select menu setup to enable the Active X option. Network module use Active X applet to display remote image. Any web browser with Active X support can connect to DVR. - Page 31 User’s Manual 8CH DVR In the interface of “Viewer Player”, input “IP”、”PORT”、”PASSWORD” of DVR, then click ”CONNECT” to enter live view of DVR. Click buttons on the right to control DVR directly though network. NOTE: All the button functions on the right are the same as DVR’s. - 30 -...
-
Page 32: Specification
User’s Manual 8CH DVR 10. Specification ITEM DESCRIPTION NOTE Video Format NTSC / PAL Operation System None STAND-ALONE Camera Input Channel 8 channel Composite BNC Video Output Channel 2 channel Composite BNC Max. 30 frames/s NTSC Max 60 fps (Total) (Each Channel) Recording Frame Rate Max. -
Page 33: Appendix
User’s Manual 8CH DVR 11. Appendix 11.1 System Connect Sketch Map 11.2 Fittings Come Along With DVR - 32 -...
