Page 1: User Manual
USER MANUAL Model #82-12475 4 CHANNEL DIGITAL VIDEO RECORDER... - Page 2 INSTRUCTION MANUAL For best results, please read this instruction manual completely before installing your new DVR. FCC Compliance USER-INSTALLER CAUTION: YOUR AUTHORITY TO OPERATE THIS FCC VERIFIED EQUIPMENT COULD BE VOIDED IF YOU MAKE CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE TO PART 15 OF THE FCC RULES.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION........................5 2. HARDWARE OVERVIEW ......................6 3. SETUP PROCEDURES ......................8 3.1 SYSTEM SETUP .......................9 3.2 CAMERA SETUP......................10 3.3 RECORD SETUP ......................11 3.4 ALARM SETUP.......................12 3.5 SCHEDULE RECORD ....................12 3.6 EVENT LIST ........................13 3.7 HDD MANAGEMENT ....................13 3.8 LOAD DEFAULT ......................14 3.9 EXIT..........................14 4. - Page 4 SETUP MENU LIST SETUP MENU SYSTEM SETUP SYSTEM SETUP SET TIME/DATE CAMERA SETUP TIME DISPLAY MODE 2007/JAN/01 RECORD SETUP TIME DISPLAY ALARM SETUP LANGUAGE SELECT ENGLISH SCHEDULE RECORD KEY LOCK EVENT LIST MENU SETUP PROTECTION HDD MANAGEMENT CHANGE PASSWORD DEAFULT SETUP SYSTEM SELECT NTSC EXIT...
-
Page 5: Introduction
1. INTRODUCTION This product is a 4 camera input appliance with multiple features and functions: Live display, play back and video recording capabilities. Reliable stand-alone operation (on-board OS). M-JPEG compression technology Standard analog camera support with BNC composite video connection ports Multi-speed recording selection on normal recording mode or alarm recording mode (max 30fps in both modes). -
Page 6: Hardware Overview
2. HARDWARE OVERVIEW Front Panel Overview 16 13 17 POWER Quad Enter PLAY H.D.D MENU Stop Pause F.Fwd Play Search Search Part Label DVR Function Part Label DVR Function Channel 1 Full screen & Channel 2 Full screen & number 1. number 2. - Page 7 Back Panel Overview VGA OUT Audio Out DC 12V / 3.5A Audio In Monitor Out Video Input Part Label Function CAM1, 2, 3, 4 Cameras 1, 2, 3, and 4 video input BNC connector. MONITOR OUT Composite video output BNC connector. AUDIO OUT Connect to audio output (Optional) AUDIO IN...
-
Page 8: Setup Procedures
3. SETUP PROCEDURES LIVE VIEWING REC 30P 2007/JAN/01 10:20:30 MON STATUS BAR CH1 O O CH2 CH3 O O CH4 231GB/239GB 97% [FULL REC] MUX INFROMATION BAR STATUS BAR - Press ▲ button to move from top to bottom, or down a line. Recording FPS will be displayed on the left upper corner. -
Page 9: System Setup
3.1 SYSTEM SETUP SYSTEM SETUP Press ▲ or ▼ buttons in "SYSTEM SETUP" & ◄ or ► to SET TIME/DATE enter: TIME DISPLAY MODE 2007/JAN/01 TIME DISPLAY Use the ▲ or ▼ button to select items. LANGUAGE SELECT ENGLISH KEY LOCK Press the ◄... -
Page 10: Camera Setup
3.2 CAMERA SETUP Press ▲ or ▼ key on "CAMERA SETUP" & ◄ or ► to CAMERA SETUP enter: CAMERA SELECT Use the ▲ or ▼ button to select items. CAMERA RECORD MOTION SENTSITIVITY 1[MIN] Press the ◄ or ► button to confirm the selection. BRIGHTNESS STANDARD CONTRAST... -
Page 11: Record Setup
3.3 RECORD SETUP Press ▲ or ▼ key on "RECORD SETUP" & ◄ or ► to RECORD SETUP enter: RECORD MODE NORMAL RECORD FPS Use the ▲ or ▼ button to select items. ALARM RECORD FPS ALARM RECORD DWELL 10SEC Press the ◄... -
Page 12: Alarm Setup
3.4 ALARM SETUP Press ▲ or ▼ key on "ALARM SETUP" & ◄ or ► to ALARM SETUP enter: BUZZER DWELL 5SEC Use the ▲ or ▼ button to select items. VIDEO LOSS ALARM MOTION ALARM Press the ◄ or ► button to confirm the selection. ALARM DISPLAY MODE EXIT Press MENU to go back to SETUP MENU. -
Page 13: Event List
3.6 EVENT LIST EVENT LIST Press ▲ or ▼ key on "EVENT LIST" & ◄ or ► to START TIME: 2007/JAN/01 12:07:06 enter: END TIME: 2007/JAN/05 12:07:30 Use the ◄ or ► button to select items. >01 RECORD 2007/JAN/05 10:07:06 02 MOT CH1 2007/JAN/05 12:06:18 Press the ▲... -
Page 14: Load Default
C. HDD CAPACITY 76GB The HDD capacity will be indicated on the screen, it can't be revised. D. HDD LEFT RATIO 73GB 97% Indicates the open space remaining on the HDD in both GB and percentage values. E. HDD FORMAT Use "◄... -
Page 15: Operating Procedures
