TRUST 445A- /450I SPEEDLINK XDSL WEB STATION
Shortened method for first use
1. Connecting
2. Network Configuration
3. XDSL station Configuration
4. Check
5. Connecting to the Internet
1 Introduction
This instruction manual is for users of the 'TRUST 445A SPEEDLINK XDSL WEB
STATION 'and the 'TRUST 450I SPEEDLINK XDSL WEB STATION'. You can use
the XDSL station as a XDSL modem and 4-port router to share your Internet
connection. The '445A' is used for XDSL via analogue PSTN / POTS lines. The 450I
is used for XDSL via ISDN lines.
2 Safety
Carefully read the following instructions before use:
- The TRUST 445A-, 450I SPEEDLINK XDSL WEB STATION does not need any
special care. Clean the product case with a damp, soft cloth.
- Never use harsh detergents like gasoline or turpentine for cleaning the product.
These will damage the material.
- Never immerse the product in fluid. This can cause danger and can damage the
product. Never use the device near water.
- Do not put anything on top of the wire. Do not use this device in a location where
people stepping on it would cause it to wear out or be damaged.
- Do not try to repair the product yourself. If you open this device, you might make
contact with parts that contain electrical charges. This device should be
maintained only by qualified personnel.
- Under the following circumstances, have the product fixed by qualified personnel:
* the wire or plug becomes damaged or worn out
* the product has made contact with rain, water or other fluid(s).
3 Approval
- This product conforms to relevant European directives and standards. The
Declaration of Conformity (DoC) can be found at www.trust.com/13521/ce and on
www.trust.com/13523/ce
-
4 Hardware and software requirements
To setup a connection to the Internet you need the following (consult your Internet
service provider if needed):
• Activated analogue XDSL-line (Annex A, XDSL via POTS telephone line
for the 445A,
• Activated Annex B XDSL line (Annex B XDSL via ISDN line for the 450I)
• Activated XDSL-account
• Username and password, if you use a PPPoA- or PPPoE-connection.
• VPI / VCI – values.
• Internet (network) protocol. (PPPoA, PPPoE, Bridged Ethernet over ATM
or Routed Ethernet over ATM)
•
Encapsulation protocol. (LLC/SNAP or VCMUX)
•
XDSL-splitter (for using the Internet and the telephone at the same time)
Notice: Without the above data, your XDSL-modem will not function and
installation is useless.
Chapter
!
(7)
(8)
(10)
(11)
U K
(12)
1
