Summary of Contents for Trust 450I RJ45
- Page 1 450I RJ45 (A)DSL MODEM & ROUTER User’s manual V2.0...
- Page 2 Thank you for your purchase. Register your product via our Internet site at www.trust.com/register, so that you will be eligible for optimal guarantee and service support. You will also be automatically informed of the development of your and other Trust products.
- Page 3 450I RJ45 (A)DSL MODEM & ROUTER Fig. 1 Fig. 2 Fig. 3...
- Page 4 450I RJ45 (A)DSL MODEM & ROUTER Fig. 4 Fig. 5 Fig. 6 Fig. 7...
-
Page 5: Table Of Contents
TRUST 450I RJ45 (A)DSL MODEM & ROUTER Table of contents INTRODUCTION..................2 SAFETY ......................2 APPROVAL ....................2 HARDWARE AND SOFTWARE REQUIREMENTS ........2 EXPLANATION INDICATORS AND CONNECTIONS ........2 CONNECTING POWER ADAPTER AND (A)DSL- LINE ......3 CONNECTING MODEM & ROUTER TO YOUR COMPUTER....3 CONFIGURE PC AND MODEM & ROUTER ..........4 CHECKING AFTER INSTALLATION/CONFIGURATION ......4... -
Page 6: Introduction
TRUST 450I RJ45 (A)DSL MODEM & ROUTER Introduction This instruction manual is for users of the ‘TRUST 450I RJ45 (A)DSL MODEM & ROUTER’. The modem/router can be connected to 4 computers with a network connection to share your Internet connection. The 450I modem/router is used for (A)DSL via ISDN lines. -
Page 7: Connecting Power Adapter And (A)Dsl- Line
TRUST 450I RJ45 (A)DSL MODEM & ROUTER Function Definition Flashing The (A)DSL station is executing a self-test. The (A)DSL station has completed its self-test. (A)DSL sync Flashing The (A)DSL station is initialising. indicator (green) Initialisation is complete, and (A)DSL signal is present. -
Page 8: Configure Pc And Modem/Router
Internet Explorer. To do this all follow the step-by-step instructions in the quick installation guide starting at step 7 to configure your Windows network settings and Trust 450I RJ45 (A)DSL MODEM & ROUTER. -
Page 9: Connecting To Internet
11.1 How does the safety and protection work? Notice: The 450I RJ45 (A)DSL MODEM & ROUTER includes a firewall. The firewall protects your computers from intrusion. This firewall is, for security reasons, always switched on. All standard Internet traffic is protected. ‘Non-standard’ access is given true “ports”. -
Page 10: Erase (A)Dsl Modem/Router Settings
TRUST 450I RJ45 (A)DSL MODEM & ROUTER Tip: Also check the included Internet Sharing guide for general Internet sharing and networking. 11.2.2 Give access / Opening ports Open web-based menu: type 10.0.0.2 in the address bar of the Internet Explorer (or other address if this is changed at configuration of the device) Click “ManagePublic Servers”. -
Page 11: Uninstalling Usb Driver
Type [D:\SETUP.EXE] and click on 'OK' to start the Trust Software Installer. The Trust Software Installer will appear. Select the language you wish the Trust Software Installer to be displayed in. Click on ‘Install USB driver‘ to start the installation of the USB driver. Figure 3 will appear. - Page 12 TRUST 450I RJ45 (A)DSL MODEM & ROUTER Problem Cause Possible solution The web-based Modem/router is Switch on the modem/router. menu from the switched off. modem/router Network cable not Connect network cable as cannot be accessed connected. described in the quick by typing 10.0.0.2 in...
- Page 13 TRUST 450I RJ45 (A)DSL MODEM & ROUTER Problem Cause Possible solution Annex A modem used Check with your ISP to Cannot connect to on an Annex B (ISDN) determine which kind of the Internet. line or vice versa. (A)DSL line you have. See chapter 5 for more information.
-
Page 14: Warranty Conditions
/help/network If you still have problems after trying these solutions, please contact one of the Trust Customer Care Centres. You can find more information at the back of this instruction manual. Please have the following information available: •... - Page 15 SERVICE CENTRE 24 HOURS free service: www.trust.com Residents in the UK and Ireland should contact: UK Office Mon - Fri Phone +44-(0)845-6090036 From 8:00 - 16:00 +31-(0)78-6543299 I residenti in Italia possono contattare: lun - ven Ufficio italiano 9:00 – 17:00...