4. OPERATING PROCEDURES 4.1 GETTING STARTED Please read the following instructions before you power-on the DVR: A. If possible, always confirm the DVR is connected to a 12VDC supply: Adapter input voltage range 100~240V, frequency range 47-63Hz. CAUTION – Incorrect supply voltage can result in damage to the DVR. B. -
Page 16: Vga Output
mark "^" will show up on corresponding location for adjustment. Use "▲ "or "▼ "keys to increases or decrease value for search condition on time or date. Press ►PLAY key to start playing back. B. EVENT LIST EVENT LIST START TIME: 2007/JAN/01 12:07:00 END TIME: 2007/JAN/05 10:47:30 >... -
Page 17: Introduction & System Requirement
5.1 INTRODUCTION & SYSTEM REQUIREMENT INTRODUCTION The Defender 4-Channel DVR comes with special PC viewer software to review and capture video footage on a PC running the Win2000 or WinXP OS. Once installed on your PC, the PC viewer software (YAViewer4) recognizes the USB-connected DVR and offers several video management options including backup to a unique .MYS video file, or capturing frames to a .BMP file. -
Page 18: View & Backup
5.2 VIEW & BACKUP EXECUTION The application first initiates a HDD detection process that may take up to 1 minute. USER INTERFACE The default page of the application is DVR HDD PC Viewer. The user interface functions are described below: HDD Select Button Direct Access Volume Control... - Page 19 C. FUNCTIONS C-1 HDD Select Button Once the application detects one or more HDDs, it automatically selects the first HDD. You can select any valid HDD [the HDDs with YAViewer4_Eng marked]. C-2 Valid Stream Region Indication Once a HDD is selected, the application detects the valid stream region where valid video streams reside.
-
Page 20: Mys Player
5.3 MYS PLAYER User Interface The application’s default page is displayed below with screen functions identified: MYS File Select Dialog MYS File Info Display MYS Player File Open Button Volume Control F. Forward F. Rewind Capture Current Forward by Rewind by Frame Frame R. - Page 21 B. FUNCTIONS B-1 File Open Open a MYS file by clicking the File Open Button. B-2 Playback Automatically displays beginning of recorded video stream and allows selection of video frames or playback streams within the designated valid stream range. B-3 Channel Selection The default screen display channel setting is ALL CHANNELS, which displays up to all four channels simultaneously.
-
Page 22: Application Setting
5.4 APPLICATION SETTING A. USER INTERFACE Change BMP File Saving Directory Change MYS File Saving Directory Default Video Mode Default Video Mode Enable/Disable Application Closing Confirm Enable/Disable Notification Message when the application detects the Enable/Disable Notification Message when the application detects invalid stream B. -
Page 23: Specifications
6. SPECIFICATIONS NTSC Image System Display 720 × 480 720 × 576 Resolution Record 640 × 224 640 × 272 Video Input BNC × 4 Video Output BNC × 1 Display Frame 4 × 30 fields/sec 4 × 25 fields/sec Recording Frame Rate (QUAD) Max 30 fps Max 25 fps... -
Page 24: Recording Time Length
7. RECORDING TIME ESTIMATES Note: recording time is directly related to recording speed and recording quality. The tables below are estimates based on HDD size and recording quality/resolution settings. Record Mode=MUX (yields longer recording times) Record Mode=QUAD (yields shorter recording time) 80GB H.D.D Record Mode=MUX NTSC Field/Sec 30/FS... -
Page 25: Hdd/Flash Compatible Table
8. HDD/FLASH COMPATIBLE TABLE Hard disk should be connected, and the capacity of hard disk is from 40GB to 500GB. When you restart the power of this appliance after install or replace new hard disk, it will format automatically. We tested the following model for your reference: Restricted : Brand Model... -
Page 26: Hard Drive Installation Procedures
9. HARD DRIVE INSTALLATION PROCEDURES Loosen the screw on the cover of the DVR. There are total 8 screws as follows. Install HDD (Master) and connect it with the power board and the main board as well as follows. Turn the bottom of the DVR up and make 4 screws on as follows. Screws are inside the accessory kit. - Page 27 After HDD installed and the power connected well, turn on the DVR. Then, OSD will display HDD information. After confirmation, screw on the cover of the DVR. Note: 1. Disconnect DVR from power source before HDD installation. 2. Set hard drive to master. 3.
